Congratulations
Congratulations on the purchase of your state-of-the-art remote start
and keyless entry system. Reading this Owner’s Guide prior to using
your system will help maximize the use of your system and its many
features. For any additional questions please contact your authorized
Directed dealer or contact Directed at 1-800-753-0600 (U.S. only).
Important information
Government Regulations and Safety Information
Read the “Government Regulations”and “Warning! Safety
First”sections of this manual prior to operating this system.
Warning! Failure to heed this information can result in
death, personal injury or property damage and may also
result in the illegal use of the system beyond its intended
purpose.
Your Warranty
Your system comes with a warranty. The warranty terms are detailed at
the end of this guide. Make sure that you receive the proof of purchase
from your dealer, indicating the product was installed by an autho-
rized Directed dealer.
Replacement remote controls
Please see your authorized dealer or visit us at www.directedstore.
com to order additional remote controls. Remote control part numbers
are found on the back of the device.

Contents
Important information ......................................................................................... 1
Getting Started.................................................................................................... 3
Keys to using this manual...................................................................... 3
Remote Control ................................................................................................... 4
Control Center .................................................................................................... 4
Using your System............................................................................................... 5
Commanding the system....................................................................... 5
Performing Commands ......................................................................... 5
Remote Control Command table ............................................................ 6
Basic Commands (Direct Access) .......................................................................... 7
Lock ................................................................................................... 7
Unlock................................................................................................ 7
Remote Start........................................................................................ 7
AUX/Trunk.......................................................................................... 7
Advanced Commands: (Level 1) ........................................................................... 8
Silent Lock........................................................................................... 8
Runtime Reset ...................................................................................... 8
AUX 1................................................................................................ 8
Advanced Commands: (Level 2) ........................................................................... 9
Remote Valet ...................................................................................... 9
Timer Start .......................................................................................... 9
AUX 2................................................................................................ 9
Advanced Commands: (Level 3) ......................................................................... 10
Car finder......................................................................................... 10
Smart Start........................................................................................ 10
AUX 3.............................................................................................. 10
Advanced Commands: (Level 4) ......................................................................... 11
Defogger .......................................................................................... 11
AUX 4.............................................................................................. 11
Remote Control Configuration ............................................................................ 12
Remote Programming ......................................................................... 12
Remote Pairing ................................................................................. 12
Remote Programming ......................................................................... 13
Remote Features ................................................................................ 13
Emergency Override......................................................................................... 15
Remote Start Features ........................................................................................ 16
Key Takeover..................................................................................... 16
Remote Start Safe-lock ...................................................................... 16
Disabling Remote Start ..................................................................... 16
Advanced Start ................................................................................. 16
Pit Stop Mode ................................................................................... 18
Manual Transmission Start (MTS mode) ................................................ 18

Turbo Timer Mode.............................................................................. 19
Remote Start Faults............................................................................. 20
Remote and System Operations.......................................................................... 21
Passive Locking ................................................................................. 21
Auto Re-locking ................................................................................ 21
Valet Mode ....................................................................................... 22
Power Save....................................................................................... 22
Rapid Resume ................................................................................... 22
Car Select......................................................................................... 22
System Expansion Options................................................................................. 23
Battery Information............................................................................................ 25
Low Battery Alerts .............................................................................. 25
Battery Replacement........................................................................... 25
Battery Disposal ................................................................................ 25
Patent Information ............................................................................................. 26
Glossary of Terms.............................................................................................. 27
Government Regulations .................................................................................... 28
Warning! Safety First......................................................................................... 29
Installation ........................................................................................ 29
Remote Start Capable ........................................................................ 29
Manual Transmission Vehicles ............................................................. 29
Interference....................................................................................... 31
Upgrades ......................................................................................... 31
Water/Heat Resistance ...................................................................... 31
Limited lifetime consumer warranty ..................................................................... 32

3
© 2013 Directed. All rights reserved.
Getting Started
Keys to using this manual
Specific actions (in bold type) and style conventions are used consis-
tently throughout this manual, they are as follows:
• Press: implies pushing in and releasing a button.
• Hold: is used after Press actions when a button needs to be held
in position for an extended period of time, typically several sec-
onds.
• Italicized words denote section/sub headings in this guide and
can be located through the table of contents.
• An asterisk (*) when used after a word or phrase denotes that
additional details can be found in related sections usually noted
at the bottom of the page or end of the section.

4© 2013 Directed. All rights reserved.
Remote Control
Feature Description
Internal Antenna Used for transmitting information
Transmit LED Active when transmitting information
Command buttons (4)
AUX
Used to perform locking, unlocking, auxiliary channel and
remote start commands
Function button Used to access function levels for commands, configuration
menus for programming and Car Selection
Control Center
Control CenterLED Button
The Control Center, typically located on the upper part of the front
windshield. It consists of:
• The In-vehicle system antenna.
• The Status LED, as a visual indicator of the system’s status.
• The Control button, for placing the system into Valet Mode* and
to perform the Emergency Override operation.
* See “Remote and System Operations” for details.

5
© 2013 Directed. All rights reserved.
Using your System
Commanding the system
Commands, Basic or Advanced, are used to activate system features
and are performed by pressing one of the Command buttons. Basic
commands control the most often used keyless entry and remote start
features while Advanced commands control more specialized fea-
tures.
Confirmations for Basic or Advanced commands are indicated
by horn honks* and parking light flashes. A description of each fea-
ture confirmation is found in the following Basic command and Ad-
vanced command sections.
Performing Commands
Perform Basic commands by pressing a Command button.
Perform Advanced Commands by first accessing Levels 1-4 using the
button and then by pressing a Command button while within a
level.
Advanced command example: Silent Lock
1. Press the button once to access Function Level 1, The trans-
mit LED single flashes for 3 seconds.
2. Press the button while the transmit LED is still flashing to
perform the Silent Lock command.
3. The system will lock the doors and flash the parking lights,
without horn honks.*
* The optional Horn Honk feature must be connected.

6© 2013 Directed. All rights reserved.
Remote Control Command table
Basic
Commands
Advanced Commands
Function
Level 1
Function
Level 2
Function
Level 3
Function
Level 4
Button
Level Direct Access x 1 x 2 x 3 x 4
Lock Silent Lock
Unlock Silent Unlock Remote Valet Car Finder
Remote Start Reset Runtime Timer Start Smart Start Defogger
AUX AUX/Trunk AUX 1 AUX 2 AUX 3 AUX 4
Advance
Level, Change
Car (3 sec),
Enter program-
ming (8 sec)

7
© 2013 Directed. All rights reserved.
Basic Commands (Direct Access)
Lock
Press and release
Doors lock (if connected), the horn honks** once and the parking
lights flash one time.
To Lock and Panic
Press and hold
To lock the system, then activate Panic. For Panic to be effective,
the optional horn honk feature must be connected. Press the
or button to stop Panic output.
Unlock
Press and release
The doors unlock (if connected), the horn honks** twice and the park-
ing lights flash.
Remote Start*
Press and release
Activates (or if On, deactivates) the remote starter. The engine turns
On, or the engine turns Off accordingly. If a Remote start configura-
tion issue prevents the engine from starting, the parking lights flash a
Remote Start fault report to identify the fault.
AUX/Trunk**
Press and hold AUX
The Trunk opens (if connected) when button is held for 2 seconds.
* For Manual transmission vehicles see “Manual Transmission Start”.
**This is an optional feature, see your authorized Directed dealer.

8© 2013 Directed. All rights reserved.
Advanced Commands: (Level 1)
Press and release the button one time first, before pressing one of
the following command buttons. The transmit LED illuminates in sets of
single flashes to indicate Level 1.
Silent Lock
Press and release
The doors lock (if connected), without horn honks.*
Silent Unlock
Press and release
Doors unlock (if connected), without horn honks.*
Runtime Reset
Press and release
If more time is needed while remote start is active, runtime reset will
reset the runtime counter to the pre-programmed setting.
Note Remote Start must be On to use this feature.
AUX 1
Press and release AUX
Activates (or if On, deactivates) the Aux 1 output.
* The optional Horn Honk feature must be connected.

9
© 2013 Directed. All rights reserved.
Advanced Commands: (Level 2)
Press and release the button two times first, before pressing one of
the following command buttons. The transmit LED illuminates in sets of
double flashes to indicate Level 2.
Remote Valet
Press and release
Enters (or if On, exits) Valet Mode. The Control Center LED turns on
and off accordingly, and prevents doors from locking passively.
Timer Start*
Press and release
Activates (or if On, deactivates) Timer Start. The parking lights flash
quickly four times for On and slowly four times for Off.
Note System needs to be locked with the remote or Timer Start
will not start the engine.
AUX 2
Press and release AUX
Activates (or if On, deactivates) the Aux 2 output.
* See “Advanced Start”under “Remote Start Features” for more de-
tails.

10 © 2013 Directed. All rights reserved.
Advanced Commands: (Level 3)
Press and release the button three times first, before pressing one
of the following command buttons. The transmit LED illuminates in sets
of triple flashes to indicate Level 3.
Car finder
Press and release
The horn emits one long honk and the parking lights flash for 10 sec-
onds. The parking light flashes stop if locked or unlocked while Car
Finder is in progress. Lock and Unlock cancels the parking light flash.
Smart Start*
Press and release
Activates (or if On, deactivates) Smart Start. The parking lights flash
quickly five times for On and slowly five times for Off.
Note System needs to be locked or Smart Start will not start the
engine.
AUX 3
Press and release AUX
Activates (or if On, deactivates) the Aux 3 output. See your authorized
Directed dealer for details.
* See “Advanced Start” for more details.

11
© 2013 Directed. All rights reserved.
Advanced Commands: (Level 4)
Press and release the button four times first, before pressing one of
the following command buttons. The transmit LED illuminates in sets of
quadruple flashes to indicate Level 4.
Defogger*
Press and release
Activates the vehicle Defogger circuit (if connected) while Remote Start
is activated and the parking lights flash 3 times. For convenience,
the Defogger circuit will also automatically activate 10 seconds after
remote starting if the temperature is below 55°F.
Note Remote Start must be active to use this feature.
AUX 4
Press and release AUX
Activates (or if On, deactivates) the Aux 4 output.
* This feature must be installed and turned on by an authorized
Directed dealer.

12 © 2013 Directed. All rights reserved.
Remote Control Configuration
The remote controls have operations that can be configured to a user’s
personal preferences. The following instruction will direct you through
the available programming options for both remote controls.
Remote Programming
To Enter Programming: Press and hold the button for 8 seconds,
the transmit LED turns on to indicate the Main Menu is accessed.
To Exit Programming: Press and release the button once then press
and hold the button again until the transmit LED shuts off.
Remote Pairing
The following instruction will step you through the remote pairing op-
eration.
Prepare the vehicle system for pairing:
1. Turn the key to the ON position.
2. Within 5 seconds press and release 1 time the Control button on
the Control Center.
3. Within 5 seconds, press and hold the Control button. The status
LED will flash one time and the horn (if connected) honks once to
confirm the system is ready for remote pairing.
4. Release the Control button and proceed to next step.
Prepare the remote control for pairing:
5. Enter programming by pressing and holding the button for 8
seconds to access the Main Menu.
6. Press and hold the button for 1 second, 3 transmit LED flash-
es indicate the remote control is ready to pair.

13
© 2013 Directed. All rights reserved.
7. Press the button.
8. Wait several seconds as the remote generates a security encryp-
tion and sends it to the Control Center. The horn honks to indicate
Pairing is complete.
If pairing is not successful press and release the button once
and then repeat steps 6 and 7.
Pairing will exit if:
• Step 7 is not completed within 60 seconds
• The doors are closed
• The ignition is turned off.
Remote Programming
Enter programming, press and hold the button for 8 seconds, the
transmit LED turns on to indicate the Main Menu is accessed.
Exit programming or go back to a previous menu, press and release
the button. When programming is exited the transmit LED turns off.
Remote Features
Enter programming to access the main menu as previously explained,
then from the main menu, press and hold the button to access the
remote operation features, 2 transmit LED flashes indicate the remote
features menu is accessed. Press the buttons indicated in the tables
below to set the feature option.
The remote control will flash the Transmit LED to indicate the setting.
Feature Button Press Single Flash Double Flash
Keypad Lock Auto Off *

14 © 2013 Directed. All rights reserved.
Feature Button Press Single Flash Double Flash
Button Beeps On* Off
Car 2 Car 2 On Car 2 Off *
* Indicates default setting.
Keypad Lock
Options: Off, Auto
When Off, the buttons do not lock and always perform a com-
mand when pressed. When set to Auto, the remote buttons lock
after a 20 second lapse between button presses to prevent unin-
tentional operations.
To unlock the buttons, press the button followed by the
button.
Note If a button is pressed when locked, a fault tone plays as an
alert. To unlock the buttons, press the button followed
by the button, tones are emitted to confirm unlocking.
Car 2
Options: Off, On
The remote controls can control two systems independently.
When set to Off, the Car Select feature is not available. When
set to On the Car Select feature is enabled. See Car Select (un-
der Remote and System Operations) for detail on using a remote
with 2 systems.

15
© 2013 Directed. All rights reserved.
Emergency Override
The override feature allows you to select a specific number of presses
needed to disable the system.
If the override button has been programmed to a new number of
presses by your authorized dealer, that number should be indicated
as follows. Number of presses_______
1. Turn the ignition On.
2. Press the control button on the Control Center the correct number
of times (the default is 1 press).
3. After a few seconds the horn output ceases and the system is
disabled.
Note As a precaution, if programmed for Passive Locking or Auto
re-locking the system should be placed into Valet Mode until
a remote is available.

16 © 2013 Directed. All rights reserved.
Remote Start Features
Key Takeover
When you are ready to drive
The system keeps the engine running until the vehicle is ready to be
driven. To perform Key Takeover:
1. Unlock the system and enter the vehicle, do not step on the foot
brake.
2. Insert the key, turn it to the run position, and then step on the foot
brake, the remote start then turns off.
3. The parking lights turn off to indicate remote start is off.
4. The vehicle is ready to drive.
Remote Start Safe-lock
Remote start safe-lock makes sure the doors are locked while the en-
gine is running and after, even if they are unlocked when remote start
is activated. Door locks may require additional parts and labor.
Disabling Remote Start
Remote start can be disabled by moving the Toggle Switch to the Off
position. If remote start is attempted while Off, the engine will not
start. (See “Remote Start Faults” under Remote Start Features) move the
switch back to the On position to resume normal operation.
Advanced Start
The Advanced start features; Timer Start and Smart Start will automati-
cally start the engine to maintain battery charge or combat extreme
cold when parked for an extended period of time.

17
© 2013 Directed. All rights reserved.
Precautions for the Advanced Start features:
• Park the vehicle in a well ventilated area away from windows
and doors that lead into inhabited spaces.
• Lock the vehicle, the engine will not start unless the doors are
locked.
• Only one Advanced start feature can be enabled at any given
time.
• For manual transmission vehicles MTS mode must be enabled
before Timer Start or Smart Start can be activated.
• Timer Start or Smart Start mode automatically exits when the ve-
hicle is unlocked.
Timer Start operation
Activation begins a countdown timer as set by the installer (de-
fault 3 hours). When the timer expires the engine starts. When
the Remote start runtime expires the engine shuts off, and the
countdown timer restarts. This will repeat as many times as set
by the installer (default 6 starts). Timer Start is exited after the
final start.
Smart Start operation
Smart Start uses the settings for Timer Start in addition to tempera-
ture and battery level to automatically start the engine. Activation
begins the countdown timer. When the timer expires the vehicle
interior temperature and battery level is checked and, if the Tem-
perature is above 100°F, below 0°F, or the battery level is be-
low 10.5V, the engine will start. When the Remote start runtime
expires the engine shuts off, and the countdown timer restarts.
Smart Start is exited after the final start.
