Liebert HPC-S 022 Operator's manual

Liebert HPC--S
006--022
Air Cooled Chillers with Scroll compressor/s
Precision Cooling for
Business--Critical Continuity
PRODUCT DOCUMENTATION
Liebert HPC--S 006--022 -- PD -- 273571 -- 01.03.2012

Liebert HPC-- S 006-- 022
Liebert HPC---S 006--- 022---PD--- 273571--- 01.03.2012
L i e b e r t H P C --- S 0 0 6 --- 0 2 2
Liebert HPC-S 006---022 is the new Emerson Network Power product line of air-cooled water
chillers, from 60 to 220 kW, designed to combine the best performance in terms of efficiency and
reliability with the lowest impact on the environment and to offer a flexible solution for each different
application requirement of this product.
Utilising hermetic Scroll compressors, heat exchangers and fans of the latest generation,
specifically designed for air conditioning applications, the new series stands out for its unrivalled
efficiency, outstanding compactness and low sound emissions.
The “Freecooling” execution and “Supersaver Evolution” system, providing complete integration
with indoor air conditioning units, allow the achievement of extraordinary energy savings and
increase system lifetime and reliability.
With @connectivity, a highly sophisticated way to let the system components communicate,
Liebert HPC-S 006---022 is part of the network created for an improved operations management
system and significant energy saving.
L i e b e r t H P C --- S 0 0 6 --- 0 2 2
Solutions Committed to your Business

Liebert HPC-- S 006-- 022
Liebert HPC---S 006---022---PD---273571---01.03.2012
Li e b e r t H PC --- S 0 0 6 --- 0 2 2
Contents
1Features and Benefits
2Model Number Description
3Operating Range
4Technical Data
5Mechanical Specifications
6Controls
7Performance Adjustment
Factors
8Sound Levels
9Electrical Data
10 Application Considerations
11 Dimensional Data
12 Refrigerant Circuit
13 Hydraulic Circuit
The product conforms to European Union directives
2006/42/EC; 2004/108/EC; 2006/95/EC and
97/23/EC.
Units are supplied complete with a test certificate
and conformity declaration and control component
list.
Liebert HPC--S 006--022 units are CE marked as
they comply with the European directives
concerning mechanical, electrical, electromagnetic
and pressure equipment safety.
The Quality Management
System of Emerson Network
Power S.r.l. High Performance
Air Conditioning has been
approved by Lloyd's Register
Quality Assurance to the
quality management system
standard ISO 9001:2008

1Features and Benefits
1--1
Liebert HPC---S 006---022---PD---273571---01.03.2012
Featu res and Ben efits
Reliability and Low Environmental Impact
Reliability
The L i e b e r t H P C --- S 0 0 6 --- 0 2 2 series is equipped with two hermetic scroll com-
pressors, which represent state---of---the---art technology in this sector. They
have been designed and optimized for air---cooledwater chillers within aircondi-
tioning applications.
The high volumetric efficiency ensures excellent performances of the Liebert
H P C --- S 0 0 6 --- 0 2 2 units at full load operation and especially at partial load.
Extremely low noise operation and the absence of vibrations aid the installation
of the unit in city sites requiring strict noise limits.
The wide operating range, bearing lubrication, component oversizing, absence
of vibrations and few moving parts, together with the resistance to liquid slug-
ging and compressor electronic control integrated with the machine micropro-
cessor enhance the well---known characteristics of operating reliability and long
life typical of this compressors type.
AllL i e b e r t H P C --- S 0 0 6 --- 0 2 2 units are run tested at thefactory before shipment.
High outdoor temperature
The oversizing of heat exchangers and the wide operating range of the scroll compressors permit the
use of L i e b e r t H P C --- S 0 0 6 --- 0 2 2 units in high temperature environments as well, up to 46° C at 100%
full load.
Resistance to liquid slugging
The robust design of the scroll compressors can tolerate/withstand amounts of liquid refrigerant that
would severely damage reciprocating compressor valves, piston rods and cylinders.
Low Sound Emission
The L i e b e r t H P C --- S 0 0 6 --- 0 2 2 series is characterized by unrivalled low sound emissions.
Compressors supported on anti---vibration mounts and positioned in a closed compartment, common
to all versions; fans specifically designed to reduce the sound emissions, a special compressor jacket
on the “B” version “models from C/FB0 011” (Digit 11 = B or D) and “G” version with 900 mm fans, and
also a special compressor’s box insulated on the “G” version with 800 mm fans “models from C/FG0 011”
allow the achievement of such performance.
All the models are equipped with stepless fan speed control, thanks to a special algorithm on the iCOM
board, the fan speed could be kept to the minimum. It is possible to reach even lower sound emissions
with EC fans (electronically commutated fans), which especially during reduced speed operation, allow
noise levels around 50% lower than the values measured at the same conditions with traditional fans.
L i e b e r t H P C --- S 0 0 6 --- 0 2 2 series sound emissions at 1 m distance
006
57
Models
dB(A)
007 009 011 014 015 018 019 022
62
67
72
77
82
800 = 800 mm fans diameter;
CJ = Compressor noise insulation Jacket;
Box = Box noise insulation.
G --- v e r s i o n
B --- v e r s i o n
B --- v e r s i o n + 8 0 0 + C J
G --- v e r s i o n + 8 0 0 + C J + B o x

Features and Benefits
1--2
Liebert HPC---S 006---022---PD---273571---01.03.2012
In the ”G” version chiller, the characteristics of the ”EC” fans can achieve significant noise reductions
according their speed (RPM), as shown in the chart below.
84
86
88
90
92
94
96
98
100
500 550 600 650 700 750 800 850 900 950 1000
FG0 014 chiller (with CJ) PWL noise emission
EC fans RPM
dB(A)
Unequalled Efficiency and Energy Saving
The use of hermetic Scroll compressors of the latest generation; plate heat exchanger evaporators selec-
ted for R410A application; aerodynamic profiled blade fans with high efficiency nozzles; large surface
condenser coils ensure the achievement of unequalled efficiency figures.
Freecooling Module
The “Freecooling” execution allows L i e b e r t H P C --- S 0 0 6 --- 0 2 2 to take advantage of low outdoor air tem-
peratures in the water cooling process in order to save energy, by avoiding compressors running.
A three---way valve arrangement permits the coolant to be diverted via the additional heat exchangers
before being fed into the cooling evaporator.
This means that even if the outside ambient temperature is not low enough to provide the complete cool-
ing load, a significant contribution to the running costs of the system can be made whenever the ambient
temperatures falls below the coolant inlet temperature.
Reduced space requirements in comparison with a conventional chiller plus a dry---cooler, are obtained
through the “Freecooling” execution’s compact design and the reduction of the compressors working
hours offers exceptional saving both in the long and short term.
The different strategies adopted by the proprietary microprocessor control in managing the various com-
ponents, fans --- compressors --- regulation valves, and operating modes, mechanical and/or free cool-
ing, together with the compressors’ partialisation ensure typical energy savings greater than 30%.
8,000
7,000
6,000
5,000
4,000
3,000
2,000
1,000
0-6-4-202468101214161820222426283032
Outdoor temperature (oC)
Annual Power consumption (kWh)
VENICE HAMBURG
8,000
7,000
6,000
5,000
4,000
3,000
2,000
1,000
0
Outdoor temperature (oC)
Annual Emergency consumption (kWh)
-18-16-14-12-10-8-6-4-202468101214161820222426283032
Annual energy consumption, Chiller.
Annual energy consumption, Chiller plus Freecooling module.

Features and Benefits
1--3
Liebert HPC---S 006---022---PD---273571---01.03.2012
Seasonal Efficiency
The ”Freecooling” execution finds its best application in combination with the “Supersaver Evolution”
system which regulates the coolant temperatures according to the variation of the thermal load, increas-
ing the numbers of hours during which free cooling is possible.
The percentage of energy saving can thus be greater than 35%.
Annual power consumption. Comparison among the systems:
12
10
8
6
4
2
0
Energy consumption (MWh)
Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec
Chiller
Superchiller
Superchiller + Supersaver
Traditional Chiller
Freecooling execution
--- Supersaver Evolution
Integration with Indoor Air Conditioners
Supersaver Evolution System
A special working mode can be set up in combination with Emerson Network Power HPAC indoor units
to obtain the ”Supersaver Evolution” system, that enhances the energy saving capabilities and thus op-
timizes the SEER (Seasonal Energy Efficiency Ratio) of the system.
Through @connectivity the information on the cooling needs of the air conditioners is available to the
L i e b e r t H P C --- S 0 0 6 --- 0 2 2 units, that will manage their resources (compressors and free cooling) in the
most efficient way in order to save addition-
al energy.
This solution does not require any
modification, mechanical or
electrical thus avoiding ad-
ditional components
and regulation al-
gorithms which
could undermine the
reliability of the sys-
tem.
@ Connectivity
When the room units
are equipped with
thesametypeofcon-
trol system Emerson
Network Power
(iCOM and CDL), it is
possible to maximize
the energy savings and im-
prove the total operation man-
agement.

Features and Benefits
1--4
Liebert HPC---S 006---022---PD---273571---01.03.2012
The solution is @connectivity, which is a highly sophisticated way to let the system components (the
Air---Conditioners as well as the L i e b e r t H P C --- S 0 0 6 --- 0 2 2 units, Chiller and Freecooling executions)
talk to each other.
The @connectivity plug---in allows the setting of different working modes for different situations, such
as:
Dhigher water temperature in low load operation (energy saving);
Dlower water temperature for dehumidification (better performance);
Dspecial ”night” Setpoint (energy saving & noise reduction);
Dlower water temperature if one or more Air Conditioners fail (keep capacity in emergency situations);
D...andmuchmore!
To add the @connectivity to your system, it is simply necessary:
To build up Hironet connection between the room units and the L i e b e r t H P C --- S 0 0 6 --- 0 2 2 units. The
network can be only 1 (if the distance and the number of units allow this) or it can be split in several net-
works.
On @connectivity it is possible to define the rules that you want your system to respect.
It will be then up to the web capabilities to allow the view and control of your system from any PC of your
Local area network (provided that the @connectivity PC is connected on the LAN) or even if you have
a connection to Internet and your system is open to external access, you will have the possibility to view
and control your system via Internet
Flexibility: Hydronic Module
In ordertomatch different kinds ofinstallations and ap-
plications, Liebert HPC-S 006---022 units
are available with a hydronic mod-
ule, which can be adapted/ad-
justed depending on the specif-
ic requests.
Based on this philosophy, the
units can be equipped with
everything that is needed for
the correct installation and, in
this way, reduce the complexity
of the commissioning: buffer
tank, 1 or 2 circulating pumps,
water filter, safety valve, expan-
sion vessel, flow switch. With all
these elements included inside
the unit, it is just a matter of con-
necting the chiller to the sys-
tem.
But, if some or all of these com-
ponents are already present in the hy-
draulic line, Liebert HPC-S 006-022 can
be equipped only with what is not already con-
nected in the system. This level of flexibility allows true customisation of the unit.
Compactness: Small Footprint
The L i e b e r t H P C --- S 0 0 6 --- 0 2 2 series achieves the high efficiency performance and low sound emission
previously described with a compactness which is one the highest in its category.
This result ispossible thanks to the high quality components selectedand a design which takes into con-
sideration the different aspects and needs of a chiller installation.
In this way the installation area can be optimized, leaving more space for other building elements. Com-
bining this aspect with the possibility of including all of the hydronic components inside the unit, Liebert
H P C --- S 0 0 6 --- 0 2 2 series is really a leader in terms of easy and compact installation

2Model Number Description
2--1
Liebert HPC---S 006--- 022---PD--- 273571--- 01.03.2012
Model Number Description
Model Nomenclature / Digit Numbers
1234567 8 9 10 11 12 13 14 15 16 17 18
Cooling Capacity
Cooling capacity (x 10 = kW)
Refrigerant
0= R410A
Versions
B= Base version
G= High efficiency class version
Specification
C= Air cooled
Chiller
F= Freecooling
Chiller
G 0 0 1C 1
L i e b e r t H P C --- S 0 0 6 --- 0 2 2
Digits 1, 2, 3, 4, 5, 6 --- Base unit
Base unit main features
DR410A refrigerant;
DOne refrigeration circuit;
DHP and LP gauges;
DFans speed control (TRIAC or EC according Bor G
version); on Bversions, different options with EC fans
are available;
DOn digit 11 base version B,opt.B&D+Gversion
opt. C compressors jacket if necessary;
DOn digit 11 Gversion opt. D compressors jacket +
compressor’s box insulated if necessary;
DExpansion valve: TXV (Thermostatic expansion
Valve) on Bversion;
EEV (Electronic Expansion Valve)
on Gversion;
DFlow switch and Hydraulic Kit (Hydraulic Kit =
expansion vessel and safety valve);
DEvaporator electric heater + tank electric heater will
protect piping too (only if pump/s are fitted on unit);
DElectrical panel ventilation;
DBuffer tank of 100, 200 and 300 litres (1, 2 and 3 fans).
Digit 7 --- Display and Switch
A=FTE display
B= FTE display + Network Switch
E= iCOM Coldfire display large
F= iCOM Coldfire display large + Network Switch
D i g i t 8 --- S o f t s t a r t e r
0=None
1= With compressors soft starter
Digit 9 --- Monitoring
0=None
1=ISHousing(noISCardincluded)
2=Webcard
3= Modbus card
4=Sitescancard
5= Web card + Modbus card
6= Web card + Sitescan card
7= Modbus card + Sitescan card
8= Bacnet card (Bacnet or Modbus over IP)
D i g i t 1 0 --- B u f f e r t a n k
0=None
1= With buffer tank
2= With buffer tank + electric heaters (only for chiller
models)
Digit 11 --- Fans options
A= TRIAC control and 900 mm fans
B=TRIAC control and 800 mm fans
C= E C --- F a n s , 9 0 0 m m
D= E C --- F a n s , 8 0 0 m m
D i g i t 1 2 --- P u m p s g r o u p (expansion tank and water
safety valve always included as standard)
1=Nopumps
2= With 1 pump LP (low pressure)
3= With 1 pump HP (high pressure)
4= With 2 pumps LP (low pressure)
5= With 2 pumps HP (high pressure)
D i g i t 1 3 --- F r e e
Digit 14 --- Electric panel options
0=None
1= With electric heaters
A= Fast start ramp
B= Fast start ramp and electric heaters
Digit 15 --- Evaporator antifreeze protection
0=None
1= With evaporator antifreeze protection
2= With evaporator and pipe antifreeze protection
Digit 16 --- Compressor power factor correction
0=None
1= With compressors power factor capacitors
Digit 17 --- Coil metal filter / Protection grid
0=None
1= With coil metal filter
Digit 18 --- Special requests
0=None
X=Asspecified

Model Number Description
2--2
Liebert HPC---S 006--- 022---PD--- 273571--- 01.03.2012
Kits / Accessories shipped loose
DAnti-vibrating mounts (spring or rubber)
DDee shackle UNI 1947
DColdfire IP40 remote box
DWater filter
Configuration Rules
In order to give the units the highest flexibility and a high option number, it is necessary to follow
the configuration rules indicated here below, so as to select the unit with all compatible options:
Rule valid for all Chiller and Freecooling versions:
Compressor soft starter are not electrically compatible with compressors power factor correc-
tions
Dif digit 8 = 1 than digit 16 = 0
on digit 11: A & B not available on G version (default: A with Base version and C with G ver-
sion)
Rules valid for Chiller versions only (on Freecooling chillers electric heaters are
not available):
Heating resistors have to be selected according to the presence of the pumps, tank, etc.
Dif digit 15 = 1 or 2, then digit 10 = 0 or 2
Dif digit 15 = 1, then digit 12 = 2, 3, 4 or 5
Dif digit 15 = 2, then digit 12 = 1
Difdigit10=2,thendigit15=1or2

3Operating Range
3--1
Liebert HPC---S 006---022---PD---273571---01.03.2012
Oper atin g Range
Working Limits
Minimum temperature of outdoor air entering condenser coils (with standard operating unit):
---25 ° C for Freecooling models;
---10°CforChillermodels.
Maximum outdoor air temperature is in relation to each model, as indicated in the following tables.
High water flow values (corresponding to a thermal difference at the evaporatorlower than3.5° C --- 4° C)
may cause corrosions and vibrations inside the plate heat exchanger and in the hydraulic circuit.
The Minimum water flow allowed corresponds to a maximum temperature difference of 8° C.
More extreme operating conditions would active safety devices and the unit would be stopped.
The outlet water temperature must range from 4° C to 15° C.
The maximum allowed water return temperature, when the unit is in full operation, is 20° C; return temper-
atures over 20° C are allowed only during start---up.
The “G” version with EC fans 900mm (digit 11 = C) admit Maximum Outlet Water Temperature of 20 ° C
and Maximum Water Return Temperature of 26° C when the units are at full power.
The maximum permitted glycol percentage is 50% (35% with standard pump groups fitted).
The necessary minimum glycol percentage depends on the minimum ambient air temperature condi-
tions referred to the place of installation.
The maximum hydraulic working pressure is 6 barg (safety valve set at 6 barg, optional).
Nominal power supply tolerance: 400V +/--- 10%; max. voltage unbalance: 2%.
See “Operation range” table reporting the limits for each model; for different values ask your agent.
All the working limits indicated in both diagrams and tables refer to steady---state operation mode.
Unit storage conditions:
Dbetween ---10 ° C and + 45 ° C for all models; humidity: 80% R.H. non-condensing.
60
A v e r a g e H P C --- S 0 0 6 --- 0 2 2 W o r k i n g L i m i t s
Ambient Temperature (_C)
LWT (_C)
25
5550454035302520151050--- 5--- 10--- 15--- 20--- 25--- 30
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Only
Gmodels
All models
Freecooling
only
Gmodels
Freecooling
only
All models
This diagram shows the average working limits of all the products family.
Refer to table 3 for the working limits of each unit.

Operating Range
3--2
Liebert HPC---S 006---022---PD---273571---01.03.2012
Tab. 3a --- Operating range --- Chiller with AC fans 900mm
Models: CB0 006---022 006 007 009 011 014 015 018 019 022
Operating range
Max. outdoor temperature (1) °C 52.0 49.5 54.0 52.5 50.0 48.5 52.0 50.5 49.0
Safety devices settings
High pressure switch (1)
High pressure safety valve
HP safety valves (each circuit)
High pressure safety valve connection
Low pressure switch
barg
barg
Nr.
inch
barg
42
45
1
3/4” G
4.4
(1) --- With nominal air flow; water outlet temperature 7° C; full load; R410A refrigerant.
Tab. 3b --- Operating range --- Chiller with AC fans 800mm
Models: CB0 006---022 006 007 009 011 014 015 018 019 022
Operating range
Max. outdoor temperature (1) °C 50.0 47.0 52.5 50.5 48.0 46.0 50.0 48.0 46.5
Safety devices settings
High pressure switch (1)
High pressure safety valve
HP safety valves (each circuit)
High pressure safety valve connection
Low pressure switch
barg
barg
Nr.
inch
barg
42
45
1
3/4” G
4.4
(1) --- With nominal air flow; water outlet temperature 7° C; full load; R410A refrigerant.
Tab. 3c --- Operating range --- Chiller with EC fans 900mm
Models: CG0 006---018 006 007 009 011 014 015 018
Operating range
Max. outdoor temperature (1) °C 53.0 56.0 56.0 53.5 55.5 54.0 53.0
Safety devices settings
High pressure switch (1)
High pressure safety valve
HP safety valves (each circuit)
High pressure safety valve connection
Low pressure switch
barg
barg
Nr.
inch
barg
42
45
1
3/4” G
5
(1) --- With nominal air flow; water outlet temperature 7° C; full load; R410A refrigerant.
Tab. 3d --- Operating range --- Chiller with EC fans 800mm
Models: CG0 006---018 006 007 009 011 014 015 018
Operating range
Max. outdoor temperature (1) °C 47.0 52.0 51.5 48.0 50.5 48.5 47.0
Safety devices settings
High pressure switch (1)
High pressure safety valve
HP safety valves (each circuit)
High pressure safety valve connection
Low pressure switch
barg
barg
Nr.
inch
barg
42
45
1
3/4” G
5
(1) --- With nominal air flow; water outlet temperature 7° C; full load; R410A refrigerant.

Operating Range
3--3
Liebert HPC---S 006---022---PD---273571---01.03.2012
Tab. 3e --- Operating range --- Freecooling with AC fans 900mm
Models: FB0 006---022 006 007 009 011 014 015 018 019 022
Operating range
Max. outdoor temperature (1) °C 50.0 47.0 53.0 51.0 48.5 46.5 50.0 48.5 47.0
Safety devices settings
High pressure switch (1)
High pressure safety valve
HP safety valves (each circuit)
High pressure safety valve connection
Low pressure switch
barg
barg
Nr.
inch
barg
42
45
1
3/4” G
4.4
(1) --- With nominal air flow; mixture outlet temperature 10° C; full load; R410A refrigerant.
Tab. 3f --- Operating range --- Freecooling with AC fans 800mm
Models: FB0 006---022 006 007 009 011 014 015 018 019 022
Operating range
Max. outdoor temperature (1) °C 48.5 45.5 52.0 49.5 46.5 44.0 48.5 46.5 45.0
Safety devices settings
High pressure switch (1)
High pressure safety valve
HP safety valves (each circuit)
High pressure safety valve connection
Low pressure switch
barg
barg
Nr.
inch
barg
42
45
1
3/4” G
4.4
(1) --- With nominal air flow; mixture outlet temperature 10° C; full load; R410A refrigerant.
Tab. 3g --- Operating range --- Freecooling with EC fans 900mm
Models: FG0 006---018 006 007 009 011 014 015 018
Operating range
Max. outdoor temperature (1) °C 51.5 55.0 55.0 52.5 54.5 53.0 52.0
Safety devices settings
High pressure switch (1)
High pressure safety valve
HP safety valves (each circuit)
High pressure safety valve connection
Low pressure switch
barg
barg
Nr.
inch
barg
42
45
1
3/4” G
5
(1) --- With nominal air flow; mixture outlet temperature 10° C; full load; R410A refrigerant.
Tab. 3h --- Operating range --- Freecooling with EC fans 800mm
Models: FG0 006---018 006 007 009 011 014 015 018
Operating range
Max. outdoor temperature (1) °C 45.5 51.5 50.5 46.5 49.5 47.5 45.5
Safety devices settings
High pressure switch (1)
High pressure safety valve
HP safety valves (each circuit)
High pressure safety valve connection
Low pressure switch
barg
barg
Nr.
inch
barg
42
45
1
3/4” G
5
(1) --- With nominal air flow; mixture outlet temperature 10° C; full load; R410A refrigerant.

4Technical Data
4--1
Liebert HPC---S 006--- 022---PD--- 273571--- 01.03.2012
Technical Data
Ta b . 4 a --- Te c h n i c a l D a t a --- C B 0 0 0 6 --- 0 2 2 --- A C 9 0 0
CB0 model with AC 900 mm fans - R410A 006 007 009 011 014 015 018 019 022
Performance (1)
Cooling capacity kW 58.5 70.6 86.8 111.6 132.9 146.5 175.8 193.1 215.9
Compressors power input kW 16.1 21.5 23.2 31.1 40.4 47.9 49.9 58.3 67.1
Total power input kW 18.5 23.9 28.0 35.9 45.2 52.7 57.1 65.5 74.3
Unit EER - 3.16 2.95 3.10 3.11 2.94 2.78 3.08 2.95 2.91
Water flow m3/h 10.08 12.14 14.91 19.19 22.85 25.21 30.20 33.19 37.14
Water pressure drop kPa 47 42 37 41 42 50 48 58 49
Sound level
SPL (Sound Pressure Level) (2) dB(A) 75 76 76.5 77 77.5 78
PWL (Sound Power Level) (3) dB(A) 92 94 94.5 96 96.5 97
Refrigeration circuit
Number of refrigeration circuits No 1
Refrigerant charge (each circuit) kg 10.5 10.5 13.0 18.0 20.0 20.0 27.5 27.5 28.5
Compressors
Number of compressors No 1+1
Type - hermetic scroll
Nominal power (each compressor) HP 10+10 13+13 15+15 15+25 25+25 25+30 30+30 30+40 40+40
Fans
Number of fans No 1 2 3
Type - axial
Wheel nominal diameter mm 900
RPM 1/min 900
Nominal power input (each fan) kW 2.4
Fans power input kW 2.4 4.8 7.2
Air flow rate m3/h 21900 21400 44800 43800 42800 42800 65700 65700 64200
Evaporator
Number of evaporators No 1
Type - brazed plate heat exchanger
Internal volume (refrigerant side) l 4.1 5.1 5.6 7.6 9.2 9.2 11.6 11.6 14.8
Condensing coil
Material tubes / Fins - aluminium / aluminium
Rows / Fins space No/mm 3 / 1.8 3/1.6 2/1.8 3/1.8 3/1.6 3/1.6 3/1.8 3/1.8 3/1.6
Face area m23.00 6.00 9.00
Internal volume (each coil) l 7.3 9.8 14.7 22.0
Water connections
Diameters inlet / outlet DN-inch DN50 2" DN65 2 1/2"
Unit volume l 10 10 23 25 25 26 34 32 36
Dimensions
Length mm 2043 3043 4043
Depth mm 1201
Height mm 1902
Weights
Net weight kg 722 738 895 1035 1152 1170 1392 1404 1444
Operating weight kg 732 748 918 1060 1177 1196 1426 1436 1480
Notes:
(1) --- At the following standard conditions: power supply 400V/3Ph/50Hz; outdoor temperature 35 ° C; water inlet/outlet temperature 12/7 ° C; ethylene glycol 0%.
(2) --- Measured with outdoor temperature 35
° C; 1m from the unit; free field conditions; according to ISO 3744.
(3) --- With outdoor temperature 35
° C; calculated according to ISO 3744.

Technical Data
4--2
Liebert HPC---S 006--- 022---PD--- 273571--- 01.03.2012
Ta b . 4 b --- Te c h n i c a l D a t a --- C B 0 0 0 6 --- 0 2 2 --- A C 8 0 0
CB0 model with AC 800 mm fans - R410A 006 007 009 011 014 015 018 019 022
Performance (1)
Cooling capacity kW 56.8 68.0 85.2 108.8 128.8 141.3 171.1 187.3 208.7
Compressors power input kW 16.9 22.7 23.9 32.4 42.4 50.4 52.1 61.1 70.3
Total power input kW 18.6 24.4 27.3 35.8 45.8 53.8 57.2 66.2 75.4
Unit EER - 3.05 2.79 3.12 3.04 2.81 2.63 2.99 2.83 2.77
Water flow m3/h 9.77 11.71 14.66 18.72 22.19 24.34 29.41 32.22 35.92
Water pressure drop kPa 44 39 36 39 39 47 46 55 46
Sound level
SPL (Sound Pressure Level) (2) dB(A) 63 64 66 66.5 67 67.5 68
PWL (Sound Power Level) (3) dB(A) 80 82 84 84.5 86 86.5 87
Refrigeration circuit
Number of refrigeration circuits No 1
Refrigerant charge (each circuit) kg 10.5 10.5 13.0 18.0 20.0 20.0 27.5 27.5 28.5
Compressors
Number of compressors No 1+1
Type - hermetic scroll
Nominal power (each compressor) HP 10+10 13+13 15+15 15+25 25+25 25+30 30+30 30+40 40+40
Fans
Number of fans No 1 2 3
Type - axial
Wheel nominal diameter mm 800
RPM 1/min 900
Nominal power input (each fan) kW 1.7
Fans power input kW 1.7 3.4 5.1
Air flow rate m3/h 18000 17800 37000 36000 35600 35600 54000 54000 53400
Evaporator
Number of evaporators No 1
Type - brazed plate heat exchanger
Internal volume (refrigerant side) l 4.1 5.1 5.6 7.6 9.2 9.2 11.6 11.6 14.8
Condensing coil
Material tubes / Fins - aluminium / aluminium
Rows / Fins space No/mm 3 / 1.8 3/1.6 2/1.8 3/1.8 3/1.6 3/1.6 3/1.8 3/1.8 3/1.6
Face area m23.00 6.00 9.00
Internal volume (each coil) l 7.3 9.8 14.7 22.0
Water connections
Diameters inlet / outlet DN-inch DN50 2" DN65 2 1/2"
Unit volume l 10 10 23 25 25 26 34 32 36
Dimensions
Length mm 2043 3043 4043
Depth mm 1201
Height mm 1902
Weights
Net weight kg 722 738 895 1035 1152 1170 1392 1404 1444
Operating weight kg 732 748 918 1060 1177 1196 1426 1436 1480
Notes:
(1) --- At the following standard conditions: power supply 400V/3Ph/50Hz; outdoor temperature 35 ° C; water inlet/outlet temperature 12/7 ° C; ethylene glycol 0%.
(2) --- Measured with outdoor temperature 35
° C; 1m from the unit; free field conditions; according to ISO 3744.
(3) --- With outdoor temperature 35
° C; calculated according to ISO 3744.

Technical Data
4--3
Liebert HPC---S 006--- 022---PD--- 273571--- 01.03.2012
Ta b . 4 c --- Te c h n i c a l D a t a --- C G 0 0 0 6 --- 0 1 8 --- E C 9 0 0
CG0 model with EC 900 mm fans - R410A 006 007 009 011 014 015 018
Performance (1)
Cooling capacity kW 59.6 77.8 89.1 113.3 142.2 158.3 178.6
Compressors power input kW 15.6 18.4 22.1 30.4 36.2 42.3 48.6
Total power input kW 18.2 23.6 27.3 35.6 44.0 50.1 56.4
Unit EER - 3.27 3.30 3.27 3.18 3.23 3.16 3.17
Water flow m3/h 10.25 13.28 15.31 19.46 24.47 27.17 30.67
Water pressure drop kPa 49 50 39 42 47 57 50
Sound level
SPL (Sound Pressure Level) (2) dB(A) 78.5 79.5 80
PWL (Sound Power Level) (3) dB(A) 95.5 97.5 99
Refrigeration circuit
Number of refrigeration circuits No 1
Refrigerant charge (each circuit) kg 10.5 12.5 16.0 18.0 26.5 26.5 27.5
Compressors
Number of compressors No 1+1
Type - hermetic scroll
Nominal power (each compressor) HP 10+10 13+13 15+15 15+25 25+25 25+30 30+30
Fans
Number of fans No 1 2 3
Type - axial with EC motor
Wheel nominal diameter mm 900
RPM 1/min 1000
Nominal power input (each fan) kW 2.6
Fans power input kW 2.6 5.2 7.8
Air flow rate m3/h 23700 50600 48500 47400 72750 72750 71100
Evaporator
Number of evaporators No 1
Type - brazed plate heat exchanger
Internal volume (refrigerant side) l 4.1 5.1 5.6 7.6 9.2 9.2 11.6
Condensing coil
Material tubes / Fins - aluminium / aluminium
Rows / Fins space No/mm 3 / 1.6 2/1.8 3/1.8 3/1.6 3/1.8 3/1.8 3/1.6
Face area m23.00 6.00 9.00
Internal volume (each coil) l 7.3 9.8 14.7 22.0
Water connections
Diameters inlet / outlet DN-inch DN50 2" DN65 2 1/2"
Unit volume l 11 22 20 23 31 33 34
Dimensions
Length mm 2043 3043 4043
Depth mm 1201
Height mm 1931
Weights
Net weight kg 723 888 934 1049 1357 1375 1418
Operating weight kg 734 910 954 1072 1388 1408 1452
Notes:
(1) --- At the following standard conditions: power supply 400V/3Ph/50Hz; outdoor temperature 35 ° C; water inlet/outlet temperature 12/7 ° C; ethylene glycol 0%.
(2) --- Measured with outdoor temperature 35
° C; 1m from the unit; free field conditions; according to ISO 3744.
(3) --- With outdoor temperature 35
° C; calculated according to ISO 3744.

Technical Data
4--4
Liebert HPC---S 006--- 022---PD--- 273571--- 01.03.2012
Ta b . 4 d --- Te c h n i c a l D a t a --- C G 0 0 0 6 --- 0 1 8 --- E C 8 0 0
CG0 model with EC 800 mm fans - R410A 006 007 009 011 014 015 018
Performance (1)
Cooling capacity kW 54.3 73.9 84.2 104.7 133.8 147.4 164.3
Compressors power input kW 18.0 20.1 24.3 34.3 40.1 47.4 55.3
Total power input kW 18.7 21.5 25.7 35.7 42.2 49.5 57.4
Unit EER - 2.91 3.44 3.28 2.93 3.17 2.98 2.86
Water flow m3/h 9.34 12.70 14.45 18.04 22.99 25.36 28.29
Water pressure drop kPa 41 46 35 37 42 50 43
Sound level
SPL (Sound Pressure Level) (2) dB(A) 58 59 61 62
PWL (Sound Power Level) (3) dB(A) 75 77 79 81
Refrigeration circuit
Number of refrigeration circuits No 1
Refrigerant charge (each circuit) kg 10.5 12.5 16.0 18.0 26.5 26.5 27.5
Compressors
Number of compressors No 1+1
Type - hermetic scroll
Nominal power (each compressor) HP 10+10 13+13 15+15 15+25 25+25 25+30 30+30
Fans
Number of fans No 1 2 3
Type - axial with EC motor
Wheel nominal diameter mm 800
RPM 1/min 718
Nominal power input (each fan) kW 0.7
Fans power input kW 0.7 1.4 2.1
Air flow rate m3/h 13900 29200 28200 27800 42300 42300 41700
Evaporator
Number of evaporators No 1
Type - brazed plate heat exchanger
Internal volume (refrigerant side) l 4.1 5.1 5.6 7.6 9.2 9.2 11.6
Condensing coil
Material tubes / Fins - aluminium / aluminium
Rows / Fins space No/mm 3 / 1.6 2/1.8 3/1.8 3/1.6 3/1.8 3/1.8 3/1.6
Face area m23.00 6.00 9.00
Internal volume (each coil) l 7.3 9.8 14.7 22.0
Water connections
Diameters inlet / outlet DN-inch DN50 2" DN65 2 1/2"
Unit volume l 11 22 20 23 31 33 34
Dimensions
Length mm 2043 3043 4043
Depth mm 1201
Height mm 1874
Weights
Net weight kg 723 888 934 1049 1357 1375 1418
Operating weight kg 734 910 954 1072 1388 1408 1452
Notes:
(1) --- At the following standard conditions: power supply 400V/3Ph/50Hz; outdoor temperature 35 ° C; water inlet/outlet temperature 12/7 ° C; ethylene glycol 0%.
(2) --- Measured with outdoor temperature 35
° C; 1m from the unit; free field conditions; according to ISO 3744.
(3) --- With outdoor temperature 35
° C; calculated according to ISO 3744.

Technical Data
4--5
Liebert HPC---S 006--- 022---PD--- 273571--- 01.03.2012
Ta b . 4 e --- Te c h n i c a l D a t a --- F B 0 0 0 6 --- 0 2 2 --- A C 9 0 0
FB0 model with AC 900 mm fans - R410A 006 007 009 011 014 015 018 019 022
Performance (1)
Cooling capacity kW 61.4 73.7 91.1 116.3 138.5 151.6 182.8 199.7 223.7
Freecooling capacity (2) kW 45.1 44.9 70.2 87.8 87.6 89.7 133.8 137.8 133.9
Compressors power input kW 16.8 22.5 23.8 32.4 42.1 50.0 52.1 61.0 70.1
Total power input kW 19.2 24.9 28.6 37.2 46.9 54.8 59.3 68.2 77.3
Unit EER - 3.20 2.96 3.19 3.13 2.95 2.77 3.08 2.93 2.89
Fluid flow m3/h 11.53 13.91 17.14 21.90 26.08 28.61 34.42 37.64 42.18
Hydraulic pressure drop kPa 132 146 103 120 140 165 158 183 188
Sound level
SPL (Sound Pressure Level) (3) dB(A) 75 76 76.5 76.5 77 77.5 78
PWL (Sound Power Level) (4) dB(A) 92 94 94.5 94.5 96 96.5 97
Refrigeration circuits
Number of refrigeration circuits No 1
Refrigerant charge (each circuit) kg 10.5 10.5 13.0 18.0 20.0 20.0 27.5 27.5 28.5
Compressors
Number of compressors No 1+1
Type - hermetic scroll
Nominal power (each compressor) HP 10+10 13+13 15+15 15+25 25+25 25+30 30+30 30+40 40+40
Fans
Number of fans No 1 2 3
Type - axial
Wheel nominal diameter mm 900
RPM 1/min 900
Nominal power input (each fan) kW 2.4
Fans power input kW 2.4 4.8 7.2
Air flow rate m3/h 19500 41800 39000 58500
Evaporator
Number of evaporators No 1
Type - brazed plate heat exchanger
Internal volume (refrigerant side) l 4.1 5.1 5.6 7.6 9.2 9.2 11.6 11.6 14.8
Condensing coil
Material tubes / Fins - copper/aluminium
Rows / Fins space No/mm 3 / 1.8 3/1.6 2/1.8 3/1.8 3/1.6 3/1.6 3/1.8 3/1.8 3/1.6
Face area m23.00 6.00 9.00
Internal volume (each coil) l 7.3 9.8 14.7 22.0
Freecooling coil
Material tubes / Fins - copper / aluminium
Rows / Fins space No/mm 3 / 2.1 3/2.5 2/2.1 3/2.1 3/2.5 3/2.5 3/2.1 3/2.1 3/2.5
Face area m23.00 6.00 9.00
Hydraulic connections
Diameters inlet / outlet DN-inch DN50 2" DN65 2 1/2"
Unit volume l 76 77 102 120 122 121 160 160 162
Dimensions
Length mm 2043 3043 4043
Depth mm 1201
Height mm 1902
Weights
Net weight kg 860 876 1062 1248 1369 1387 1678 1690 1728
Operating weight kg 936 953 1164 1368 1491 1508 1838 1850 1890
Notes:
(1) --- At the following standard conditions: power supply 400V/3Ph/50Hz; outdoor temperature 35 ° C; water inlet/outlet temperature 15/10 ° C; ethylene glycol 30%.
(2) --- At the following standard conditions: power supply 400V/3Ph/50Hz; outdoor temperature 5
° C; fluid inlet temperature 15 ° C; ethylene glycol 30%.
(3) --- Measured with outdoor temperature 35
° C; 1m from the unit; free field conditions; according to ISO 3744.
(4) --- With outdoor temperature 35
° C; calculated according to ISO 3744.

Technical Data
4--6
Liebert HPC---S 006--- 022---PD--- 273571--- 01.03.2012
Ta b . 4 f --- Te c h n i c a l D a t a --- F B 0 0 0 6 --- 0 2 2 --- A C 8 0 0
FB0 model with AC 800 mm fans - R410A 006 007 009 011 014 015 018 019 022
Performance (1)
Cooling capacity kW 59.9 71.3 89.7 114.0 134.9 147.2 178.9 194.8 217.4
Freecooling capacity (2) kW 41.6 41.0 65.2 81.1 80.5 82.2 123.3 126.7 122.9
Compressors power input kW 17.5 23.5 24.4 33.5 43.7 52.2 53.9 63.3 72.9
Total power input kW 19.3 25.3 28.0 37.1 47.3 55.8 59.3 68.7 78.3
Unit EER - 3.10 2.82 3.20 3.07 2.85 2.64 3.02 2.84 2.78
Fluid flow m3/h 11.32 13.45 16.88 21.47 25.44 27.68 33.70 36.76 41.04
Hydraulic pressure drop kPa 128 137 100 116 134 155 152 176 179
Sound level
SPL (Sound Pressure Level) (3) dB(A) 63 64 66 66.5 67 67.5 68
PWL (Sound Power Level) (4) dB(A) 80 82 84 84.5 86 86.5 87
Refrigeration circuits
Number of refrigeration circuits No 1
Refrigerant charge (each circuit) kg 10.5 10.5 13.0 18.0 20.0 20.0 27.5 27.5 28.5
Compressors
Number of compressors No 1+1
Type - hermetic scroll
Nominal power (each compressor) HP 10+10 13+13 15+15 15+25 25+25 25+30 30+30 30+40 40+40
Fans
Number of fans No 1 2 3
Type - axial
Wheel nominal diameter mm 800
RPM 1/min 900
Nominal power input (each fan) kW 1.8
Fans power input kW 1.8 3.6 5.4
Air flow rate m3/h 17000 36000 34000 51000
Evaporator
Number of evaporators No 1
Type - brazed plate heat exchanger
Internal volume (refrigerant side) l 4.1 5.1 5.6 7.6 9.2 9.2 11.6 11.6 14.8
Condensing coil
Material tubes / Fins - copper / aluminium
Rows / Fins space No/mm 3 / 1.8 3/1.6 2/1.8 3/1.8 3/1.6 3/1.6 3/1.8 3/1.8 3/1.6
Face area m23.00 6.00 9.00
Internal volume (each coil) l 7.3 9.8 14.7 22.0
Freecooling coil
Material tubes / Fins - copper / aluminium
Rows / Fins space No/mm 3 / 2.1 3/2.5 2/2.1 3/2.1 3/2.5 3/2.5 3/2.1 3/2.1 3/2.5
Face area m23.00 6.00 9.00
Hydraulic connections
Diameters inlet / outlet DN-inch DN50 2" DN65 2 1/2"
Unit volume l 76 77 102 120 122 121 160 160 162
Dimensions
Length mm 2043 3043 4043
Depth mm 1201
Height mm 1902
Weights
Net weight kg 860 876 1062 1248 1369 1387 1678 1690 1728
Operating weight kg 936 953 1164 1368 1491 1508 1838 1850 1890
Notes:
(1) --- At the following standard conditions: power supply 400V/3Ph/50Hz; outdoor temperature 35 ° C; water inlet/outlet temperature 15/10 ° C; ethylene glycol 30%.
(2) --- At the following standard conditions: power supply 400V/3Ph/50Hz; outdoor temperature 5
° C; fluid inlet temperature 15 ° C; ethylene glycol 30%.
(3) --- Measured with outdoor temperature 35
° C; 1m from the unit; free field conditions; according to ISO 3744.
(4) --- With outdoor temperature 35
° C; calculated according to ISO 3744.

Technical Data
4--7
Liebert HPC---S 006--- 022---PD--- 273571--- 01.03.2012
Ta b . 4 g --- Te c h n i c a l D a t a --- F G 0 0 0 6 --- 0 1 8 --- E C 9 0 0
FG0 model with EC 900 mm fans - R410A 006 007 009 011 014 015 018
Performance (1)
Cooling capacity kW 63.0 82.6 93.5 118.8 149.3 165.4 187.2
Freecooling capacity (2) kW 45.7 70.7 84.2 88.6 130.2 136.5 135.1
Compressors power input kW 16.1 18.9 22.7 31.3 37.2 43.6 50.1
Total power input kW 18.8 24.3 28.1 36.7 45.3 51.7 58.2
Unit EER - 3.35 3.40 3.33 3.24 3.30 3.20 3.22
Fluid flow m3/h 11.84 15.50 17.58 22.35 28.08 31.12 35.21
Hydraulic pressure drop kPa 139 120 99 125 132 157 165
Sound level
SPL (Sound Pressure Level) (3) dB(A) 78.5 79.5 80
PWL (Sound Power Level) (4) dB(A) 95.5 97.5 99
Refrigeration circuits
Number of refrigeration circuits No 1
Refrigerant charge (each circuit) kg 10.5 12.5 16.0 18.0 26.5 26.5 27.5
Compressors
Number of compressors No 1+1
Type - hermetic scroll
Nominal power (each compressor) HP 10+10 13+13 15+15 15+25 25+25 25+30 30+30
Fans
Number of fans No 1 2 3
Type - axial with EC motor
Wheel nominal diameter mm 900
RPM 1/min 1000
Nominal power input (each fan) kW 2.7
Fans power input kW 2.7 5.4 8.1
Air flow rate m3/h 22000 46600 44000 66000
Evaporator
Number of evaporators No 1
Type - brazed plate heat exchanger
Internal volume (refrigerant side) l 4.1 5.1 5.6 7.6 9.2 9.2 11.6
Condensing coil
Material tubes / Fins - copper / aluminium
Rows / Fins space No/mm 3 / 1.6 2/1.8 3/1.8 3/1.6 3/1.8 3/1.8 3/1.6
Face area m23.00 6.00 9.00
Internal volume (each coil) l 7.3 9.8 14.7 22.0
Freecooling coil
Material tubes / Fins - copper / aluminium
Rows / Fins space No/mm 3 / 2.5 2/2.1 3/2.1 3/2.5 3/2.1 3/2.1 3/2.5
Face area m23.00 6.00 9.00
Hydraulic connections
Diameters inlet / outlet DN-inch DN50 2" DN65 2 1/2"
Unit volume l 77 101 117 121 159 159 160
Dimensions
Length mm 2043 3043 4043
Depth mm 1201
Height mm 1931
Weights
Net weight kg 861 1055 1147 1266 1643 1661 1702
Operating weight kg 938 1156 1264 1387 1802 1820 1862
Notes:
(1) --- At the following standard conditions: power supply 400V/3Ph/50Hz; outdoor temperature 35 ° C; water inlet/outlet temperature 15/10 ° C; ethylene glycol 30%.
(2) --- At the following standard conditions: power supply 400V/3Ph/50Hz; outdoor temperature 5
° C; fluid inlet temperature 15 ° C; ethylene glycol 30%.
(3) --- Measured with outdoor temperature 35
° C; 1m from the unit; free field conditions; according to ISO 3744.
(4) --- With outdoor temperature 35
° C; calculated according to ISO 3744.

Technical Data
4--8
Liebert HPC---S 006--- 022---PD--- 273571--- 01.03.2012
Ta b . 4 h --- Te c h n i c a l D a t a --- F G 0 0 0 6 --- 0 1 8 --- E C 8 0 0
FG0 model with EC 800 mm fans - R410A 006 007 009 011 014 015 018
Performance (1)
Cooling capacity kW 57.4 78.2 88.3 109.9 140.3 154.0 172.1
Freecooling capacity (2) kW 33.9 55.3 65.0 66.5 99.7 103.1 100.9
Compressors power input kW 18.6 20.6 25.0 35.3 41.2 48.9 57.0
Total power input kW 19.3 22.0 26.4 36.7 43.3 51.0 59.1
Unit EER - 2.97 3.55 3.34 3.00 3.24 3.02 2.91
Fluid flow m3/h 10.82 14.72 16.64 20.73 26.44 29.05 32.49
Hydraulic pressure drop kPa 118 109 90 109 118 139 143
Sound level
SPL (Sound Pressure Level) (3) dB(A) 58 59 61 62
PWL (Sound Power Level) (4) dB(A) 75 77 79 81
Refrigeration circuits
Number of refrigeration circuits No 1
Refrigerant charge (each circuit) kg 10.5 12.5 16.0 18.0 26.5 26.5 27.5
Compressors
Number of compressors No 1+1
Type - hermetic scroll
Nominal power (each compressor) HP 10+10 13+13 15+15 15+25 25+25 25+30 30+30
Fans
Number of fans No 1 2 3
Type - axial with EC motor
Wheel nominal diameter mm 800
RPM 1/min 715
Nominal power input (each fan) kW 0.7
Fans power input kW 0.7 1.4 2.1
Air flow rate m3/h 13500 28000 27000 40500
Evaporator
Number of evaporators No 1
Type - brazed plate heat exchanger
Internal volume (refrigerant side) l 4.1 5.1 5.6 7.6 9.2 9.2 11.6
Condensing coil
Material tubes / Fins - copper / aluminium
Rows / Fins space No/mm 3 / 1.6 2/1.8 3/1.8 3/1.6 3/1.8 3/1.8 3/1.6
Face area m23.00 6.00 9.00
Internal volume (each coil) l 7.3 9.8 14.7 22.0
Freecooling coil
Material tubes / Fins - copper / aluminium
Rows / Fins space No/mm 3 / 2.5 2/2.1 3/2.1 3/2.5 3/2.1 3/2.1 3/2.5
Face area m23.00 6.00 9.00
Hydraulic connections
Diameters inlet / outlet DN-inch DN50 2" DN65 2 1/2"
Unit volume l 77 101 117 121 159 159 160
Dimensions
Length mm 2043 3043 4043
Depth mm 1201
Height mm 1874
Weights
Net weight kg 861 1055 1147 1266 1643 1661 1702
Operating weight kg 938 1156 1264 1387 1802 1820 1862
Notes:
(1) --- At the following standard conditions: power supply 400V/3Ph/50Hz; outdoor temperature 35 ° C; water inlet/outlet temperature 15/10 ° C; ethylene glycol 30%.
(2) --- At the following standard conditions: power supply 400V/3Ph/50Hz; outdoor temperature 5
° C; fluid inlet temperature 15 ° C; ethylene glycol 30%.
(3) --- Measured with outdoor temperature 35
° C; 1m from the unit; free field conditions; according to ISO 3744.
(4) --- With outdoor temperature 35
° C; calculated according to ISO 3744.
