Vivotek FE8191 User manual

Quick Installation Guide
360° Surround View • PoE
All specications are subject to change without notice.
Copyright 2015 VIVOTEK INC. All rights reserved.
c
P/N:625028701G Rev.: 1.1
FE8191 Fisheye
Network Camera
English 繁中 日本語 Español Português
簡中 Français Deutsch Italiano Türkçe Polski Русский Česky Svenska
Dansk
Dutch
Indonesia
VIVOTEK Europe
Randstad 22-133, 1316BW Almere, The Netherlands
T:[phone] E:[email protected]

EN - 1
English
Warning Before Installation
Power off the Network Camera as
soon as smoke or unusual odors are
detected.
Do not place the Network Camera on
unsteady surfaces.
Do not insert sharp or tiny objects
into the Network Camera.
Refer to your user's manual for
the operating temperature.
Do not touch the Network Camera
during a lightning storm.
Do not drop the Network Camera.
Package Contents
1
D
r
i
l
l
h
o
l
e
D
r
i
l
l
h
o
l
e
5
1
0
0
0
0
2
1
0
G
FE8191
Alignment Sticker
Screws / Anchors / Cable tie
Quick Installation Guide
Software CD
Power & I/O Cables
(Sold Separately in US & Canada)

EN - 2
Physical Description
2
Inner View
J6
J7
Headers
Contacts
Lens Contacts for microphone
Ethernet 10/100 RJ45 Socket
MicroSD/SDHC/SDXC Card Slot
Reset Button
Status LEDs
Cabling Cutout

EN - 3
English
Outer View
Built-in Microphone
Dome Cover
IMPORTANT:
Record the MAC address under the camera
base before installing the camera.
Hardware Installation
3
Release button
First, open the dome cover by pressing the release button. You may squeeze the opposite edge of
the dome cover if the dome cover does not come off easily. Then, follow the steps below to install the
camera to either a ceiling or a wall.
083236
8181
If you plan to route cables from the side of camera, re-
move the rubber slide cover from the dome cover.
Slide cover

EN - 4
Connect the supplied power & IO cables if your
switch does not support PoE. Connect the white
header connectors to J6 and J7 on the camera.
Power and IO
cables
Connecting Ethernet Cable
& the Power and IO Cable
Connecting Cables
If you need to route cables through the side opening, proceed with the following:
1. Connect the Ethernet and the Power & IO cables. The Ethernet cable is user-supplied.
2. Use the included cable ties to secure the Ethernet and IO cable to the base plate. Insert the cable
ties through the vertical mounting tabs on the side of the plastic cover and on the edge of the
cabling cutout.
3. Arrange the cables neatly to avoid getting in the way when the dome cover is attached.
4. Cut the extra length from the cable tie.
It is recommended to remove the strain relief boot if your Ethernet cable
comes with one.
J6
J7
Ethernet
Power & IO Cable
Strain relief boot
If you route cables through a drill hole on
a wall/ceiling, simply route cables through
the cabling cutout.

EN - 5
English
D
r
i
l
l
h
o
l
e
D
r
i
l
l
h
o
l
e
D
r
i
l
l
h
o
l
e
D
r
i
l
l
h
o
l
e
D
r
i
l
l
h
o
l
e
D
r
i
l
l
h
o
l
e
Ceiling or Wall Mount
12
3
4
1. Attach the supplied alignment sticker for the camera base to the a ceiling or wall.
2. Using the circles on the sticker, drill pilot holes into the ceiling. Then hammer the supplied plastic
anchors into the holes.
3. (Optional) Drill a cable hole on the ceiling/wall, and feed the cables through the hole.
4. Secure the camera base to the ceiling/wall with the supplied screws.
You may also install the camera to a U.S. standard 4 in. junction box.
You can align the camera’s curved slots with the mounting holes on
a junction box. Use diagonal mounting positions on the camera to
match those on a junction box.
NOTE:

EN - 6
Install the plastic dome cover by aligning the snap-
t tabs on the dome cover with the slotted tabs on the
camera base. Install the dome cover by pressing it
evenly to the camera base.
Make sure the dome cover and the base plate are
ush-aligned before pressing down. The dome cover is
secured using a snap-t mechanism.
Attach the Dome Cover
Snap-t tabs
Dome cover

EN - 7
English
1. Connect RJ45 Ethernet cable to a switch.
2. Connect the power cable from the Network Camera to a power outlet.
3. If you have external devices such as sensors and alarms, make the connection from the general
I/O terminal block.
General Connection (without PoE)
Network Deployment
4
POWER C
OLLIS
ION
LINK
RECEIVE
PARTITION
12345
+3V3
DO
D1
GND
1
2
3
General I/O Terminal Block
Power Cord Socket (Black)
Microphone In (Pink)
Audio Out (Green)
+3V3: Power, 3.3V DC
DO: Digital Output
D I: Digital Input
GND: Ground
IMPORTANT:
If DC power is preferred, it should comply with: O/P: 12VDC, 2A min., L.P.S. per IEC 60950-1.

EN - 8
Use a PoE power injector (optional) to connect between the Network Camera and a non-PoE switch.
When using a non-PoE switch
Power over Ethernet (PoE)
The Network Camera is PoE-compliant, allowing transmission of power and data via a single Ether-
net cable. Follow the below illustration to connect the Network Camera to a PoE-enabled switch via
Ethernet cable.
When using a PoE-enabled switch
POWER C
OLLIS
ION
LINK
RECEIVE
PARTITION
12345
PoE Switch (802.3af)
PoE 802.3af Power
Injector (optional)
Non-PoE Switch
NOTE:
1. This equipment is only to be connected to PoE networks without routing to outside plants.
2. For PoE input, use only UL listed I.T.E. with PoE output.

EN - 9
English
1. Install “Installation Wizard 2” from the Software Utility directory on the software CD.
2. The program will conduct an analysis of your network environment. After your network is
analyzed, please click on the “Next” button to continue the program.
3. The program will search for VIVOTEK Video Receivers, Video Servers, and Network Cameras on
the same LAN.
4. After a brief search, the main installer window will pop up. Double-click on the MAC address that
matches the one printed on the camera label or the serial number on the package box label to
open a browser management session with the Network Camera.
Assigning an IP Address
5
1. A browser session with the Network Camera should prompt as shown below.
2. You should be able to see live video from your camera. You may also install the 32-channel record-
ing software from the software CD in a deployment consisting of multiple cameras. For its installa-
tion details, please refer to its related documents.
Ready to Use
6
For further setup, please refer to the user's manual on the software CD.
NOTE:
If you encounter problems with displaying live view or the onscreen plug-in control, you may try to
remove the plug-ins that might have been installed on your computer. Remove the following folder: C:\
Program Files (x86)\Camera Stream Controller\.
