volkano Lunar Series User manual

VK-2004-WTGD
Please read these instructions carefully and retain for future reference.
INSTRUCTION MANUAL
Lunar Series
BLUETOOTH
WIRELESS HEADPHONES

• Bluetooth:
Version: 4.0
Range: 10 m
• Playback Time: ± 7 Hours
• Battery Capacity: 3.7 V, 300 mAh
• Charge Time: ± 1.5 Hours
• Battery Type: Lithium-Ion
• Power Requirement: 5V DC, 1 A
• Volkano Lunar Bluetooth Headphones
• Micro USB Charging Cable
• Aux Cable
• Instruction Manual
• Bluetooth Wireless: V4.0
• Charge Input: DC 5V 1 A
• Playback Time / Music Time: ± 7 Hours
• Standby Time: 30 Hours
PACKAGE CONTENTS
HIGHLIGHTS
SPECIFICATIONS
2

IDENTIFYING PARTS
3
2
3
4
5
6
7
1
8
9
1. TF Slot
2. USB Charging Port
3. Microphone
4. Aux-in Cable
5. LED Light Indicator
6. Power Button / Mode Switch (TF Mode, Radio Mode, Bluetooth Mode)
7. Next Song / Increase Volume
8. Previous Song / Decrease Volume
9. Play / Pause / Answer Calls

4
INSTRUCTIONS FOR USE:
CHARGING THE HEADPHONES
SWITCHING ON / OFF THE HEADHONES
PAIRING WITH BLUETOOTH DEVICES
Connect the USB A end of the Charging Cable to a USB Charging Port and insert
the Micro USB end to the port on the Lunar Headphones. Make sure it is properly
connected. A Red Indicator Light will immediately light up followed by a Blue Indicator
Light to indicate charging mode. Once the Lunar Headphones have fully charged, the
Blue Indicator Light will turn off and the headphones will be ready for use.
1. Start-up: Long press the “ ” button for approximately 3 seconds, the
headphones will start up and enter “Bluetooth Mode” automatically, the LED
Indicator Light turns Blue.
2. Shutdown: Long press the “ ” button for more than 3 seconds, the LED
Indicator Light turns off.
a) Hold the “ ” button to turn on the Lunar Headphones.
A short tone plays to indicate the headphones are on.
Turn on Bluetooth mode on your mobile device and search for the “Lunar”.
No password is required to establish a pairing.
While the headphones are searching for a device, the Indicator Light will rapidly
alternate between Blue and Green.
Once connected to a mobile device, the Indicator Light will change to Blue and the
headphones will play a short tone.
The Indicator Light will flash once every second to indicate that it is in use.

5
MICRO SD CARD PLAYBACK MODE
Insert the Micro SD Card, the LED Indicator Light turns to Green, a short tone prompts
“Music”. Then it plays media automatically, the LED Indicator Light turns to Green
flashing every 4 seconds.
NOTE:
• The Lunar Headphones will automatically pair to the last mobile device used.
• If no device is found within 3 seconds, the Lunar Headphones will automatically
re-enter Pairing Mode.
• If no connection can be established after 5 minutes, the Lunar Headphones will
automatically switch off.
• When connected to an Aux Cable, the Lunar Headphones will switch off to save
power.
FM RADIO MODE
1. Turn the Lunar Headphones ON “ ” until you see the Indicator Light change
to Green.
2. Press the Play / Pause Button “ ” to enter FM Radio Mode and it will play
a short tone. Press the Play / Pause Button “ ” to automatically scan radio
stations.
3. To scan through radio stations, press the “ ” Next Track or the “ ”
Back Buttons and fine tune.

6
1. Volume Controls
Function Operation
Increase Volume Long press the Next Track / Volume Up Button
Decrease Volume Long press the Previous Track / Volume Down Button
2. Audio Controls
Function Operation
Play or Pause Track Short press the Play / Pause / Call Button
Next Track Short press the Next Track / Volume Up Button
Previous Track Short press the Prev Track / Volume Down Button
Hang Up Short press the Play / Pause / Call Button
Redial Double press the Play / Pause / Call Button
CONTROLS

7
Aux-in Mode
When the headphones are on, insert the Aux Cable and the headphones will play a
short tone.Then it plays the smart device’s media automatically.
LED Indicator
Charge Status LED Indicator Light will turn Red and then Blue to indicate
charging mode
Power on Status Blue LED Indicator Light turns on
Power off Status LED Indicator Light turns off
Pairing Status Green and Blue LED Indicator Lights rapidly alternating
flash
Standby Status Blue LED Indicator Light turns on
Connected Status Blue LED Indicator Light turns on
Mode Indicator
Blue LED Indicator Light flashes every 4 seconds
Radio Mode: Green LED Indicator Light turns on
Micro SD Card Mode: Green LED Indicator Light flashes
every 4 seconds
Aux-in Mode: The headphones automatically turn off, the
LED Indicator Light turns off

• The product should only be used with the parts provided by the manufacturer.
• This product is intended for indoor use only.
• Never use your Lunar Headphones near water or in areas where they can come
into contact with water. Never handle the Lunar Heaphones if they have been dropped
in water or any other liquid. If the product comes into contact with water while still
plugged in, this is a safety hazard.
• Always make sure your hands are dry before touching the USB cable or power
connections.
• Do not operate the product with a damaged cable, or after it malfunctions, has been
dropped, or damaged in any manner.
• The Lunar Headphones are intended for personal use only. Commercial use
invalidates the warranty and the supplier cannot be held responsible for injury or
damage caused when using the device for any other purpose than that which it was
intended for.
• The Lunar Headphones are not intended for use by children, or persons with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the device by a
person responsible for their safety. Extreme caution must be exercised.
• Children should be supervised to ensure that they do not play with the
Lunar Headphones. Packaging must never be left within reach of children, since it is
potentially dangerous
SAFETY PRECAUTIONS
CLEANING AND CARING INSTRUCTIONS
8
• Before Cleaning: Ensure that your Lunar Headphones are not charging before
cleaning or maintaining them.
• Cleaning: Wipe down the surface of your Lunar Headphones using a soft, slightly
damp cloth.
• Do not use any harsh or abrasive cleaning chemicals or materials on your Lunar
Headphones as doing so may damage or scratch the surface finish.
• Do not expose your Lunar Headphones to direct sunlight or high temperatures for
extended periods of time.
• Do not store in temperatures over 140 °F (60 °C).

1. My mobile phone cannot find any new Bluetooth devices?
a. Ensure the Device has entered the pairing mode.
b. Ensure the Device is within effective working range.
2. Bluetooth device cannot pair up?
Ensure your mobile phone allows new connections and has not reached the
maximum number of allowed devices.
3. The Device does not play music or answer calls when it is connected to a
Bluetooth mobile phone.
a. Ensure your mobile phone supports A2DP and HSF (Hands-free) profiles.
b. Ensure your mobile phone is within effective working range.
4. When paired with my computer, Windows asks for a new driver. Can you supply
this?
We recommend you find compatible drivers for your computer online.
5. Why can I not remotely control the pause, play function when music is playing?
This feature needs the Bluetooth device paired with the earphones to support
AVRCP (Audio / Video Remote Control Profile). Please ensure your device supports
this.
TROUBLESHOOTING
9
ENVIRONMENTALLY FRIENDLY DISPOSAL
Do not dispose of electrical appliances as unsorted municipal waste,
use separate collection facilities. Contact your local government for
information regarding the collection systems available. If electrical
appliances are disposed of in landfills or dumps, hazardous substances
can leak into the groundwater and get into the food chain, damaging
your health and well-being.

10
All products and company names are trademarks™ or registered®trademarks of their
respective holders. Use of them does not imply any affiliation with or endorsement by
them.
These Volkano Lunar Headphones come with a standard 12-month limited warranty
against manufacturing defects and faults. Should your product be unboxed with any
faulty parts, poor finishing or visible damage, or fail to perform due to a manufacturing
defect or poor workmanship, please return it with your proof of purchase (till slip or
invoice) to the store of purchase for an exchange, or repair, depending on the store’s
returns policy.
This warranty commences from the date of purchase.
Kindly retain your proof of purchase as well as the packaging for your warranty period.
NOTE:
The Warranty does not apply to a product that:
a.) Has failed due to excessive wear and tear beyond what is considered to be
reasonable.
b.) Has been misused or neglected.
c.) Has been damaged accidentally or by acts of God including fire and flooding.
d.) Has been used or operated contrary to operating or maintenance instructions
outlined in this manual.
The Store of Purchase / Seller cannot accept any returned products that have not been
returned in accordance to this warranty or which does not follow their own Returns
Policy. Please refer to the Store of Purchase / Sellers Returns Policy for details.
Should you require any further assistance or have any questions on your warranty,
please contact the store of purchase.
DISCLAIMER
WARRANTY
