Vivitar DVR 620V3 User manual

DVR 620v3 Digital Video Camera
User Manual
© 2009-2011 Sakar International, Inc. All rights reserved.
Windows and the Windows logo are registered trademarks of Microsoft Corporation.
All other trademarks are the property of their respective companies.

1
Contents
Introduction .................................................................................................................................. 2
What Your Camera Includes......................................................................................................... 2
Parts of the Camera..................................................................................................................... 3
Initial Camera Setup..................................................................................................................... 4
Main Camera Modes.................................................................................................................... 7
Camera Technical Specifications.................................................................................................. 8
Computer System Requirements –Windows............................................................................... 9
Computer System Requirements –Macintosh............................................................................. 9
Powering ON/OFF Your Digital Video Camera........................................................................... 10
Changing Camera Mode.............................................................................................................11
Navigating the Menus................................................................................................................. 12
Video Capture Mode .................................................................................................................. 13
Video Playback Mode................................................................................................................. 17
Photo Capture Mode.................................................................................................................. 21
Photo Playback Mode ................................................................................................................ 24
Connecting the Digital Video Camera to a TV............................................................................ 28
Installing the Software................................................................................................................ 29
Connecting the Camera to the Computer................................................................................... 30
Getting Photos and Videos from your Camera to Your Computer .............................................. 31
Get started!................................................................................................................................. 32
Transferring Images from my Camera to my Computer Manually.............................................. 33
Camera Maintenance................................................................................................................. 34
Sakar Warranty Card.................................................................................................................. 34
Technical Support....................................................................................................................... 35
Troubleshooting.......................................................................................................................... 35

2
Introduction
Thank you for purchasing this camera. Everything you need to take quality digital photos and
videos is included with your camera.
Vivitar makes capturing those special moments as easy as possible.
Note: Your camera needs an SD Memory card (up to 16GB) for normal use.
SD Memory cards are not included and need to be purchased separately.
Please read this manual carefully first in order to get the most out of your digital video camera.
What Your Camera Includes
1. Digital Video Camera
2. AV Cable
3. Vivitar Experience Image Manager
software Installation CD
4. Wrist Strap
5. Built-in USB Connector
(not shown)
Note: SD memory card and batteries not included.

3
Parts of the Camera
1. Power Button
12. USB Connector
2. Delete Button
13. TV Out Port
3. MENU Button
14. Wrist Strap Connector
4. MODE Button
15. Tripod Socket
5. Shutter/OK Button
16. USB ejector
6. Up/Zoom In/Vol +
17. LED Light
7. Down/Zoom Out/Vol -
18. Lens
8. Left
19. Speaker
9. Right
20. Microphone
10. LCD Screen
21. Battery Compartment
11. SD Card Slot

4
Initial Camera Setup
Installing the Batteries
Installing the Memory Card
Turning On the Camera
Using the Camera
Insert SD Memory card (up to
16GB) before use.

5
When powering the camera ON for the first time the camera will take you through the initial
camera setup.
Powering the Digital Video Camera ON
1) Batteries
Make sure the batteries have been inserted properly into your digital video camera.
Slide the battery cover on the back of the camera in a downward direction to open the cover.
Insert 2 x AA (1.5v) batteries (not included) with the correct polarity, according to the polarity
illustrated inside the battery compartment.
Note:
Alkaline batteries are recommended.
Remove the batteries from the camera when not in use for an extended period.
Do not mix alkaline and non-alkaline batteries.
Some camera features (Flash) will not work if the battery power level is low.
When the battery power is low the battery icon turns red and the camera will
automatically turn off a few seconds later.
The energy status of the power is displayed on LCD as shown below:
Full battery power Medium battery power Low battery power
2) SD Memory Card
Make sure an SD card has been inserted into your digital video camera.
(SD Memory card not included.)
To properly insert the SD Card:
Push the SD card into the slot in the direction shown on the camera (see SD icon by the SD
card slot). Push the SD card until you hear a slight clicking sound. This indicates the SD
card has been inserted correctly.
Note:
After the camera is powered on, an SD icon will appear on the LCD display. If you do not
see the SD icon on the display, please check if the card was inserted properly.
Make sure the SD card is not locked (check the lock switch on the side of the SD card). If the
SD card is locked this will prevent the camera from saving captured photos to the SD
card.

6
3) Power On
Press the POWER button to turn on the camera.
Setting the Camera Language
1) You will first be prompted to select a language for the camera. The Language selection
menu will appear. Select the language of your choice and press the Shutter/OK button to
confirm the selection.
2) After selecting a language, you will be asked if you would like to continue with the initial
camera setup. A message will appear: “Continue with Camera Setup?” Select “Yes” to
continue or “No” to exit the setup.
Note: If you select “No” and decide to leave the camera setup, the camera will be set to its default
settings. These settings can be adjusted at any time manually through the menus in the camera.

7
Main Camera Modes
Your digital video camera has different modes for the various camera functions.
You can switch modes by pressing the MODE button on your digital video camera after the
camera has been powered ON.
Video Capture Mode
Use this mode to capture videos with your digital video camera.
This is the default mode when the camera is powered ON.
To take a video, aim your camera as desired and press the Shutter button to start the
record. A red record indicator will appear on the LCD screen while record is in progress. To
stop the record, press the Shutter button again. The video will be automatically saved to
your camera‟s memory card.
To access the various menus for the Video Capture mode, press the MENU button while in
the Video Capture mode.
Photo Capture Mode
Use this mode to capture pictures with your camera.
After turning on your camera, press the MODE button once to open the Photo Capture
mode.
To take a picture, aim your camera as desired and press the Shutter button.
The picture will be automatically saved to your camera‟s memory card.
To access the various menus for the Photo Capture mode, press the MENU button while in
the Photo Capture mode.
Playback Mode (Photos & Videos)
Use this mode to view and manage the photos and videos on your camera.
After turning on your camera, press the MODE button twice to open the Playback mode for
photos and videos. You can scroll through the photos and videos that you‟ve previously
taken to view and delete them as desired.
To access the various menus for the Playback mode for photos and videos, press the
MENU button while in the Playback mode.

8
Camera Technical Specifications
Image Sensor
CMOS Sensor
Image Resolution
(5M) 2592x1944 pixels, (3M) 2048x1536 pixels
Video Resolution
1280x720 (HD 30 fps), 640X480pixels (VGA 30fps),
320X240pixels (QVGA 30 fps)
File Format
JPEG/AVI
External Memory
SD Card (up to 16GB) –SD Card not included
LCD Display
1.8 Inch TFT ; the LCD screen opens up 180 degree
Lens
f=6.5mm F3.1
Zoom
4X Digital Zoom
Scene
Auto
Image Quality
Normal
White Balance
Auto
Color Effect
Standard
Light Exposure
Auto
ISO
Auto
Frequency
60 Hz
Auto Power Off
3 minutes
Metering
Center
Language
English, French
Microphone
Yes
Speaker
Yes
Interface
USB 2.0 (HS)
System Requirements
Window XP SP3 / Vista SP1/ Windows 7
Mac OS X v10.5.x or higher
Battery
2 x AA Alkaline batteries
Working Temperature
0~40 C

9
Computer System Requirements –Windows
To be able to download photos and videos to your PC, you will need the following minimum
configuration:
Microsoft® Windows XP with Service Pack 3, Windows Vista with Service Pack 1 orWindows 7
Pentium® 4 processor (or above)
512 MB of RAM, with 250 MB of free hard disk space
16-bit Color monitor, 1024 X 768 recommended screen resolution
CD-ROM Drive
QuickTime® 6 or higher
Microsoft® Internet Explorer 7 or higher
Windows Media Player 10 or higher
DirectX 9 or higher
Internet connection required
Computer System Requirements –Macintosh
To be able to download photos and videos to your Macintosh, you will need the following
minimum configuration:
Intel processor running Mac OS X v10.5.x or later
256 MB RAM, 250 MB free hard disk space
Display: 1024 x 768 or higher-resolution monitor
QuickTime® 6 or higher
Internet connection required

10
Powering ON/OFF Your Digital Video Camera
Make sure the batteries have been inserted properly into your digital video camera.
If your camera comes with a rechargeable lithium battery, make sure it is fully charged before
the first use.
Make sure an SD card has been inserted into your camera.
(SD card up to 16GB - SD Card not included)
Powering the camera ON
Press the Power button to turn your camera ON.
The camera will be in Video Capture mode to start.
Powering the camera OFF
While the camera is on, you can press the Power button again at any point to turn your
camera OFF. You will see a “Goodbye” splash screen and then the camera will power off
completely.
Note: When there is insufficient battery power, a “Low Battery”message will appear on the LCD
screen. The digital video camera will automatically power off a few moments later.
Auto Power Saving
Your digital video camera has an Auto Power Off feature that will automatically turn off the
camera if it has not been in use after 3 minutes.

11
Changing Camera Mode
Your camera has three main modes:
1) Video Capture Mode - Use this mode to capture videos with your camera.
2) Photo Capture Mode - Use this mode to capture photos with your camera.
3) Playback Mode (for photos and videos) - Use this mode to view the photos and videos
you have already taken with your camera.
When the camera is first powered ON, the Video Capture Mode will be active. The icons that
appear on the LCD screen are the best default settings so that you can begin to capture and
enjoy clear quality videos and photos.
To change the active camera mode, make sure the camera is powered ON and press the MODE
button.
When in Video Capture Mode, this icon will display on the top-left corner of the LCD display
When in Photo Capture Mode, this icon will display on the top-left corner of the LCD display
When in Playback Mode, this icon will display on the top-left corner of the LCD display

12
Navigating the Menus
Each camera mode has a set of menus specific to that mode.
1) Press the MENU button to open the menus for the current mode.
2) Press the LEFT or RIGHT direction control buttons to scroll between the various menus for
the current mode.
3) Press the UP or DOWN direction control buttons to highlight the desired menu selection.
4) Press the Shutter/OK button to confirm and select the highlighted menu option.
5) If the selection can be remembered by the camera, a selection icon will appear to the
right of the selected menu option. Changes made to these options will remain as is until you
decide to change them again at a later time.
6) Some menu options are single-use functions that are not remembered by the camera and
do not display this icon when selected.
7) At any time you can press the MODE button to exit the menus and return to the previous
screen.

13
Video Capture Mode
The Video Capture Mode allows you to capture videos with your digital video camera. When the
camera is first powered ON, the camera will display by default.
Taking a Video
1) While in Video Capture Mode use the LCD display to direct the camera at the scene you
would like to capture.
2) Click the UP - Zoom In and Down - Zoom Out buttons to better set the camera display if
desired.
3) Press the Shutter button to start the video capture.
4) The elapsed time will begin to appear on the top right corner of the LCD screen and a red
indicator will appear in place of the video icon on the screen.
5) To stop the video record, press the Shutter button again.
6) The video will automatically be saved to the camera‟s SD card.
7) You can also capture your videos using the Flip Screen. The LCD screen opens 180
degrees to allow Self Portrait image capture. When you would like to quickly and easily
include yourself in the video, simply flip the LCD display out and hold out the front of camera
facing towards you. Make sure you can see yourself within the scene on the LCD screen
and click the Shutter button to begin the recording.
It‟s as easy as twist and shoot!
Note: The amount of recording time available for the resolution selected appears on the top
center of LCD screen. The lower the resolution setting the more recording time is available.
However, videos recorded at lower resolution are of less quality than videos recorded at the
higher resolution.
Remember, the amount of time that you can capture videos also depends on the size of the SD
memory card inserted as well as the video resolution selected.

14
Video Capture Mode Quick Function Buttons
Your digital video camera has a four-directional pad and additional buttons that functions as
Quick Function buttons.
Button
Function
LEFT
-
UP
Zooms in
RIGHT
-
DOWN
Zooms out
Other
Shutter/OK
Starts and stops your video capture
Delete
Allows you to delete last video taken by opening the „Delete‟ options
MENU
Opens the Video Menu options
Note: To navigate through the Menus, use the Left, Up, Right, and Down
directions control buttons.
MODE
Toggles between the Video Capture Mode, Photo Capture Mode, and
Playback Mode
Exits the menu screen

15
Deleting Images with the Delete Button
You can delete videos from your digital video camera by pressing the Delete button.
You can choose to either delete the selected video or to delete all images.
Delete This Video:
1) Select the image you wish to delete.
2) Press the Delete button until the „Delete‟ menu appears.
3) Press the UP or DOWN direction control buttons to highlight the „Delete this Video‟ option,
and then press the Shutter/OK button confirm and continue.
4) A „Delete This Video‟ confirmation menu appears.
- Highlight „No‟ then press the Shutter/OK button to exit without deleting the selected video.
- Highlight „Yes‟ then press the Shutter/OK button to delete the selected video.
Delete All Images (all videos and photos):
1) Press the Delete button until the „Delete‟ menu appears.
2) Press the UP or DOWN direction control buttons to highlight the „Delete All Images‟ option,
and then press the Shutter/OK button confirm and continue.
3) A „Delete All Files?‟ confirmation menu appears.
- Highlight „No‟ then press the Shutter/OK button to exit without deleting all of your images.
- Highlight „Yes‟ then press the Shutter/OK button to delete all of your captured images.
Caution: Please use this Delete feature with care. Once all the images are deleted they are
permanently removed from your SD memory card. Please make sure that you only use this
feature once you have downloaded and saved all the images you wish to your computer.
Video Capture Mode Menus
The following are the menus that appear in your camera‟s Video Capture Mode:

16
Image Resolution Menu
The Image Resolution menu allows you to choose the desired size of the images taken by your
camera. Keep in mind that images with a larger size will also take up more of your camera‟s
memory.
1) Press the MENU button to open the menus for the current mode.
2) Press the LEFT or RIGHT direction control buttons to scroll and select the Image Resolution
menu.
3) Press the UP or DOWN direction control buttons to scroll through the menu options.
4) Press the Shutter/OK button to select the desired option.
5) A selected option icon will appear on the selected item.
6) Press the LEFT or RIGHT button to select the next menu item.
7) Press the MODE button to exit the menu and return to your previous mode.
8) An icon reflecting your selection will display on the LCD screen.
9) Remember that this setting will be saved by your camera until you manually change the
setting or restore the camera‟s default factory settings.
Language Menu
You can select your camera‟s language setting by selecting the desired language from the
Language menu.
1) Press the MENU button to open the menus for the current mode.
2) Press the LEFT or RIGHT direction control buttons to scroll and select the Language menu.
3) Press the UP or DOWN direction control buttons to scroll through the menu options.
4) Press the Shutter/OK button to select the desired option.
5) A selected option icon will appear on the selected item.
6) Press the LEFT or RIGHT button to select the next menu item.
7) Press the MODE button to exit the menu and return to your previous mode.
8) Remember that this setting will be saved by your camera until you manually change the
setting or restore the camera‟s default factory settings.

17
Video Playback Mode
The Playback mode allows you to review photos and videos that you‟ve already taken with your
digital video camera.
When you first turn on the camera, the camera will be in Video Capture mode by default.
Press the MODE button twice to open the Playback Mode.
The Playback screen appears with the Playback icon appearing on the top left corner of
the screen.
Playing Videos on Your Digital Video Camera
1) Select your Video:
Once in Playback mode, press the LEFT or RIGHT direction buttons to scroll through the
images on your digital video camera‟s memory card until you find the video you would
like to view.
Each captured image (both videos and photos) is displayed on the LCD screen.
Videos appear with an „AVI‟icon on the top left of the LCD screen.
2) Play your selected Video:
Press the Shutter button to START playing the video.
- Press the UP button to increase the volume of the playing video.
- Press the DOWN button decrease the volume of the playing video.
- While the Video is playing all the icons on the top section of the LCD disappear.
- The video playing time is shown on the bottom right.
Press the Shutter button again to STOP the video.

18
Video Playback Mode Quick Function Buttons
Your digital video camera has a four-directional pad and additional buttons that functions as Quick
Function buttons.
Button
Function
LEFT
- Displays the PREVIOUS image
- Scrolls through your Thumbnail images
UP
- Increases Volume (while playing back your video)
- Scrolls through your Thumbnail images
RIGHT
- Displays the NEXT image
- Scrolls through your Thumbnail images
DOWN
- Decreases Volume (while playing back your video)
- Opens the Thumbnail display
- Scrolls through your Thumbnail images
Other
Shutter/OK
- Plays the selected video file.
- Stops the selected playing video.
- Opens selected image from the Thumbnail display.
Delete
Allows you to delete last image taken by opening the „Delete‟ options
MENU
Opens the Video Menu options
Note: To navigate through the Menus, use the Left, Up, Right, and Down
directions control buttons.
MODE
Toggles between the Video Capture Mode, Photo Capture Mode, and
Playback Mode
Exits the menu screen

19
Thumbnail View
Easily navigate and select the image you wish to view by using the Thumbnail View.
The images on your camera will be displayed in a 3 X 3 matrix where you can use the direction
buttons to scroll and select images from the thumbnails.
1) Press the DOWN button for the images to appear in Thumbnail View.
2) Use the UP/DOWN/LEFT/RIGHT direction control buttons to navigate the thumbnails and
select the image you wish to view.
Videos appear with a „V‟ icon.
3) Press the Shutter/OK button for the selected image to appear in full screen.
Note: You can identify from the thumbnail the image type:
AVI files have a Vappear on the thumbnail image
JPEG files do not have any icons on the thumbnail image
