Vonets WiFi-SB-L3 User instructions

WiFi-SB-L3 300M WiFi Router WiFi Bridge WiFi Repeater
1
300M WiFi Router、
WiFi Repeater 、WiFi Bridge
WiFi-SB-L3
Quick Setting Guide

WiFi-SB-L3 300M WiFi Router WiFi Bridge WiFi Repeater
2
Chapter 1 Router Mode Quick Setup Guide
1. Let WiFi-SB-L3 be powered on.
2.Turn on wireless network connection, disabled local connection or other network
connection
3.Set up a computer network IP for automatic access, as the following:
4.Computer or mobile phone search to WiFi-SB-L3 hot spot, then connect to it.
Remark: The hot spot name of the device is VONETS_the last six characters of MAC
address, password is 12345678
5. Open the webpage, input Virtual configuration domain name (VDNS) http://vonets.cfg on
the browser, press enter into the loading page.
6.Enter user name and password.
Remark：The default user name and password is : admin

WiFi-SB-L3 300M WiFi Router WiFi Bridge WiFi Repeater
3
7.WAN interface Settings
Enter the web page and click on WAN interface Settings, select connection method, the default connection way
is DHCP, if choose PPPoE to connect, you should enter User name and password provided by ISP, then click
confirm button , as the follow:
8.Operating mode
Selecting work mode can shift LAN or WAN interface, the default interface is “Ethernet cable-LAN,
Ethernet interface-WAN”. It means the default interface is Ethernet interface-WAN
Remark:
(1) The cable one side connect WiFi-SB-L3 interface, and the other side connect out net, such as:
router, modem, the interface is “Ethernet cable-LAN, Ethernet interface-WAN”. At this moment,
WiFi-SB-L3 interface is LAN interface.
(2) The cable one side connect WiFi-SB-L3 interface, and the other side connect to net, such as:
computer, the interface is “Ethernet cable-WAN, Ethernet interface-LAN”. At this moment, WiFi-SB-L3
interface is WAN interface.
9. LAN interface setting
Enter the webpage, click LAN interface setting, DHCP service is default open. As the follow:

WiFi-SB-L3 300M WiFi Router WiFi Bridge WiFi Repeater
4
10.WiFi Settings
In Basic Settings, user can choose to disable WiFi network, change WiFi Repeater (SSID), Channel. In WiFi
Security, user can revise Security Mode and Pass Phrase.

WiFi-SB-L3 300M WiFi Router WiFi Bridge WiFi Repeater
5
Chapter 2 Bridge Mode Quick Setup Guide
1. Shift work mode
Enter the configuration interface, click work mode, choose device mode as “WIFI
Transparent intelligent bridge ”, as the follow:
Remark: WiFi-SB-L3 default mode is ROUTER MODE, after correction, it need to restart, then it can
come into effect.
2. Search for WIFI hotspot
After the jump page, it will automatically appear scan window, it can search the around
wireless signal which has opened the SSID broadcasting. As the follow:
Select one correct WiFi hotspot and click next step, it will appear the follow interface.

WiFi-SB-L3 300M WiFi Router WiFi Bridge WiFi Repeater
6
Enter the right password, click submit button after confirmation.
After submission, it will appear above prompt, configuration parameters saved

WiFi-SB-L3 300M WiFi Router WiFi Bridge WiFi Repeater
7
successfully, after ensuring the password is right, please restart the device.
Remark:
1.After configured successfully, the WiFi name of the device is the name of source hot spot_the last two charact
er of MAC address, the password, encryption method and channel are the same as the source hot spot,
the users can go to WiFi Repeater option to change SSID (WiFi name) and password.
2.After successful configuration, if you want to use the function of wired to wireless, you need to reset
factory settings
Prompt：
1.User can enter configuration interface, click RESET button to let the device restore factory setting
2.User can restore factory settings by reset button:
(1) If choose the “Normal reset”mode on the reset mode of configuration interface, user need to press
button for 5 seconds, about waiting 60 seconds for restoring factory settings.
(2) If choose the “Hotel reset”mode, user only need one long time press, and then quick two times
short press to finish restore, the restoring process need 60 seconds.
(3) The device default mode is “Normal reset”
