Vivid CAMERA LINK CLR-101B User manual

CLR-101B CAMERA LINKTM REPEATER
User’s Manual
Document # 200608, Rev 1.0, 9/1/2006
Vivid Engineering
418 Boston Turnpike #104 • Shrewsbury, MA 01545
Phone [phone] • Fax [phone]
www.vividengineering.com • [email protected]m

Table of Contents
1. Introduction 1
1.1. Overview 1
1.2. Features 2
1.3. Functional Description 3
1.4. Typical Applications 4
1.4.1. Standard Base Application 4
1.4.2. 40 Meter Application 5
1.4.3. Medium Application 6
1.5. Specifications 7
2. Interface 8
2.1. Front Panel Connections 8
2.2. Rear Panel Connections 9
2.2.1. Video Connector Signals 10
2.2.2. Cable Shield Grounding 10
3. Mechanical 12
3.1. Dimensions 12
3.2. External Power Supply 13
4. Regulatory Compliance 14
4.1. FCC Compliance Statement 14
4.2. Canadian Compliance Statement 14
5. Revision History 15

1
1. Introduction
1.1. Overview
The CLR-101B Camera LinkTM1Repeater supports applications requiring separation
between camera and frame grabber in excess of the maximum Camera LinkTM cable
length (10 meters).
One Camera LinkTM cable connects the camera to the CLR-101B, and a second cable
connects the CLR-101B to the frame grabber. This solution provides a 20 meter reach
between camera and frame grabber using a pair of standard 10m Camera LinkTM cables.
Up-to three repeaters may be cascaded to support greater distances. CLR-101B
incorporates high-speed 85MHz interfaces and is compatible with any Camera Link
“Base” configuration camera. “Medium” configuration applications are supported using
two repeaters in parallel.
Featuring a sturdy compact enclosure with mounting flange and locking power supply
connector, the CLR-101B is well suited for OEM and industrial applications.
V ivid E ngineering
CLR-101B
CAMERAPOWER
1The Camera LinkTM interface standard enables the interoperability of cameras and frame grabbers,
regardless of vendor. The Automated Imaging Association (AIA) sponsors the Camera LinkTM
program including the oversight Camera Link Committee, the self-certification program, and the
product registry. The Camera LinkTM specification may be downloaded from the AIA website,
found at www.machinevisiononline.org
Camera LinkTM is a trademark of the Automated Imaging Association

2
1.2. Features
•Doubles max distance between camera and frame grabber
•Uses standard Camera LinkTM cables (not included)
•Supports Camera LinkTM “base” configuration
•“Medium” configuration support using two CLR-101B’s in parallel
•High-speed interfaces support camera clock rates up-to 85 MHz
•Up-to three CLR-101B’s may be cascaded, supporting a 40m reach
•Locking power supply connector
•Flow-through connector positioning
•Sturdy, compact aluminum enclosure w/ mounting flange
•3-year warrantee
•Cost-effective solution
•Well suited for industrial and OEM applications

3
1.3. Functional Description
A block diagram of the CLR-101B is provided in Figure 1-1. The CLR-101B regenerates
the “base” configuration signal set defined in the Camera Link Specification. The
regenerated signals may then be transmitted an additional distance up-to 10 meters over
standard Camera LinkTM cables.
The CLR-101B incorporates the connectors, signals, pinouts, and chipset in compliance
with the Camera LinkTM specification. The CLR-101B regenerates all the “base”
configuration signals, consisting of video data, camera control, and serial communications.
.
Channel
Link
Receiver
(85 MHz)
Channel
Link
Transmitter
(85 MHz)
LVDS
Receiver
LVDS
Transmitter
LVDS Rcvr
To Camera Link
TM
Camera
Video
Data
Camera
Control
Serial
Comm
Link LVDS Xmtr
LVDS Xmtr
LVDS Rcvr
Video
Data
Camera
Control
Serial
Comm
Link
To Camera Link
TM
Frame Grabber
CLR-101B Camera Link
TM
Repeater
Figure 1-1: CLR-101B Block Diagram
The CLR-101B incorporates high-speed (85MHz) interfaces and is compatible with any
“base” configuration camera. “Medium” configuration applications are supported using a
pair of CLR-101B’s in parallel. The CLR-101B does not support the Camera Link “full”
configuration.
The CLR-101B is powered by an external wall plug-in power supply (optional). A
locking power supply connector reduces the risk of an accidental disconnect.

4
1.4. Typical Applications
1.4.1. Standard Base Application
A typical CLR-101B application is shown in Figure 1-2. A Camera LinkTM “base”
configuration camera is connected to the CLR-101B via a standard 10m Camera
LinkTM cable. A second 10m Camera LinkTM cable is then connected from the CLR-
101B to a Camera LinkTM frame grabber. This provides a 20 meter reach between
camera and frame grabber
Vivid Engineering
CLR-101B
CAMERAPOWER
Camera Link
TM
Camera
Camera Link
TM
Frame Grabber
CLR-101B
Camera Link
TM
Repeater
Standard 10m
Camera Link
TM
Cables
20 Meter Reach
Figure 1-2: CLR-101B Standard Application

5
1.4.2. 40 Meter Application
Figure 1-3 shows an application in which multiple CLR-101Bs and standard cables
are cascaded to provide a 40 meter separation between camera and frame grabber. In
this example, a 40 meter reach is achieved using three CLR-101Bs and four standard
10m Camera LinkTM cables.
Camera Link
TM
Camera
Camera Link
TM
Frame Grabber
CLR-101B Camera Link
TM
Repeaters (3)
40 Meter Reach
Standard 10m
Camera Link
TM
Cables
V ivid E ngineering
CLR-101B
CAMERAPOWER
V ivid E ngineering
CLR-101B
CAMERAPOWER
V ivid E ngineering
CLR-101B
CAMERAPOWER
Figure 1-3: CLR-101B 40m Application

6
1.4.3. Medium Application
CLR-101B medium application is shown in Figure 1-4. Medium configuration, in
which two cables connect the camera to the frame grabber, is supported using two
CLR-101B’s in parallel. A Camera LinkTM medium configuration camera is
connected to two CLR-101Bs via a pair of standard Camera LinkTM cables. A second
pair of cables is then used to connect the CLR-101Bs to the Camera LinkTM frame
grabber
Camera Link
TM
Camera
(Medium Config)
Camera Link
TM
Frame Grabber
CLR-101B Camera Link
TM
Repeaters (2)
h
20 Meter Reach
Standard 10m
Camera Link
TM
Cables
V ivid E ngineering
CLR-101B
CAMERAPOWER
V ivid E ngineeri ng
CLR-101B
CAMERAPOWER
Figure 1-4: CLR-101B “Medium” Application

7
1.5. Specifications
Table 1-1: CLR-101B Specifications
Feature Specification
Video Interfaces Camera Link Spec “base” configuration
Video Connectors 26-pin MDR type
Frequency Range 20 - 85 MHz
Chipset National Semi. DS90CR287 / DS90CR288A
Power Supply Optional US/Europe Transformer w/ Outlet Plug Set
Power Jack Circular locking, Switchcraft p/n TRASM3MX
Power Plug Circular locking, Switchcraft p/n TA3FLX
Power Requirements 5-7 VDC, 150 mA (typical)
Cabinet Dimensions 3.28” (L) x 1.14” (H) x 4.87” (D), including mounting flange
Weight 7 oz
Operating Temperature Range 0 to 50° C
Storage Temperature Range -25 to 75° C
Relative Humidity 0 to 90%, non-condensing

8
2. Interface
2.1. Front Panel Connections
The CLR-101B Camera LinkTM Repeater front panel is shown in Figure 2-1. The front
panel contains a 26-pin MDR video connector for connecting to the camera and an LED
power indicator. The MDR-26 connector is a 3M device as specified in the Camera Link
Spec. Figure 2-2 identifies the MDR-26 pin positions.
V ivid E ngineering
CLR-101B
CAMERAPOWER
Figure 2-1: CLR-101B Front Panel
pin 1pin 13
pin 14pin 26
Figure 2-2: MDR-26 Connector Pin Positions

9
2.2. Rear Panel Connections
The CLR-101B Camera LinkTM Repeater rear panel is shown in Figure 2-3. The rear
panel contains a 26-pin MDR video connectors for connecting to the frame grabber and a
DC power jack. The MDR-26 connector is a 3M device as specified in the Camera Link
Spec.
The DC power jack is a circular locking type, Switchcraft p/n TRASM3MX. The DC
power jack accepts 5 to7 volts DC. Power jack pin assignments are shown in Figure 2-4.
The mating DC power plug is Switchcraft p/n TA3FLX.
Camera Link Repeater
5-7 VDCFRAME GRABBER
Figure 2-3: CLR-101B Rear Panel
pin 1, + 5-7 vdc
pin 2, ground
pin 3, unused
Figure 2-4: Power Jack Pins

10
2.2.1. Video Connector Signals
The MDR-26 video connector signal assignments comply with the Camera LinkTM
“base” configuration. The camera connector signal assignments correspond to the
frame grabber interface defined in the Camera Link Specification. Conversely, the
frame grabber connector assignments are as defined for the camera interface in the
Camera Link Specification. This arrangement provides compatibility with standard
Camera LinkTM cables.
Table 2-1 identifies the signal assignments for the MDR-26 video connectors.
2.2.2. Cable Shield Grounding
Camera and frame grabber cable “outer” shields are connected to the CLR-101B
aluminum case. Case and endplate contacting surfaces are unpainted, providing a
Faraday cage to shield internal circuitry. The case is isolated from the CLR-101B
circuitry and the cable “inner” shields, avoiding possible safety concerns.
The frame grabber cable “inner” shield connects to circuit digital ground, maintaining
signal reference levels between the CLR-101B and the frame grabber.

11
Table 2-1: MDR-26 Connector Assignments
Camera Link Signal
Name
Camera
Connector
Pin #
(frame grabber
pinout)
Frame Grabber
Connector
Pin #
(camera pinout)
Signal Direction
Inner shield 1 1 N/A
Inner shield 14 14 N/A
X0- 25 2 CAM →FG
X0+ 12 15 CAM →FG
X1- 24 3 CAM →FG
X1+ 11 16 CAM →FG
X2- 23 4 CAM →FG
X2+ 10 17 CAM →FG
Xclk- 22 5 CAM →FG
Xclk+ 9 18 CAM →FG
X3- 21 6 CAM →FG
X3+ 8 19 CAM →FG
SerTC+ 20 7 FG →CAM
SerTC- 7 20 FG →CAM
SerTFG- 19 8 CAM →FG
SerTFG+ 6 21 CAM →FG
CC1- 18 9 FG →CAM
CC1+ 5 22 FG →CAM
CC2+ 17 10 FG →CAM
CC2- 4 23 FG →CAM
CC3- 16 11 FG →CAM
CC3+ 3 24 FG →CAM
CC4+ 15 12 FG →CAM
CC4- 2 25 FG →CAM
Inner shield 13 13 N/A
Inner shield 26 26 N/A
“FG” = Frame Grabber
“CAM” = Camera

12
3. Mechanical
3.1. Dimensions
The CLR-101B Camera LinkTM Repeater cabinet dimensions are shown in Figure 3-1.
The CLR-101B is housed in a sturdy aluminum enclosure. The body is extruded
aluminum, with detachable front and rear endplates. The enclosure incorporates a
mounting flange. The flange contains four predrilled holes (0.15” diameter) for
convenient equipment mounting. A mounting hole template drawing is provided in Figure
3-2.
3.28"
1.14"
4.87" (including mounting flange)
V ivid E ngineering
CLR-101B
CAMERAPOWER
Figure 3-1: CLR-101B Cabinet Dimensions

13
4.87"
3.28"
(Front )
(Rear)
2.69"
4.43"
Mounting Holes (4): 0.15" dia
Figure 3-2: Mounting Hole Template
3.2. External Power Supply
The CLR-101B is powered by 5-7 VDC. The circular power jack is a locking type to
prevent accidental disconnection. The mating power plug is Switchcraft p/n TA3FLX.
Power jack/plug pin assignments are specified in Section 2.2.
The optional multi-nation wall-mount power supply handles a wide power range (90-264
VAC, 47-63 Hz) and comes with a set of outlet plugs suitable for most countries (US,
Europe, UK, etc).
The CLR-101B is protected by an internal resettable fuse.

14
4. Regulatory Compliance
4.1. FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide a
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his/her own expense.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
4.2. Canadian Compliance Statement
This digital apparatus does not exceed the Class A limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian Department
of Communications.

15
5. Revision History
Table 5-1: CLR-101B User’s Manual Revision History
Document ID # Date Changes
200608-1.0 9/1/2006 Initial release of manual
