MAINTENANCE INFORMATION
1995 Volvo 850
1993-96 MAINTENANCE
Volvo Maintenance Information
1993-96 850 Sedan
1994-96 850 Turbo Sedan
1995-96 850 T-5R Turbo Sedan
1994-96 850 Wagon
1994-96 850 Sportswagon
1995-96 850 T-5R Turbo Sportswagon
* PLEASE READ THIS FIRST *
NOTE: For scheduled maintenance intervals and the related fluid
capacities, fluid specifications and labor times for major
service intervals, see SCHEDULED SERVICES article below:
* SCHEDULED SERVICES - NON TURBO
* SCHEDULED SERVICES - TURBO (1994-96)
Warranty information and specifications for fluid
capacities, lubrication specifications, wheel and tire size,
and battery type are covered in this article.
NEW MODEL HIGHLIGHTS
NOTE: For more information regarding 1995 Model changes refer to
the GROUP 00, NO. 809 1995 850 NEW CAR FEATURES article in
the TSB section.
MODEL IDENTIFICATION
VIN LOCATION
The Vehicle Identification Number (VIN) is located on the
left side of the dash panel at the base of the windshield. The VIN
chart explains the code characters.
VIN CODE ID EXPLANATION
Numbers preceding the explanations in the legend below refer
to the sequence of characters as listed on VIN identification label.
See VIN example below.


(VIN) Y V 1 L S 5 5 1 X P 1 0 0 0 0 0 1


1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17



1 - Manufacturing Country
Y * Sweden Or Belgium
2 - Manufacturer
V * Volvo
3 - Vehicle Type
1 * Passenger Vehicle
4 - Vehicle Series

L * 850 Sedan
5 - Body Style & Restraint System
S * 850 4-Door Sedan W/ Driver & Passenger Airbags
S * 850 4-Door W/ Dual Airbags & Pretentioners
W * 850 5-Door Wagon W/ Driver & Passenger Airbags
6-7 - Engine Type
55 * B5254S 2.4L 5-Cylinder
57 * B5234T 2.3L Turbo 5-Cylinder
58 * B5234T5 2.3L Turbo 5-Cylinder
8 - Emission Control System
0 * Three-way Converter, Heated Oxygen Sensor, W/O EGR
1 * Three-way Converter, Heated Oxygen Sensor, W/EGR
2 * Three-way Converter, Heated Oxygen Sensor, W/EGR, Airpump
9 - VIN Check Digit
* Computer Generated
10 - Vehicle Model Year
P * 1993
R * 1994
S * 1995
T * 1996
11 - Assembly Plant
0 * Kalmar, Sweden
1 * Torslanda, Sweden
2 * Ghent, Belgium
3 * Halifax, Nova Scotia, Canada
A * Uddevalla, Sweden
12-17 - Serial Number
* Sequential Production Number
MAINTENANCE SERVICE INFORMATION
SEVERE & NORMAL SERVICE DEFINITIONS
NOTE: Use the Severe Service schedule if the vehicle to be serviced
is operated under ANY (one or more) of these conditions:
Service is recommended at mileage intervals based on vehicle
operation. Service schedules are based on the following primary
operating conditions:
Normal Service
* Driven More Than 10 Miles Daily
* No Operating Conditions From Severe Service Schedule
Severe Service (Unique Driving Conditions)
* Extended Idling Or Low Speed Operation
* Frequent Short Trips Of Less Than 7 Miles
* Extended Operation In Dusty Or Sandy Conditions
* Trailer Towing Operations
* Driving In Mountainous Conditions
CAMSHAFT TIMING BELT

CAUTION: Failure to replace a faulty camshaft timing belt may result
in serious engine damage.
The condition of camshaft drive belts should always be
checked on vehicles which have more than 50,000 miles. Although some
manufacturers do not recommend belt replacement at a specified
mileage, others require it at 60,000-100,000 miles. A camshaft drive
belt failure may cause extensive damage to internal engine components
on most engines, although some designs do not allow piston-to-valve
contact. These designs are often called "Free Wheeling".
Many manufacturers changed their maintenance and warranty
schedules in the mid-1980’s to reflect timing belt inspection and/or
replacement at 50,000-60,000 miles. Most service interval schedules in
this manual reflect these changes.
Belts or components should be inspected and replaced if any
of the following conditions exist:
* Cracks Or Tears In Belt Surface
* Missing, Damaged, Cracked Or Rounded Teeth
* Oil Contamination
* Damaged Or Faulty Tensioners
* Incorrect Tension Adjustment
Volvo recommends replacement of the camshaft timing belt at
the following intervals:
CAMSHAFT TIMING BELT REPLACEMENT INTERVAL TABLE

Application Interval (Miles)
1993 ................................................... 50,000
1994-96 ................................................ 70,000

SERVICE POINT LOCATIONS
Fig. 1: Service Point Locations (Non-Turbo)
Courtesy of Volvo Cars of North America.

Fig. 2: Service Point Locations (Turbo)
Courtesy of Volvo Cars of North America.
Fig. 3: OBD II Diagnostic Link Connector Location (1996)
Courtesy of Volvo Cars of North America.
ALIGNING CAMSHAFT TIMING MARKS

Fig. 4: Aligning Camshaft & Crankshaft Timing Marks
Courtesy of Volvo Cars of North America.

Fig. 5: Lubricating Tensioner Pulley Bushing (Pivot Bearing)
Courtesy of Volvo Cars of North America.
CAUTION: Lubrication of the Tensioner Pulley Bushing is REQUIRED on
1993 Models, it is recommended that the bushing be checked
for free play and lubrication on 1994-95 models.
NOTE: For more information regarding camshaft timing belt service
refer to the 2.3L 5-CYL TURBO article in the
ENGINE MECHANICAL section.
Fig. 6: Installing Washer on Timing Belt Tensioner
Courtesy of Volvo Cars of North America.
MODEL 850 TIMING BELT REPLACEMENT TABLE


Model

Part

50K

60K

70K

80K

90K

100K


Year

Number
      



1993*

271952-4

X
    
X




1994

271834-4
  
E
   




* = Late M/Y 93 850’s (from engine no. 131035) should


have M/Y 94 timing belt (p/n 271834-4). See Parts


Bulletin 21-13 and Tech DCS 21-02.


E = Recommended timing belt replacement


X = Required timing belt replacement




NOTE: On 1993 850’s, lubricate timing belt tensioner


pivot bearing during timing belt replacement.



LUBRICATING AUXILIARY DRIVE BELT TENSIONER
Fig. 7: Auxiliary Drive Belt Tensioner Lubrication Points
Courtesy of Volvo Cars of North America.
NOTE: The automatic tensioner for the auxiliary drive belt must be
greased every 30,000 miles (45,000 km) or if an abnormal

noise is heard from the tensioner.
NOTE: The auxiliary drive belt and automatic tensioner must be
removed from engine in order to properly lubricate.
FLAME TRAP MAINTENANCE - PCV SYSTEM
Fig. 8: Flame Trap Location
Courtesy of Volvo Cars of North America.
CHANGING CONTROL MODULE BOX FILTER (1993)
Fig. 9: Control Module Box Filter (1993)
Courtesy of Volvo Cars of North America.
BODY LUBRICATION POINTS

Fig. 10: Body Lubrication Points (Typical)
Courtesy of Volvo Cars of North America.
VEHICLE LIFT POINTS
Fig. 11: Vehicle Lift Points (Typical)
Courtesy of Volvo Cars of North America.
CAUTION: Use extreme caution when putting a T-5R model, or any model
with a front spoiler and lowered suspension onto a lift.

NOTE: For more information regarding lifting and hoisting refer to
the JACKING & HOISTING article in the
WHEEL ALIGNMENT section.
INFORMATION LABEL LOCATIONS
Fig. 12: Information Label Locations
Courtesy of Volvo Cars of North America.
SERVICE LABOR TIMES

SERVICE LABOR TIMES TABLE (HOURS)

Application (1) 30,000 60,000
Mile Service Mile Service
2.5L 5-Cylinder
Automatic Transmission ...... 3.8 ..................... 4.6
Manual Transmission ......... 3.8 ..................... 4.6
2.5L 5-Cylinder Turbo
Automatic Transmission ...... N/A ..................... N/A
Manual Transmission ......... N/A ..................... N/A
(1) - To replace camshaft timing belt, add 2.0 hrs.

LUBRICATION SPECIFICATIONS
CAUTION: DO NOT use SAE 15W-40 oil in extremely low ambient
temperatures.
LUBRICATION SPECIFICATIONS TABLE

Application Fluid Specifications
Coolant ............................. 50/50 Mix Ethylene Glycol
and Distilled Water
Brake Fluid ....................... DOT 4 Or DOT 4+ Brake Fluid
Engine Oil
Ambient Temperature
Less Than 68

F (20

C) .................. SAE 5W-30 API SH/CD
-4

F To 100

F (-20

To 38

C) .......... SAE 10W-30 API SH/CD
Greater Than 14

F (-10

C) ............. SAE 15W-40 API SH/CD
Power Steering Fluid (1) ............. Dexron-IIE or Mercon ATF
Automatic Transaxle (AW50-42) ............ Dexron-IIE or Mercon
Manual Transmission (2) ......... Volvo Synthetic (P/N 1161423)
Or Type F/G ATF
Wheel Bearings .................... NLGI Grade 2 Category GC-LB
Steering Linkage (3)(4) ........... NLGI Grade 2 Category GC-LB
Ball Joints (3)(5) ................ NLGI Grade 2 Category GC-LB
Weatherstrip ....................... Dielectric Silicone Grease
(1) - At temperatures below -4

F (-20

C) Volvo oil (P/N1161001-1)
can be used.
(2) - DO NOT use Dexron fluid in manual transmissions.
(3) - Use low pressure grease gun to prevent seal damage.
(4) - Fill until lubricant squeezes out from the base of seals.
(5) - Fill ball joint until seal starts to swell.

FLUID CAPACITIES
FLUID CAPACITIES TABLE

Application Quantity (1)
A/C R-134a Refrigerant ................................ 26 Ozs.
Brake System .................................. 0.5 Qts. (0.6L)
Cooling System
Non-Turbo ................................... 7.6 Qts. (7.2L)
Turbo ....................................... 7.4 Qts. (7.0L)
Engine Oil (2)

850 (Non-Turbo)
1993-94 ................................... 5.6 Qts. (5.3L)
1995 (M/T) ................................ 5.6 Qts. (5.3L)
1995 (A/T) ................................ 6.1 Qts. (5.8L)
Turbo (3)
Without Oil Cooler ........................ 5.6 Qts. (5.3L)
With Oil Cooler ........................... 6.5 Qts. (6.2L)
Fuel Tank .................................... 19.3 Gals. (73L)
Power Steering ................................ 0.7 Qts. (0.8L)
Automatic Transmission (AW50-42)
Fluid Change ................................ 3.3 Qts. (3.0L)
Overhaul .................................... 8.0 Qts. (7.6L)
Manual Transmission
1993-94 (M56L) .............................. 2.5 Qts. (2.1L)
1995-96 (M56H) .............................. 2.2 Qts. (2.1L)
(1) - Capacities are recommended or calculated levels. Always use
dipstick (if available) to measure level.
(2) - Includes Filter Change
(3) - Oil Cooler capacity is .95 Qts. (0.9L).

WHEEL & TIRE SPECIFICATIONS
WHEEL & TIRE SPECIFICATIONS TABLE (1)

Wheel Size Tire Size
15 x 6" (Steel) .............................. P195/60HR15
15 x 6.5" (Aluminum) ......................... P195/60HR15
16 x 6.5" (Aluminum) ......................... P205/50ZR16
Temporary Spare (Steel) ....................... T115/70R15
(1) - Snow chains should be used on the front original
equipment tires only.

TIRE INFLATION
Tire specification label is located on the right front door.
TIRE INFLATION SPECIFICATIONS TABLE

Tire Size/Application psi (kg/cm

)
195/60R-15 ........................................... ( 1)
205/50R-16 ........................................... ( 1)
Spare Tire ........................................... ( 1)
(1) - Check tire pressure label located on the inside of the
fuel filler flap.

WHEEL TIGHTENING
Tighten all wheel lug nuts to 80 ft. lbs. (110 N.m) using
pattern shown in Fig. 13.
TIRE ROTATION PATTERNS

Fig. 13: Tire Rotation Pattern & Lug Nut Torque Pattern
Courtesy of Volvo Cars of North America.
BATTERY SPECIFICATIONS
CAUTION: When battery is disconnected, vehicles equipped with
computers may lose memory data. When battery power is
restored, driveability problems may exist on some vehicles.
These vehicles may require a relearn procedure. See COMPUTER
RELEARN PROCEDURES article in the GENERAL INFORMATION
section.
All models use a 520 A/100 Min. battery.
CAUTIONS & WARNINGS
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM
NOTE: See the AIR BAG RESTRAINT SYSTEM article in the
ACCESSORIES/SAFETY EQUIPMENT Section.
The SRS has no user-servicable parts. Always have servicing
done by an authorized dealer.
When performing maintenance on air bag equipped vehicles
always observe proper safety precautions.
WARNING: To avoid injury from accidental air bag deployment, read and
carefully follow all warnings and service precautions. See
appropriate AIR BAG RESTRAINT SYSTEM article in the
ACCESSORIES/SAFETY EQUIPMENT section.
CAUTION: Disconnect negative battery cable before servicing any air
bag system, steering column or passenger side dash
component. After any repair, turn ignition key to the ON
position from passenger’s side of vehicle in case of
accidental air bag inflation
ANTI-LOCK BRAKE SYSTEM (ABS)
CAUTION: Never mix different diameter tires. On loose or uneven
surfaces, the ABS system may require longer stopping
distances than conventional brake systems. Exercise caution
when removing mud or snow from the wheels so as not to
damage the ABS wiring or speed sensors.
BATTERY WARNING

WARNING: When battery is disconnected, vehicles equipped with
computers may lose memory data. When battery power is
restored, driveability problems may exist on some vehicles.
These vehicles may require a relearn procedure. See
appropriate COMPUTER RELEARN PROCEDURES article in the
GENERAL INFORMATION section below.
REPLACING BLOWN FUSES
Before replacing a blown fuse, remove ignition key, turn off
all lights and accessories to avoid damaging the electrical system. Be
sure to use fuse with the correct indicated amperage rating. The use
of an incorrect amperage rating fuse may result in a dangerous
electrical system overload.
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning
that brake pads need replacement.
CATALYTIC CONVERTER
Continued operation of vehicle with a severe malfunction
could cause converter to overheat, resulting in possible damage to
converter and vehicle.
COOLANT (PROPYLENE-GLYCOL FORMULATIONS)
CAUTION: To avoid possible damage to vehicle use only ethylene-glycol
based coolants with a mixture ratio from 44-68% anti-freeze.
DO NOT use 100% anti-freeze as it will cause the formation
of cooling system deposits. This results in coolant
temperatures of over 300

F (149

C) which can melt plastics.
100% anti-freeze has a freeze point of only -8

F (-22

C).
CAUTION: Propylene-Glycol Mixtures has a smaller temperature range
than Ethylene-Glycol. The temperature range (freeze-boil)
of a 50/50 Anti-Freeze/Water Mix is as follows:
Propylene-Glycol -26

F (-32

C) - 257

F (125

C)
Ethylene-Glycol -35

F (-37

C) - 263

F (128

C)
CAUTION: Propylene-Glycol/Ethylene-Glycol Mixtures can cause the
destabilization of various corrosion inhibitors. Also
Propylene-Glycol/Ethylene-Glycol has a different specific
gravity than Ethylene-Glycol coolant, which will result in
inaccurate freeze point calculations.
ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS
WARNING: Many solid state electrical components can be damaged by
static electricity (ESD). Some will display a warning label,
but many will not. Discharge personal static electricity by
touching a metal ground point on the vehicle prior to
servicing any ESD sensitive component.
ENGINE OIL
CAUTION: Never use non-detergent or straight mineral oil.
FUEL SYSTEM SERVICE
WARNING: Relieve fuel system pressure prior to servicing any fuel

system component (fuel injection models).
HALOGEN BULBS
WARNING: Halogen bulbs contain pressurized gas which may explode if
overheated. DO NOT touch glass portion of bulb with bare
hands. Eye protection should be worn when handling or working
around halogen bulbs.
RADIATOR CAP
CAUTION: Always disconnect the fan motor when working near the
radiator fan. The fan is temperature controlled and could
start at any time even when the ignition key is in the OFF
position. DO NOT loosen or remove radiator cap when cooling
system is hot.
RADIATOR FAN
WARNING: Keep hands away from radiator fan. Fan is controlled by a
thermostatic switch which may come on or run for up to
15 minutes even after engine is turned off.
TURBOCHARGED MODELS
CAUTION: Do not race engine immediately after starting. When
stopping engine, allow engine to idle for approximately 60
seconds before shutting it off. Failure to do so may cause
turbocharger damage due to lack of oil flowing to
the turbocharger bearings.
WHEELS & TIRES
Only wheels tested and approved by the manufacturer should be
used on models equipped with Air Dam aerodynamic components.
WARRANTY INFORMATION
CAUTION: Due to the different warranties offered in various regions
and the variety of after-market extended warranties
available, please refer to the warranty package that came
with the vehicle to verify all warranty options.
BASIC WARRANTY
Warranty coverage is 3 years or 50,000 miles, whichever
occurs first.
MAJOR ASSEMBLY COVERAGE
Warranty coverage is 3 years or 50,000 miles, whichever
occurs first.
CORROSION PROTECTION WARRANTY
Painted body panels are warranted against perforation for a
period of 5 years. Structural damage due to rust or corrosion is
warranted for 8 years.
SUPPLEMENTAL RESTRAINT SYSTEMS & SEAT BELTS

Factory installed seat belts or restraint systems are
warranted for a period of 5 years.
EMISSION SYSTEM WARRANTY
Manufacturer warrants that the vehicle emission control
system was designed and installed to conform, at the time of sale, to
all applicable U.S. emission standards. The warranty covers repairs
resulting from any defect in material or workmanship which could cause
the vehicle not to meet emission standards during the warranty period.
The warranty period is 5 years or 50,000 miles.
The following components are covered by Emission System or
Emission Performance warranties:
* Ignition Cables
* Distributor Components
* Ignition Coil
* Power Stage
* Ignition Control Unit
* Spark Plugs
* Knock Sensor
* Engine RPM Sensor
* Fuel Pressure Regulator
* Mass Airflow Meter
* Fuel Injection Control Unit
* Fuel Injectors
* Idle Air Valve
* Coolant Temperature Sensor
* Throttle Position Sensor
* Throttle Potentiometer
* Series Resistor
* Oxygen Sensor
* Cold Start Injector
* Temperature Sensor
* Manifold Pressure Sensor
* Camshaft Sensor
* Evaporative Emission System
* Turbocharger System
* PCV System
* Air Intake System
* Catalytic Converter
* Exhaust Manifold
* Exhaust Pipe (Manifold-To-Catalyst)
* EGR System
* Miscellaneous Items Used In Above System
FUSES & CIRCUIT BREAKERS
The fuse panel is located in the engine compartment. A label
on the inside of the cover lists the fuse amperage and circuits
protected.

Fig. 14: Fuse Panel Identification
Courtesy of Volvo Cars of North America.
Fuse & Circuit Breaker Identification
1 - 15 Amp
Fuel Injection, Distributor Ignition, Automatic Gearbox
2 - 15 Amp
Fuel Pump, Alarm System
3 - 10 Amp
Courtesy Lights, Oil Level Sensor
4 - Not Used (1993-95)
10 Amp (1996)
Electronic Start Inhibitor (Immobilizer)
5 - 30 Amp
ECC Blower (Speed 4)
6 - 25 Amp
Central Locking System, Alarm
7 - 15 Amp
Audio System (Amplifier)
8 - 25 Amp (1993-95)
Power Antenna, Trailer Connector
40 Amp (1996)
Electronic Start Inhibitor (Immobilizer)
9 - 30 Amp
ABS, Traction Control System
10 - Not Used (1993-95)
15 Amp (1996)
Heated Rear Seat (If Equipped)
11 - 30 Amp
Heated Rear Window & Side Mirrors
12 - 10 Amp
Brake Lights
13 - 15 Amp
Hazard Flashers, Headlight Flashers, Alarm
14 - 30 Amp
ABS, Traction Control System
15 - 10 Amp (1993-95)
Audio System, Courtesy Lights, Door Open Light, Trunk Light,
Glove Box Light, Remote Control Central Locking System,
Oil Level Sensor, Seat Belt Reminder
10 Amp (1996)
Audio System, Courtesy Lights, Door Open Light, Trunk Light,
Glove Box Light, Remote Control Central Locking System,
Oil Level Sensor, Seat Belt Reminder, Data Link Connector
16 - 30 Amp (1993-95)

Accessories
30 Amp (1996)
Power Antenna, Trailer Connector, Accessories
17 - 10 Amp
Key Reminder
18 - 25 Amp (1993-95)
Heated Front Seats, Power Mirrors
15 Amp (1996)
Front Fog Lamps
19 - 15 Amp
Left High Beam Headlight
20 - 15 Amp
Right High Beam Headlight, High Beam Indicator
21 - 15 Amp
Left Low Beam Headlight
22 - 15 Amp
Right Low Beam Headlight
23 - 10 Amp
Left Parking Light, License Light
24 - 10 Amp
Right Parking Light, Bulb Failure Warning Sensor
25 - 10 Amp
Rear Fog Lamps, Fog Lamp Indicator
26 - Not Used (1993-95)
25 Amp (1996)
Heated Front Seats, Power Mirrors
27 - 15 Amp
Back-Up Lights, Turn Signals
28 - 10 Amp
Cruise Control, Heated Rear Window, Seat Belt Reminder Light,
Shiftlock, Bulb Failure Warning Sensor, Heated Rear Seat
29 - 15 Amp
ABS, Traction Control System
30 - 10 Amp
Cigarette Lighter
31 - 25 Amp
ECC, ECC Blower (Speeds 1-3)
32 - 10 Amp
Audio System, Remote Controlled Central Locking System
33 - 15 Amp (1993-95)
Power Seats, OBD Test Socket, Tailgate Washer/Wipe (Wagon)
15 Amp (1996)
Power Seats, Tailgate Washer/Wipe (Wagon)
34 - 25 Amp
Windshield Wiper/Washer, Horn, Headlight Washer/Wiper
35 - 10 Amp
Instrument Lights, Sun Roof, Traction Control System
36 - Not Used
37 - Circuit Breaker
Power Windows, Power Sun Roof
38 - Not Used
39 - Circuit Breaker
Drivers Power Seat
40 - Circuit Breaker
Passengers Power Seat
RELAY PANEL LOCATION
The relay panel is located at the left corner of the
instrument panel.
RELAY PANEL IDENTIFICATION

Fig. 15: Relay Panel Identification
Courtesy of Volvo Cars of North America.
Relay Identification

A - Control Module, Cruise Control
B - Fuel Pump Relay
C - Main Headlight Relay with Bulb Malfunction Indicator
D - Overload Relay (+X Supply)
E - Overload Relay (+15 Supply)
F - Overload Relay (+X Supply)
G - Fog Lamp Relay
H - Deadlock Setting Relay
I - Intermittent Windshield Wiper Relay
J - Intermittent Wiper Relay (Rear Tailgate - Wagon)
K - Central Lock and Delayed Inside Lighting Relay
L - Speed Warning Relay
M - Heated Rear Window and Door Mirror Relay
N - Not Used
O - Anti-Theft Alarm Relay
P - Seat Belt Reminder/Key Warning Relay
Q - Front Fog Lamp (Bridge)
R - Heated Rear Seat Relay
S - Not Used
