Vitek VTC-C770DN User manual

BLACKYELLOWMAGENTACYAN
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VTD-VS48B2 1/4” 4mm-8mm Varifocal Color
Dome Camera w/420 TVL
BLACKYELLOWMAGENTACYAN
VTC-C770DN
700TVL True
Day and Night
(ICR) Camera
• 1/3” Sony High Density EXVIEW CCD
• Sony Effio Digital Signal Processor
• 700TVL High Resolution
• .003Lux (F1.2@50IRE)
• Supports C/CS mount DC drive lenses
• Supports NTSC & PAL Standards
• Adaptive Tone Reproduction
• 2DNR - Two Dimensional Motion Adaptive Noise Reduction
• Motion Detection
• Privacy Mask
• On Screen Display (OSD) Menu
• 24VAC/12DC Dual Voltage
FEATURES
OSD Menu
Day
Night
(Lens not included)
Our most advanced CCD Camera yet, the VTC-C770DN offers superior color reproduction and
the highest resolution available to date in an Analog Surveillance Camera. Featuring the latest
technology in signal processing by use of the Sony Effio DSP along with a 1/3” Sony High
Density Exview CCD, the VTC-C770DN delivers 700TV Lines of resolution with extremely low
noise. Advanced on screen display and True ICR Day/Night function are among the many other
features which place this camera at the best in its class.
2DNR
Supports
NTSC
PAL
Motion
Detection
Privacy

BLACKYELLOWMAGENTACYAN
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VTD-VS48B2 1/4” 4mm-8mm Varifocal Color
Dome Camera w/420 TVL
BLACKYELLOWMAGENTACYAN
VTC-C770DN
700TVL True
Day and Night
(ICR) Camera
Detailed Specifications
Image Device
Image Processor
Effective Pixels
Scan System
Scan Frequency
Synchronization
H. Resolution
Sensitivity
S/N Ratio
Electronic Iris
White Balance
Motion Detection
Privacy Mask
Adaptive Tone Reproduction
OSD Language
Day & Night
Lens Mount
Video Output
Operating Power
Operating Condition
Dimensions (W X H X L)
1/3” Sony High Density EXVIEW CCD
Sony Effio Digital Signal Processor
976(H) x 494(V) 976(H) x 582(V)
2:1 Interlace
59.94Hz(V), 15.734Khz(H) 50Hz(V), 15.625Khz(H)
Internal
700TVL
0.003Lux (F1.2@50IRE)
More than 50dB with AGC OFF at 50IRE
1/60 ~ 1/100,000sec 1/50 ~ 1/100,000sec
1,800 ~ 10,500’K Automatic Tracking
YES (24x16 BLOCK ALARM AREA)
8 mask
[On or Off / Luminance - Low, Middle, High & Contrast - Low, Midlow, Middle, Midhigh, High]
EN, FR, DE, ES, POR, SC, RUS, JP
True Day and Night by ICR
C/CS (C-mount ring - optional)
VBS 1 Vpp +/- 10%, 75ohm
24VAC/12VDC
-4’F ~ 122’F / -20’C ~ 50’C, 85% RH. Max. Non-condensing
65mm X 55mm X 126mm (2.6in X 2.2in X 4.9in) About 400g / .9lb (Net)
NTSC PAL
OSD MenuPrivacy Supports
NTSC
PAL
Day
Night
Motion
Detection
2DNR
