Volkswagen Taos 2022 User manual

2022 Taos
Quick-Start Guide

*Available on select trim lines.
8. Remote Start* (not shown)
If your vehicle is equipped, the engine can be started
from outside the vehicle with the Remote Start button,
allowing the HVAC system to heat or cool the interior.
On your key fob, press the Lock button, then the Remote
Start button twice.
Requires VW Car-Net Mobile App and compatible factory-installed or dealer-installed
remote start feature. See Owner’s Manual for further details and important warnings
about the keyless ignition feature. Do not leave vehicle unattended with the engine
running, particularly in enclosed spaces. Consult local laws for any limitations on use.
Standard text and data rates may apply.
7. Steering Wheel Right Side Controls
Voice Control Button: Activates the Voice
Recognition System. A short press will activate
Volkswagen Voice Control.* A long press will
activate third party voice control with a compatible
smart phone connected to App-Connect.
VIEW Button: switches between wide and
standard display.
OK Button: Used to select settings for features in
the Digital Cockpit.
Horizontal Menu Buttons: Used to navigate
through the Digital Cockpit main menus.
Vertical Arrow Buttons: Push to navigate inside a
specific menu.
Horizontal Arrow Buttons: Push to change radio
stations, scroll through radio presets or select the
next or previous media track.
9. Refueling
In order to refuel, you must first unlock the fuel filler flap
by pressing the button on the driver ’ s door.
1. Digital Cockpit/Instrument Cluster*
Displays vehicle system and function information. You can
customize the display using the multi-function steering
wheel controls.
2. Infotainment
Touch-sensitive icons that control the various
Infotainment functions, including radio, media
selections, the App-Connect function, phone operation,
vehicle functions and the optional Navigation system.
3. Start-Stop System
When the light is off the system is activated. System is
deactivated when the light is on. Start-Stop is
automatically activated when the ignition is switched
on. See operating conditions in Owner ’ s Manual.
4. USB-C Port
USB Type C ports allow you to connect your mobile
phone to your Taos using the latest generation of USB. To
utilize USB Type C, you must have a compatible cable. To
find a cable that converts your phone ’ s charging port to a
USB Type C connector, click here .
5. Wireless Charging
This feature can charge a Qi-capable mobile phone without
the need to plug in a cable. Simply place it securely in the
center of the surface with the display facing up. The
Infotainment system will indicate when charging begins.
6. Steering Wheel Left Side Controls
Buttons for operating the Cruise Control and Adaptive
Cruise Control,* as well as radio volume settings,
Navigation system notifications and phone calls.
Introduction to
Your Taos
The information within this guide must be used in conjunction with the information in the Volkswagen Owner’s Manual. You should refer to your vehicle’s Owner’s Manual
and Infotainment System Booklet for all information, warnings and feature limitations. Always pay careful attention to the road and do not drive while distracted.
Some Infotainment features can only be accessed and operated when the vehicle is standing still.
12
3
45
67
9
Optional features shown.

Warning: See Driver Assistance Systems in your Owner's Manual for more detailed information and for important safety warnings. Driver Assistance
features are not substitutes for attentive driving.
Assistance System Setting
If your vehicle is equipped with Driver Assistance features, you can
access the Assistance system settings menu in the Infotainment
system, allowing you to modify Driver Assistance feature operation.
1. Press Menu.
2. Press the Assist Syst. icon on the display.
3. Touch the image that represents the feature.
OR
Touch to access Assistance system settings .
Dramatization
Watch the Deactivate ACC video.
Deactivating Adaptive Cruise Control
To deactivate Adaptive Cruise Control, and use Conventional Cruise
Control:
Applies to vehicles equipped with Adaptive Cruise Control.
1. Press the button. Depending on vehicle equipment it may be
on the steering wheel or the end of the turn signal stalk located on
the left side steering wheel controls.
2. Using the vertical menu buttons on the steering wheel, scroll
to Speed .
3. Select Cruise Control in the Digital Cockpit then press the
button.
Adaptive Cruise Control is now deactivated, and your vehicle will
maintain the set speed using conventional cruise control.
Watch the Adaptive Cruise Control video.
Note: This feature is not a substitute for attentive driving. See the Owner’s Manual for further details and important limitations.
When the ACC button is pressed to set distance level, the indicator light illuminates in the Digital Cockpit.
To change the ACC distance level, press the button to cycle through the distance intervals. When the shortest interval
is reached, the distance returns to the greatest interval when the button is pressed again.
When the ACC system brings the vehicle to a stop for more than 3 seconds, briefly press the accelerator pedal to resume
Adaptive Cruise Control.
Adaptive Cruise Control Distance Level Setting
Adaptive Cruise Control (ACC) helps maintain an individually stored constant speed and a previously set distance in time
intervals between your vehicle and those in front of you. When you approach a slower moving vehicle, your vehicle may brake if
the situation requires. When the vehicle is no longer present, ACC will accelerate back to the stored speed.
You can set the speed-dependent distance from the vehicle ahead to one of five levels.
Applies to vehicles equipped with Adaptive Cruise Control.
Press twice.
Turning Cruise Control System Off
1. To cancel the cruise speed, press the brake pedal or press the button once on the multi-function steering wheel.
2.
The green cruise control indicator light will disappear.
3. To resume your set speed, press the RES button on the multi-function steering wheel.
Cancel and Resume Cruising Speed
1. When you get to your cruising speed, press the SET button on the multi-function steering wheel.
2. A green cruise control indicator light will appear in the Digital Cockpit.
3. To increase/decrease the speed by 1 mph increments, press the + or - button.
4. To increase/decrease the speed by 5 mph increments, press and hold the + or - button.
Set Cruising Speed
Cruise Control
Locate the Cruise Control buttons on the left side of the multi-function
steering wheel.
Press the button to activate Cruise Control.
A speedometer icon will appear in the Digital Cockpit.
Watch the Cruise Control video.
Driver Assistance
Features
2. To cancel the cruise speed, press the brake pedal or press the button once on the multi-function steering wheel.
3.
To cancel the travel assist, press the brake pedal or press the button once on the multi-function steering wheel.
4. To resume Travel Assist, press button on the steering wheel.
The Comfort Travel Assist system, within the system limitations, can maintain a distance, which has been preselected by the
driver, to the vehicle in front and stay within the lane.
Note: Pressing the RES button will only resume ACC capabilities, and not lane centering.
Warnings: See Driver Assistance Systems in your Owner’s Manual for more detailed information and for important safety warnings.
Applies to vehicles equipped with Travel Assist.
Travel Assist System
1. To enable, press the button on the steering wheel at the desired speed.

Car-Net Plus Navigation
With real-time information,* navigation is even smarter: keep up-to-date with practical details such as online traffic
information, route calculation and map updates. Constantly updated data provides you with useful information and ensures
the best possible route to your destinations.
* Availability is subject to your mobile network provider’s network coverage. Requires additional paid subscription.
Alternative Navigation
Turn-by-turn directions are also available by mirroring your favorite smartphone app to your Infotainment screen. Using the
maps app on your device, you can connect to Volkswagen App-Connect wirelessly if available, or you can connect by using a
manufacturer-approved USB-C cable.
Cancel Active Route Guidance
1. Press Stop Route Guidance directly.
OR
1. Select Menu icon in the Navigation screen.
2. Select the Stop Route Guidance option on the touchscreen.
Point of Interest (POI)
To find a specific point of interest:
1. Press the NAV icon. Then press on the touchscreen to open the
keyboard function to search POIs.
2. Search for your desired POI i.e., airport.
3. Select Start to begin route guidance.
OR
1. Press the NAV icon, then select a POI currently displayed on the
map (this is great for finding nearby fueling stations).
2. Select Start to begin route guidance.
Additional Settings
With Route Options you can:
*Requires the vehicle to be equipped with MIB3 Infotainment with navigation, an active data plan, vehicle cellular and GPS connectivity, as well as a VW Car-Net paid subscription
and acceptance of their Terms of Service.
Choose between 3 alternative routes, if available, by clicking on the route
info panel where the most recommended route is highlighted in blue.
Use Dynamic route guidance* if online traffic is available.
Before starting your route:
Route criteria can be modified by tapping .
After starting your route:
Modifications to the current route such as avoiding tolls or seasonal restricted roads are possible by tapping .
Route criteria can also be modified by tapping and selecting .
Note: Always pay careful attention to the road, and do not drive while distracted. SiriusXM audio and data services each require a subscription sold separately, or as a package by
Sirius XM Radio Inc. If you decide to continue service after your trial, the subscription plan you choose will automatically renew thereafter and you will be charged according to your
chosen payment method at the current rates. Fees and taxes apply. To cancel, you must call SiriusXM at 1-8 - 35-2349. See SiriusXM Customer Agreement for complete terms
at www.siriusxm.com. All fees and programming subject to change. SiriusXM and all related marks and logos are trademarks of SiriusXM Radio Inc.
Discover Media Touchscreen Navigation
Press the NAV icon on the touchscreen to open the Navigation Home
View . The Home View shows your current position in the middle of the
screen as a cursor that is situated in relation to the actual position of the
vehicle and five suggested destinations which are based off of your last
destinations, predicted destinations, favorites or imported destinations
from your Car-Net® app. The Home View map is oriented with north at
the top of the screen and the actual positions of the proposed (0-5)
destinations are relative to the actual position of the vehicle.
To search for a specific destination:
1. Select the search icon .
2. Begin entering a Point of Interest (POI) or address information with
House number, Street and City.
3. When your search address or POI appears in the dropdown suggestion
bar, select the correct address on the screen.
4. Select Start to begin the route.
Applies to vehicles equipped with the Navigation feature. When entering an address for another state,
use only the two-character abbreviation for the state. Entering a destination on the touchscreen or
changing any settings can only be done when the vehicle is stationary.
Collapse Button
Navigation/
Car-Net®
Pairing/Remote Start (available on select trims):
Log in to VW Car-Net mobile app with your VW ID and PIN.
On first log-in, accept the pairing request. If you do not receive this request, then you can initiate it by going to Manage
Paired Devices under the Account Management screen .
Accept the pairing confirmation in the vehicle ’ s display.
Remote start is now enabled.
Press to start the vehicle from any location.
1Applies to vehicles equipped with remote start feature.
2 Refer to your vehicle’s warning and indicator lights for the most current diagnostic information. Always consult owner’s literature for maintenance guidelines.
3 Do not use feature to locate stolen vehicle.
4 Must agree to separate Terms of Service.
5Applies to vehicles equipped with Navigation System.
Powered by Parkopedia. Requires parking facility participation. Volkswagen not responsible for accuracy of pricing & payment options, hours of operation, and features.
See parkopedia.com for important information and details.
7 Roadside Call Assist connects you to a Roadside Call Assist third-party provider and may require additional payment for services rendered.
8 Assistance can be provided by pressing the button in the vehicle’s overhead console.
*Available on most MY20 and newer vehicles. Always pay careful attention to the road and do not drive while distracted. Certain services require trial or paid subscriptions,
which may have their own terms and conditions. VW Car-Net requires cellular connectivity, availability of vehicle GPS signal, and acceptance of Terms of Service. Not all
services and features are available on all vehicles. Certain Car-Net services, such as Roadside Call Assist, connect out to 3rd party providers that may require additional
payment. Standard text and data rates may apply for app and web features. Certain services may collect location and vehicle information. See Terms of Service, Privacy
Statement, and other important information at www.vw.com/carnet.
Watch the Car-Net Mobile App Remote Start video.
Car-Net® Enrollment Process8 (if not performed by dealer):
Call [phone]
OR
Download the “ Volkswagen Car-Net ” mobile app from the App Store.
Select Login to register and create your unique VW ID.
Log in to Car-Net mobile app with your VW ID, complete your profile and create a PIN.
Add your vehicle to your Garage by entering VIN and follow the steps to verify ownership.
Mobile App
Remote Door Lock/Unlock
Remote Honk and Flash
Remote Start1
Last Parked Location3
Parking Information6
Maintenance Alerts & Scheduling
Vehicle Health Reports2
Vehicle Status2
DriveView4
POI/Destinations5
Curfew Alert
Valet Alert
Boundary Alert
Speed Alert
Roadside Call Assist7
VW Car-Net is your connection to available convenience features. The five year no
charge Remote Access* package allows you access to:
Volkswagen Car-Net
Watch the Car-Net Smart Nav Upgrades video.
Warning: See Navigation in your Infotainment System Booklet for more detailed information and for important safety warnings. Navigation is an optional feature
Warning: See VW Car-Net in your Owner's Manual for more detailed information and for important safety warnings.

Warning: Visit www.knowyourvw.com/bluetooth to view more detailed information and important safety warnings for Bluetooth Pairing.
Warning: See Voice Control in your Infotainment System Booklet for more detailed information and for important safety warnings.
Destination Entry with Voice Recognition
1. Short press the Voice Contro l button on the multi-function
steering wheel. A beep will sound.
2. Say, “ New destination. ”
3. After the beep, speak the address. For example, “ Two zero two
four Main Street, Los Angeles. ” Speak in single digits.
4. The system will repeat the address for confirmation and ask if
you would like to start route guidance.
Cancel Active Voice Recognition or an Active Route
Double press the Voice Control button on the multi-function steering wheel to end Voice Recognition. To end an active
route, short press the Voice Control button and say “ Cancel destination ” after you hear a beep.
End a Call
If you are in the Phone Menu function, press the red Phone icon on the touchscreen. Or:
1. Use the Horizontal Menu buttons on the multi-function steering wheel to access the Phone menu in the Digital
Cockpit.
2. Press the Vertical Arrow buttons until “ End ” appears in the display.
3. Press the button on the multi-function steering wheel.
Switch to Private Mode
To prevent passengers from overhearing a conversation, switch a
Bluetooth call to your mobile phone:
1. Once a call has been answered, use the Horizontal Menu buttons
on the multi-function steering wheel to customize the instrument
cluster display.
2. Use the Vertical Arrow buttons on the right side multi-function
steering wheel to scroll to the Telephone menu.
3. Use the horizontal menu buttons to open the Telephone menu.
4. Use the vertical menu buttons to scroll to Private and select with the button.
Volume Settings
To adjust the volume of the Bluetooth system while on a call, press the Volume Up or Volume Down button on the left
side of the multi-function steering wheel.
Answer an Incoming Call
The Bluetooth system will interrupt your car stereo with a ringtone. Press the button on the multi-function steering wheel
or the green Phone icon on the Infotainment touchscreen to answer the call.
Voice Recognition Tips
The contact must be said exactly as it is stored in your phone ’ s contact list.
If multiple numbers are stored per contact, you may use the shortcut, “ Call John Smith work, ” or the system may ask you to
choose: work, mobile, home, etc.
Call by Name via Native Bluetooth Technology
Applies to vehicles with Voice Recognition feature.
1. Short press the Voice Control button on the multi-function
steering wheel.
2. After the chime say, “ Call, ” followed by the name of the person you
want to call. For example, “ Call Mike Brown. ”
3. The system will confirm, “ Do you want to call Mike Brown? ” You
then reply, “ Yes. ” If the contact has multiple numbers, select or say
the desired line number on the screen when prompted. Once
selected, the system will then say, “ Contact is being dialed. ”
Note: If connected to App-Connect, Apple CarPlay, press and hold the Voice Recognition button to activate Apple Siri > then say, “Call Mike Brown.”
Note: This feature is not available when the phone is connected to App-Connect, Apple CarPlay®or Android AutoTM.
Primary and Secondary Phone Functionality
Two active phones can be connected simultaneously. Follow steps 1-7 above. Only contacts from the primary phone will be
shown within the Infotainment system. Switching between phones requires pressing the Swapping icon .
Bluetooth Technology/
Voice Recognition
Pairing a Compatible Phone
1. With the ignition on and the vehicle in Park, turn the Infotainment
system on. Your vehicle ’ s Bluetooth system will be in “ discovery ”
mode.
2. From the Bluetooth menu on your phone, search for new devices
and select XXXX (last four digits of VIN).
3. A connection request will appear on the Infotainment touchscreen
display.
4. Press Connect on the Infotainment touchscreen.
5. The touchscreen will then show a PIN.
6. Make sure the same PIN is displayed on your phone and press Yes
on the Infotainment touchscreen, then press Pair on your phone.
7. Allow contacts to Sync when prompted.
Note: If your phone displays a prompt asking to connect to your vehicle, make sure to enable future automatic
connections. This will help to automatically reconnect the compatible paired device to the system. Once the PIN
is shown, pairing must be completed within 30 seconds; otherwise, the process will need to be repeated.

Warning: See App-Connect in your Infotainment System Booklet for more detailed information and for important safety warnings.
Features
1. Google Assistant: Use your voice to easily send messages, get
directions, control media and more. Just say “ Hey Google, ” long-press
the Voice Control button on the multi-function steering wheel, or
tap the Microphone icon on the touchscreen to get started.
2. Navigation: Predictive navigation provides turn-by-turn directions,
traffic conditions and estimated travel time. Android Auto can predict
where you want to go next based on your calendar and recent
destinations.
3. Phone: Listen and reply to text messages, make calls or check your
voicemail.
4. Home Screen: Takes you back to the home screen of Android Auto.
5. Music and Audio: Use your touchscreen to access your favorite artists, songs and playlists. Android Auto lets you stream
from apps such as Pandora, Spotify and iHeartRadio.
1
2 3
4
5
Tapping the Exit icon simply takes you to the Volkswagen native user interface, then select Disconnect if you wish to
completely disconnect from Android Auto.
Android Auto ™
Use some of your favorite Android ™ applications on the road through your Volkswagen ’ s Infotainment screen. You can talk to
Google on Android Auto to get driving directions, send a text, or place a hands-free phone call. Android Auto is made to help
you focus on the road while having fun along the way.
1. Ensure you are running the latest Android ™ OS on your device and download Android Auto from the Google Play Store. An
active Google Account and an internet connection is required. If you ’ re using Android 10 or higher, the app is already on your
phone.
2. Plug your Android phone into the USB port using a certified USB Cable.
3. Press the App key on the touchscreen.
4. Select Android Auto on the touchscreen. Ensure your phone is unlocked OR pair your Android phone to your Infotainment
system ’ s Bluetooth connection. Then, select Use Android Auto .
5. At the data transfer prompt, select OK on the touchscreen.
6. Follow the instructions on your device to continue setup.
7. Android Auto will appear on the Infotainment touchscreen once all the prompts have been accepted on your device.
Google, Android, Google Play and Android Auto are trademarks of Google LLC. Click here for further information.
To use Android Auto on your car display, you’ll need an Android phone running Android .0 or higher, an active data plan and the Android Auto app.
Watch the Android Auto USB video.
Wireless App-Connect Android Auto
To connect:
Note: Please confirm all prompts from Android Auto on the mobile device for successful Android Auto
connection.
1. Pair your phone to the Volkswagen Infotainment system with Bluetooth.
2. Select Use Android Auto or select Cancel for Bluetooth connection.
Watch the Android Auto Wireless Connection video.
Features
Apple CarPlay features Siri voice control. Siri must be enabled on the
device to use Apple CarPlay. There are two ways to activate Siri:
1
2 3 4
5
Press and hold the Voice Control button on the multi-function
steering wheel until you hear the tone, which activates Siri.
Press and hold Home on the touchscreen to activate Siri.
1. Home features include:
Return to the Apple CarPlay home screen or to the Apple CarPlay
Dashboard.
Long press to activate Siri.
2. Phone: Siri can help you make calls, return missed calls and listen to voicemail.
3. Maps: Opens Apple Maps for turn-by-turn directions, traffic conditions, immersive 3D experiences and estimated travel time.
Siri can also help with directions. Activate Siri and say, “ Navigate to, ” and your destination.
4. Messages: Siri can send, read and reply to your text messages for you.
5. Tapping the Volkswagen Logo icon simply takes you to the Volkswagen native user interface with all the features and functions
of Apple CarPlay still active.
To charge iPhone only, disconnect from Apple CarPlay by pressing the Volkswagen Logo icon, then select Disconnect on the
touchscreen. This will allow Bluetooth® access while charging your iPhone.
*Always pay careful attention to the road, and do not drive while distracted. Not all features are available on all operating systems. Standard text and data usage rates apply.
App-Connect features require a compatible device, operating system and mobile apps. See mobile device and app providers for terms and privacy.
Click here for further information on Apple CarPlay apps.
Apple CarPlay®
Apple CarPlay is a smarter way to use your iPhone while you are in your
Volkswagen. With an updated user interface that helps you control
tunes, directions and Siri®suggestions, a calendar app that lets you view
and manage your day, and maps that can reveal more of what ’ s around
you, getting there just got a whole lot easier — and a lot more fun.*
1. Ensure you are running the latest iOS on your device.
2. Unlock your iPhone and plug it into the USB port using a certified
lightning cable.
3. A message will appear on the touchscreen display stating that a new device has been detected. It will ask, “ Do you want to
connect with Apple CarPlay? ” Select Connect .
OR
1. Pair your iPhone to your Infotainment system ’ s Bluetooth connection. When the “ Select a connection technology ” pop-up
appears, select Apple CarPlay .
2. Select “ Allow ” on your iPhone to enable Apple CarPlay to access your iPhone while your iPhone is locked.
Watch the Apple CarPlay USB video.
Note: You will have to have had an unlocked iPhone within the past hour in order to use Apple CarPlay. When you are connected using Apple CarPlay, your iPhone can no longer be
used as a MEDIA source or as a Bluetooth device. Apple CarPlay is compatible with iPhone 5 or higher running iOS 7.1 or later. Further information can be found at support.apple.com
and siriuserguide.com. Apple CarPlay is a trademark of Apple Inc.
Wireless App-Connect with Apple CarPlay Integration
To connect:
1. Pair your phone to the Volkswagen Infotainment system with Bluetooth.
2. A prompt will display the vehicle touchscreen asking if you want to
use Bluetooth or Apple CarPlay.
3. Select Apple CarPlay. If this is the first time, accept the confirmation
on your iPhone®.
OR
1. Simply unlock your iPhone and plug it into the USB port using a certified
lightning cable. After choosing to use Apple CarPlay, your iPhone will
ask if you ’ d like to use Apple CarPlay wirelessly for future connections.
Note: Please confirm all prompts from App-Connect on the mobile device for successful Apple CarPlay connection.
Watch the Apple CarPlay Wireless Connection video.
Volkswagen App-Connect makes your Volkswagen more like a personal assistant. To start App-Connect, pair your smartphone
to your VW ’ s Bluetooth and watch as your select apps appear on the touchscreen display. Once paired, you will have access to
all your apps without having to take your phone out of your pocket or purse. Need a couple extra bars on your phone ’ s battery?
Get a charge beyond just your driving experience. Plug your phone into your VW ’ s USB port, and enjoy all the same access.
App-Connect

Warning: See TPMS, Keyless Access and Wipers in your Infotainment System Booklet for more detailed information and for important safety warnings.
Service Position
With hood closed and ignition off, press and hold the windshield lever down. Wipers will move into the service position. Lift
wipers by arm away from windshield. Before driving, fold wiper arms back onto the windshield. Turn ignition ON, and press the
wiper level down briefly. The wipers will move back to the park position.
Rear Wiper
To operate, push the lever one click away from you. If you have the front wipers on and you put the car in reverse, the rear
wiper activates in a single wipe.
Continuous
LOW : From the OFF position, move the wiper stalk up two clicks.
HIGH : From the OFF position, move the wiper stalk up three clicks.
Rain-Sensing Wipers
To activate and deactivate wipers within the Infotainment touchscreen.
Note: Applies to vehicles equipped with rain sensors.
1. Select Car .
2. Select Settings .
3. Select Mirror and wiper settings .
4. Select Automatic wiper during rain . A check mark indicates it is active.
Intermittent
From the OFF position, move the wiper stalk one click up to activate
the intermittent wipers with rain-sensing.
The switch on top of the stalk varies the time interval between each
wipe.
The farther the switch is moved to the right, the shorter the interval
between each wipe will be.
Note: Ensure wiper stalk is in OFF position before entering a car wash.
Windshield Wipers and Washer
Watch the Windshield Wipers video.
Customize which Doors to Unlock with Keyless Access
1. Make sure the vehicle is parked. The vehicle will not allow you to
customize Keyless Access while driving.
2. Select CAR from the Infotainment touchscreen.
3. Select Settings .
4. Select Open and close settings .
5. Select Unlock doors and select which doors to lock or unlock with
keyless entry.
"All doors" unlocks all doors.
"Single Door" unlocks only the driver's door.
"Vehicle side" unlocks only the door(s) on the side where the key is at the moment.
Unlock
1. Make sure you have your key fob with you.
2. Push the button on the door handle once to unlock driver's door.
3. Pull the handle to open door.
Keyless Access
Lock
1. Make sure you have your key fob with you.
2. Push the button once on the door handle to lock all the doors.
Tire Pressure Monitoring System (TPMS) Recalibration
The TPMS must be recalibrated each time the tire pressure in one or more
tires has been adjusted or after one or more tires has been changed,
exchanged or repaired. The new tire pressures are stored in the system
after at least 20 minutes of normal driving. To recalibrate the TPMS:
1. Turn the ignition ON.
2. Press the CAR button on your touchscreen
3. Select Settings on the touchscreen.
4. Select Tire settings.
5. Select Set.
6. Select Confirm to store.
Watch the TPMS video.
TPMS
TPMS/Keyless Access/
Wipers

Eco driving mode
Normal driving mode
Individual driving mode
Sport driving mode
Service due
High beams or headlight flasher
Lane Assist active
Speed stored,
regulation active
Press the brake pedal
Speed stored,
Regulation active
Trailer turn signal
Turn signals
Collision warning deactivated
Lane Assist in control
Engine coolant temperature too high
High beam control active
Autonomous Emergency Braking starts
Distance warning
Cruise control system malfunction
ACC is regulating
No vehicle driving ahead is detected
ACC is regulating
Vehicle driving ahead is detected
Hill descent assist
Offroad driving profile
Offroad Custom driving profile
Mobile phone connected via Bluetooth
Outside temperature is below +39 (+4 C)
Snow driving mode
Mobile phone battery charge level
Cruise control system is switched on
Start/Stop system active
Start/Stop system not available
Economical driving condition
Blind Spot Monitor active
Windshield wiper malfunction
Engine oil level too low,
Engine oil system malfunction
Tank almost empty
Adaptive Cruise Control (ACC) not available
Transmission malfunction
Engine RPM limited
Tire pressure too low
Tire Pressure Monitoring System (TPMS) malfunction
Steering malfunction
Particulate filter clogged with soot
Exhaust system malfunction
Washer fluid level too low
Driving light failure
Anti-Lock Braking System (ABS) malfunction
Anti-Lock Braking System (ABS) malfunction
Electronic Stabilization Program (ESC) or
Anti-Slip Regulation (ASR) is regulating
Electronic Stability Control (ESC) has been switched off due to
system requirements
Rain/light sensor malfunction
Anti-Slip Regulation (ASR) switched off,
ESC Sport switched on
Check brake system
Central warning light
Malfunction in the emergency call system
Limited function in the emergency call system
Electronic parking brake malfunction
Collision warning
12 V vehicle battery
Rear Traffic Alert has detected an obstacle to the rear
Steering malfunction
Engine coolant system malfunction
Engine oil level too low
Engine oil pressure too low
Take over steering and be ready to brake
Check brake system
Brake system malfunction
Brake fluid level too low
Brake system malfunction
Electronic parking brake
Electronic parking brake
Fasten safety belt
Central warning light
Warning/
Indicator Lights
For additional information on indicator lights, refer to your vehicle's Owner's Manual.
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
MY22-Taos-01 | Volkswagen Customer Care Center [phone]
© 2021 Volkswagen of America, Inc. "Volkswagen" and the Volkswagen logo are registered trademarks of Volkswagen AG. All other trademarks are the property of their
respective owners.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
Park the vehicle at a safe distance from moving traffic and where no part of the hot catalytic converter and exhaust system can come into contact with flammable
materials under the vehicle, such as dry grass, brush, spilled fuel, etc.
A broken-down vehicle presents a high accident risk for itself and others. Switch on emergency flashers and set up a warning triangle to warn oncoming traffic.
Before opening the engine hood, always switch off the engine and let the engine cool down.
Always be very careful when working in the engine compartment, which is a potentially dangerous area in any motor vehicle and can cause serious personal injury.
•
•
•
•
•
•
