VIVO HOME PRO STAND MIXER User manual

PRO STAND MIXER
Instruction Manual
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.

GENERAL SAFETY INSTRUCTIONS
CHILDREN AND FRAIL LNDIVIDUALS
Read the operating instructions carefully before putting the appliancein to operation
and keep the instructions including the warranty, the receipt and, if possible, the box
with the internal packing. If you give this device to other people, please also pass on
the operating instructions.
The appliance is designed exclusively for private use and for the envisaged pur-
pose.This appliance is not t for commercial use. Do not use it outdoors (except if
it is designed to be used outdoors). Keep it away from sources of heat, direct sun-
light, humidity (never dip it into any liquid)and sharp edges. Do not use the appli-
ance with wet hands. If the appliance is humid or wet, unplug it immediately.
When cleaning or putting it away, switch o the appliance and always pull out the
plug from the socket (pull on the plug, not the cable) if the appliance is not being
used and remove the attached accessories.
Do not operate the machine without supervision. lf you should leave the work-
place, always switch the machine o or remove the plug from the socket (pull the
plug itself, not the lead).
Check the appliance and the cable for damage on a regular basis. Do not use the
appliance if it is damaged.Do not try to repair the appliance on your own. Always
contact an authorized technician.If the supply cord is damaged,it must be replaced
by the manufacturer, its service agent or similarly qualied persons in order to
avoid a hazard.
Use only original spare parts.
Pay careful attention to the following "Special Safety Instructions".
-
-
-
-
-
-
ln order to ensure your children's safety, please keep all packaging (plastic bags,
boxes, polystyrene etc.) out of their reach.
Caution: Do not allow small children to play with the foil as there is a danger of
suocation!
When using accessory blender and chopperthe appliance shall not be use by chil-
dren.Keep the appliance and its cord out of reach of children.
When using accessory beater and whisk, the appliance can be used by children
aged from 8 years and above if they have been given supervision or instruction
concerning use of the appliance in a safe way and if they understand the hazards
involved. Cleaning and user maintenance shall not be made by children unless
they are aged from 8 years and above and supervised. Keep the appliance and its
cord out of reach of children aged less than 8 years.
This device is not a toy. Children shall not play with the appliance.
Appliances can be used by persons with reduced physical, sensory or mental capa-
bilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and if they understand
the hazards involved.
-
-
-
-
-
-1-

SPECIAL SAFETY INSTRUCTIONS FOR THIS MACHINE
This is the safety alert symbol.This symbol alerts you to potential haz-
ards that can kill or hurt you and others.All safety messages will follow
the safety alert symbol and either th.a.vord "DANGER" or "WARNING,"
These words mean.
Always disconnect the appliance from the supply if it is left unattended and before
assembling, disassembling or cleaning.
Switch o the appliance and disconnect from supply before changing accessories
or approaching parts that move in use.
Do not use appliance for other than intended purpose.
CAUTION: ln order to avoid a hazard due to inadvertent resetting of the thermal
cut-out, this appliance must not be supplied through an external switching device,
such as a timer, or connected to a circuit that is regularly switched on and o by the
utility.
Only operate this machine under supervision.
Do not interfere with any safety switches.
Do not insert anything into the rotating hooks while the machine is working.
Place the machine on a smooth, at and stable working surface.
Do not insert the mains plug of the machine into the power socket without having
installed all the necessary accessories.
CAUTION: Ensure that the blender is switched o before removing it fromthe
stand.
Regarding operating time and speed setting,refer to page 6-10.
Warning: Potential injury from misuse.
-
-
-
-
-
-
-
-
-
You can be killed or seriously injured if you don't immediately follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce
the chance of injury, and tell you what can happen if the instructions are not
followed.
-
-
-2-

FIG1 FIG2 FIG3
FIG4 FIG5 FIG6
Step 1
Step 2
USING THE MIXING BOWL
ln order to lift the arm, Lift up handle metal ball (2). The arm will now move
upwards.(FIG1)
Place the pot cover into its body.(FIG2)
Place the mixing bowl into its holding device (Step 1) and turn the bowl clockwise
until it locks into place (Step 2).(FIG3)
Mount the required utensil (Dough hook or Beater or Whisk) by inserting the top
into the output shaft, and turn anti-clockwise until it locks intoplace.(FIG4&FIG5)
Now ll in your ingredients.
Do not overll the machine - the maximum quantity of ingredients is 1.5 kg
Lower the arm using the Lift up handle metal ball (2).(FIG6)
lnsert the mains plug into a properly installed AC120V 60Hz safety power socket.
Switch the machine using the speed knob to a speed between 1and 6 (correspond-
ing to the mixture).
For pulse operation (kneading at short intervals), turn the switch to the “PULSE"
position.The switch has to be held in this position according to the desired interval
length.When the switch is released it returns automatically to the "0" position.
After kneading/stirring turn the speed knob(3) back to the "0" positionas soon as
the mixture has formed a ball. Then remove the mains plug.
Lift up handle metal ball (2)downwards and the arm will be raised.
The mixture can now be released with the help of a spatula and removed from the
mixing bowl.
The mixing bowl can now be removed.
Clean the parts as described under"cleaning".
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-3-

-
-
-
-
-
TECHNICAL SPECIFICATIONS
POINTS TO CONSIDER DURING TRANSPORTATION AND HANDLING
WEEE
AC120V, 60Hz, 800W
Economic life: 2 years
Since this appliance is designed with recyclable parts in accordance
with the WEEE Directive, do not dispose it of together with domestic
waste. Please bring it to the nearest waste collection centre to enable
the recycling of the appliance.
Keep the appliance in its original box in order to avoid damage during transporta-
tion and handling.
Keep the appliance in its normal position during transportation.
Do not drop the appliance on the oor and protect it from impacts during trans-
portation.
Damages and breakdowns caused by transportation and handling after the deliv-
ery of the appliance to the customer will be out of the warranty coverage.
This device complies with the AEEE Directive.
-4-

12
3
4
6
910
5
7 8
4
MAIN COMPONENTS AND STANDARD ACCESSORIES
-5-
1- Output shaft
2- Handle metal ball
3- Speed knob
4- Bowl cover
5- Mixing bowl
6-Dough hook
7-Beater
8- Whisk
9- Front cover
10- Release Botton

CLEANING
Adjusting the Levels and Using the Dough Hook for not more than1.5kg of Mixture.
Before cleaning remove the mains lead from the socket.
Never immerse the housing with motor in water.
Do not use any sharp or abrasive detergents.
-
-
-
MIXING BOWL,MIXING EQUIPMENT
The components are not suitable for cleaning in a dishwasher. lf exposed to heat or
caustic cleaners they might become misshapen or discolored.
Components that have come into contact with food can be cleaned in soapy water.
Allow the parts to dry thoroughly before reassembling the device.
Please apply a small quantity of vegetable oil likely to the screens after they have
dried.
-
-
-
-
MOTOR HOUSING
Only a damp rinsing cloth should be used to clean the outside of thehousing.-
-6-
Use Picture Levels Time Maximum Operating Steps
Dough
hook 1-3 3-5
1000g our
and
538g water
1 speed run for 30s, the 2 speed run for
30s, and then the 3 speed run for 2 min
to 4 min to form a cluster.After contin-
uous operation of 10 min please stop
working.
Beater 2-4 3-10
660g our
and
840g water
2 speed run for 20s, the 4 speed run for
more than 2 min 40s.
Whisk 5-6 3-10 3 egg whites
(Minimum) Open 5 or 6 speed to run3 min above.
