Vizio SV472XVT User manual

Version 12/10/2009 1
www.VIZIO.com
VIZIO SV472XVT HDTV User Manual
Dear VIZIO Customer,
Congratulations on your new VIZIO SV472XVT HDTV purchase. To get the most out of
your new VIZIO HDTV, please read these instructions before making any adjustments,
and retain them for future reference. We hope you will experience many years of
enjoyment from your new VIZIO VIA Connected High Definition Television.
For assistance, please call 877-MYVIZIO (877-698-4946) or e-mail us
at www.VIZIO.com.
To purchase or inquire about accessories and installation services for your VIZIO HDTV,
please visit our website at www.VIZIO.com or call toll free at [phone].
You will register your VIZIO HDTV when you turn on your HDTV for the first time. You
can also register on our website www.VIZIO.com. It is important to register your
HDTV so you can receive future product updates and support information that will
continually maximize the enjoyment of your HDTV.
For peace of mind and to protect your investment beyond the standard warranty, VIZIO
offers on-site extended warranty service plans. These plans give additional coverage
during the standard warranty period. Visit our website or call us to purchase a plan.
Write down the serial number located on the back of your HDTV for easy reference when
obtaining warranty support:
Serial #: _____________________ Purchase Date _____________________
VIZIO is a registered trademark of VIZIO, Inc. dba V, Inc.
HDMI logo and “High Definition Multimedia Interface” are registered trademarks of HDMI Licensing LLC.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
and are trademarks of SRS Labs, Inc.
TruSurround HD and TruVolume technologies are incorporated under license from SRS Labs, Inc.
This product qualifies for ENERGY STAR in the “factory default (Home Use)” setting and this is the setting in which
power savings will be achieved. Changing the factory default picture setting or enabling other features will increase
power consumption that could exceed the limits necessary to qualify for Energy Star rating.
THE TRADEMARKS SHOWN HEREIN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS; IMAGES USED
ARE FOR ILLUSTRATION PURPOSES ONLY. BRAVO, VIZIO AND THE V LOGO AND WHERE VISION MEETS VALUE AND
OTHER VIZIO TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF VIZIO INC. PRODUCT SPECIFICATIONS ARE
SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION. © 2008 VIZIO INC. ALL RIGHTS RESERVED.

VIZIO SV472XVT HDTV User Manual
Important Safety Instructions
Your HDTV is designed and manufactured to operate within defined design limits, and misuse
may result in electric shock or fire. To prevent your HDTV from being damaged, the following
instructions should be observed for the installation, use, and maintenance of your HDTV. Read
the following safety instructions before operating your HDTV. Keep these instructions in a safe
place for future reference.
•To reduce the risk of electric shock or component damage, switch off the power before
connecting other components to your HDTV.
•Unplug the power cord before cleaning your HDTV. A damp cloth is sufficient for cleaning your
HDTV. Do not use a liquid or a spray cleaner for cleaning your HDTV. Do not use abrasive
cleaners.
•Always use the accessories recommended by the manufacturer to insure compatibility.
•When moving your HDTV from an area of low temperature to an area of high temperature,
condensation may form in the housing. Wait before turning on your HDTV to avoid causing fire,
electric shock, or component damage.
•Use only with the cart, stand, tripod, bracket, or table specified by manufacturer or sold with your
HDTV. When a cart is used, use caution when moving the cart/HDTV combination to avoid injury
from tip-over. Do not place your HDTV on an unstable cart, stand, or table. If your HDTV falls, it
can injure a person and cause serious damage to your HDTV. Use only a cart or stand
recommended by the manufacturer or sold with your HDTV.
•A distance of at least 3 feet should be maintained between your HDTV and any heat source, such
as a radiator, heater, oven, amplifier etc. Do not install your HDTV close to smoke. Operating
your HDTV close to smoke or moisture may cause fire or electric shock.
•Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure
reliable operation of your HDTV and to protect it from overheating, be sure these openings are
not blocked or covered. Do not place your HDTV in a bookcase or cabinet unless proper
ventilation is provided.
•Never push any object into the slots and openings on your HDTV cabinet. Do not place any
objects on the top of your HDTV. Doing so could short circuit parts causing a fire or electric shock.
Never spill liquids on your HDTV.
•Your HDTV should be operated only from the type of power source indicated on the label. If you
are not sure of the type of power supplied to your home, consult your dealer or local power
company.
•Do not apply pressure or throw objects at your HDTV. This may compromise the integrity of the
display. The manufacturer’s warranty does not cover user abuse or improper installations.
•The power cord must be replaced when using different voltage than the voltage specified. For
more information, contact your dealer.
•Your HDTV is equipped with a three-pronged grounded plug (a plug with a third grounding
pin). This plug will fit only into a grounded power outlet. This is a safety feature. If
your outlet does not accommodate the three-pronged, have an electrician install
the correct outlet, or use an adapter to ground your HDTV safely. Do not defeat
the safety purpose of the grounded plug.
•When connected to a power outlet, power is always flowing into your HDTV. To
totally disconnect power, unplug the power cord.
•The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of un-isolated, dangerous
voltage within the inside of your HDTV that may be of
sufficient magnitude to constitute a risk of electric shock to
persons.
•The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and servicing instructions in the literature
accompanying your HDTV.
•Do not overload power strips and extension cords. Overloading can result in fire or electric shock.
2
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
•The wall socket should be installed near your HDTV and easily accessible.
•Only power of the marked voltage can be used for your HDTV. Any other voltage than the
specified voltage may cause fire or electric shock
•Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power
cord during electrical storms.
•Unplug your HDTV during a lightning storm or when it will not be used for long period of time.
This will protect your HDTV from damage due to power surges.
•Do not attempt to repair or service your HDTV yourself. Opening or removing the back cover may
expose you to high voltages, electric shock, and other hazards. If repair is required, contact your
dealer and refer all servicing to qualified service personnel.
•Keep your HDTV away from moisture. Do not expose your HDTV to rain or moisture. If water
penetrates into your HDTV, unplug the power cord and contact your dealer. Continuous use in
this case may result in fire or electric shock.
•Do not use your HDTV if any abnormality occurs. If any smoke or odor becomes apparent, unplug
the power cord and contact your dealer immediately. Do not try to repair your HDTV yourself.
•Avoid using dropped or damaged appliances. If your HDTV is dropped and the housing is
damaged, the internal components may function abnormally. Unplug the power cord immediately
and contact your dealer for repair. Continued use of your HDTV may cause fire or electric shock.
•Do not install your HDTV in an area with heavy dust or high humidity. Operating your HDTV in
environments with heavy dust or high humidity may cause fire or electric shock.
•Follow instructions for moving your HDTV. Ensure that the power cord and any other cables are
unplugged before moving your HDTV.
•When unplugging your HDTV, hold the power plug, not the cord. Pulling on the power cord may
damage the wires inside the cord and cause fire or electric shock. When your HDTV will not be
used for an extended period of time, unplug the power cord.
•To reduce risk of electric shock, do not touch the connector with wet hands.
•Insert batteries in accordance with instructions. Incorrect polarities may cause the batteries to
leak which can damage the remote control or injure the operator.
•If any of the following occurs, contact the dealer:
oThe power cord fails or frays.
oLiquid sprays or any object drops into your HDTV.
oYour HDTV is exposed to rain or other moisture.
oYour HDTV is dropped or damaged in any way.
oThe performance of your HDTV changes substantially.
Version 12/10/2009 3
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
Television Antenna Connection Protection
External Television Antenna Grounding
If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the
antenna or cable system is electrically grounded to provide some protection against voltage surges and
static charges.
Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge
unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding
electrodes, and requirements of the grounding electrode.
Lightning Protection
For added protection of the TV during
a lightning storm or when it is left
unattended or unused for long periods
of time, unplug the TV from the wall
outlet and disconnect the antenna or
cable system.
Power Lines
Do not locate the antenna near
overhead light or power circuits, or
where it could fall into such power
lines or circuits.
Remember, the screen of the coaxial cable is intended to be connected to earth in the building
installation.
Advisory of the DTV Transition
The nationwide switch to digital television broadcasting was completed on June 12, 2009. Your VIZIO
HDTV is capable of receiving Digital Broadcasts, and no Digital Converter Box is required.
For additional information, please contact the parties listed below, as appropriate:
FCC (US Federal Communications Commission)
http://www.fcc.gov/
Phone: 1-888-CALL-FCC (1-888-225-5322)
TTY: 1-888-TELL-FCC (1-888-835-5322)
Fax: [phone]
E-mail: [email protected]
NTIA (National Telecommunications and Information Administration)
http://www.ntia.doc.gov/ 1-888-DTV-2009
Listings of US Television Stations: http://www.high-techproductions.com/usTVstations.htm
4
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
Table of Contents
Important Safety Instructions..................................................................................................................... 2
Television Antenna Connection Protection ............................................................................................... 4
Advisory of the DTV Transition.................................................................................................................. 4
Finding a Location for Your HDTV ............................................................................................................ 9
Wall Mounting your HDTV....................................................................................................................... 10
Attaching the safety strap........................................................................................................................ 10
CHAPTER 1 BASIC CONTROLS AND CONNECTIONS.......................................................................... 11
Front Panel Controls................................................................................................................................ 11
Left-Side Panel Controls & Connections................................................................................................. 11
Rear Panel Connections.......................................................................................................................... 12
CHAPTER 2 VIZIO REMOTE CONTROL .................................................................................................. 13
Installing the Batteries .............................................................................................................................13
Activating Your Bluetooth Remote .......................................................................................................... 13
Remote Control Buttons .......................................................................................................................... 14
Basic TV Functions ..............................................................................................................................14
A/V Functions....................................................................................................................................... 15
VIA Functions....................................................................................................................................... 15
Making it Your Universal Remote............................................................................................................ 16
Remote Control Range............................................................................................................................ 16
VIZIO Remote Control Precautions......................................................................................................... 16
CHAPTER 3 GETTING STARTED............................................................................................................. 17
CHAPTER 4 USING YOUR HDTV FOR THE FIRST TIME ....................................................................... 18
Connecting to the Internet ....................................................................................................................... 18
Selecting an Input Source ....................................................................................................................... 18
Setting the Time Zone & Daylight Savings.............................................................................................. 18
Watching a TV Program .......................................................................................................................... 19
Viewing Digital TV Program Information ................................................................................................. 19
INFO Button ......................................................................................................................................... 19
GUIDE Button ...................................................................................................................................... 20
Exploring VIZIO Internet Apps (VIA) ....................................................................................................... 21
CHAPTER 5 CONNECTING EQUIPMENT................................................................................................ 22
Which Video Connection Should I Use? ................................................................................................. 22
Connecting Your Cable or Satellite Box.................................................................................................. 23
Using HDMI (Best) ............................................................................................................................... 23
HDMI Connections for Cable or Satellite Boxes with DVI ................................................................... 23
Using Component Video (Better)......................................................................................................... 24
Using S-Video (Better)......................................................................................................................... 24
Using Composite Video (Compatible).................................................................................................. 25
Using Coaxial (Antenna) (Compatible) ................................................................................................ 25
Connecting Your DVD Player.................................................................................................................. 26
Using HDMI (Best) ............................................................................................................................... 26
HDMI Connections for DVD Players with DVI ..................................................................................... 26
Using Component Video (Better)......................................................................................................... 27
Using S-Video (Bette) .......................................................................................................................... 27
Using Composite (AV) Video (Compatible) ......................................................................................... 28
Connecting Coaxial (RF) ......................................................................................................................... 28
Using Your Antenna or Digital Cable for Standard or Digital TV ......................................................... 28
Connecting Your VCR or Video Camera................................................................................................. 29
Using S-VIDEO .................................................................................................................................... 29
Using AV .............................................................................................................................................. 29
Version 12/10/2009 5
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
Connecting a Home Theater System ...................................................................................................... 30
Using RCA ........................................................................................................................................... 30
Using Optical (SPDIF).......................................................................................................................... 31
Connecting a Computer........................................................................................................................... 31
RGB (VGA) .......................................................................................................................................... 31
Using HDMI.......................................................................................................................................... 32
Ethernet Connection................................................................................................................................ 32
CHAPTER 6 USING VIA ............................................................................................................................ 33
Connecting to the Internet ....................................................................................................................... 33
Navigating the VIA Dock ......................................................................................................................... 33
Using VIZIO Internet Apps (VIA) ............................................................................................................. 34
Navigating Apps................................................................................................................................... 34
Adding Apps......................................................................................................................................... 34
Deleting Apps...................................................................................................................................................35
Moving Apps ....................................................................................................................................................35
Using Profiles....................................................................................................................................... 35
Creating a New Profile .....................................................................................................................................35
Switching Profiles.............................................................................................................................................36
Editing your Profile ...........................................................................................................................................36
Removing a Profile...........................................................................................................................................36
Updating your TV..................................................................................................................................... 36
CHAPTER 7 ADJUSTING YOUR HDTV SETTINGS ................................................................................ 37
Using the HDTV Settings App ................................................................................................................. 37
Input Menu............................................................................................................................................... 37
Wide Menu ................................................................................................Error! Bookmark not defined.
CC Menu ................................................................................................................................................. 38
Analog Closed Caption ........................................................................................................................ 39
Digital Closed Caption ......................................................................................................................... 39
Digital CC Style.................................................................................................................................... 39
Sleep Timer Menu ................................................................................................................................... 39
TV Settings Menu.................................................................................................................................... 40
Input Source......................................................................................................................................... 40
Picture.................................................................................................................................................. 40
Picture Mode ....................................................................................................................................................40
Backlight...........................................................................................................................................................40
Brightness ........................................................................................................................................................40
Contrast............................................................................................................................................................40
Color.................................................................................................................................................................40
Tint ...................................................................................................................................................................40
Sharpness ........................................................................................................................................................40
Size & Position .................................................................................................................................................41
Color Temperature ...........................................................................................................................................41
Advanced Picture .............................................................................................................................................41
Reset Picture Mode..........................................................................................................................................42
Audio.................................................................................................................................................... 42
Audio Mode ......................................................................................................................................................42
Balance ............................................................................................................................................................42
Lip Sync ...........................................................................................................................................................42
TV Speakers ....................................................................................................................................................42
Advanced Audio ...............................................................................................................................................42
Pick Device Type .............................................................................................................................................43
Pick Device Brand............................................................................................................................................43
Confirm Remote Connection ............................................................................................................................43
Equalizer Settings ............................................................................................................................................43
Reset Audio Mode............................................................................................................................................43
Tuner.................................................................................................................................................... 44
Tuner Mode......................................................................................................................................................44
6
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
Auto Channel Search .......................................................................................................................................44
Partial Channel Search ....................................................................................................................................44
Add Analog Channel ........................................................................................................................................44
Skip Channel....................................................................................................................................................44
Analog MTS .....................................................................................................................................................44
Digital MTS.......................................................................................................................................................44
Name Input .......................................................................................................................................... 45
Device Setup........................................................................................................................................ 45
Input Source.....................................................................................................................................................45
Pick Device Type .............................................................................................................................................45
Pick Device Brand............................................................................................................................................45
Confirm Remote Connection ............................................................................................................................46
Parental Controls ................................................................................................................................. 46
Rating Enable...................................................................................................................................................46
Channel Locks .................................................................................................................................................46
USA-TV............................................................................................................................................................46
USA-Movie .......................................................................................................................................................47
CAN-English.....................................................................................................................................................47
CAN-French .....................................................................................................................................................47
Block Unrated Shows .......................................................................................................................................47
Change PIN......................................................................................................................................................48
RESET LOCKS ................................................................................................................................................48
Menu Language ................................................................................................................................... 48
Time & Local Settings.......................................................................................................................... 48
Time Zone ........................................................................................................................................................48
Daylight Saving ................................................................................................................................................48
Postal Code......................................................................................................................................................48
PIP Menu................................................................................................................................................. 49
PIP Mode ............................................................................................................................................. 49
PIP Source........................................................................................................................................... 49
Position ................................................................................................................................................ 49
Size ...................................................................................................................................................... 49
Audio.................................................................................................................................................... 49
Network Menu ......................................................................................................................................... 50
Wired Connection ................................................................................................................................ 50
Manual Setup....................................................................................................................................... 50
Change Settings...............................................................................................................................................50
Test Connection ...............................................................................................................................................50
Wireless Connection ............................................................................................................................ 50
Wireless Access Points....................................................................................................................................50
More Access Points .........................................................................................................................................51
Manual Setup ...................................................................................................................................................51
Enter Access Point Name ................................................................................................................................51
Bluetooth Menu.................................................................................................................................... 51
Unpair Devices.................................................................................................................................................51
Pair Devices .....................................................................................................................................................51
Help Menu ............................................................................................................................................... 52
System Info .......................................................................................................................................... 52
Reset All Settings/Presets ................................................................................................................... 52
Clear Memory (Factory Default) .......................................................................................................... 52
CHAPTER 8 MAINTENANCE AND TROUBLESHOOTING ..................................................................... 53
Cleaning the TV and Remote Control ..................................................................................................... 53
Troubleshooting Guide ............................................................................................................................ 53
TV/Display Troubleshooting................................................................................................................. 53
Audio Troubleshooting......................................................................................................................... 56
Bluetooth Troubleshooting................................................................................................................... 56
VIZIO Internet Apps Troubleshooting .................................................................................................. 56
Remote Control Troubleshooting......................................................................................................... 57
Version 12/10/2009 7
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
Internet Connection Troubleshooting................................................................................................... 57
Telephone & Technical Support.............................................................................................................. 58
Compliance.............................................................................................................................................. 58
FCC Class B Radio Interference Statement ........................................................................................... 58
CHAPTER 9 SPECIFICATIONS ................................................................................................................ 59
Resolution through RGB Input ................................................................................................................ 60
Preset PC Resolutions ............................................................................................................................ 61
Using a Cable or Satellite Box Remote................................................................................................... 61
LIMITED PRODUCT WARRANTY............................................................................................................. 62
VIZIO RETURN POLICY ............................................................................................................................ 63
VIZIO INTERNET APPLICATIONS DISCLAIMER .................................................................................... 65
VIZIO INTERNET APPLICATIONS SOFTWARE LICENSE AGREEMENT ............................................. 65
INDEX ......................................................................................................................................................... 69
Opening the Package
Your HDTV and its accompanying accessories are carefully packed in a cardboard carton that has been
designed to protect it from transportation damage. Once you have opened the carton, check that your
HDTV is in good condition and that all of the contents are included.
The glass surface can easily be scratched or broken, so handle your HDTV gently and never place your
HDTV with the glass facing downwards on a surface without protective padding.
IMPORTANT: Save the carton and packing material for future shipping.
Package Contents
•VIZIO SV472XVT
•VIZIO remote control VUR10, including full
keyboard, IR, and Bluetooth
•AA batteries for the remote control (2)
•Power cord
•Safety Strap
•Cleaning Cloth
•This user manual
•Quick Setup Guide
Caution: Do not apply pressure or throw objects at your HDTV. This may compromise the integrity
of the display. The manufacturer’s warranty does not cover user abuse or improper installations.
8
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
HDTV Accessories and Services
Additional certified accessories for your HDTV are sold separately, including:
•Wall mounts
•High Definition cables
•Extra or replacement remote controls
•Sound Bars
•Blu-ray DVD Players
VIZIO also offers installation services and extended warranty services for your HDTV.
To purchase or inquire about additional accessories and services for your VIZIO HDTV, visit our website
at www.VIZIO.com or call us toll free at 877-MYVIZIO (877-698-4946).
Finding a Location for Your HDTV
Here are some things you should consider when deciding on a proper location for your HDTV:
•The power consumption of your HDTV is about 130W (AVG).
oUse the included power cord.
oWhen an extension cord is required, use one with the correct power rating. The 3-
pronged cord must be grounded and the grounding feature (3rd prong) must not be
compromised.
•To take full advantage of your TV, you will need an Internet connection. Set up the Internet
connection using the initial Setup App or the Network Menu in the HDTV Settings App. Your
HDTV has 802.11n dual-band wireless built-in (which is also compatible with 802.11b and
802.11g wireless networks), so you can connect your TV to the Internet through your wireless
home network. Or you can connect to the Internet by plugging in an Ethernet cable from your
Internet connection to the Ethernet port on your HDTV. A wired connection may provide a more
consistent connection depending on the conditions in your home environment. See Network
Menu on page 50 for detailed information on setting up your Internet connection.
•Install your HDTV on a flat surface to avoid tipping.
•For proper ventilation, you must allow space between the back of your HDTV and the wall.
•Avoid installing your HDTV in places with high humidity, dust, or smoke so you do not shorten the
service life of the electronic components.
•Install your HDTV in a level, landscape orientation, with the VIZIO logo at the bottom to prevent
poor ventilation and excessive component damage.
•If you want to mount your HDTV on the wall, see below for additional information.
•Read this user manual carefully before installing your HDTV.
VIZIO offers professional installation services including home networking. Contact VIZIO for more
information on these services at 877-MYVIZIO (877-698-4946) or www.VIZIO.com.
Version 12/10/2009 9
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
Wall Mounting your HDTV
Your HDTV can be mounted on the wall for viewing. If
you choose to mount your HDTV on the wall, follow the
instructions below.
1. Write down the serial number located on the back
of your HDTV:__ __ __ __ __ __ __ __ __ __ __ __
2. Remove the stand base and neck:
a. Disconnect the cables from your HDTV.
b. Place your HDTV face down on a soft, flat
surface to prevent damage to the screen.
c. Remove the eight (8) screws holding the
stand neck, and then remove the neck
and base. Pull straight down on the base
after removing the screws to disconnect it
from the TV.
3. Mount your HDTV on the wall:
a. Attach your HDTV to a wall mount (sold
separately) using the mounting holes in the
back panel of your HDTV.
b. Read the instructions that came with your
specific wall mount to properly hang your
HDTV.
Wall Mount Specs:
•Hole Pattern: 400mm x 200mm
•Screw Size: M6 Pitch 1.0mm
Attaching the safety strap
When your HDTV is not mounted on the wall, use the included safety strap to attach your HDTV to the
wall to reduce the chance of your HDTV being pulled over. The Safety Strap should be used with
common sense practice such as ensuring that children (or adults) do not climb up, grabbing the top of
your HDTV and pulling it onto themselves.
1. Attach one end of the strap to the wall:
•If you have a drywall finish attach it to a stud, using a
washer underneath the screw head.
•If you have a solid wall you should use a lag bolt, again
using a washer under the nut.
2. Attach the other end of the Safety Strap to
one of the upper wall mounting holes on
the back of your HDTV, using a washer
under the screw head.
10
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
Chapter 1 Basic Controls and Connections
Front Panel Controls
Power ‘VIZIO’ Light—When you first connect power
or turn your HDTV off, wait for the VIZIO logo to stop
flashing before pressing the power button on the TV or
the remote control to turn your HDTV on. Once
powered on, the VIZIO logo turns white.
Remote Control Sensor—When in IR mode, point
the remote control at this sensor in the lower right-
hand corner for the best response to the remote signal.
Your remote control normally operates with Bluetooth
which allows you to point the remote control anywhere
to control the TV. You will pair (Activate) your remote
during the initial setup procedure.
Left-Side Panel Controls & Connections
Power ( )—Turn your HDTV on by pressing the button once. Press the button again to
your HDTV off.
VIA / MENU—Press to launch the VIZIO Internet Apps (VIA) Dock on the bottom of the TV,
including the HDTV Settings App, used to make adjustments to your TV.
CH ▲/ ▼—Use these buttons to step up or down the TV channels. When in a menu, these
buttons function as up and down navigation.
VOL + / - —Use these buttons to increase or decrease the speaker volume. When in a menu,
these buttons function as left and right navigation.
INPUT—Repeated pressing of this button steps through the input sources in the following
sequence: TV, AV (Composite), COMP (Component), HDMI-1, HDMI-2, HDMI-3, HDMI side,
and RGB (VGA). Once you have stepped through the entire sequence, you will return to the
beginning. When in a menu, this button functions as the OK or select control.
USB 1, 2, 3—These ports are currently for service only. Register your HDTV to receive
future product updates including upgrades for these ports.
HDMI SIDE—Connect another digital video device such as a DVD player or set-top box
through this all digital connector.
Version 12/10/2009 11
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
Rear Panel Connections
1. HDMI 1 & 2—Connect digital video devices such as DVD players or set-top box through these
all digital connectors. There is an additional HDMI port on the side of your HDTV.
2. RGB PC—Connect the video and audio from a computer here. Connect a 1/8” mini plug stereo
connector from the computer to the TV if you want sound to be transmitted.
3. S-VIDEO/AV—Connect composite or S-Video video devices, such as a VCR or game console.
Use the white and red connectors to connect the external audio from the same source.
4. DTV/TV—Connect to an antenna or digital cable source for digital TV. For digital TV stations in
your area visit www.antennaweb.org. For cable and satellite set-top boxes, we recommend that
you use a HDMI or component cable connection for high definition image quality.
5. AUDIO OUT—
a. (OPTICAL) When digital TV is selected for viewing, the audio associated with the
programming will be available on the SPDIF Optical connector for connection to a VIZIO
Sound Bar or your home theater system.
b. (ANALOG L/R) Connect the audio from your HDTV to an external device, such as a
VIZIO Sound Bar or a home theater system. Non-amplified speakers cannot be
connected directly here.
6. ETHERNET—Connect an Ethernet cable to access the Internet. Set up the Internet connection
using the initial Setup App or the Network Menu in the HDTV Settings App. Your HDTV also
has 802.11n dual-band wireless, so you can connect your TV to the Internet through you
wireless home network. See Network Menu on page 50 for detailed information on setting up
your Internet connection.
7. HDMI 3—Connect another digital video device such as a DVD player or set-top box through
this all digital connector. For users who want to connect to a DVI enabled device, use a DVI-
HDMI cable and connect the analog audio output of the device to the L+R AUDIO here. Your
VIZIO Certified HDMI and HDMI-DVI cables are available for purchase from www.VIZIO.com or
by calling 877-MYVIZIO (877-698-4946).
8. COMPONENT (Y Pb/Cb Pr/Cr)—Connect component video devices such as a DVD Player or
cable/satellite set-top box here.
12
www.VIZIO.com

Version 12/10/2009 13
www.VIZIO.com
VIZIO SV472XVT HDTV User Manual
Chapter 2 VIZIO Remote Control
Your new VIZIO HDTV comes with an IR / Bluetooth-enabled universal remote that lets you interact with
Internet content delivered to your HDTV. You can also use it to program other A/V devices connected to
your TV, such as DVD or Blu-ray player, cable/satellite set-top box, DVR, home theater, and more.
Installing the Batteries
1. Remove the battery cover.
2. Insert two AA batteries into the remote control. Make sure that you match the
(+) and (-) symbols on the batteries with the (+) and (-) symbols inside the
battery compartment
3. Replace the battery cover.
Precautionary Tips for Inserting the Batteries:
•Only use quality AA batteries.
•Do not mix new and old batteries. This may result in cracking or leakage
that may cause a fire or lead to personal injury.
•Inserting the batteries incorrectly may also result in cracking or leakage
that may cause a fire or lead to personal injury.
•Dispose of batteries according to local hazardous waste regulations.
•Keep the batteries away from children and pets.
Activating Your Bluetooth Remote
You will activate your Bluetooth remote control in the Setup App. Follow the instructions on the screen to
complete the activation.
You can also activate your remote control using your HDTV Settings App. See Bluetooth Menu on
page 51 for detailed information on activating your remote control.

VIZIO SV472XVT HDTV User Manual
Remote Control Buttons
Basic TV Functions
INPUT—Press to cycle through the various devices connected to your
TV (called Inputs). You can name your inputs when you set them up
during the HDTV Settings App. The inputs cycle in the following
sequence: TV, AV (Composite), COMP (Component), HDMI-1, HDMI-2,
HDMI-3, HDMI side, and RGB (VGA). Once you have stepped through
the entire sequence, you will return to the beginning.
Device Power ( next to INPUT button)—Press to turn the device
connected to the active input (i.e. HDMI, COMP) ON and OFF. The
device must first be set up during the Setup App or using Device Setup
in the HDTV Settings App.
Power ( top right corner)—Press to turn the TV on from the standby
mode. Press it again to return to standby mode.
LIST—Press to display a list of available channels. If a DVR has been
programmed to work with this remote, this button will display the list of
recorded programs.
INFO—Press to display program information. If a device has been
programmed to work with this remote, this button will act as the INFO
button for that device.
EXIT—Press to exit from open menus.
MENU—Press to launch the VIZIO Internet Apps (VIA) Dock on the
bottom of the TV, including the HDTV Settings App, used to make
adjustments to your TV. This button also opens the menu for the device
connected to the active input (i.e. HDMI, COMP).
Press to navigate open menus, adjust other TV settings such
as brightness and contrast, or turn menu options on and off.
OK—Press to select an option in the menu.
BACK—Press to go back to the previous page in open menus.
GUIDE—Press to display detailed information when viewing a digital TV
program.
YELLOW—Press to perform the same function as the “A” button on
your cable/satellite box.
BLUE—Press to perform the same function as the “B” button on your cable/satellite box.
RED—Press to perform the same function as the “C” button on your cable/satellite box.
GREEN—Press to perform the same function as the “D” button on your cable/satellite box.
VOL ▲/▼—Press to turn the volume up or down.
VIA—Press to launch the VIZIO Internet Apps (VIA) Dock on the bottom of the TV, including the HDTV
Settings App, used to make adjustments to your TV. This button also opens the menu for the device
connected to the active input (i.e. HDMI, COMP).
MUTE—Press to turn the sound on and off.
LAST—Press to recall the previously viewed channel. Also, press repeatedly to go back to the previous
menu screen or out to your program when you press it repeatedly.
CH ▲/▼—Press to change the channels up or down.
Number Button Pad—Press to select a channel or enter a password.
14
www.VIZIO.com

Version 12/10/2009 15
www.VIZIO.com
VIZIO SV472XVT HDTV User Manual
PIP—Press to activate the picture-in-picture feature. The screen will display the sub-screen in the corner
over the main screen. Press it again to display the POP (Picture Outside Picture) option.
—(DASH)—Press to insert a dash between the main and sub-channels. For example, digital channel 28-
2 would be selected by the button sequence 2, 8, DASH, 2.
A/V Functions
Use these buttons on your remote control to control your pre-programmed DVR, DVD Player or
Cable/Satellite Box.
Fast Reverse ( )—Press to reverse
playback.
Pause (II)—Press to pause playback.
Play (►)—Press to start playback.
Fast Forward ( )—Press to skip to the
next chapter.
(●)—Press to begin recording.
Stop ( )—Press to stop playback/recording.
VIA Functions
Use these buttons on your remote control to control the VIZIO Internet Apps (VIA) functions on your
HDTV. See Using VIA on page 33 for more information about the VIA functions on your HDTV.
Slide the keyboard open to
input letters and characters in
various Apps. You must
activate your remote control
during the initial Setup App
that plays when you first turn
on your TV in order to use the
sliding keyboard.
Press to launch the VIA Dock. The Apps in the
dock let you watch movies, TV shows, listen to
m
us
i
c,
a
n
d
m
uc
h m
o
r
e
.
Press to move or delete
an App from the VIA
Dock. Or, create a new
App and add it to your
VIA Dock.
Press to switch between
different video screen sizes
when the Sidebar is open.
Press to view settings
for the active App
Press to exit an App or
from the VIA Dock

VIZIO SV472XVT HDTV User Manual
Making it Your Universal Remote
The Setup App that runs when you first turn on your TV will help you set up your various devices that are
connected to your HDTV, so that you can use your VIZIO remote control for all of your devices.
You can also set up your devices by accessing the HDTV Settings App. See Device Setup on page 45 for
more information on setting up your remote.
Remote Control Range
When in IR mode (factory default):
•Point the remote control directly at this sensor for the best
response to the remote signal.
•Do not place any obstacles between the remote control and
the remote control sensor.
•The effective range of the remote control is approximately
30 feet (10 meters) from the front of the remote control
sensor, 30° to the left and right, 20° up and down.
When in Bluetooth mode:
•Your remote control also has Bluetooth and when paired with your HDTV, allows you to point the
remote control anywhere to control the TV.
•The effective range of the remote control is approximately 30 feet (10 meters) from the front of
the remote control sensor.
VIZIO Remote Control Precautions
•The remote control should be kept dry and away from heat sources. Avoid humidity.
•If the TV responds erratically to the remote control or does not respond at all, check the batteries.
If the batteries are low or exhausted, replace them with fresh batteries.
•When not using the remote control for a long period of time, remove the batteries.
•Do not take the batteries apart, heat them, or throw them into a fire.
•Do not subject the remote control to undue physical stress, such as striking or dropping it.
•Do not attempt to clean the remote control with a volatile solvent. Wipe it with a clean, damp cloth.
16
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
Chapter 3 Getting Started
Your VIA-enabled HDTV has a built-in Setup App that plays when you turn on your TV for the first time.
Follow the on-screen directions to easily setup your new HDTV.
1. Insert batteries into the remote control.
2. Connect the power cord to the power cord connector on your HDTV, and then plug the power
cord into an AC wall socket.
3. Gather the devices your want to connect to your HDTV. Don’t connect them yet. We will help you
do that in the Setup App.
4. Turn on your TV. The Setup App will automatically play and guide your thru the initial setup of
your HDTV. Use the arrow and OK buttons to navigate through the Setup App. During the setup
process you will:
•Activate your new remote control for Bluetooth
•Connect to the Internet
•Add your TV channels (unless you have a cable/satellite set-top box)
•Connect your devices and set up your remote to control them
Version 12/10/2009 17
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
Chapter 4 Using your HDTV for the first time
Connecting to the Internet
Set up the Internet connection using the initial Setup App or the Network Menu in the HDTV Settings App.
Your HDTV has 802.11n dual-band wireless, so you can connect your TV to the Internet through your
wireless home network. Or you can also connect to the Internet by plugging in an Ethernet cable from
your Internet connection into the Ethernet port on your HDTV. A wired connection may provide a more
consistent connection depending on the conditions in your home environment. See Network Menu on
page 50 for detailed information on setting up your Internet connection.
Selecting an Input Source
Select the input source for your HDTV by pressing INPUT on the remote
control or side of the TV. Pressing this button will cycle you through the
following options: TV, AV (Composite), COMP (Component), HDMI-1, HDMI-
2, HDMI-3, HDMI Side, and RGB (VGA).
Turn on your device and you will see a picture on your HDTV. If there is no
picture, make sure you have selected the correct input on your HDTV.
Note: If the selected device is RF connected, your HDTV needs to be in TV
mode and on either channel 3 or channel 4 matching the channel which has
been selected on the back of the VCR, Cable Box, External TV Tuner or
Satellite Receiver. Please refer to Owner or User’s Manual of such equipment
for details.
Setting the Time Zone & Daylight Savings
1. Press the VIA button.
2. Press ◄or ►on the remote control
to select the HDTV Settings App,
and then press OK. The Main Menu
will be displayed.
3. Press ◄, ►, ▲,or ▼on the remote
control to highlight HDTV Settings,
and then press OK to select it. The
Input Source sub-menu will be
highlighted.
4. Press
▲or ▼on the remote control
to highlight Time & Local Settings,
and then press ►to select it. The
Time Zone sub-menu will be
highlighted. Press ◄or ►to select
your time zone.
5. Press
▼to scroll down to Daylight
Savings, and then press ◄or ►to
set to On or Off.
6. Press EXIT to return to your program.
18
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
Watching a TV Program
Before you start watching TV, please make sure that any cable, satellite or off-air antenna connections
are secure. Also, verify that the power cord is plugged into a correctly grounded electrical outlet or surge
protector.
1. Turn on the TV. The VIZIO logo on the front will change from orange to white.
2. Select the input to which your device is connected that provide TV programming (i.e. TV, HDMI,
COMP).
Note: You should be able to see a picture. If you do not, make sure that all of your HDTV connections
are secure and you have selected the correct video input source. Each press of INPUT will cycle through
the available inputs. Press INPUT until the input associated with the device you want to view is shown.
3. When using the TV input, press the CH ▲or ▼buttons to change the channel. The channel
buttons will not work if you are watching a program using the HDMI, Component, or AV (S-Video
or Composite) inputs.
4. Press LIST or OK to view the available channels. Press ▲or ▼to scroll through the list and
press OK to select a channel.
Viewing Digital TV Program Information
INFO Button
When the channel is changed or when you press INFO, an information header is shown over the picture
for a few seconds. Each press of the INFO button will display more information about the program:
Version 12/10/2009 19
www.VIZIO.com

VIZIO SV472XVT HDTV User Manual
GUIDE Button
When you press GUIDE on the remote control, the guide is shown on the screen displaying information
provided by the broadcaster about the current and upcoming programs,
•Press ◄or ►to go to the previous or next channel in the guide.
•Press ▲or ▼to scroll through the list and view information about upcoming programs.
•The guide will close automatically or you can press EXIT to close it manually.
20
www.VIZIO.com
