Volkswagen Passat 2022 User manual

2022 Passat
Quick-Start Guide

7. Steering Wheel Left Side Controls
Buttons for operating the Cruise Control system and
increasing or decreasing volume settings for radio,
Navigation system notifications or phone calls.
8. Steering Wheel Right Side Controls
Voice Control Button: Activates the Voice
Recognition system. Short press to activate
Volkswagen Voice Control, long press to activate
third party voice control with a compatible
connected smartphone.
Phone Button: Displays the Phone ’ s main menu or
can be used to accept or end phone calls.
OK Button: Used to select settings for features in
the instrument cluster display.
Horizontal Menu Buttons: Used to navigate
through the instrument cluster main menus.
Vertical Arrow Buttons: Push to navigate inside a
specific menu.
Horizontal Arrow Buttons: Push to change radio
stations, scroll through radio presets or select the
next or previous media track.
6. USB Port
The USB port in the center console marked with
will transfer data and charge your device.
1. Driver Information Display
When the ignition is switched on, you can display trip
computer information and control a variety of vehicle
functions using the multi-function steering wheel.
2. Climatronic Climate Control
Your vehicle is equipped with either an Automatic
Climate Control system or a Manual Climate Control
system.
3. Infotainment
Hard keys and touchscreen buttons control the various
Infotainment functions, including radio, media selections,
phone operation, vehicle functions and the optional
Navigation system.
4. Remote Start (not shown)
If equipped, the engine can be started from outside the
vehicle with the Remote Start button, allowing the HVAC
system to heat or cool the interior. On your key fob, press
the Lock button , then the Remote Start button
twice. Pressing three times will cancel the operation.
5. Tire Pressure Monitoring System (TPMS)
After inflating tires to the correct pressure, turn the ignition
on and press the SET button inside the glove box for at least
two seconds to reset the TPMS.
Introduction to
Your Passat
The information within this guide must be used in conjunction with the information in the Volkswagen Owner’s Manual. You should refer to your vehicle’s Owner’s Manual
and Infotainment System Booklet for all information, warnings and feature limitations. Always pay careful attention to the road and do not drive while distracted.
Some Infotainment features can only be accessed and operated when the vehicle is standing still.
1
2
3
6
5
78

Warning: Visit www.knowyourvw.com/bluetooth to view more detailed information and important safety warnings for Bluetooth Pairing .
Warning: See App-Connect in your Infotainment System Booklet for more detailed information and for important safety warnings.
Features
1
2 3
4
5
Tapping the Exit icon simply takes you to the Volkswagen native user interface, then select Disconnect if you wish to
completely disconnect Android Auto.
1. Microphone: Google Assistant can be activated with a long press of
the Microphone icon on the touchscreen or by using touchscreen
commands that work with available apps. Google Assistant can also
be activated with a long press of the Voice Control button on
the multi-function steering wheel or just by saying “ Hey Google ” .
2. Navigation: Predictive navigation provides turn-by-turn directions,
traffic conditions and estimated travel time. Android Auto can
predict where you want to go next based on your calendar and
recent destinations.
3. Phone: Listen and reply to text messages, make calls or check your
voicemail.
4. Home Screen: Takes you back to the home screen of Android Auto.
5. Music and Audio: Use your touchscreen to access your favorite artists, songs and playlists. Android Auto lets you stream
from apps such as Pandora, Spotify and iHeartRadio.
Google, Android, Google Play and Android Auto are trademarks of Google LLC. Click here for further information. To use Android Auto on your car display, you’ll need an Android
phone running Android .0 or higher, an active data plan, and the Android Auto app.
1. Ensure you are running the latest Android ™ OS on your device and download Android Auto from the Google Play Store. An
active Google account and an internet connection is required. If you ’ re using Android 10 or higher, the app is already on your
phone.
2. Plug your Android phone into the USB port using a certified USB Cable.
3. Press the App key on the touchscreen.
4. Select Android Auto on your touchscreen. Ensure phone is unlocked.
5. Select OK on the touchscreen for data transfer prompt.
6. Follow instructions on your device to continue setup.
7. Android Auto will appear on the Infotainment touchscreen once all the prompts have been accepted on the device.
Android Auto ™
Features
Apple CarPlay features Siri voice control. Siri must be enabled on the
device to use Apple CarPlay. There are two ways to activate Siri:
1
2 3 4
5
Press and hold the Voice Control button on the multi-function
steering wheel until you hear the tone, which activates Siri.
Press and hold Home on the touchscreen to activate Siri.
5. Tapping the Volkswagen Logo icon simply takes you to the Volkswagen native user interface with all the features and
functions of Apple CarPlay still active.
To charge iPhone only, disconnect from Apple CarPlay by pressing the Volkswagen Logo icon, then select Disconnect
on the touchscreen. This will allow Bluetooth® access while charging your iPhone.
4. Messages: Siri can send, read and reply to your text messages for you.
3. Maps: Opens Apple Maps for turn-by-turn directions, traffic conditions, immersive 3D experiences and estimated travel
time. Siri can also help with directions. Activate Siri and say, “ Navigate to, ” and your destination.
2. Phone: Siri can help you make calls, return missed calls and listen to voicemail.
1. Home features include:
Return to the Apple CarPlay home screen or to the Apple CarPlay
Dashboard.
Long press to activate Siri.
Click here for further information on Apple CarPlay apps.
Apple CarPlay®
Apple CarPlay is a smart way to use your iPhone®. With the updated
user interface that helps you control tunes, directions and Siri®
suggestions, a calendar app that lets you view and manage your day,
and maps that reveal more of what ’ s around you, getting there just got
a whole lot easier — and a lot more fun.*
1. Ensure you are running the latest iOS on your device.
2. Unlock your iPhone and plug it into the USB port using a certified
lightning cable.
3. A message will appear on the Infotainment touchscreen stating that a new device has been detected. It will then ask,
“ Do you want to connect with Apple CarPlay? ” Select Connect .
4. Select Allow on iPhone to enable Apple CarPlay to access your iPhone while your phone is locked.
*Always pay careful attention to the road, and do not drive while distracted. Not all features are available on all operating systems. Standard text and data usage rates apply.
App-Connect features require a compatible device, operating system and mobile apps. See mobile device and app providers for terms and privacy.
Note: You will have to have had an unlocked iPhone within the past hour in order to use Apple CarPlay. When you are connected using Apple CarPlay, your iPhone can no longer be
used as a source in MEDIA or as a Bluetooth device. Apple CarPlay is compatible with iPhone 5 or higher running iOS 7.1 or later. Further information can be found at
support.apple.com and siriuserguide.com. Apple CarPlay is a trademark of Apple Inc.
App-Connect
Volkswagen App-Connect can make your Volkswagen seem more like a personal assistant. To start App-Connect, plug your
compatible smartphone into your VW ’ s USB port and watch as select apps appear on the touchscreen display of your
Volkswagen! Now you can experience some of your favorite smartphone apps with layouts and interactions specifically
meant to be used in your vehicle.
To stream music from a secondary paired device:
1. Press MEDIA .
2. Choose BT audio as the source and then select the secondary
device.
Watch the Bluetooth Audio Streaming video.
Note: Browsing capability is available only with an iPhone® Bluetooth connection.
1. First, pair your compatible Bluetooth-equipped phone or audio
player. Refer to Pairing a Compatible Phone steps 1-5 above.
2. Press the MEDIA Infotainment button.
3. Tap Source on the touchscreen and select BT audio .
4. To browse through your music, select Play, Pause, Previous or
Next on the touchscreen.
Bluetooth® Audio Streaming
Note: This feature is not available when the phone is connected to App-Connect, Apple CarPlay®
or Android AutoTM.
Primary and Secondary Phone Functionality
Two active phones can be connected simultaneously. Follow steps
1-5 above. Both devices can receive incoming calls. However, only
the primary phone ’ s contact list will be available through the
Infotainment system. To switch between phones, press the
Swapping icon on the Infotainment touchscreen.
Watch the Phone Pairing video.
Pairing a Compatible Phone
1. With ignition on and vehicle in Park, turn the Infotainment system
on. Your vehicle ’ s Bluetooth system will then be in “ discovery ” mode.
2. From the Bluetooth menu on your phone, search for new devices
and select VW BT XXXX (last four digits of VIN).
3. A connection request will appear on the Infotainment display.
4. Make sure the same PIN is displayed on the touchscreen and press
Yes on the touchscreen, then press Pair on your phone.
Note: If your phone displays a prompt asking to connect to your vehicle, make sure to enable future
automatic connections. This will help to automatically reconnect the compatible paired device to the
system. Once the PIN is shown, pairing must be completed within 30 seconds; otherwise, the process
will need to be repeated.
Bluetooth®/
App-Connect

Warning: See Climate Control in your Owner's Manual for more detailed information and for important safety warnings.
Fan Speed
Adjust fan speed by turning the dial clockwise to increase, counterclockwise to decrease.
6
AUTO
When AUTO is activated, the control knob will illuminate and the system will control fan speed and airflow direction to achieve
the set temperature.
1. Adjust the driver ’ s side dial to the desired temperature.
2. Press the AUTO button.
5
Seat Heating
To warm up quickly, press the button for seat heating.
4
Air Distribution
The Air Distribution button directs air to either the floor, panel or defrost vents or a combination of vents.
3
SYNC
The driver ’ s settings will be applied to the passenger climate zones.
1. Select your preferred temperature with the left temperature dial.
2. Adjust the fan speed and vents if necessary.
3. A light on the button will illuminate when active.
2
Max Defrost/Rear Defrost
1. Press the Max Defrost button. It is recommended to turn the temperature setting to HI for quickest defrost/defogging.
2. The A/C function comes on automatically and it is recommended to leave A/C on to dry the air.
3. When the windshield is clear, press the AUTO button.
4. Switch on outside mirror heating . Heats only at outside air temperatures below +68°F (+20°C).
Note: In the event of significant fogging, opening a window briefly can help.
Watch the Climate Control/Defrost video.
1
Heating and Air Conditioning
Press the AUTO button to reach a selected temperature automatically. The system will control fan speed and direction.
Adjust the driver ’ s temperature dial to your preferred setting.
Press the SYNC button to synchronize the temperatures between the zones. If there is a large temperature difference
between the two zones, it may hamper the system ’ s ability to quickly cool the interior.
In extreme heat, press the MAX A/C button. When a comfortable temperature has been reached, press the AUTO button.
Watch the Automatic Climate Control video.
Climatronic
Climate Control

Navigation/
Car-Net®
Destination Entry with Voice Recognition
1. Short press the Voice Control button on the multi-function
steering wheel. A beep will sound.
2. Say, “ Enter address. ”
3. After the beep, speak the address. For example: “ Two zero two
four Main Street, Los Angeles. ” Speak in single digits.
4. The system will repeat the address for confirmation and ask
if you would like to start route guidance. After the beep, say,
“ Yes ” and route guidance will begin.
Note: If you would like to change the state say, “Enter state again,” and say your current state, then follow instructions.
Points of Interest
1. Press NAV button, then press POIs on the touchscreen to
choose the most common POI types for your travels.
2. Select Start to begin route guidance.
Note: The navigation SD card must be in one of the Media Box SD card slots.
Watch the Navigation Point of Interest video.
Cancel Active Route Guidance
1. Select Route on the touchscreen.
2. Select Stop route guidance option on the touchscreen.
Most economical route
Fastest route
Shortest route
Include up to three alternative routes.
Use Dynamic route guidance using SiriusXM® Traffic.
Avoid certain road types and more.
If you wish to include alternative routes and make additional
navigation customizations, select route options prior to entering a
destination. While in the navigation function, select Settings on your
touchscreen > Route options > enable Suggest 3 alternative routes .
Here you can:
Additional Settings
1. Press the NAV button.
2. Press New destn. on the touchscreen.
3. Begin entering Point of Interest (POI) or address information
starting with House number, Street, then City.
4. When your POI or address appears, touch the correct address
on the screen.
5. Press Start to begin route calculation.
Note: Navigation is available on select trims. When entering an address for another state, use only the two character abbreviation for the state. Entering a destination on the
touchscreen or changing any settings can only be done when the vehicle is stationary. The navigation SD card must be in one of the Media Box SD card slots.
Enter a Destination on Your Touchscreen
Watch the Navigation Manual Destination video.
Cancel an Active Route with Voice Recognition
1. Short press the Voice Control button on the multi-function steering wheel. A beep will sound.
2. Say, “ Cancel destination. ”
1 Standard text and data rates may apply.
2 Refer to your vehicle’s warning and indicator lights for the most current diagnostic information. Always consult owner’s literature for maintenance guidelines.
3 Do not use feature to locate stolen vehicle.
4 Must agree to separate Terms of Service.
5 Applies to vehicles equipped with Navigation System.
Powered by Parkopedia. Requires parking facility participation. Volkswagen not responsible for accuracy of pricing & payment options, hours of operation, and features.
See parkopedia.com for important information and details.
7 Roadside Call Assist connects you to a Roadside Call Assist third-party provider and may require additional payment for services rendered.
8 Assistance can be provided by pressing the button in the vehicle’s overhead console.
9 Standard text and data rates may apply. See Owner’s Manual for further details and important warnings about locking and unlocking your vehicle remotely.
*Available on most MY20 and newer vehicles. Always pay careful attention to the road and do not drive while distracted. Certain services require trial or paid subscriptions,
which may have their own terms and conditions. VW Car-Net requires cellular connectivity, availability of vehicle GPS signal, and acceptance of Terms of Service. Not all
services and features are available on all vehicles. Certain Car-Net services, such as Roadside Call Assist, connect out to 3rd party providers that may require additional
payment. Standard text and data rates may apply for app and web features. Certain services may collect location and vehicle information. See Terms of Service, Privacy
Statement, and other important information at www.vw.com/carnet.
Car-Net® Enrollment Process8 (if not performed by dealer):
Call [phone]
OR
Download the “ Volkswagen Car-Net ” mobile app from the App Store.
Select Login to register and create your unique VW ID.
Log in to Car-Net mobile app with your VW ID, complete your profile and create a PIN.
Add your vehicle to your Garage by entering VIN and follow the steps to verify ownership.
Mobile App
Remote Door Lock/Unlock9
Remote Honk and Flash1
Vehicle Status2
Last Parked Location3
Maintenance Alerts & Scheduling1
Vehicle Health Reports2
DriveView2
POI/Destinations5
Parking Information6
Curfew Alert1
Valet Alert1
Boundary Alert1
Speed Alert1
Roadside Call Assist7
VW Car-Net is your connection to available convenience features. The five year no
charge Remote Access* package allows you access to:
Volkswagen Car-Net
Watch the Car-Net Smart Nav Upgrades video.
Warning: See Navigation in your Infotainment System Booklet for more detailed information and for important safety warnings. Navigation is an optional feature
Warning: See VW Car-Net in your Owner's Manual for more detailed information and for important safety warnings.

Warning: See Driver Assistance Systems in your Owner's Manual for more detailed information and for important safety warnings.
Watch the Adaptive Cruise Control video.
Note: This feature is not a substitute for attentive driving. Adaptive Cruise Control only works when driving above 1 mph. See the Owner’s Manual for further details and
important limitations. Adaptive Cruise Control is available only on select trim lines.
When the button is pressed to activate ACC distance level setting, the indicator light illuminates in the instrument
cluster.
To change the ACC distance interval, press the button to cycle through the distance intervals. When the greatest
interval is reached, the distance returns to the shortest interval when the button is pressed again.
Adaptive Cruise Control
Adaptive Cruise Control (ACC) maintains a set speed within the range of 16mph and 95mph. and will decelerate to maintain
a set distance from vehicles in front. ACC may also automatically apply braking when necessary. When vehicles ahead clear,
ACC resumes the set speed.
You can set the speed-dependent distance from the vehicle ahead to one of five levels.
1. To cancel the cruise speed, press the brake pedal or press the CNL button on the multi-function steering wheel. The green
cruise indicator light will go off.
2. To resume your speed, press the RES button on the multi-function steering wheel.
3. To turn off the cruise control, press the button twice.
Cancel, Resume and Off
1. When you get to your cruising speed, press the SET button on the multi-function steering wheel.
2. A green cruise control indicator light will appear in the instrument cluster display.
3. To increase/decrease the speed by 1 mph increments, press the + or - button.
4. To increase/decrease the speed by 5 mph increments, press and hold the + or - button.
Set Cruising Speed
Activate Cruise Control
Locate the Cruise Control buttons on the left side of the multi-function
steering wheel.
Press the button to activate Cruise Control.
A speedometer icon will appear in the instrument cluster display.
Watch the Cruise Control video.
Driver Assistance
Features
Driver Assistance Systems
If your vehicle is equipped with Driver Assistance features, you can activate/deactivate the system.
1. Press the Driver Assistance System button on the end of the turn signal stalk or press the Horizontal Menu buttons
on the multi-function steering wheel until you access the Assistance menu in the instrument cluster display.
2. Use the Vertical Arrow buttons on the multi-function steering wheel to select the Driver Assist system you wish to
modify.
3. A check mark indicates the system is active.
You can modify some Driver Assist functions further using the multi-function steering wheel and instrument cluster display.
1. Press the Horizontal Menu buttons on the multi-function steering wheel until you reach the Settings menu.
2. Use the Vertical Arrow buttons to access the Assistance menu.
3. When Front Assist is selected, you can activate/deactivate the system, along with distance warning and advance
warning level.

Warning: See Voice Recognition in your Owner's Manual for more detailed information and for important safety warnings.
Cancel Active Voice Recognition
Double press the Voice Control button on the multi-function steering wheel.
End a Call
On the multi-function steering wheel, press the Phone button to end the call.
Press the red Phone icon on the touchscreen while in the Phone menu function.
Press the Vertical Arrow buttons on the multi-function steering wheel until “ End ” appears on the Infotainment touchscreen.
Press the button on the multi-function steering wheel.
1. From the Phone menu, press the Voice Control button on the multi-function steering wheel and a selection of possible
voice commands will appear on the Infotainment touchscreen.
2. Say “ Help ” and then follow the prompts.
Help
Switch to Private Mode
To prevent passengers from overhearing a conversation, switch a
Bluetooth call to your mobile phone:
1. Use the Horizontal Menu buttons on the multi-function
steering wheel to access the Phone menu in the instrument cluster
display.
2. Press the Vertical Arrow buttons until “ Private ” appears in the
display.
3. To select, press the button on the multi-function steering wheel.
Answer an Incoming Call
The Bluetooth system will interrupt your car stereo with a ringtone. Press the Phone button on the multi-function steering
wheel or the green Phone icon on the Infotainment screen to answer the call.
Volume Settings
To adjust the volume of the Bluetooth system while on a call, press the Volume Up or Volume Down switch on the left
side of the multi-function steering wheel.
Voice Recognition Tips
The contact must be said exactly as it is stored in your phone ’ s contact list.
If multiple numbers are stored per contact, you may use the shortcut, “ Call John Smith work, ” or the system may ask you to
choose: work, mobile, home, etc.
Watch the Voice Recognition video.
Call by Name via Native Bluetooth Technology
1. Short press the Voice Control button on the multi-function
steering wheel.
2. After the chime say, “ Call, ” followed by the name of the person you
want to call. For example, “ Call John Smith. ”
3. The system will ask, “ Do you want to call John Smith? ” You then
reply “ Yes. ” If the contact has multiple numbers, select or say the
desired line number on the screen when prompted. Once selected,
the system will then say, “ Contact is being dialed. ”
Note: If connected to App-Connect, Apple Carplay, press and hold the Voice Recognition button to
activate Apple SIRI > then say, “Call Mike Brown.”
Voice
Recognition

Warning: See Time and Keyless Access in your Infotainment System Booklet for more detailed information and for important safety warnings.
To Set the Time in Your Vehicle
The clock can be set using the button in the Instrument cluster.
1. With the ignition on and vehicle in Park, press the button to highlight the hour or the minutes in the clock display.
2.
2
To advance the clock, push the button. Press and hold button to fast forward.
3. Push the button again to finish setting the clock.
1
2
Setting the Clock
1
Customize which Doors to Unlock with Keyless Access
1. Make sure the vehicle is parked. The vehicle will not allow you to
customize Keyless Access while driving.
2. Using the horizontal steering wheel buttons , select
Settings from the Instrument cluster.
3. Select Convenience .
4. Select Central Locking .
5. Select Unlock doors and select which doors to lock or unlock with
keyless entry.
"All doors" unlocks all doors.
"Single Door" unlocks only the driver's door.
"Vehicle side" unlocks only the door(s) on the side where the key is at the moment.
Watch the Keyless Access video.
Unlock
1. Make sure you have your key fob with you.
2. Slide hand behind driver or front passenger door handles and wait
for the door to unlock. Avoid touching the indent on the front of
the handle or the door will remain locked.
3. By touching the unlocking sensor twice in a row, the entire vehicle
will unlock.
4. PuII the handle to open door.
Keyless Access
Lock
1. Make sure you have your key fob with you.
2. Touch your thumb to the lock depression on the handle.
Keyless Access/
Time
Watch the Setting the Clock video.

Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
5 1 012 003 AJ
MY22-Passat-01 | Volkswagen Customer Care Center [phone]
© 2021 Volkswagen of America, Inc. "Volkswagen" and the Volkswagen logo are registered trademarks of Volkswagen AG. All other trademarks are the property of their respective owners.
Never ignore warning lights or text WARNINGS
Always stop the vehicle as soon as it is safe to do so
Park the vehicle at a safe distance from moving traffic and where no part of the hot catalytic converter and exhaust system can come into contact with flammable materials under
the vehicle, such as dry grass, brush, spilled fuel, etc.
A broken-down vehicle presents a high accident risk for itself and others. Switch on emergency flashers and set up a warning triangle to warn oncoming traffic.
Before opening the engine hood, always switch off the engine and let the engine cool down.
Always be very careful when working in the engine compartment, which is a potentially dangerous area in any motor vehicle and can cause serious personal injury.
•
•
•
•
•
•
Charge level of the mobile phone battery. Applies only to
models with a factory-installed mobile phone package.
Icy road warning. Outside temperature colder than +39 °F (+4 °C)
Service reminder display
When displayed in white, ACC is active. Vehicle detected
ahead. When displayed in grey ACC is not active. Vehicle
detected ahead. System switched on, doesn’t regulate.
Cruise control malfunction
ACC is active. No vehicle has been detected ahead
High beams switched on or headlight flashers in use.
Lane Assist switched on and ready.
Cruise control is regulating vehicle speed. Or Adaptive Cruise
Control (ACC) switched on.
Cruise control is regulating vehicle speed. Or Adaptive Cruise
Control (ACC) switched on.
Lights up: Depress brake pedal! Flashes: The lock button in the
selector is not engaged.
Daytime running lights (DRL) on
Daytime running lights (DRL) on
Fog lights switched on (indicator light on the headlight
switch).
Turn signals, left or right. Emergency flashers switched on
Lane Assist switched on
Blind Spot Monitor malfunction
Passenger front airbag turned OFF
Passenger front airbag turned OFF
Airbag and safety belt pretensioner system malfunction.
Lights up: Engine oil level too low. Flashes: Engine oil system
malfunction.
Fuel filler cap not properly closed.
Fuel tank almost empty.
Fuel tank almost empty.
Tire pressure too low or Tire Pressure Monitoring System
(TPMS) malfunction.
Lights up or flashes: Problem with the steering.
Engine control malfunction
Lights up or flashes: Engine control / monitoring system
malfunction (engine Malfunction Indicator Light - MIL).
Not enough windshield washer fluid.
One or more driving lights burned out. Cornering light
malfunction.
ABS malfunction
ABS malfunction
Lights up: ESC malfunction or ESC switched off by the system.
Flashes: ESC or ASR is working.
Lights up: ESC malfunction or ESC switched off by the system.
Flashes: ESC or ASR is working.
Brake! Depress brake pedal. ACC driver intervention warning.
Front brake pads worn.
DSG® transmission too hot.
Alternator malfunction.
Driver and/or passenger safety belts not buckled.
Stop! Lights up or flashes: Steering system malfunction.
Stop! Trunk lid is open or not closed properly.
Stop! Engine hood is open or not closed properly.
Stop! At least one vehicle door is ajar or not closed properly.
Stop! Engine oil pressure too low.
Stop! Lights up: Engine coolant level too low, too high,
coolant temperature too high, or engine coolant system
malfunction. Flashes: Engine coolant system malfunction.
Stop! Brake fluid level too low or brake system malfunction.
Stop! Brake fluid level too low or brake system malfunction.
Stop! Parking brake engaged.
Stop! Parking brake engaged.
Central warning light: Read and follow the text message in
the instrument cluster display.
Warning/
Indicator Lights
For additional information on indicator lights, refer to your vehicle's Owner's Manual.
