Headrest Installation
Section I – Headrest Installation
1. Remove factory OE headrest.
2. Insert rigid wire “fishing tool” into the top of the headrest post guide and out the lower
inside corner of the seat back.
3. Hook end of headrest cable to the top of the “fishing tool” and pull cables through
the seat.
4. Insert Vizualogic headrest in into post guide tubes. Now the headrest is secure.
5. Route headrest cable under the seat to the location of the A/V Controller. Be sure to
secure your wires and allow enough slack for seat travel on the tracks. Make sure the
seat does not pinch or cut cables.
Section II – Wiring
1. Place A/V module in a well protected area under seat or behind panel.
2. Connect 12 Volt harness to 12V + and 12V Ground. (use same power source
and ground as video sources). Wires are color-coded. Red = main power,
White = accessory, Black = ground.
3. Use an A/V RCA cable to connect the DVD output to the input side of the A/V
Controller box.
4. Connect monitor 1 and monitor 2 cables to the output side of the A/V Controller Box.
5. Select the headrest monitor that will be the master output to the FM Modulator. If you
select monitor 1 to be the master, connect the FM Modulator with “Y” cables (not
supplied) to slave 1 out. If you select monitor 2 connect to slave 2 out.
6. Pull radio and disconnect the antenna wire from the radio. Now connect the car radio
antenna cable to the FM Modulator. Connect the male FM Modulator cable to the back
of the radio. (Refer to the FM Modulator owner’s manual). Connect power to the FM
Modulator. (Note – Antenna adapter may be required for some GM vehicles)
7. Using the RCA cables supplied with the headphone transmitter connect the output
audio slave 1 and slave 2 to the input of the RF headphone transmitter box.
Now connect power to the transmitter.
Section III – IR Repeater (included in the A/V Control Module).
An IR repeater is built into each monitor allowing video source control by pointing the
remote at he screen. This feature eliminates the need to install a stand-alone IR repeater
elsewhere in the vehicle. Use supplied black wire with 1/8˝ phono jacks to connect source
and A/V Controller Box. IR 1 and IR 2 inputs are located on the A/V Control Module.
Kits
VizuaLogic®offers 3 different ways to buy PerfectMatch™
Headrest Monitor Systems:
1. Vehicle Specific Kit (2 headrest monitors)
2. Single Headrest Monitor Kit (1 headrest monitor)
3. Dual Headrest Monitor Kit (2 headrest monitors)
Each Vehicle Specific Kit includes:
• 2 VizuaLogic PerfectMatch™OEM Headrest Monitors
• A/V control module with dual source
video inputs
• Unified remote control. Controls monitor
functions, A/V source input selection
and Vizualogic DVD.
• 1 Dual input RF Transmitter
• 2 Wireless three-channel crystal tuned
RF head phones
• 1 FM modulator
• Some wiring components may not be included.
Each Monitor Kit includes:
• 1 or 2 VizuaLogic PerfectMatch™OEM
Headrest Monitors
• A/V control module with dual source
video inputs
• Unified remote control. Controls monitor functions,
A/V source input selection and Vizualogic DVD.
