IFM SmartLine AC3226 User manual

Operating instructions
AS-i SmartLine Repeater
AC3226
80272532/00 05/2018
UK

2
Contents
1 Preliminary note���������������������������������������������������������������������������������������������������3
2 Safety instructions �����������������������������������������������������������������������������������������������3
2�1 Symbols used ������������������������������������������������������������������������������������������������3
3 Functions and features ����������������������������������������������������������������������������������������4
4 Operating and display elements ��������������������������������������������������������������������������4
5 Electrical connection��������������������������������������������������������������������������������������������5
5�1 Terminal connection���������������������������������������������������������������������������������������5
6 Operation / LEDs �������������������������������������������������������������������������������������������������5
7 Installation������������������������������������������������������������������������������������������������������������6
7�1 Installation of the device ��������������������������������������������������������������������������������6
7�2 Removal of the device �����������������������������������������������������������������������������������6
8 Maintenance, repair, disposal������������������������������������������������������������������������������7
8�1 Servicing��������������������������������������������������������������������������������������������������������7
8�2 Cleaning of the housing surface ��������������������������������������������������������������������7
8�3 Disposal���������������������������������������������������������������������������������������������������������7

3
UK
1 Preliminary note
Technical data, approvals, accessories and further information at
www�ifm�com�
2 Safety instructions
• Read this document before setting up the product and keep it during the entire
service life�
• The product must be suitable for the corresponding applications and
environmental conditions without any restrictions�
• Only use the product for its intended purpose (→ Functions and features).
• If the operating instructions or the technical data are not adhered to, personal
injury and/or damage to property may occur�
• The manufacturer assumes no liability or warranty for any consequences
caused by tampering with the product or incorrect use by the operator�
• Installation, electrical connection, set-up, operation and maintenance of the
product must be carried out by qualified personnel authorised by the machine
operator�
• The plant operator is responsible for the safety of the plant in which the device
is installed�
• If the device is not used as intended by the manufacturer, the protection
supported by the device may be impaired�
• Protect units and cables against damage�
2.1 Symbols used
►Instructions
→Cross-reference
Important note
Non-compliance may result in malfunction or interference�
Information
Supplementary note�

4
3 Functions and features
The AS-i repeater is used to extend the cable length of an AS-i network by another
100 m� The incoming data of the AS-i line 1 is processed and transmitted to the
AS-i line 2� The data of the AS-i line 2 is also processed and transmitted to the
AS-i line 1�
• Electrical separation of the incoming and outgoing AS-i network
• Additional AS-i power supply required
• Connection of the AS-i lines via Combicon connectors (accessories)
4 Operating and display elements
1
LED
2
3
1: Connector with cage clamps
2: Panel for labelling
3: DIN rail adapter

5
UK
5 Electrical connection
►Connect the incoming AS-i line 1 to the terminals A+ and A- and the outgoing
AS-i line 2 to the terminals A+ and A-�
An additional AS-i power supply is required for the outgoing AS-i line 2�
Incoming and outgoing AS-i lines must not be connected to each other,
otherwise the electrical separation of the repeater is eliminated�
In case of AS-i lines longer than 100 m, the AS-i bus can be terminated� For
this purpose, connect T1 and T2 using the supplied link�
5.1 Terminal connection
A2-A2+ A2-A2+
A1+A1- A1+A1-
T1 T2
A2-: AS-i - line 2
A2+:AS-i + line 2
A2-: AS-i - line 2
A2+:AS-i + line 2
A1+:AS-i + line 1
A1-: AS-i - line 1
A1+:AS-i + line 1
A1-: AS-i - line 1
T1, T2 termination
6 Operation / LEDs
LED PWR 1 green: AS-i voltage 1 OK
LED TERM yellow: Termination active
LED PWR 2 green: AS-i voltage 2 OK

6
7 Installation
7.1 Installation of the device
►Install the device on a 35 mm DIN rail�
►Leave enough space between the unit and the top and bottom of the control
cabinet to enable air circulation and to avoid excessive heating�
►Take into account the internal heating of all devices when mounting several
devices side by side and observe the environmental conditions for every
device�
7.2 Removal of the device

7
UK
8 Maintenance, repair, disposal
8.1 Servicing
The device is maintenance-free�
8.2 Cleaning of the housing surface
►Disconnect the device�
►Clean the device from dirt using a soft, chemically untreated and dry cloth�
Micro-fibre cloths without chemical additives are recommended�
8.3 Disposal
►Dispose of the device in accordance with the national environmental
regulations�
