Vizualogic HindSight F150 User manual

LCD Monitor &
CCD Color Camera
Ford Models
Expedition–2003-2004
Lincoln Navigator–2003-2004
F150–2003-2004
F250–2003-2004
F350–2003-2004
F150 Crew Cab–2003-2004
Installation Manual
1493 Bentley Drive • Corona, CA 92879 • 909-272-1996 • 800-624-7960 • Fax [phone]
www.vizualogic.com
Copyright © 2003 TMI Products, Inc.
All Rights Reserved
Corona, CA U.S.A.
060300
99-8019-003 10/03
Backup Monitor System
Backup Monitor System
Fall 2003

A/V Control Module Installation
1. Locate suitable A/V Control Module mounting location
(i.e. under seat or alternate location).
2. Attach the A/V Control Module wires as follows:
Wire Color Connection
1. Red +12V Battery
2. Orange +12V Reverse Light
3. Black Ground
3. Secure the A/V Control Module using the provided screws.
Monitor Installation
1. Mount the monitor into the housing cavity using the provided screws.
(Fig.1)
2. Route the monitor cable from the center of headliner to the A/V
Control Module via the A-pillar. (Fig. 2)
3. Clean windshield prior to installation.
3. Connect the monitor cable to the LCD monitor. (Fig. 3)
4. Peel off the double-faced tape at the back of the housing. (Fig. 4)
5. Secure the (2) monitor housing rear-hooks to the headliner. (Fig. 5)
6. As soon as both hooks are in place, center the housing with respect
to the rear view mirror and push it against the windshield to adhere.
Installed Back-up Monitor: (Fig. 6)
Package Contents & System Diagram
• 3.5˝ LCD Monitor w/Mirror Mode Display
• Color CCD Bullet-Type Camera w/Cable
• Angled Controller Rings (3 sizes)
• Fixing Rings
• A/V Control Module
• Monitor Cable
Camera Installation
1. Locate a suitable camera mounting location on the Car Body
(i.e. rear bumper cover).
2. Drill a 1-1⁄8˝ diameter hole at that location.
3. Attach an Angle Controller Ring to the Camera Body.
4. Insert the Camera Body through the Car Body and attach the
matching Angle Controller Ring to the Camera Body.
5. Secure the Fixing Rings to the threaded portion of the Camera Body.
6. Route the cable to the A/V Control Module location
(i.e. center console).
A/V Control
Module
LCD
Monitor
+12V
Battery
Ground
+12V
Reverse light
CCD
Camera
