Volvo S80 - User manual

WELCOME TO YOUR NEW VOLVO!
Getting to know your car is an exciting experience.
After looking through this Quick Guide you'll like your new Volvo even more.
You can find detailed information in the Owner's Manual.
Warning texts and other important information are only available in the
Owner's Manual, not in this folder. The Owner's Manual contains the most
up-to-date information.
Options are marked with an asterisk (*).
At www.volvocars.com you will find further information relating to your
car
VOLVO S80
Quick Guide WEB EDITION

12
3 4
12
Locks doors and boot lid and arms the
alarm*A.
Unlocks doors and boot lid and deac-
tivates the alarmA.
Unlocks the boot lid – this does not
open.
Approach lighting in side mirrors*, in
the passenger compartment, at floor
level and at the numberplate. Direction
indicators and parking lamps come on.
"Panic" button. Held down for approx.
3 seconds in an emergency to trigger
the alarm.
AAutomatic relocking takes place if a door/boot lid
is not opened within 2 minutes after unlocking.
REMOTE KEY
START
SWITCH OFFTHE ENGINE AND REMOVETHE REMOTE KEY
Insert the remote key in the ignition switch. Press gently on the remote key, which is
then pulled in.
Depress the clutch or brake pedal. Press the START/STOP/ENGINE button to
start the engineB.
BThe idling speed may be slightly higher for a short time during cold starting.
Park the car and press the START/STOP/
ENGINE button to switch off the engine.
Press gently on the remote key, which is
then pushed out. Automatic transmission must
be in position P.

12
3
4
1
PERSONAL CAR COMMUNICATOR, PCC* WITH KEYLESS DRIVE
Information on the car can be obtained
within a radius of 20 m.
• Press the button and wait 7 seconds.
Pressing the button out of range shows the
last status stored in the memory.
1Green light: The car is locked.
2Yellow light: The car is unlocked.
3Flashing alternating red light: Someone
may be inside the car.
4Red light: The alarm has been triggered.
STARTING WITH KEYLESS DRIVE
Get into the car with the PCC in your pocket for
example.
Depress the clutch or brake pedal.
Press the START/STOP/ENGINE button to
start the engineA.
AThe idling speed may be slightly higher for a short time during cold starting.
SWITCHING OFFTHE ENGINE
Park the car and press the START/STOP/
ENGINE button to switch off the engine
IMPORTANT
With keyless drive the PCC only needs to
be inside the car. Keep it in your pocket for
example when you go to and from the car
and while driving.
The car is unlocked when someone grips the
outer handle of a door.
When parking the car after driving you only
need to press the button on the outside of
the door to lock the car.
LEATHER CARE BLIS – BLIND SPOT INFORMATION
SYSTEM*
Leather upholstery requires regular cleaning.
Treat with leather care products, 1–4 times a
year or as required. Leather care products are
available from your Volvo dealer.
If the BLIS’ indicator lamp illuminates despite
there being no vehicle within the blind spot,
the cause could be for example, reflection
from shiny wet road surface or low sun in the
camera. In the event of a direct fault in the
system the display shows the text Blind spot
syst. Service required

2
6
3 4 157
2
1
AUDIO SYSTEM
3Set the sound pattern
Press the button to select BASS, TREBLE,
FADER, BALANCE, Dolby Pro Logic II*.
Turn the control to adjust.
AAUX input for e.g. MP3 player (set volume at medium
for optimum audio reproduction).
1Press for ON/OFF
Turn to adjust the volume
Radio, TP, Handsfree* and RTI volume are
stored individually for the next time they
are used.
2Select AM,FM1,FM2,CDor MODE.
Use MODE to activate AUXAand to adjust
the AUX audio source volume.
CD
4Change CD track using Left/Right arrow
or turn (3).
Select CD disc* using Up/Down arrow.
6CD eject
Press to eject current CD disc.
Keep the button depressed to eject all
CD discs in the CD changer*.
7CD changer*. Select CD disc 1–6.
RADIO
3Turn to select radio station
4Search station with left/right arrow. Store
up to 20 stations by holding in 0–9 on
FM1 and 0–9 on FM2. When a station has
been stored it is confirmed in the display.
5Autostore the 10 strongest stations
Press in AUTO for approx. 2 seconds.
Autostoring is shown in the display for as
long as the search continues.
Then select 0–9 to playback one of the
stored radio stations.
LOWERINGTHE REAR SEAT BACKRESTS
Pull the handles separately to lower the left
and/or right-hand backrest.
Make sure that the rear head restraints are
raised. Lower the backrests.

1
2
ELECTRONIC CLIMATE CONTROL, ECC*
MANUAL CONTROL
Fan speed
Air distribution
Defroster to quickly remove misting
from the windscreen and side windows.
Air quality system. OFF/AUT/Recir-
culation.
Air conditioning ON/OFF
Heated rear window and outer mir-
rors. Automatic shutdown.
AUTOMATIC CONTROL
In AUTO mode the ECC system controls all
functions automatically, making driving simpler
with optimum air quality.
1Temperature
Turn the controls to select the required
temperature. The set temperature is shown
in the display.
2Press AUTO for automatic control of tem-
perature and other functions.
STORAGE SPACES, 12 V SOCKET AND AUX
IMPORTANT
Using the 12 V socket in the cargo area could
discharge the battery.
The 12 V sockets in the centre console front/
rear work in ignition position I or higher. The
12 V socket on the right-hand side of the cargo
area is always active.

123456
12.3 12:34
P_3 C
o
01
1000km
to empty tank
T2
3 62 41 5
8 9
7
1Trip meter
The car is equipped with two independent
trip meters, T1 and T2, which are always
on. For switching between T1/T2 and
resetting, see button (6).
2Fuel gauge
The arrow shows which side the fuel filler
cap is on.
3Low fuel level
When this symbol is illuminated, the level
in the fuel tank is low. Top up with fuel as
soon as possible
4Distance to empty tank
Turn the thumbwheel of the trip computer
(8) to see approximately how far is left to
drive before the tank is empty.
IMPORTANT
"Kilometres to empty tank" is an estimate of
the possible distance left to drive, based on
earlier driving conditions.
TRIP COMPUTER ANDTRIP METERS
5Clock
Turn the control (6) clockwise or anticlock-
wise to set the clock.
6Turn to display e.g. KILOMETRES TO
EMPTY TANK in the display (4).
Turn to set the clock.
7Press to read the messages in the dis-
play. Press again to turn off the message.
8Trip computer
Select the required function using the
thumbwheel.
9Resets the current function in the trip
computer.
ADJUSTINGTHE STEERING WHEEL REFUELLING
WARNING! Adjust the steering wheel before
starting to drive – never do this while driving.
Press the button to open the fuel filler flap.

AB
C
0
D
E
F
G
HEADLAMP CONTROL
Display and instrument lighting
Fog lamps (front)
Fog lamps (rear, driver's side only)
Automatic dipped beam. Main beam
flash works but not fixed main beam.
Parking lamps
Dipped beam. Dipped beam switches
off when the ignition is switched off.
Main beam can be activated with the
lever.
Headlamp levelling, dipped beam.
Automatic function for Bi-Xenon®
lights*.
Main beam flash.
Switch between main/dipped beam.
C
Single sweep, windscreen wipers
DInterval wiping. Turn the thumbwheel
(B) to adjust the wiper interval.
ENormal speed
FHigh speed
GWindscreen and headlamp washing
Display symbol when rain sensor is
on.
RAIN SENSOR* AND WINDSCREEN WIPERS
RAIN SENSOR
APress to activate the rain sensor when the
lever is in position 0.
BAdjust rain sensor sensitivity by turning
the thumbwheel.
DRIVER SUPPORT SYSTEM* BLUETOOTH*
To help the driver to brake in time, for exam-
ple, keep a safe distance from other vehicles
or maintain a good road position, the car may
be fitted with a number of systems:
Adaptive cruise control*
Distance control*
Collision warning with auto brake*
Driver Alert System*.
•
•
•
•
Makes mobile phone searchable/visible
Hold down the PHONE button on the
audio system
Select Add phone from the audio system
display
Select the phone you want to connect
Input the digits shown in the audio
system display using the mobile phone's
keypad
1.
2.
3.
4.
5.

2
1
+
-
3
2
1
5 4 4352
PARKING BRAKE
To apply
Press the button.
The lamp flashes until the parking
brake is fully applied, after which the
lamp stays on.
KEY POSITIONS (0 & I) ADJUSTINGTHE FRONT SEAT
1Lumbar support
2Backrest rake
3Raise/lower seat
4Seat cushion front edge raise/lower
5Forwards/backwards
0Instrument/clock lighting, steering lock
unlocks.
ISunroof, window motors, fan, ECC,
windscreen wipers, 12 V socket in cen-
tral console, RTI
KEYLESS DRIVE
Posi-
tion I
Audio system and passenger compartment
lighting operate irrespective of key position.
The clutch/brake pedal must not be
depressed.
REMOTE KEY
Posi-
tion 0
Posi-
tion I
To disengage
Key position 0or I.
Depress the clutch or brake pedal.
2
Pull out the button.
Disengage automatically
Select a gear and drive away.
(For cars with an automatic gearbox, the
driver has to be wearing the seat belt.)
•
TP 10030 (English). AT 0820. Printed in Sweden, Göteborg 2008. Copyright © 2000-2008 Volvo Car Corporation.
