Viz-art automation Smart box 2.0 User manual

Programming the controller set SMART Box 2.0 consisting of:

•IR receiver

•RS232

•Low Voltage Control - TRIGGER 5-30V

•Potential Free Control (Dry Contact Control)

SMART Box 2.0

Device controller

1/4

PROGRAMMING BUTTON

Before turning on the power, press and hold the programming button and then turn on the power

(button still pressed). Count the LED flashes.

3 flashes: the device will receive signals from the IR infrared remote control

6 flashes: the device will receive codes from the RS232 serial port (logical '1' -5V, logical '0' + 5V)

9 flashes: the device will receive codes from the UART serial port (logical '1' + 5V, logical '0' 0V)

CONNECTION DIAGRAM RS232 control/UART:

PIN 5 CONNECT TO GND PIN 2, 3 CONNECT TO DATA

PROGRAMMING RS232 control / UART:

HEXAGONAL CODE:

UP „U” or „0X55” or „55h”

STOP „S” or „0X53” or „53h”

DOWN „D” or „0X44” or „44h”

DECIMAL CODE:

UP „85”

STOP „83”

DOWN „68”

CONNECTION DIAGRAM IR RECEIVER:

SHIELD OF SHIELDING WIRE WHITE WIRE RED WIRE

CONNECT TO GND CONNECT TO DATA CONNECT TO +

SOCKET DB9

2/4

Programming IR infrared remote control code:

After turning the power on, press shortly the programming button once.

The LED diode will light up. It is waiting for the code from the IR remote

control switching on the '1' direction.

After receiving the code, the LED diode will blink fast several times and

light up again.

SMART Box is waiting for the code from the IR remote control to turn off

the directions (code 'STOP').

After receiving the code, the LED diode will blink fast several times and

light up again.

SMART Box is waiting for the code from the IR remote control switching

on the '2' direction. After receiving the code, the LED diode will blink fast

several times and turn off.

This is the end of programming.

CONNECTION DIAGRAM POTENTIAL FREE CONTROL:

GND CONNECT TO A or GND CONNECT TO B

CONNECTION DIAGRAM LOW VOLTAGE CONTROL TRIGGER 5-30V:

MINUS –CONNECT TO GND PLUS + CONNECT TO B 5 ÷ 30 V DC

PROGRAMMING BUTTON

3/4

Producer: VIZ-ART Automation

tel.+48 22/6138899 www.viz-art.eu
