Vision TC-HDMIWM User manual

1
TC-HDMIWM_manual_en.doc
TECHCONNECT TC-HDMIWM
OWNERS MANUAL
www.visionaudiovisual.com/techconnect/tc-hdmiwm/

2
TC-HDMIWM_manual_en.doc
DECLARATION OF CONFORMITY
Where applicable Vision products are certified and comply with all known local regulations to a
‘CB Certification’ standard. Vision commits to ensure all products are fully compliant with all
applicable certification standards for sale in the EU and other participating countries.
The product described in this owner manual is in compliance with RoHS (EU directive
2002/95/EC), and WEEE (EU directive 2002/96/EC) standards. This product should be returned
to the place of purchase at the end of its useful life for recycling.
WARNINGS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be
of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle, is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
All products are designed and imported into the EU by ‘Vision’ who is wholly owned by ‘Azlan
Logistics Ltd.’, Registered in England Nr. 04625566 at Lion House, 4 Pioneer Business Park,
Clifton Moor, York, YO30 4GH. WEEE Registration: GD0046SY
DECLARATION OF ORIGIN
All Vision products are made in the People’s Republic of China (PRC).

3
TC-HDMIWM_manual_en.doc
USE ONLY DOMESTIC AC OUTLETS
Connecting the unit to an outlet supplying a higher voltage may create a fire hazard.
HANDLE THE POWER CORD WITH CARE
Do not disconnect the plug from the AC outlet by pulling the cord; always pull the plug itself.
Pulling the cord may damage it. If you do not intend to use your unit for any considerable
length of time, unplug the unit. Do not place furniture or other heavy objects on the cord, and
try to avoid dropping heavy objects on it. Do not tie a knot in the power cord. Not only could
the cord be damaged, but a short circuit could also be caused with a consequent fire hazard.
PLACE OF INSTALLATION
Avoid installing this product under the following conditions:
• Moist or humid places
• Places exposed to direct sunlight or close to heating equipment
• Extremely cold locations
• Places subject to excessive vibration or dust
• Poorly ventilated places
Do not expose this product to dripping or splashing. DO NOT PLACE OBJECTS FILLED WITH
LIQUIDS ON OR NEAR THIS PRODUCT!
MOVING THE UNIT
Before moving the unit, be sure to pull out the power cord from the AC outlet and disconnect
the interconnection cords with other units.
WARNING SIGNS
If you detect an abnormal smell or smoke, turn this product off immediately and unplug the
power cord. Contact your reseller or Vision.
PACKAGING
Save all packing material. It is essential for shipping in the event the unit ever needs repair.
IF ORIGINAL PACKAGING IS NOT USED TO RETURN THE UNIT TO THE SERVICE CENTRE,
DAMAGE IN TRANSIT WILL NOT BE COVERED BY WARRANTY.

4
TC-HDMIWM_manual_en.doc
SPECIAL WARNINGS
Never use this product near an aircraft or medical facility. It can cause interference.
Use of product in the following locations may result in abnormal video and audio output:
•Product installed in the walls made of concrete
•Product situated near refrigerator. Microwave oven, or other metal items
•A cluttered room where the wireless signals may be blocked
This product has been tested and manufactured to comply with each country‟s safety rules,
however there is no guarantee that interference will not occur in some scenarios. If
interference happens, adjust distance between transmitter and receiver. Optimal range
between transmitter and receiver is between 2 and 7 meters line of sight.
This product may interfere 5GHz wireless devices. If interference occurs configure your
5GHz router to 2.4 GHz band only.
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. This equipment generates, uses and can radiate radio
frequency energy and may in extreme cases cause harmful interference to radio
communications. If this happens the user should try:
•Relocating the receiving antenna
•Increasing the separation between the equipment and receiver
•Connect the equipment to a different power circuit.
RADIATION EXPOSURE STATEMENT:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator and your body.

5
TC-HDMIWM_manual_en.doc
TRANSMITTER (Tx)
1. Channel LCD Display
2. Channel Select Button
3. Present Button (only works with 1 x Rx in system)
4. IR receiver
1. Power Input (Phoenix Connector)
2. HDMI Input
3. Wireless Indicator – lights when Tx is correctly connected to Rx
4. PRESENT button dip switch
5. Input indicator – lights when source is connected with supported resolution
6. IR Blaster 3.5mm minijack socket
1
2
3
1
4
2
5
3
6
4

6
TC-HDMIWM_manual_en.doc
RECEIVER (Rx)
1. Channel LCD Display
2. Channel Select Button
3. IR receiver
1. Power Input (Phoenix Connector)
2. HDMI Output
3. Data Indicator – flashes slowly when establishing connection / fast when data transferring.
4. PRESENT button dip switch
5. Male 9-Pin RS-232 Serial connector for external control
6. Wireless Indicator – lights when Tx is correctly connected to Rx
7. IR Receiver 3.5mm minijack socket
1
2
3
1
2
6
3
7
4
5

7
TC-HDMIWM_manual_en.doc
REMOTE CONTROL
1. Channel Selection
2. Info Onscreen Display
3. Present (for Tx)
3
1
2

8
TC-HDMIWM_manual_en.doc
INSTALLATION NOTES
SYSTEM RULES
These two rules will help you understand what is possible with this product:
Rule 1: This product uses 10 channels. Each transmitter needs to use a different channel,
therefore you can have up to 10 transmitters in the same WiFi environment.
Rule 2: Only 2 receivers at most can be linked to a transmitter.
DISPLAY SLEEP
The Rx will stop outputting HDMI if no source is present for 10 minutes. This allows the display
to go to sleep when the source is off.
SWITCH TIME
Can be up to 7 seconds because an EDID has to happen each time.
FREQUENCY SPECTRUM
This product uses 5GHz WIFI channels so it can be affected by outside interference in the same
way as any wifi device. This product uses non-DFS channels.
IR PASSBACK
If using a source device which has a remote control, this product allows the remote to be
pointed at the display in the remote location. The IR signal is relayed from the Rx to the Tx to
the source device.
To make this happen the IR blaster and receiver cables mush be used.
•The diode on the blaster must be as close as possible to the source IR receiver.
•The diode on the receiver must be in line-of-sight of the remote control.

9
TC-HDMIWM_manual_en.doc
MATRIX
1. Connect sources to Tx, and displays to
Rx
2. Set each Tx to different channels. You
cannot have two Tx sharing same
channel.
3. Adjust channel on each Rx to switch
which source is shown.
The maximum number of devices in a matrix
system is 2 x 2.
Because you can use 10 x Tx simultaneously you could have 5 discrete matrix systems, or a
blend of Matrix, Distribution, and Switching systems running at the same time.
DISTRIBUTION
Shows content from one source on two
displays.
1. Connect source to Tx, and displays to
Rxs
2. Set them all to the same channel.
Because you can use 10 x Tx simultaneously you could have 10 discrete Distribution systems, or
a blend of Matrix, Distribution, and Switching systems running at the same time.

10
TC-HDMIWM_manual_en.doc
SWITCHING
Up to 10 sources, and one receiver.
1. Connect sources to Txs, and display to Rx
2. Set each Tx to different channels.
3. Change channel on Rx to determine which source it displays.
It is possible to have multiple switching systems in the same
environment; the limitation is the number of Tx in total: 10.
Because you can use 10 x Tx simultaneously you could have a
blend of Matrix, Distribution, and Switching systems running at the
same time.
PRESENT BUTTON
If you have just one display, you can use PRESENT button on the
front panel of Txs (or remote control).
This button sends a command to Rx saying “switch to my
channel”. To activate set dip switch on rear of all devices to “1RX”.
`
If system has more than one receiver this function cannot be used.

11
TC-HDMIWM_manual_en.doc
INFO ONSCREEN DISPLAY
Press i button on remote control to display channel information, showing other SSID device in
the area. It shows signal strength and Wifi congestion to help trouble-shoot.
Note: To show all SSID in range the Rx must not be “connected” to any Tx when you do this.
Change the Rx channel to an unused channel first.
Note: if you are having problems and need to Contact Us via www.visionaudiovisual.com please
send a photo of the information on this screen.
RS-232
Baud rate: 115 200
Command
ASCII
HEX
Channel 0
rxch:00
72 78 63 68 3a 30 30
Channel 1
rxch:01
72 78 63 68 3a 30 31
Channel 2
rxch:02
72 78 63 68 3a 30 32
Channel 3
rxch:03
72 78 63 68 3a 30 33
Channel 4
rxch:04
72 78 63 68 3a 30 34
Channel 5
rxch:05
72 78 63 68 3a 30 35
Channel 6
rxch:06
72 78 63 68 3a 30 36
Channel 7
rxch:07
73 78 63 68 3a 30 37
Channel 8
rxch:08
74 78 63 68 3a 30 38
Channel 9
rxch:09
75 78 63 68 3a 30 39

12
TC-HDMIWM_manual_en.doc
NOT WORKING?
1. Set computer to duplicate or extend desktop (right-click on desktop > select Display
settings)
2. Reduce refresh rate:
Resolution no more
than 1920 x 1080
Select List All Modes to change refresh rate

13
TC-HDMIWM_manual_en.doc
3. Try other cables between the source and Tx
4. EDID handshakes and HDCP key authentication can create HDMI issues. Try rebooting all
equipment to reset.
5. Press i (info) button on remote to show wifi spectrum. If crowded try changing channel.
SPECIFICATIONS
TRANSMITTER DIMENSIONS: 135 x 80 x 23 mm / 5.3” x 3.1” x 0.9” (length x width x height)
RECEIVER DIMENSIONS: 135 x 80 x 23 mm / 5.3” x 3.1” x 0.9” (length x width x height)
PACKAGED DIMENSIONS: 200 x 150 x 80 mm / 7.9 ″ x 5.9 ″ x 3.1” (length x width x height)
PRODUCT WEIGHT:
Tx: 290 g / 0.64 lbs
Rx: 290 g / 0.64 lbs
PACKAGED WEIGHT: 630 g / 1.39 lbs (Tx and Rx is separately packaged.)
CONSTRUCTION MATERIAL: Metal
COLOUR: White
TECHNICAL DETAILS:
Maximum Video Format Supported: 1920×1080 / 1080P @ 60Hz
Video: HDMI 1.3 with HDCP 1.2
Max transfer rate: 10.2 Gbps
TMDS Signal: 0.5~1.5Vp p
DDC Signal: 5Vp p
Audio: Stereo
IR Passback: 20-60KHz
Max Input and Output cable length: up to 5m (16.4 feet)
Electrostatic Protection: Contact and air discharge level 3 IEC 61000-4-2
Operating Temperature Range: 0-40°C
Operating Humidity Range: < 90 % RH (no condensation)
MTBF (Mean Time Between Failures): > 30,000 hours
Transmitter Power Consumption: Max 5 watts
Receiver Power Consumption: Max 4.5 watts

14
TC-HDMIWM_manual_en.doc
Latency: < 200 ms
Switch time: up to 7s (allowing for EDID handshake each time)
Maximum distance: 30 m (98 feet)
Encryption: 128 bit AES
CHANNELS:
LED Channel –> wifi channel –> freq –> bandwidth
0–>36–>5.180–>ht20
1–>44–>5.220–>ht20
2–>48–>5.240–>ht20
3–>48–>5.240–>ht40
4–>149–>5.745–>ht20
5–>153–>5.765–>ht20
6–>157–>5.785–>ht20
7–>161–>5.805–>ht20
8–>165–>5.825–>ht20
9–>161–>5.805–>ht40
TRANSMITTER CONNECTIVITY:
1 x HDMI socket – gold-plated input
1 x DC power – phoenix connector
1 x 3.5mm Minijack socket – for IR blaster
RECEIVER CONNECTIVITY:
1 x HDMI (type A) output
1 x DC Power – phoenix connector
1 x 3.5mm Minijack socket – for IR receiver
1 x 9-Pin D-Sub Male for RS-232
POWER SUPPLY: 100-240v AC 50/60Hz 5 volt / 2 amp 10 watt. DC tail length: 1.8 m / 5.9 ft
Transformer integrated into plug. Includes interchangeable plugs: UK/EU/US/AU. Transformer
dimensions: 66 x 43 x 32 mm / 2.6″ x 1.7″ x 1.3″
ACCESSORIES INCLUDED:
1 x IR Blaster cable, black, length: 1 m / 3.3 ft
1 x IR Receiver cable, black, length: 1 m / 3.3 ft
1 x Remote control: black
WARRANTY: Lifetime return-to-base
2 years onsite (UK only)
COMPLIANCES: RoHS, WEEE, CE/Tx, CE/Rx, CAC/Tx, CAC/Rx, FCC/Tx, FCC/Rx, RCM-POC, RCM-
SDOC
ORDER PART CODE:
Transmitter: TC-HDMIWMTX [SAP: 4432256]
Receiver: TC-HDMIWMRX [SAP: 4432257]

15
TC-HDMIWM_manual_en.doc
LIFETIME RETURN-TO-BASE WARRANTY
This product comes with a lifetime return to base warranty. If you have a problem you are
required to provide a DETAILED DESCRIPTION of the fault.
Some Vision products are very technical and require troubleshooting all elements of the
installation as it may not be the Vision product at fault. Because of this the manufacturer may
refuse to replace the item if an adequate description is not provided.
•This warranty applies only to the original purchaser and is not transferable.
•This warranty protects you against the following:
oFailure of any components, including the power supply.
oDamage when the product is first removed from its packaging if reported within
24 hours of purchase.
•If the product is DOA (dead on arrival), you have 21 days from purchase date to notify the
national distributor via your AV reseller.
•The original purchaser is responsible for shipment of the product to the Vision’s appointed
service centre.
•The liability of Vision is limited to the cost of replacement of the faulty unit under warranty
except for death or injury (EU85/374/EEC).
•If the product is end of line (EOL) the Vision will provide a credit instead of replacement.
•This warranty does not protect this product against faults caused by abuse, misuse,
incorrect installation, unstable or faulty power input, or modification.
Vision aims to send a replacement item within 5 working days however this may not always be
possible, in which case it will be sent as soon as practicably possible. UK End users and resellers
can request support at http://www.visionaudiovisual.com/support
LEGAL DISCLAIMER: Because we are committed to improving our products, the details above
may change without prior warning. This User Manual is published without warranty and any
improvements or changes to the User Manual necessitated by typographical errors, inaccuracies
of current information, or improvements to programs and/or equipment, may be made at any
time and without notice. Such changes will be incorporated into new editions of the User
Manual.
Table of contents
Popular Matrix Switcher manuals by other brands

Audio Authority
Audio Authority ADX-0808 Installation and operation guide

Gefen
Gefen GTB-HDFST-444 user manual

MuxLab
MuxLab 500470 installation guide

Matrix Switch Corporation
Matrix Switch Corporation MSC-HD88AAS product manual

Albalá Ingenieros, S.A.
Albalá Ingenieros, S.A. IMB2000C01 manual

Extron electronics
Extron electronics MTPX 1616 Setup guide
