Switch Retrot Kit
RX/RX-LC/S1
Installation Instructions
Customer Service
1-877-671-7011 www.allegion.com/us
© Allegion 2014
Printed in U.S.A.
941038-00 Rev. 01/14-c
Cable Tie 1.5"
RX {
RX-LC
{
Standard (RX)
or low current (RX-LC)
Base Plate
Assembly
Remove push bar.
Slide
to
remove
Slide
to
remove
Remove screws.
Remove mechanism case.
Dogging assembly may not
be present on all devices.
Step 1 Disassemble the device. (Remove from door if mounted.)
This kit includes the following parts:
8-18 X 3/8" Flat Head Screw (2) Switch Assembly Nylon Fastener
This switch is intended for signaling purposes only and is rated for a
maximum 2 ampere resistive load at 24VDC/AC. Use with inductive
or capacitive loads (magnetic locks or solenoid devices) derates the
capacity of the switch. Consult the factory for assistance.
22 Device
This switch is intended for systems using low current signals. The switch is
rated for a maximum of 50mA. Consult the factory for assistance.
3
2
1

Slide
to
remove
Base Plate
Assembly
÷
Remove mechanism case.
ø
Remove push bar.
Slide
to
remove
Dogging assembly may not
be present on all devices.
If the push bar has 2 screws
for end cap, replace with the
2 screws provided in this kit.
ù
ù
Remove push bar.
Slide
to
remove
Base Plate
Assembly
ø
Remove mechanism case.
Dogging assembly may not
be present on all devices.
Slide
to
remove
÷
Remove.
ú
If the push bar has 2 screws
for end cap, replace with the
2 screws provided in this kit.
This end only
33/35 Device
33A/35A & 98/99 Device
1
4
2
3
1
2
Used on 33A/35A
device only
98/99 device
center case shown
Step 1 Continued
3

Drill two1/8" holes through rear
guide base only if holes are
not present.
Remove & discard this bearing
strip before snapping switch
assembly onto rear guide base.
Rear Guide Base
1 3/8"
3/8"
Install Switch Assembly.
Route the wires from the
switch assembly through
this hole. Wires are not to
interfere with any moving
parts. Secure wires with
a cable tie.
Install nylon fastener.
1 7/8"
2
4
1
3
5
Step 2 Install Switch
Cable tie

*Red = 2A
Green = 50mA
End Cap Mounting Bracket
Drill 5/16" - 5/8" hole in the door
this side only using the end cap
mounting bracket for location.
Connect wires to power transfer,
electric hinge, etc. Refer to
product instructions.
Hole is not necessary for
an alarm kit, refer to its installation
Step 4 Prepare door for device wiring.
Switch Yel
Blue
Switch Yel
*Red or Green *Red or Green
Blue
Depress the bellcrank, the
switch should actuate
during this movement
Release the bellcrank, the
switch should actuate
during this movement
If adjustment is needed, loosen
screw in the side of the switch
assembly and slide switch forward
or backward as necessary.
RX actuator position
Step 3 Check the switch for proper actuation.
