Vision Audio Visual TECHCONNECT TC-MATRIX User manual

1
TC-MATRIX_manual_en.doc
TECHCONNECT TC-MATRIX
OWNERS MANUAL
www.visionaudiovisual.com/techconnect/tc-matrix/

2
TC-MATRIX_manual_en.doc
DECLARATION OF CONFORMITY
Where applicable Vision products are certified and comply with all known local regulations to a
‘CB Certification’ standard. Vision commits to ensure all products are fully compliant with all
applicable certification standards for sale in the EU and other participating countries.
The product described in this owner manual is in compliance with RoHS (EU directive
2002/95/EC), and WEEE (EU directive 2002/96/EC) standards. This product should be returned
to the place of purchase at the end of its useful life for recycling.
WARNINGS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be
of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle, is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
All products are designed and imported into the EU by ‘Vision’ who is wholly owned by ‘Azlan
Logistics Ltd.’, Registered in England Nr. 04625566 at Lion House, 4 Pioneer Business Park,
Clifton Moor, York, YO30 4GH. WEEE Registration: GD0046SY
DECLARATION OF ORIGIN
All Vision products are made in the People’s Republic of China (PRC).

3
TC-MATRIX_manual_en.doc
USE ONLY DOMESTIC AC OUTLETS
Connecting the unit to an outlet supplying a higher voltage may create a fire hazard.
HANDLE THE POWER CORD WITH CARE
Do not disconnect the plug from the AC outlet by pulling the cord; always pull the plug itself.
Pulling the cord may damage it. If you do not intend to use your unit for any considerable
length of time, unplug the unit. Do not place furniture or other heavy objects on the cord, and
try to avoid dropping heavy objects on it. Do not tie a knot in the power cord. Not only could
the cord be damaged, but a short circuit could also be caused with a consequent fire hazard.
PLACE OF INSTALLATION
Avoid installing this product under the following conditions:
• Moist or humid places
• Places exposed to direct sunlight or close to heating equipment
• Extremely cold locations
• Places subject to excessive vibration or dust
• Poorly ventilated places
Do not expose this product to dripping or splashing. DO NOT PLACE OBJECTS FILLED WITH
LIQUIDS ON OR NEAR THIS PRODUCT!
MOVING THE UNIT
Before moving the unit, be sure to pull out the power cord from the AC outlet and disconnect
the interconnection cords with other units.
WARNING SIGNS
If you detect an abnormal smell or smoke, turn this product off immediately and unplug the
power cord. Contact your reseller or Vision.
PACKAGING
Save all packing material. It is essential for shipping in the event the unit ever needs repair.
IF ORIGINAL PACKAGING IS NOT USED TO RETURN THE UNIT TO THE SERVICE CENTRE,
DAMAGE IN TRANSIT WILL NOT BE COVERED BY WARRANTY.

4
TC-MATRIX_manual_en.doc
TRANSMITTER
1. IR receiver (to switch Matrix channel, not for IR passthrough)
2. Standby indicator
3. Channel adjust button
4. Channel display (each Tx in system must be set to different channel)
5. Channel adjust button
1. 5V 3A Power input (note device cannot run on PoE)
2. Data transmission indicator
a. Slow flashing; establishing connection
b. Fast flashing; successfully connected and transmitting data
3. CAT5e/6 Output
4. Connection indicator; if no light then not connected to Rx
5. IR blaster minijack socket (plug IR blaster in here)
6. HDMI Input
7. Reset/restart button
1
2
3
1
5
4
2
3
4
5
6
7

5
TC-MATRIX_manual_en.doc
RECEIVER
1. Channel adjust button
2. Channel display (each Rx in system must be set to different channel)
3. Channel adjust button
4. IR receiver (to switch Matrix channel, not for IR passthrough)
5. Standby indicator
6. TX Channel adjust button
7. TX Channel display (determines which source this Rx will display)
8. TX Channel adjust button
1. 5V 3A Power input (note device cannot run on PoE)
2. Data transmission indicator
a. Slow flashing; establishing connection
b. Fast flashing; successfully connected and transmitting data
3. CAT5e/6 Input
4. Connection indicator; if no light then not connected to Tx
5. IR Receiver minijack socket (plug IR receiver in here)
6. HDMI Output
7. Reset/restart button
1
2
5
8
7
6
3
4
9
1
2
3
4
5
6
7

6
TC-MATRIX_manual_en.doc
FACTORY RESET
1/ Hold the two buttons circled at the same time until 00 is displayed
2/ Disconnect power
3/ Wait 3 seconds
4/ Reconnect power

7
TC-MATRIX_manual_en.doc
REMOTE CONTROL
M – Normal Mode
F – Video Wall Mode
Video Wall related functions:
L – Left
R – Right
U – Up
D – Down
(See Video Wall section for more information)
Left Arrow / Right Arrow
Selects LCD to adjust. LCD will start flashing:
+ / -
Once LCD is flashing, use these buttons to adjust up or down.
1
2
3
4

8
TC-MATRIX_manual_en.doc
SETUP – POINT TO POINT
It is not necessary to run the signal through a network switch. To use as an HDMI extender:
1. CONNECT TX TO RX Use a CAT6 cable to link a Tx directly to an Rx. The CAT6 cable must
be wired using normal IEEE-568B standard. It can be UTP or STP. Maximum length: 120
metres (394ft).
2. SET “TX CONNECTED” CHANNEL ON RX to match the channel on the Tx.

9
TC-MATRIX_manual_en.doc
SETUP – OVER NETWORK
This product uses Multicasting which is what allows one transmitter to send to many receivers.
Multicasting changes the way a network behaves.
VERY IMPORTANT:To use this product IGMP snooping MUST be activated on the network
switch. This is what allows multicasting. IGMP snooping can only be activated on a “layer-3”
managed switch.
Consider Netgear’s M4300-28 (24 port) or M4300-52 (48 port) as they are pre-configured for AV
Applications.
1. TURN IGMP SNOOPING ON You must use a managed switch. The network administrator
needs to go to the switch settings page in their browser and activate it.

10
TC-MATRIX_manual_en.doc
2. CONNECT ALL TX AND RX DEVICES TO NETWORK All devices must be on same subnet.
Microwave extenders may not have enough bandwidth to support this product which uses
up to 24Mbps transmitting 4K 60 Hz video
3. CONNECT SOURCES TO TX AND DISPLAYS TO RX One Tx for each source, one Rx for each
display. Uses proprietary encoding and cannot decode a stream from another product or
VLC.
4. SET CHANNEL ID ON ALL DEVICES
a. All Tx should be on different channels.
b. All Rx should be on different channels.
5. SET “TX CONNECTED” CHANNEL ON RECEIVERS The source connected to the Tx selected
will show on the display. Allow a few seconds for the HDCP handshake.
Set to Forwarding

11
TC-MATRIX_manual_en.doc
IR PASS THROUGH
The source remote control can be used at the display. It supports IR standards from 20-60 kHz.
This feature IS NOT Bi-directional; the signal is only carried from the receivers to the
transmitters.
1. CONNECT IR RECEIVER CABLE TO RX position the receiver diode near front of display.
2. CONNECT IR BLASTER CABLE TO TX position diode over the IR receiver window on the
source device.

12
TC-MATRIX_manual_en.doc
APP CONTROL
A free generic app called MATRIX CONTROL LITE is available from the Apple app store and
Google’s Play store. The app can be used for switching and renaming each end point.
1. INSTALL APP
2. CONNECT PHONE OR TABLET TO WIFI The wifi router must be on the same network as
the devices.
3. RUN APP then press SCAN to find Tx and Rx on network. They will automatically populate.
If they do not you are not on the same network.
To rename click here
Drag and Drop
to change “CONNECTED TX” of
RX1 to TX10

13
TC-MATRIX_manual_en.doc
CRESTRON OR AMX CONTROL
Download native Crestron and AMX drivers from www.visionaudiovisual.com/techconnect/tc-
matrix/ to integrate into a larger system.
Note: Control is via IP. Check that firewalls and VPNs are disabled. The computer’s IP address
must be in the same range as the devices: 192.168.1.xxx
PC SOFTWARE
Software available from www.visionaudiovisual.com/techconnect/tc-matrix/
Allows switching like the app, and adds two advanced features:
1. CHANGE DEVICE IP ADDRESSES For advanced management:

14
TC-MATRIX_manual_en.doc
2. CREATE “SCENES” OR “MODES” If uses want to switch more than one device at a time
they can use modes.
a. Create a scene and save it.
b. Create another scenario and save it.
c. Switch between the two.
NOTE:
If devices cannot be found when you click SCAN check that firewalls and VPNs are
disabled. The computer’s IP address must be in the same range as the devices: 192.168.1.xxx
To change it in Windows 10 press the windows key and type: Network Connections
Right click and select Properties

15
TC-MATRIX_manual_en.doc
1
2
Enter 192.168.1.xxx here

16
TC-MATRIX_manual_en.doc
VIDEO WALL
Video wall configurations are pre-set. There is no bezel thickness adjustment.
Set channels on receivers:
Note: Video walls can only receive from up to 10 Tx.
Rx Channel Settings:
F1 1x F1 2x F1 3x
F4 1x F4 2x F4 3x
F1 4x F1 5x F1 6x
F4 4x F4 5x F4 6x
F1 7x F1 8x F1 9x
F2 1x F2 2x
F5 1x F5 2x F5 3x
F2 3x F2 4x
F3 1x F3 2x
F6 1x
F3 3x F3 4x
F6 2x
F3 5x F3 6x
F6 3x
1/ Set to F for
Video Wall
2/ Determines shape of wall
3/ Determines which
display this is attached to
4/ set which Tx is source

17
TC-MATRIX_manual_en.doc
Bezel Adjustment:
The RX ID buttons can be used to fine tune the image on the screen.
Pressing the left button cycles through:
0
1
2
3
4
5
6
7
8
9
F
L
R
U
D
The last four are used for Video Wall fine tuning:
Once adjustment done, select F again. All this can also be done on remote control.
1/ Press to cycle
through edges:
L Left
R Right
U Up
D Down
2/ Press to cycle through 10
steps of adjustment

18
TC-MATRIX_manual_en.doc
SPECIFICATIONS
PRODUCT DIMENSIONS: 164 x 108.5 x 23.6 mm / 6.46″ x 4.27″ x 0.93”
PACKAGED DIMENSIONS: 357 x 153.5 x 85 mm / 14″ x 6.04″ x 3.35”
PRODUCT WEIGHT: 330g / 0.73 lb
PACKAGED WEIGHT: 0.8kg / 1.76 lb
CONSTRUCTION MATERIAL: Metal
COLOUR: White
TECHNICAL DETAILS:
Input and Output TMDS Signal: 0.7-1.5 volts p-p
Input and Output DDC Signal: 5 volts p-p (TTL)
Maximum Video Format Supported: 4K
Output Video: HDMI 2.0 with HDCP 2.2
Output Audio: PCM
Compression: H.264
Input and Output HDMI Cable Length: 5m (16.4 ft) AWG 26
Operating Temperature Range: 0-50°C
Storage Temperature Range: -10-70°C
Operating Humidity Range: 0 to 90 % no condensation
Tx Power Consumption: 7 watts
Rx Power Consumption: 10 watts
CAT6 Maximum distance (if connected peer-to-peer directly): 120 m (394 ft)
IR Passback Bandwidth: 20-60 kHz
ESD protection: 1a Contact discharge level 3 / 1b Air discharge level 3 (Standard: IEC61000-4-
2)
CONNECTIVITY:
1 x HDMI (type A)
1 x Ethernet (RJ45)
1 x DC Power (2-port phoenix)
1 x 3.5mm Minijack (IR)
POWER SUPPLY: 100-240v 50/60Hz AC 5 volt / 3 amp
Transformer integrated into plug. Includes interchangeable plugs: UK/EU/US/AU. DC tail length:
1.8m. Transformer dimensions: 81 x 52 x 38mm / 3.2″ x 2.05″ x 1.5″
ACCESSORIES INCLUDED:
2 x Mounting ears
1 x Remote Control
1 x IR Emitter Cable
1 x IR Receiver Cable
WARRANTY: Lifetime return-to-base http://www.visionaudiovisual.com/support
COMPLIANCES: RoHS, WEEE, CE/EMC
ORDER PART CODE:
Transmitter TC-MATRIXTx [EU SAP: 4631209 / US SAP: 4631209]
Receiver TC-MATRIXRx [EU SAP: 4631210 / US SAP: 13293566]

19
TC-MATRIX_manual_en.doc
LEGAL DISCLAIMER: Because we are committed to improving our products, the details above
may change without prior warning. This User Manual is published without warranty and any
improvements or changes to the User Manual necessitated by typographical errors, inaccuracies
of current information, or improvements to programs and/or equipment, may be made at any
time and without notice. Such changes will be incorporated into new editions of the User
Manual.

1
TC-MATRIX_manual_de.doc
TECHCONNECT TC-MATRIX
BEDIENUNGSANLEITUNG
www.visionaudiovisual.com/de/techconnect-de/tc-matrix/
