Mounting Instructions
Easylon®Repeater
(Order Code: P.R 10003)
WARNING NOTES
•Installation should only performed by qualified and
technical experienced personnel. The device must be
installed in compliance with the relevant DIN/VDE
regulations or the relevant national standards.
•The connection to the supply voltage must be per-
formed in accordance with VDE 0100 and VDE
0160.
•Trouble-free and safe operation of the unit is de-
pendent on proper transport and storage.
INSTALLATION
•The Easylon Repeater can be snapped onto DIN rails
(DIN EN 50022-35).
•The Easylon Repeater is only protected by a simple
non-shielded plastic housing. It should not be placed
close to strongly influencing devices.
•Ensure that all wires to be connected are powerless!
•Connect the bus wires to the corresponding LONA+,
LONA-, LONB+ and LONB- connectors.
•The Easylon Repeater does not include a bus termi-
nation. For trouble free operation of the Easylon Re-
peater both segments of the LONWORKS network
must be properly terminated.
•Connect the 24 VAC or 24 VDC power supply. The
Easylon Repeater has a simple filter at the power
input. Therefore it should not be supplied from a
strongly disturbed source.
•Never connect ground to the bus shield and to the
supply voltage (e.g. 0 VDC)
PRODUCT DESCRIPTION
The Easylon Repeater is a signal amplifier in the
LONWORKS network. It increases the maximum bus
length and increases the permissible number of net-
work nodes. It is completely transparent to the net-
work.
TECHNICAL SPECIFICATIONS
Power Supply DC 12-28 V DC
AC 24 V AC +/-20%
Power consumption < 1VA
TemperatureOperating 0 - +60 °C
at free convection
Storage -20 - +85 °C
Relative humidity Class F (DIN 40 040)
Protection class IP 00
EMV Emission EN55022 A/B,
EN 55011 A/B,
EN50081-1/2
Immunity EN50022-2
Housing Dimensions 96*45*38 [mm]
Mounting DIN rail
(EN50022-35*7,5) or
(EN50022-35*15)
Connectors Screw-clamp
0.5-2.5 mm²

Manufacturer: Gesytec GmbH, Pascalstr. 6, 52076 Aachen, Germany
Repeater/
Doku/MontAnl-LRP-E, V01.00 02/99, D.BZ000046
DIMENSIONAL DRAWING
45 mm38mm
96 mm
CONNECTION DIAGRAM
LON A +
LON A - LON B +
LON B -
Shield
AC/DC +
LON B +
LON A -
LON B -
LON A +
Shield
AC/DC -
Side A Side B
Bus connectors exist twice for every bus side.
CONNECTOR SPECIFICATION
Voltage supply
Clamp Specification
AC/DC+ AC: 24 V / DC: 12-28 V
AC/DC- AC: 24 V / DC: 0 V
LON Bus
Clamp Specification
LON A+ LON bus, side A
LON A- LON bus, side A
LON B+ LON bus, side B
LON B- LON bus, side B
Shield Bus shield (optional)
LON B+
LON B-
LON B-
LON B+
LON B
Shield
LON B
LON A+
LON A-
LON A-
LON A+
LON A
Shield
LON A
AC/DC+
AC/DC-
24 VDC / 24VAC
0 VDC / 24VAC
Repeater
Electronics
