Vitek VT-HD User manual

VITEK
VT-HD/EX2
Compact 1x2 HD-SDI
Reclocking Video
Distribution Amplifier
• Extends 1080P HD-SDI Signals up to an additional
700’ from the camera source or to the DVR for a
total of 1400’ per VT-HD/EX2 (depending on cable
characteristics)
• Up to Four VT-HD/EX2 extenders can be configured
in series for a total of 3600’ from camera to DVR
• Built-In 1x2 output HD-SDI Splitter
• Integrated Reclocker to Maintain Signal Integrity
• Supports 1080P, 1080i, 720P, NTSC, and PAL
Video Signals
• Compact size for easy, discreet installation
• 5VDC Power Supply Included

2
Green LED (Power)
Blue LED (Signal Status)
Power ON
SDI Signal Input
LED ON LED OFF
LED Status
Power OFF
NO SDI Signal Input
VT-HD/EX2 is a repeater for HD-SDI links operating with 75Ωcoax cable. With 1
input & 2 output distributor function to allow two HD-SDI monitors to display one
HD-CCTV camera. It can also be daisy-chained to an additional VT-HD/EX2 repeater
for longer distance applications.
Introduction / Configuration:
Inputs/Outputs / LED’s:
Up to 700’ with high
quality RG6Q
Up to 700’ with
high quality
RG6Q
HD-SDI
Camera
HD-SDI
Camera
HD-SDI
Monitor / DVR
HD-SDI DVR
VT-HD/EX2
VT-HD/EX2
VT-HD/EX2
VT-HD/EX2
Run up to 4
VT-HD/EX2
Extenders in
Series
Up to 700’ with high
quality RG6Q
Up to 700’
with high
quality
RG6Q
Up to 700’ with high
quality RG6Q

2 3
SDI Protocols
Input/Output
Power Supply
Power Consumption
Operation Temp.
Dimensions
Weight
SDI (SMPTE 259M) / HD-SDI (SMPTE 292M) / 3G-SDI
(SMPTE 424M)
BNC x 3 (75Ω)
DC 5V 1A
500 mA (Max)
32º to 130ºF @ >95% RH
1.92” x 5.52” x 1” (48.7 x 140.3 x 25.2mm)
5.65oz (160g)
Specifications
SD resolution (270Mbps: 480i,576i)
HD resolution (1.45Gbps: 720p,1080i,1080p @ 24/25/30 fps)
Full HD resolution (2.97Gbps: 1080p @ 50/60 fps)
1400’ 1400’
700’ 700’
350’ 350’
From Source To DVR
Max distance via high quality Coaxial Cable (Belden 1505A,1694A RG6Q)
SD resolution (270Mbps: 480i,576i)
HD resolution (1.45Gbps: 720p,1080i,1080p @ 24/25/30 fps)
Full HD resolution (2.97Gbps: 1080p @ 50/60 fps)
1000’ 1000’
500’ 500’
260’ 260’
From Source To DVR
Max distance via high quality Coaxial Cable (Belden 1505A RG59)
Working Distance / Recommend Cable:
To transmit an HD signal, the coax cable Bandwidth must over 1.5G. If transmitting
a Full HD signal, the coax cable Bandwidth must over 3G.
We recommend the use of high quality 75ΩCoaxial Cable and BNC connectors,
low quality coaxial cable may cause signal loss and effect transmission distance and
reliability.

VITEK LIMITED PRODUCT WARRANTY
VITEK products carry a three (3) year limited warranty. VITEK war-
rants to the purchaser that products manufactured by VITEK are free
of any rightful claim of infringement or the like, and when used in the
manner intended, will be free of defects in materials and workman-
ship for a period of three (3) years, or as otherwise stated above,
from the date of purchase by the end user. This warranty is nontrans-
ferable and extends only to the original buyer or end user customer
of a VITEK Authorized Reseller.
The product must have been used only for its intended purpose, and
not been subjected to damage by misuse, willful or accidental dam-
age, caused by excessive voltage or lightning.
The product must not have been tampered with in any way or the
guarantee will be considered null and void.
This guarantee does not affect your statutory rights.
Contact your local VITEK Reseller should servicing become neces-
sary.
VITEK makes no warranty or guarantee whatsoever with respect to
products sold or purchased through unauthorized sales channels.
Warranty support is available only if product is purchased through a
VITEK Authorized Reseller.
Version 1.0
June 2014
