INSTRUCTION MANUAL
VSBCC4V8(Colour) VSBMC4V8(Monochrome)
Thank you for choosing this high quality camera, before attempting to connect or operate this product, please
read and follow these instructions
General
These CCD video colour camera employs a 1/3" Sony Super HAD CCD solid-state imaging device, which
provide high reliability. These bullet cameras can be easily installed in both internal and external locations
along with its very low current consumption of 120mA the camera is not only simple to install but achieves an
excellent reliability record.
Features
1. High quality picture.
2. Indoors or out-door use.
3. Long life and high reliability.
SPECIFICATION
VSBMC4V8 VSBCC4V8
Image sensor 1/3”Monochrome CCD 1/3" Colour Super HAD
Number of Pixel 500(H) x 582(V) <CCIR> 500(H) x 582(V) <PAL>
Resolution 420TV lines 380 TV lines
Min. Illumination 0.02Lux F2.0 1.0Lux / F2.0
S/N Ratio More than 50dB More than 46dB
Electronic Shutter 1/50 to 1/100,000 sec.
White Balance N/A Auto white balance
Video Output 1.0Vp-p composite, 75Ω
Standard Board 4V8mm / F2.0
Lens Angle Wide: 89.2°, Tele: 44.2°
Power Source DC12V+ 10%
Current 100mA 120mA
Operating Temp -10°C ~ +50°C
Storage Temp -20°C ~ +60°C
Dimension (mm) 37Ø x 110(H) mm
Box Dims 70(W) x 70(L) x 142(H)
Weight 325g incl. bracket 308g incl. bracket
Weight boxed 378g 361g
Mounting Bracket 40(W) x 75(H)

Major operating controls and functions
1. DC12V Input Terminal: For connected to power supply.
2. Video Output Connector (VIDEO OUT): For connected to video terminal.
3. To remove lens cover turn cover anti clockwise, to adjust the focus loosen the locking ring then turn ∞
←→N before relocking the ring. Loosen the locking screw to adjust the Tel/wide T←→W before relocking
the screw. Ensure that the lens cover is returned to it’s tight position to ensure the integrity of the seal.
Connections
1. Connect to the power cord:
This is to connect camera to a 12V DC regulated power supply. (2.1mm centre positive)
2. Connect to video input:
This is to connect camera to 75Ωvideo terminal CCTV quality 75 Ωcoaxial cable via a BNC connector
Standard Accessories
1. Main Body (1)
2. DC-BNC Connector (1)
3. Instruction Manual (1)
4. Mounting bracket (1) and screws (3)
Vista
1. A regulated DC 12V power supply is recommended for use with this camera for the
best picture and most stable operation. An unregulated power supply can cause
damage to the camera.
2. It is recommended that the camera is used with a monitor that has a CCTV quality 75
ohm video impedance level. If your monitor is switched to high impedance then please
adjust accordingly.
3. Apart from removing lens cover for lens adjust. Do not attempt to disassemble the
camera to gain access to the internal components. Refer servicing to your dealer.
4. Never face the camera towards the sun or any bright or reflective light, which may
cause smear on the picture and possible damage to the CCD.
Norbain House
Eskdale Road
Winnersh Triangle
WOKINGHAM
Berkshire
RG41 5TS
Tel: [phone]
Fax: [phone]
www.vista-cctv.com
