Vizio VBR231 User manual

VIZIO VBR231 User Manual
Version 6/4/2010 1
www.VIZIO.com
Dear VIZIO Customer,
Congratulations on your new VIZIO VBR231 Blu-ray DVD Player with dual-band wireless Internet.
For maximum benefit of your Blu-ray DVD Player, read these instructions before making any
adjustments, and retain them for future reference. We hope you will experience many years of
enjoyment from your new VIZIO Blu-ray DVD Player.
For assistance, please call 877-MYVIZIO (877-698-4946) or e-mail us at www.VIZIO.com.
To purchase or inquire about accessories and installation services for your VIZIO Blu-ray DVD
Player, please visit our website at www.VIZIO.com or call toll free at [phone].
We recommend you register your VIZIO Blu-ray DVD Player at our website www.VIZIO.com.
For peace of mind and to protect your investment beyond the standard warranty, VIZIO offers on-
site extended warranty service plans. These plans give additional coverage during the standard
warranty period. Visit our website or call us to purchase a plan.
Write down the serial number located on the back of your player for easy reference when
obtaining warranty support:
Serial #: _____________________ Purchase Date _____________________
ENERGY STAR and the ENERGY STAR mark are registered U.S. marks.
THE TRADEMARKS SHOWN HEREIN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS; IMAGES USED ARE FOR
ILLUSTRATION PURPOSES ONLY. VIZIO, THE V LOGO, WHERE VISION MEETS VALUE AND OTHER VIZIO TRADEMARKS
ARE THE INTELLECTUAL PROPERTY OF VIZIO INC. PRODUCT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT
NOTICE. © 2010 VIZIO INC. ALL RIGHTS RESERVED.

VIZIO VBR231 User Manual
2
www.VIZIO.com
Important Safety Instructions
Your Blu-ray DVD Player is designed and manufactured to operate within defined design limits,
and misuse may result in electric shock or fire. To prevent your Blu-ray DVD Player from being
damaged, the following instructions should be observed for the installation, use, and maintenance
of your Blu-ray DVD Player. Read the following safety instructions before operating your Blu-ray
DVD Player. Keep these instructions in a safe place for future reference.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use your player near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the accompanying instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other heat-
generating devices (including amplifiers).
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs and convenience
receptacles and the point where they exit from your player.
11. Only use accessories specified by VIZIO.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or sold with
your player. When a cart is used, use caution when moving the cart and player combination to
avoid injury from tip-over.
13. Unplug your player during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when your player has been
damaged in any way, such as when the power-supply cord or plug is damaged, when liquid has
been spilled or objects have fallen into your player, when your player has been exposed to rain or
moisture, or when your player does not operate normally or has been dropped.
15. To reduce the risk of fire or electric shock, do not expose your player to rain or moisture. Your
player should not be exposed to dripping or splashing and no objects filled with liquids, such as
vases, should be placed on your player.
16. The main power plug is the disconnect device and should easy to access. Make sure that the
plug is easy to remove.
17. Do not install your player in a confined space, such as a bookcase, without allowing enough
space for ventilation. Do not cover the ventilation openings with items such as newspaper,
tablecloths, or curtains. Make sure that you allow at least 4 inches (10 cm) of space on all sides
of your player to allow for ventilation.
18. Do not place items with flames, such as candles, on your player.
19. Dispose of batteries according to local hazardous waste regulations.
20. Use your player in mild climates. Excessive heat or cold can damage your player.
21. Use of controls or adjustments other than these specified in this guide may result in hazardous
radiation exposure.

VIZIO VBR231 User Manual
Version 6/4/2010 3
www.VIZIO.com
Table of Contents
Important Safety Instructions..................................................................................................................... 2
TABLE OF CONTENTS ............................................................................................................................... 3
Opening the Package................................................................................................................................ 5
Package Contents ..................................................................................................................................... 5
Blu-ray DVD Player Accessories and Services......................................................................................... 5
Finding a Location for Your Player ............................................................................................................ 6
CHAPTER 1 FEATURES & FORMATS....................................................................................................... 6
Features .................................................................................................................................................... 6
Supported Discs ........................................................................................................................................ 7
Supported file extensions .......................................................................................................................... 7
Region codes............................................................................................................................................. 7
CHAPTER 2 BASIC CONTROLS AND CONNECTIONS............................................................................ 8
Front .......................................................................................................................................................... 8
Rear Panel Connections............................................................................................................................ 9
VIZIO Remote Control............................................................................................................................. 10
Insertion of Batteries in the Remote Control........................................................................................ 10
Remote Control Range ........................................................................................................................ 10
VIZIO Remote Control Precautions ..................................................................................................... 10
Remote Control Buttons....................................................................................................................... 11
CHAPTER 3 USING YOUR PLAYER FOR THE FIRST TIME .................................................................. 13
Connecting to the Internet ....................................................................................................................... 13
Exploring the Home Menu....................................................................................................................... 13
CHAPTER 4 CONNECTING EQUIPMENT ................................................................................................ 14
Which Video Connection Should I Use? ................................................................................................. 14
Which Audio Connection Should I Use? ................................................................................................. 15
Connecting to a TV.................................................................................................................................. 16
Using HDMI (Best) ............................................................................................................................... 16
Using Component Video (Better)......................................................................................................... 17
Using Composite/AV Video (Compatible)............................................................................................ 18
Connecting a USB drive .......................................................................................................................... 19
Connecting to your home network........................................................................................................... 19
Using a wired (Ethernet) connection.................................................................................................... 19
Using a wireless connection with DHCP.............................................................................................. 20
Using a wireless network with WPS (WiFi Protected Setup – Button Method) ................................... 21
CHAPTER 5 USING NETFLIX ................................................................................................................... 22
Activating your player for Netflix.............................................................................................................. 22
Watching a movie with Netflix ................................................................................................................. 22
CHAPTER 6 USING VUDU ........................................................................................................................ 23
Activating your player for Vudu ............................................................................................................... 23
Watching a movie with Vudu ................................................................................................................... 23
CHAPTER 7 USING PANDORA ................................................................................................................ 24
Activating your player for Pandora .......................................................................................................... 24
Listening to music with Pandora.............................................................................................................. 24
CHAPTER 8 PLAYING A DISC ................................................................................................................. 25

VIZIO VBR231 User Manual
4
www.VIZIO.com
CHAPTER 9 ACCESSING BD-LIVETM CONTENT .................................................................................... 26
CHAPTER 10 PLAYING MUSIC FILES..................................................................................................... 27
Home.................................................................................................................................................... 27
Previous folder ..................................................................................................................................... 27
Media Menu ......................................................................................................................................... 27
Play Files ............................................................................................................................................. 27
Browse Pictures ................................................................................................................................... 28
Now Playing ......................................................................................................................................... 28
CHAPTER 11 VIEWING PICTURES.......................................................................................................... 28
Home.................................................................................................................................................... 28
Previous folder ..................................................................................................................................... 28
Media Menu ......................................................................................................................................... 28
Start Slide Show .................................................................................................................................. 28
Browse Music....................................................................................................................................... 29
Now Playing ......................................................................................................................................... 29
CHAPTER 12 ADJUSTING BLU-RAY DVD PLAYER SETTINGS ........................................................... 29
Display Menu........................................................................................................................................... 30
Resolution ............................................................................................................................................ 30
TV Aspect ............................................................................................................................................ 31
Film Mode (1080p24)........................................................................................................................... 31
Audio Menu ............................................................................................................................................. 32
PCM Downsampling ............................................................................................................................ 32
Digital Output ....................................................................................................................................... 32
Dynamic Range Control....................................................................................................................... 33
Language Menu....................................................................................................................................... 33
OSD ..................................................................................................................................................... 33
Menu .................................................................................................................................................... 33
Audio.................................................................................................................................................... 33
Subtitle ................................................................................................................................................. 33
Home Menu ............................................................................................................................................. 33
Parental Menu ......................................................................................................................................... 34
Parental Country .................................................................................................................................. 34
Parental Control ................................................................................................................................... 34
Parental Level ...................................................................................................................................... 34
Parental Password............................................................................................................................... 34
System Menu........................................................................................................................................... 35
Optical Disc AutoPlay .......................................................................................................................... 35
BD-LiveTM Internet Access ................................................................................................................... 35
BD-LiveTM Internet Storage.................................................................................................................. 35
Erase Blu-ray Storage.......................................................................................................................... 35
Screen Saver Duration......................................................................................................................... 35
Update Via Network ............................................................................................................................. 35
Restore Factory Defaults ..................................................................................................................... 36
Network Menu ......................................................................................................................................... 36
Wired (Dynamic) .................................................................................................................................. 37
Wired (Manual) .................................................................................................................................... 37
Wireless (with DHCP) .......................................................................................................................... 38
Wireless with WPS (WiFi Protected Setup – Button Method) ............................................................. 39
Network Test........................................................................................................................................ 39
Info Menu................................................................................................................................................. 39
CHAPTER 13 MAINTENANCE AND TROUBLESHOOTING .................................................................. 40
Maintenance ............................................................................................................................................ 40

VIZIO VBR231 User Manual
Version 6/4/2010 5
www.VIZIO.com
Updating Your Player .............................................................................................................................. 41
Updating your player via USB.............................................................................................................. 41
Updating your player via the Internet................................................................................................... 41
FAQ & Troubleshooting........................................................................................................................... 42
Operation Troubleshooting .................................................................................................................. 43
Audio Troubleshooting......................................................................................................................... 44
Video Troubleshooting......................................................................................................................... 45
BD-Live & USB Troubleshooting ......................................................................................................... 45
Netflix, Pandora, and Vudu Troubleshooting....................................................................................... 46
Internet Connection Troubleshooting................................................................................................... 46
Telephone & Technical Support .............................................................................................................. 47
SPECIFICATIONS ...................................................................................................................................... 48
LEGAL NOTICES ....................................................................................................................................... 49
ONE-YEAR LIMITED WARRANTY ON PARTS AND LABOR ................................................................. 52
INDEX ......................................................................................................................................................... 53
Opening the Package
Your Blu-ray DVD Player and its accompanying accessories are carefully packed in a cardboard carton
that has been designed to protect it from transportation damage. Once you have opened the carton,
check that your player is in good condition and that all of the contents are included.
IMPORTANT: Save the carton and packing material for future shipping.
Package Contents
VIZIO VBR231
VIZIO remote control
AA batteries for the remote control (2)
HDMI cable
Quick Setup Guide
Blu-ray DVD Player Accessories and Services
Additional certified accessories for your player are sold separately:
High Definition Video cables (HDMI or Component)
High Definition Audio cables (HDMI, Coaxial, or Optical)
Extra or replacement remote
VIZIO also offers installation services and extended warranty services for your player.
To purchase or inquire about additional accessories and services for your player, visit our website at
www.VIZIO.com or call us toll free at 877-MYVIZIO (877-698-4946).

VIZIO VBR231 User Manual
6
www.VIZIO.com
Finding a Location for Your Player
Here are some things you should consider when deciding on a proper location for your player:
The power consumption of your player is about 25W (average).
oUse the included power cord.
oWhen an extension cord is required, use one with the correct power rating.
To take full advantage of your player, you will need an Internet connection. Your player has 802.11n
dual-band wireless built-in (which is also compatible with 802.11b and 802.11g wireless networks), so
you can connect your player to the Internet through your wireless home network. Or you can connect
to the Internet by plugging in an Ethernet cable (not included) from your Internet connection to the
Ethernet port on your player. A wired connection may provide a more consistent connection
depending on the conditions in your home environment. See Connecting to your home network on
page 19 for detailed information on setting up your Internet connection.
For proper ventilation, you must allow at least 4 inches (10 cm) between the back of your player and
the wall.
Avoid installing your player in places with high humidity, dust, or smoke so you do not shorten the
service life of the electronic components.
Read this user manual carefully before setting up your player.
VIZIO offers professional installation services including home networking. Contact VIZIO for more
information on these services at 877-MYVIZIO (877-698-4946) or www.VIZIO.com.
Chapter 1 Features & Formats
Features
Movies, music, photos, chat and more all from the Internet.
Full, high-definition video playback at up to 1080p resolution for an amazing viewing experience.
Up-conversion of standard-definition DVDs for enhanced picture quality at up to 1080p via HDMI.
Rich multi-channel surround sound.
802.11n dual-band wireless, operating at both 5GHz and 2.4 GHz.
o5GHz is optimized for HD video streaming.
o2.4GHz supports all types of data.
Easy HDTV connection using a single HDMI cable (included with VBR231).
Multiple outputs for connecting your home theater system or amplifier.
PIP functionality that lets you display primary and secondary video at the same time (if available on
the Blu-ray Disc).
Pop-up menu display without interrupting playback (if available on the Blu-ray Disc).
HDMI 1080p output (Blu-ray Disc only) that provides smooth playback of video with a frame rate of 60
frames per second (TV must be connected with an HDMI cable and be compatible with 1080p 60
frames per second).
Java support that enables you to get the most out of the latest Blu-ray discs. When a BD disc loads,
explore the title menu to enjoy these extra features.

VIZIO VBR231 User Manual
Version 6/4/2010 7
www.VIZIO.com
Supported Discs
Note:
Your player can play CD-Rs, CD-RWs, DVD-RWs,
and DVD-Rs recorded with UDF or ISO9660 format.
Writeable DVDs (DVD-RW, DVD-R) must be
finalized (VR mode only).
Your player supports AVCHD playback on
writeable media (DVD±R, DVD±RW) only.
Supported file extensions
.mp3 (high bit-rate or variable bit-rate .mp3 files
may not play back correctly)
Region codes
Blu-ray Discs and DVDs have region codes to help prevent
illegal distribution of discs. If the disc’s region code does
not match your player’s region code, the disc will not play.
The disc’s region code is displayed on the disc or disc
packaging. You can only play Blu-ray Discs that have a
region code of A and you can only play DVDs that have a
region code of 1 or ALL.
Disc Type Logo
Blu-ray Disc
DVD-video
(DVD-ROM)
DVD-RW
DVD-R
DVD+R
DVD+RW
CD-R
CD-RW
Audio CDs
(CDDA)
MP3/JPEG/Data
CD

VIZIO VBR231 User Manual
8
www.VIZIO.com
Chapter 2 Basic Controls and Connections
Front
The controls on the front of your player are touch-sensitive. Just touch a finger anywhere on the
front panel and the controls will light up.
1. Standby/On ( )—Press to turn your player on or off. When your player is off, power is still
entering your player. To disconnect all power, unplug the power cord.
2. Open/Close ( ) —Press to open or close the disc tray.
Note: Due to the nature of Blu-ray discs, it may take a moment for the disc tray to respond.
3. Disc Tray—Insert a disc with the label side up into this tray.
4. Play/Pause ( )—Press to start or pause playback.
5. Stop ( )—Press to stop playback, and then press to begin playback at the beginning of
the disc.
6. Next ( )—Press to go to the next title, chapter, or track.
7. Previous ( )—Press to go to the previous title, chapter, or track.
8. USB 2.0—Connect a USB flash drive to view multimedia content such as pictures and music
or to view BD-LiveTM Content. Also use this port to perform system updates.
9. Remote Control Sensor—Point the remote control directly at this sensor for the best
response to the remote signal.
10. WiFi Network Indicator—Lights to indicate network status:
a. Orange to indicate the antenna is working.
b. Blue to indicate that data is transferring.

VIZIO VBR231 User Manual
Version 6/4/2010 9
www.VIZIO.com
Rear Panel Connections
1. ETHERNET—Connect an Ethernet cable (not included) to access services such as Netflix
streaming, BD-Live, and software updates. Your player also has 802.11n wireless, so you
can connect your player to the Internet through your wireless home network instead of using
this connector. See Connecting to your home network on page 19 for detailed information on
setting up your Internet connection.
2. HDMI—Connect a digital video and audio device, such as TV, to this all digital connector. No
additional audio connection is needed. Only HDMI is capable of delivering 1080p video and
the highest quality Dolby and DTS soundtracks.
3. COMPONENT (Y/CbPb/CrPr)—Connect a component video device, such as a TV. For
component TVs, you will also need to connect the red and white audio jacks (see #2 above)
to the Analog L/R Audio Out jacks. Component video is limited to 1080i.
4. L/R AUDIO OUT—Connect the audio for the TV you connected to the VIDEO OUT or
COMPONENT jack to these audio jacks. You can connect the audio for a component TV to a
sound system instead of to the TV.
5. COAXIAL DIGITAL AUDIO OUT— If you are not using an HDMI-capable audio receiver,
connect to a sound system that has a coaxial audio jack.
6. WIFI ANTENNA—Sends and receives signals from your wireless home network operating at
both 5GHz and 2.4 GHz. See Connecting to your home network on page 19 for detailed
information on setting up your Internet connection.
7. POWER—Connect this cord into a power outlet.
8. OPTICAL DIGITAL AUDIO OUT—If you are not using an HDMI-capable audio receiver,
connect to a sound system that has an optical audio jack.
9. VIDEO OUT—Connect a standard AV TV. For composite TVs, you will also need to connect
the red and white audio jacks (see #4 above) to the Analog L/R Audio Out jacks.

VIZIO VBR231 User Manual
10
www.VIZIO.com
VIZIO Remote Control
Insertion of Batteries in the Remote Control
1. Remove the battery cover.
2. Insert two AA batteries into the remote control. Make sure that
you match the (+) and (-) symbols on the batteries with the (+)
and (-) symbols inside the battery compartment.
3. Replace the battery cover.
Precautionary Tips for Inserting the Batteries:
Only use the specified AA batteries.
Do not mix new and old batteries. This may result in cracking or
leakage that may cause a fire or lead to personal injury.
Inserting the batteries incorrectly may also result in cracking or
leakage that may cause a fire or lead to personal injury.
Dispose of batteries according to local hazardous waste regulations.
Keep the batteries away from children and pets.
Remote Control Range
The effective range of the remote control is approximately 23 feet (7
meters) from the front of the remote control sensor, 30° to the left
and right, 30° up and down.
Point the remote control at the remote control sensor to transmit the commands.
Do not place any obstacles between the remote control and the remote control sensor.
VIZIO Remote Control Precautions
The remote control should be kept dry and away from heat sources. Avoid humidity.
If your player responds erratically to the remote control or does not respond at all, check the
batteries. If the batteries are low or exhausted, replace them with fresh batteries.
When not using the remote control for a long period of time, remove the batteries.
Do not take the batteries apart, heat them, or throw them into a fire.
Do not subject the remote control to undue physical stress, such as striking or dropping it.
Do not attempt to clean the remote control with a volatile solvent. Wipe it with a clean, damp cloth.
