Volvo 2010 XC70 User manual

WElCOME TO THE glOBal faMIlY Of vOlvO
OWnERs!
Getting to know your new vehicle is an exciting experience.
This Quick Guide provides a brief overview of the most common features and
functions in your Volvo.
However, for the most up-to-date and detailed descriptions and instructions,
as well as important warnings and other information not included in this
folder, please refer to your Owner’s Manual.
An asterisk (*) indicates optional equipment.
For additional information, contact Customer Service:
U.S.A.: 1-800-458-1552 www.volvocars.us
Canada: 1-800-663-8255 www.volvocanada.com
VOLVO XC70
Quick Guide

REMOTE KEY WITH PCC* – PERSONAL CAR COMMUNICATOR
IGNITION MODES (MODES 0 AND I)
To access the following ignition modes: The
brake pedal must not be depressed.
Mode Active functions
Remote key inserted but not drawn
into ignition slot – audio system and
courtesy lighting.
Remote key drawn into ignition slot
– audio system and courtesy lighting.
Instrument/clock lighting, steering
wheel lock/unlocked.
Remote key drawn into ignition slot
and START pressed briefly – power
moonroof/windows, blower, ECC,
wipers, 12-volt sockets in center
console, Volvo Navigation System*.
To exit ignition modes 0/Iand turn off the
vehicle’s electrical system: Press in the remote
key. It will be partially ejected from the igntion
slot.
PCC*
1
Green light: vehicle is locked.
2
Yellow light: vehicle is unlocked.
3
Red light: alarm has been triggered.
4
Alternatively flashing red lights: the alarm
was triggered less than 5 minutes ago.
Locks the doors and tailgate and
arms the alarmA.
Unlocks the doors and tailgate, and
disarms the alarmB
Unlocks the tailgate.
Approach lighting illuminates lights in
door mirrors, cabin, footwells, license
plates. Turn signals and parking lights
illuminate.
“Panic” alarm.
– Press and hold to sound the alarm.
Turn off alarm with unlock button.
Information about the car can be gath-
ered within a range of 65 ft. (20 m).
– Press the button and wait for 7 sec-
onds.
If the vehicle is out of range when the
button is pressed, the most recently
stored status information will be shown.
A The accessory inclination and movement alarm sensors
can be turned off. See the “Alarm” section of your owner’s
manual for information.
B Automatic relock occurs if no door/tailgate is opened within
2 minutes after unlock.

STARTING THE ENGINE
– Insert the remote key as shown in the illustra-
tion, with the buttons upward and push lightly
on it – the key will be drawn into the lock.
COLDSTART
NOTE
After cold starts, your engine will idle at a
higher speed for a short time.
– Press the START/STOP/ENGINE button to
start the engine.
– Press the brake pedal.
SWITCHING OFF THE ENGINE AND
REMOVING THE REMOTE KEY
1. Park the vehicle and press the START/STOP
ENGINE button to switch off the engine.
2. Press lightly on the remote key. It will be par-
tially ejected from the ignition slot. The gear
selector must be in the Pposition.
DRIVER SUPPORT SYSTEMS
The vehicle may be equipped with a number of
other optional systems to help the driver brake
in time, keep a safe distance to the vehicle
ahead or stay in a traffic lane. These include:
Adaptive Cruise Control
Distance Alert
Collision Warning with Auto-brake
Driver Alert System
•
•
•
•

2
6
3 4 157
2
AUDIO SYSTEM
1
Press for on/off.
Turn to adjust volume.
2
Select AM, FM1, FM2, CD, or MODE.
Use MODE to activate Sirius satellite
radio* or the AUX/USB socketsA.
3
Sound settings
Press to select e.g., BASS, TREBLE, etc.
– turn to adjust.
BLUETOOTH®
Make the cell phone searchable/visible.
Press the PHONE button on the audio sys-
tem control panel briefly.
Select “Add phone” in the audio system
display.
Select the cell phone to be connected.
Enter the numbers shown in the audio sys-
tem display using the cell phone’s keypad.
A. AUX/USB sockets for e.g., mp3 player. Set the device’s vol-
ume to medium for best sound quality. An iPod® connected
to the USB socket will also be charged.
1.
2.
3.
4.
5.
Opening
– Press the button on the lighting panel/remote
key until the tailgate begins to open.
– The tailgate can also be opened by pulling
the handle on the tailgate.
Closing
– Press the closing button on the tailgate or
close the tailgate manually.
POWER TAILGATE*
RADIO
3
Turn to select a radio station.
4
Search for stations with the left/right ar-
rows. Store up to 20 stations by holding
in buttons 0–9 in FM1 och 0–9 in FM2,
until the stored station is confirmed in the
display.
5
Autostore stations by pressing for 2 sec-
onds. AUTOSTORE is displayed during
the search. The 10 strongest stations are
stored. Press 0–9to select a station.
CD PLAYER
3
Turn to change tracks.
4
Change tracks with left/right arrows.
Select CDBwith up/down arrows.
6
Press to eject current CD.
Press and hold to eject all CDsB
7
CD selectB. Press 1–6.
BOptional CD changer only.
HD RADIO
HD radio reception is subject to coverage limi-
tations. See your Owner’s Manual for details.

ELECTRONIC CLIMATE CONTROL (ECC)
STORAGE SPACES, 12-VOLT SOCKETS & AUX/USB* CONNECTOR
CAUTION
Using the optional 12-volt socket in the cargo
area with the engine switched off will drain
the battery.
The 12-volt sockets in the cabin function in
ignition positions Ior II.
The 12-volt socket* in the cargo area always
functions.
AUX/USB* can be used to connect e.g., an
mp3 player to the vehicle’s audio system.
MANUAL CONTROL
2
Driver/front passenger seat ventilation*.
3
Blower speed.
4
Heated driver/front passenger seat*.
5
Air distribution.
7
Recirculation
8
Defroster to defog the windshield and
side windows.
9
Heated rear window and door mirrors.
10
Air conditioning Off/On to cool the cabin
and defog the windows.
AUTOMATIC CONTROL
In AUTO mode, ECC controls all functions
automatically and makes driving more pleasant
with optimal air quality.
1
Turn the control to the desired temperatu-
re on the left/right sides of the cabin. The
set temperature is shown in the display.
6
Press to automatically control the tem-
perature and other functions.

8 9
7
1
Low fuel level indicator
When the symbol illuminates, refuel as
soon as possible.
2
The trip odometer display shows two
separate trip odometers, T1 & T2.
3
Fuel gauge
The fuel filler door is on the right, as indi-
cated by the arrow.
4
Trip computer display. Select function
with (8).
5
Clock
Adjust with (6).
6
Multi-function control
Turn the control clockwise or counter-
clockwise to set the clock.
A short press toggles between T1 & T2.
A long press resets the displayed odome-
ter.
TRIP COMPUTER AND ODOMETER
7
Press to display or erase a message.
8
Turn to show trip computer information
alternatives.
9
A short press resets current function.
A long press resets all functions.
STEERING WHEEL ADJUSTMENT REFUELING
WARNING
Never adjust the steering wheel while
driving.
– Press the button to open the fuel filler door.
NOTE
The display text Miles to empty tank is an
approximation, based on recent average fuel
consumption.

LIGHTING PANEL
WIPERS AND RAIN SENSOR*
EMERGENCY BRAKE ASSIST (EBA) CAR CARE
EBA is designed to provide full brake effect
immediately in the event of sudden, hard
braking. When EBA is activated, the brake
pedal will go down more than usual.
– Press and hold the brake pedal for as long
as necessary – there will be no braking ef-
fect if the pedal is released.
Hand washing is gentler on the paint than an
automatic car wash. Since the paint on a new
vehicle may take several months to harden
completely, we recommend washing the
vehicle by hand during this period. Use clean
water, a suitable car washing detergent and
a sponge. Keep in mind that dirt or grit on the
sponge can scratch the paint.
A
High beam flash
B
Toggle between high/low beams. Home
safe lighting.
1
Rain sensor On/Off with the lever in the
0position.
2
Turn to adjust intermittent wiper speed or
rain sensor sensitivity where applicable.
3
Tailgate wiper – normal/interval.
A
Single wiper sweep.
0
Off
B
Intermittent wipers. Turn (2) to adjust
interval.
C
Normal wiper speed.
D
High wiper speed.
E
Windshield and headlight washer.
F
Tailgate washer.
Displayed when the rain sensor is
active.
Display & instrument panel lighting.
Front fog lights.
Rear fog light (driver’s side only).
Automatic headlights. High beam flash
only.
Parking lights.
Headlights: turn off when ignition is
switched off, high/low beams.
Open the fuel filler door.
Press once to unlock the trunk, press
twice to pop open the trunk slightly.

ADJUSTING THE FRONT SEAT
1
Lumbar support.
2
Backrest tilt.
3
Raise/lower the seat.
4
Raise/lower the front edge of the seat
cushion.
5
Forward/rearward.
6
Folding down the passenger’s seat back-
rest.
TP 12009 (USA & Canada). AT 1020. Printed in Sweden, Göteborg 2010. Copyright © 2000-2010 Volvo Car Corporation.
When a low tire pressure warning message
(Low tire press. check tires or Very low tire
pressure) has been displayed and the tire
pressure warning light ( )has illuminated,
one or more tires has low inflation pressure.
Check the inflation pressure of all four tires
with a tire pressure gauge as soon as pos-
sible and pump the tire(s) with low pressure
to the recommended inflation pressure.
Refer to the inflation pressure tables in the
section “Wheels and tires” in the Owner’s
Manual.
If the BLIS indicator lights illuminate even
when there are no vehicles in the blind area,
this may be due to light reflected from a
wet road surface, the vehicle’s own shadow
against a large, light, smooth surface, or
sunlight directly in the camera when the sun is
low on the horizon.
In the event of a fault, Blind spot syst.
service required will be displayed. See the
Owner’s Manual for other BLIS-related mes-
sages.
ELECTRIC PARKING BRAKE
Setting
– Press the button. The light flashes until the
parking brake is fully applied, then glows
continuously.
Releasing
Ignition mode 0or higher.
Press the brake pedal and pull out the but-
ton.
Release automatically
– Select a gear and begin driving. The parking
brake will release automatically (the driver’s
seat belt must be fastened).
1.
2.
TIRE PRESSURE MONITORING
SYSTEM (TPMS)
BLIND SPOT INFORMATION
SYSTEM (BLIS)*
