VIORE LC32VH5HTL User manual

*Features and specifications are subject to change without notice.
32” Commercial Grade HD LCD Television
LC32VH5HTL
FEATURES
31.5"(measured diagonally) Wide TFT LCD Screen
1366 x 768 native resolution for HD performance
Integrated ATSC Tuner for HDTV Broadcast reception
High Brightness (500cd/m2) provide a vivid and brilliant
Deep Black and Bright White with high contrast (1200:1)
Wide Viewing Angle 170°/170°
Dual HDMI inputs for true digital connections
HDMI and component inputs provide HDTV support
VGA port for connection to PC
Multi Language OSD (English/Spanish/French)
On Screen Program Guide
On/Off Timer
Sleep Timer
VESA Wall Mountable
Comply with FCC, ETL, RoHS Standard
Special Feature Package for Hotel Application
Connectivity
HDMI x 2
Composite Video x 1
Component Video YPbPr x 1
VGA Port x 1
S Video x 1
Audio Input x 1
PC Audio Input x 1
Accessories
Instruction Manual
Remote Control with Battery
Specifications
Power Supply: AC 100-240V, 50/60Hz
Power Consumption: 180W
Unit Dimension: 31.5” x 8.5” x 23.2”
Carton Dimension: 39.0” x 7.5” x 24.8”
Carton Weight (with unit): 40.1 lbs
UPC Code: 792885223475
Stuffing Quantity: 378 pcs (40‘ HQ)
Special Feature Package for Hotel Application
1. Special programmable OSD
2. Cloning Support - Master TV settings can be easily
transferred to multiple guest room TVs using the Cloning
Tool (Optional).
3. Swivel Stand for optimum viewing angle
4. Base is built with stronger material
5. Lockable Base for theft protection
6. Firmware upgradeable through USB port
7. Metal Cover for Jack-Pack to secure and protect the
connectors and to manage cables
8. High reliability power supply design to insure stable
operation
9. ENERGY STAR qualified design for energy efficiency
COMMERCIAL SERIES

Security Screws are used.
Tool for Security Screws
is supplied.
LC32VH5HTL
32” Commercial Grade HD LCD Television
Special programmable OSD
By enabling the HOTEL MODE, “maximum Volume
Level”, “Power on Channel”, “Input Source”, etc.
can be controlled.
Lockable Base
The Security Lock will secure the TV Base to the top of
cabinet or the counter top for preventing theft.
Security Lock
Master TV
Cloning Tool
Model: CL100 (Optional)
TVs for
Guest Rooms
Upload setting Download setting
Swivel Stand
Optimum viewing angle for your guest.
Metal Cover
Cloning Support
Master TV settings can be easily transferred to multiple
guest room TVs using the optional Cloning Tool.
Metal Cover for protecting connections
The metal cover restricts access to connectors and improves
cable management. It is secured by security screws, and a
special tool is required to remove it.
