Volvo FMX 440 6x4 R RSS Rigid Installation guide

volvo fmX
FMX 440 6x4 R RSS Rigid

volvo fmX
FMx 440 6x4 R RSS rigid
VTSPEC/6x4CR/102011/001
Volvo Malaysia Sdn Bhd reserves the right to replace the component offered or design with other equivalent without prior notification. Any picture shown are for illustration purpose only.
KOTA KINABALU
Lots 34-6 & 7,
Jln 1E, Industrial Zon 4 (IZ 4),
KKIP Selatan, Jln Sepangar,
88460 Kota Kinabalu, Sabah
Tel : [phone]
Fax: [phone]
SANDAKAN
Lot 2, Block G, Ground Floor,
Bandar Ramai-Ramai,
P.O. Box 3541,
90739 Sandakan, Sabah
Tel
Fax
: 089-272 707
: 089-235 855
MIRI
Lot 2541, Jln Manettia,
Piasau Lorong 8,
Pujut-Lutong Road,
98000 Miri, Sarawak
Tel
Fax
: 085-655 855
: 085-655 618
SHAH ALAM (HQ)
No. 6, Jalan Bicu 15/6,
Seksyen 15, 40200 Shah Alam,
Selangor Darul Ehsan
Tel
Fax
: 03-5510 3300
: 03-5519 4233/
03-5519 0592/
03-5510 9096 (Parts)
KUCHING
Lot 1017, Section 66,
KTLD, Jalan Kilang,
(P/O Jalan Tekad),
Bintawa, 93450 Kuching,
Sarawak
Tel : [phone]
Fax: [phone]
KUANTAN
Lot 108,
Semambu Industrial Estate,
25350 Kuantan,
Pahang
Tel : [phone]
Fax: [phone]
JOHOR BAHRU
PLO 251, Jalan Firma 2,
Kawasan Perindustrian Tebrau IV,
81100 Johor Bahru, Johor
Tel
Fax
: 07-358 4955/
07-357 4834/
07-357 4835
: 07-357 4899
PRAI
2410, Jalan Perusahaan Prai,
Kawasan Perusahaan Prai,
13600 Seberang Prai,
Pulau Pinang
Tel
Fax
: 04-398 9184/
04-398 9185
: 04-398 9187
BINTULU
Lot 3069, Sublot 4,
Kidurong Industrial Estate,
97008 Bintulu, Sarawak
Tel
Fax
: 086-327 646
: 086-255 722
DAI LIENG MACHINERY SDN BHD Private Dealer:VOLVO MALAYSIA SDN BHD Owned Dealers:
GVW/GCW
FRONT AXLE LOAD
REAR AXLE LOAD
: 41,000Kg/100,000Kg
: 9,000Kg
: 32,000Kg
RIM SIZE
8.5 x 24’ pressed steel rim
TYRE SIZE
12.00 - 24, tube tire
ELECTRICAL SYSTEM
24V system with 12V transformer
CABIN
L1EH1, day cab with two (2) seats
Fully adjustable air suspended driver seat
3-points safety belts
Laminated windshield with electrical control winding tampered windows
Internal sun visor
Kerb mirror and front view mirror
Colour : Winter White (1103WHIT)
LIGHTING
Two (2) fog lights incorporated in front cluster light
Two (2) pilot/ roof lights
One (1) rotating beacon light
ACCESSORIES
Reverse buzzer
Air horn (Jericho type)
Air-conditioning system
12V Electrical transformer
Radio-CD player with speakers
Rubber floor mats
First aid kit
3Kg fire extinguisher
Breakdown warning triangle
Standard paint
Speed limit adjustment
ENGINE
D13A440 (Euro 3)
In-line six cylinders Inter-cooled turbo charged. Tropicalised water-
cooled.
Electronic Management System (EMS) with Cruise Control and Speed
Limiter, incorporated with engine brake
Smart water separator as standard
Maximum output: 324kW (440hp) 1400-1800rpm
Maximum torque: 2200Nm 1050-1400rpm
Economy engine speed range 1050-1600rpm
GEARBOX
VT2514B
Manual 14-speed splitter and range gearbox, 2 non-synchronised
crawler and 4 reverse gears
Incorporated with oil cooler
REAR AXLE
RT3210HV
Rear axle with differential lock between wheels and axles
FRONT SUSPENSION
Parabolic leaf springs with stabilizer and double-acting hydraulic shock
absorbers.
REAR SUSPENSION
Multi leaf spring
BRAKE SYSTEM
Compressed air system with separate circuit for front & rear with air drier,
z-cam/drum brake with automatic slack adjustment
Hand control trailer brake
Safety blocking valve and load sensing valve on drive axles
EXHAUST SYSTEM
Right hand side vertical horizontal with exhaust heat shield
WHEELBASE
3,700mm
