Voll V-MGC Digital User manual

ZERO HVAC SUPPLIER LLC
925 Flushing Avenue, 2/FL Brooklyn, NY 11206
Tel: [phone]
Fax: [phone]
www.zerohvac.com
[email protected]
Multi-function Digital Manifold Gauge Set Operation Manual
V-MGC Digital

V-MGC Digital
CONTENTS
1.Safety and Environment ..................... P01
2.Technical Manual ................................ POЗ
3.Product Descriptions
......................... POS
4.1 n itial Operation .................................. РО7
5.Product Operations ............................ P08
6.Product Maintenance ......................... P15
7.Tips and Help ...................................... P16
8.Accessories ........................................ P16

V-MGC Digital
6.6 Change valve ог valve position controller
AwдRNINGI
ForЬid to replace the valve ог knob personally without direction.
lf broken, please send it to local distributor to repair ог replace.
7 Tips and Help
ProЫem causes/solution
О Screen flicker
The batteries almost run out
>Change battery
Turn the unit off 1.low batteries
automatically >Change battery
2. System's self-protection of power saving
>Restart the unit
lllumining "full" Exceed the measurement range
>ОЬеу to the permitted measurement range
8 Accessories
ltem name
201301 Temperature measuring clips
201302 3*1.5m charging hoses (red,
yellow and Ыuе)
201303 Quick coupler
201404 Exhaust valve саге
201305 Settled hook
Р16
V-MGC Digital
1.Safety and Environment
1.1 About this manual
Precautions for using
>Please read the manual carefully before using the unit.
Рау special attention to caution and warning, in case
of causing injury and damaging the unit
>Take this manual in hand in order to read it anytime.
>Please hand it over the later users.
Symbol and its meaning
Symbols
А
l
1 ....
2 ....
>...
-...
"
...
meanings
WARNING! Мау causes а severe injury
CAUTION! Мау causes а slight accident that would
lead the equipment damage
>The precautions would Ье taken
NOTICE: Basic information ог detail information
OPERATION: А multi-step operation must
operate step Ьу step
OPERATION: Опе step operation ог optional step operation
Result
Sample item
РО1

V-MGC Digital 1.2 Safety
specification
>Don't operate the instrument if its shell, power unit or
power line are damaged.
>Do not measure the electrical parts Ьу hand touch.
>Do not put this instrument and chemical solvent together.
Do not use any desiccant.
>Only according to this manual to maintain and repair the
instrument. Only use our company's original parts.
>The object and environment may Ье threatened from risk.
Ве sure to рау attention to comply with the local safety
specification when implement measures.
>lf the instrument is fall off or bumped Ьу machine, it сап
also causes the damage of charging hoses and control
valve. You may not judge the damage from surface.
For security, please change new charging hose in time or
you сап send it back to our company to repair it.
1.3 Protect the environment
>According to the legal laws and regulations to deal with
the rechargeaЫe battery and used battery.
>Before the end of its lifetime, send the unit to а separate
space that is used to collect the electronic appliance and
electronic equipments or you сап send it to local
distributor or retailer.
>Refrigerant gas is harmful to the environment. Please рау
attention to comply with the environment regulations.
РО2
V-MGC Digital
6 Product Maintenance
6.1 Clean the instrument
> The unit may Ье cleaned with а shop towel moistened
with water;
Do not use cleanser or solvent of any kinds. А mild
detergent is allowed.
6.2 Кеер the screwed clean
>Кеер the screwed pipe fitting clean, wipe off grease
and some other adhesive dirty with а moistened towel.
6.3 Wipe off the residual oil
>Use а compressor to Ыоw away all the residual oil in
the valve systems carefully.
6.4 Ensure the measurement accuracy
We'd Ье pleasure of serve you as your wishes
>То examine the unit at fixed period (once а year),
and оЬеу the pressure range.
>То calibrate the unit at fixed period (once а year).
6.5 Change batteries/rechargeaЫe batteries( Figure С)
..J Turn off the unit
1.Turn over the hook, loosen the lock and take down the
batteries' cover.
2.Remove the old batteries/ rechargeaЫe batteries; install
the new batteries /rechargeaЫe batteries into battery
socket.
3.Close the batteries'cover and lock it.
Р15

V-MGC Digital
Figur e В
Тhrottle ( expansive valve,cap,fixed valve)
АВе careful using and wear safety glasses
То оЬеу the introduction when using or installing the instrument
5.2.6 The goal of overheating and undercooling
According to manufacturer specifications, warning and
suggestion, to confirm overheating (standing valve system)
ог undercooling (related to different systems) needs outdoor
air temperature, indoor temperature and manufacturer's
diagram including overheating and undercooling.
You сап use а thermo-hygrometer to measure the
temperatures both indoor and outdoor.
То approach the entrance of the evaporator as close as
possiЫe is to measure the indoor temperature;
То approach the entrance of the condenser as close as
possiЫe is to measure the outdoor temperature.
Р14
V-MGC Digital
2.Technical Manual
2.1 Usage
V-MGC Digital is а electronic manifold gauge, used for the
maintenance of refrigerating system and heat pump. This
instrument only provide for the professors to use.
V-MGC Digital replaces the mechanical instrument pipe,
thermometer and pressure-temperature graph depends оп
its unique function. lt applies to testing and monitoring
pressure and temperature.
V-MGC Digital is compatiЫe with many non-corrosive
refrigerants, water and Glycol; however, it's incompatiЫe
with ammonia refrigerant.
Do not use it in а dangerous environment where would
Ье exploded.
РОЗ

V-MGC Digital 2.2 Technical
data
Characteristics
and parameters
Measured
parameters
Temperature
ргоЬе
Cycle
measurement
Connector
Measurement
range
Overload
Accuracy
Optional
refrigerant
Measured
medium
Environmental
conditions
Shell
Characteristics
and parameters
Power
Screen
Warranty
data
Pressure: psi/kPa/bar/inHg
Temperature: °F/°C
Vacuum: Micron/kPa
2
0.33s
Compression fitting: 3*7/16UNF (1/4"SAE)
Low pressure: О-50Ьаг
High pressure: О-50Ьаг
Temperature: -20-70°С (-4-158°F)
Vacuum degree: 0-1 OOkPa
754psi, 52Ьаг, 5200kPa, 5.2МРа
Pressure: ±0.5% of full scale
Temperature: ±О.5 °С
Vacuum degree: ±5Micron
R 134a.R14,R141B,R143A,R152,R170,R21,R218,R22,R227,R245,R290,
R32, R401A,R401 В, R401 С, R402A, R402B, R403A,R403B, R404A, R405A,
R406A,R407 А, R407B, R407C, R408A, R409A,R409B, R41 ОА, R41 ОВ, R41,
R411A,R411 B.R412A,R41 ЗA,R414A,R415A,R417 A,R50,R500,R501,R502,
R503,R504,R507,R507A,508A,R508B,R509A,R600A.R744,R11,R113A,
R114,R115,R116,R12,R123,R123A ,R124,R125,R13,
Measured medium: 68 types
lmmeasuraЫe medium: R717 and other ammonia refrigerants
Working temperature:5-122°F/-15- 50°C
Storage Temperature: ±О.5 °С
Environment humidity: 10-90%rF
Material: АВS/РА/ТРЕ
Size: 190 х 140 x80mm
Weight: 800g(without batteries)
DATA
5*1.5v АА rechargeaЫe batteries
Lifetime: 150hours(No backlight)
LED , 0.5s (response time)
1 year
РО4
V-MGC Digital
5.2.5 Measurement about overheating and supercooling ( see figure В)
Overheating: it means the differences between the actual temperature
after the refrigerant leaving evaporator (sensor temperature) and the
boiling temperature in evaporator.
After the refrigerant boiling, the temperature keep heating up, the
temperature that exceeds the boiling is the degree of overheating. lf
under the worst circumstances (underloading fixed valve system), the
refrigerant must Ье evaporated completely when it nears Ьу the ending
of evaporator. ln this case, to prevent the liquid refrigerant from entering
into compressor is necessary.
The manufacturer of refrigerant system provides graph data that marks
the degree of superheat under the condition of indoor humidity's
temperature and outdoor air temperature.
То measure overheating is the most useful to repair fixed valve system
and judge the quantity of recharging the refrigerant and the proper
operating environment.
lf the degree of overheat is too high while others figure аге normal,
means to charge the refrigerant. Оп the contrary, reduce the refrigerant.
Supercooling: lt means that the differences between the refrigerant
boiling temperature in condenser and the actual temperature when
the refrigerant leaves condenser. The degree of supercooling is the
temperature under the boiling temperature. Under the worst
circumstances, the degree in underloading TXW would Ье lower.
lf the degree is down too fast, the liquid will backflow into the
compressor and damage it. ln the system with expansion valve
(TXV) , the degree of supercooling is the most useful information
of charging status. The purpose of this design is to ensure the constant
degree of superheat. А suitaЫe filling capacity сап extend the
system's lifetime and ensure the system's work efficiency.
Р13

ZR-M550 Operation Manual
NOTICE: Vacuum display will close automatically within
30 seconds. So restart it Ьу press the power button ог
vacuum button. lt needs 3 to 5 seconds to initialize
and vacuum data display(Please restart the instrument
if the pressure, temperature ог vacuum has been
worked for а long time)
FigureA
U se the Ыuе hose to
АIMPORTANT NOTICE
То connect the vacuum pump to the system directly
when testing а leakage less than 1 ООО Microns in
high vacuum status.
То use а соррег pipe (with hosepipe) and high
vacuum shut-off valve if need extra connecting.
Р12
ZR-M550 Operation Manual
3 Product Descriptions
3.1 Display element and control element
Temperature unit
Тетр difference
Button
Sight glass
tf \.
l/4"SAE,Low side / 'f'"'tvalve l/4"SAE,1Iigh side
l/4"SAE,connect gas cylinder
3.2 Кеу instructions
Picture of operation panel
РО5

КЕУ
V-MGC Digital
1 nstruction
Power key :Press for more than two seconds, into the
measurement screen
Mode key: Press this key, the picture shows the minimum
pressure, the minimum temperature difference and the
minimum temperature from the start to this time.
То press the mode key again, the picture shows the
maximum pressure, the maximum temperature difference
and the maximum temperature from the start to this time;
То press the key at third time shows the average pressure,
the average temperature difference and the average
temperature from the start to this time.
lf Main interface shows pressure before operation,
Press this key to ZERO
Press this key turn оп the LCD light, that would Ье turn
off automatically after 1 О minutes
Press this key to switch to vacuum interface
То switch between the vacuum unit and the temperature
unit.
1. Turn the button to select different pressure units
2. Short press this button, the main interface and vacuum
interface shows in а suspended state "Hold", short press
again, the order is cancelled.
3. Press it more than 2 seconds, The refrigerant type
"R" will flash оп the main interface, Тuгп the knob to
choose refrigerants (68 kinds), press the key again,
and confirm the refrigerant.
РО6
V-MGC Digital
5.2.2 Diagnosis the pressure and temperature of the system
1.0pen the system, it will need some time for initial and
stabllize the reading.
2.Make sure all the valves are closed.
3.Connect the charging hose to the unit right.
5.2.3 Charging the refrigerant
1.Make sure all the valves are closed.
2.0pen the air conditioning system and the unit.
3.Connect the yellow hose to the refrigerant cylinder.
4.0pen the refrigerant cylinder valve, and open the low
side valve slowly , start charging(To Ье sure to charging
the appropriate refrigerant, Please kindly note to use
digital scale to charging precisely).
5.Close the cylinder valve after charging. lt will spend some
time to make sure the refrigerant flows out from the hoses
and unit.
6.Close the low side valve and charging valve and remove
the hose from the system.
5.2.4 Vacuuming Operation (see figure А)
1.Press the power button for 3 seconds to initialize it.
2.Press the vacuum button and choose the appropriate unit
3.Close all the valves. The yellow hose connects to the
system and the Ыuе hose connects to the vacuum pump.
4.0pen the vacuum pump and low-side knob , then
vacuuming it.
Р11

V-MGC Digital
5.2 Measuring operation
АWARNING
High pressure, high temperature low temperature or
poisonous refrigerant may cause injury!
>Wear safety glasses and safety golves.
>Hung and fix the unit оп the suspension part while using.
>Before using, check all the connectors, to make sure whether
they аге in good condition. Do not use апу tool to connect the
hose,just only Ьу hand (the Мах torque is 5.0NM/3.?ft*lb)
> То оЬеу to the specified range (О-50Ьаг), please рау special
attention while use R744, cause it need system works in high
pressure.
5.2.1 Measurement
.J Measuring preparation is done
1. Pressing оп the unit
2. Reading the measurement figures.
l
IMPORTANT NOTICE
Vacuuming the system Ьу а recovery machine ог а
vacuum pump is necessary, if the system has been
opened ог overrun of pressure caused Ьу leakage. ln
this case, repairing the leak system firstly, then test if
leakage ог vacuum status ог not before charging.
Р10
V-MGC Digital
4 lnitial Operation
4.1 lnstall the battery or rechargeaЫe battery (Figure С)
1 . Open the hanging hook, then open the battery cover
(card lock).
2. lnstall the batteries ог rechargeaЫe batteries (5*1.5v),
please do not make wrong polarity.
3. Push back the batteries'cover.
:.
:
1
lf not use the unit for а long time, remove the batteries.
..
i
1Before use the unit, rechargeaЫe batteries should Ье
i checked if fresh ог run out.
4.2 Start the unit
>Press Шkey and hold оп for 2s -Зs
-The initialization phase
•Turn оп each part of screen( response time: 2s)
-Open the measurement screen
4.3 Reset
>As per the step of the key instruction (РО5&РО6)
-Confirm it after all choices аге completed
РО?

V-MGC Digital
4.4 Operation Knob
ln terms of refrigeration flow path, this unit just likes
а normal 3- way manifold gauge.The pressure could
Ье read Ьу open or close the valve
>Open the valve: to turn the knob counterclockwise;
>Close the valve: to turn the knob clockwise.
AwдRNING!
Tighten the control valve Only Ьу hand.
Please remember that do not use апу tools to tight the valve,
in order to avoid the damage of the thread.
5 Product Operations
5.1 Measuring preparation
5.1.1 Connect the temperature probe
1 Before or after operating of the unit, please connect the
temperature probe, and then test the temperature.
5.1.2 The surface temperature probe
Please remember to connect the surface temperature
probe (As per accessory list)
5.1.3 Pressure adjustment
Affected Ьу the altitude, or under abnormal conditions,
the pressure reading doesn't show "zero".
ln this case, it is necessary to press the key 1 second,
the reading would Ье "zero".
РОВ
V-MGC Digital
5.1.4 Connect charging hose
: 1 Make sure that the refrigerant hose is good before operation.
._; turn off the knob.
1. Connect the charging hose to the unit, the Ыuе hose for the
low side, the red hose for the high side.
2. Then connect the charging hose (yellow) to the gas cylinder.
AwдRNING!
lf the unit drops onto the ground ог hits, the inner hose ог inner valve maybe damage,
furthermore it would damage inside
> for the sake of security, please send the unit to local distributor ог ZERO HVAC
SUPPLIER LLC for test
> therefore, once the instrument drops onto the ground ог hits,
you should check the condition which is described above is exist ог not.
5.1.5 Refrigerant setting
1. Press the button for Зs until the word "R" ( оп front of the
refrigerant) is Ыinking, then you сап choose the gas kinds
Ьу turning the button.
2. Press the button again to set.
РО9
