VonHaus 3500006 User manual

20V MAX ANGLE
GRINDER
3500006 - Instruction Manual
CAUTION: Using this product with 1.5Ah Battery or
2.0Ah Battery can cause the Battery to overheat.

CONTENTS
Safety Instructions 1
Safety Instructions 2
Safety Instructions 3
Safety Instructions 4
Safety Symbols 5
Specification 6

Battery Capacity Indicator, Charging Lights 7
Attaching the Safety Guard and Grinding Disc 8
Battery Insertion/Removal, Powering On/Off 9
Care & Maintenance, Troubleshooting 10
User Notes 11
Warranty 12

WARNING
PLEASE READ THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE
1
GENERAL SAFETY INFORMATION.
WARNING! Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in
electric shock, fire and/or serious injury.
Please retain all warnings and instructions
for future reference.
The term “power tool” in the warnings
refers to your mains-operated (corded)
power tool or battery-operated (cordless)
power tool.
INTENDED USE.
This 20 Max Angle Grinder is not
intended for use by persons with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instructions concerning use of the tool by
a person responsible for their safety.
Children should be supervised to ensure
they do not play with the tool.
WORK AREA SAFETY.
Keep your work area clean and well lit.
Cluttered or dark areas invite accidents.
Do not operate power tools in explosive
atmospheres such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the
dust or fumes.
Keep bystanders, children and animals
away whilst operating the power tool.
Distractions can cause you to lose control.
ELECTRICAL SAFETY.
Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if
your body is earthed or grounded.
Do not expose power tools to rain or wet
conditions. Water entering the power tool
will increase the risk of electric shock.
BEFORE USE.
Use personal protective equipment.
Always wear eye protection. Protective
equipment such as a dust mask, non-
skid safety shoes, hard hat, or hearing
protection used for appropriate
conditions will reduce personal injuries.
Dress appropriately. Do not wear loose
clothing or jewellery. Keep your hair,
clothing and gloves away from moving
parts to prevent them from becoming
caught in the tool.
If devices are provided for the connection
of dust extraction and collection facilities,
ensure that these are connected and
properly used to reduce dust-related
hazards.
POWER TOOL USE AND CARE.
Prevent unintentional starting. Ensure the
switch is in the off position before picking
up or carrying the tool. Carrying power
tools with your finger on the switch, or
energising power tools that are switched
on, invites accidents.
Do not use the power tool if the switch
does not turn it on and off. A power tool
that cannot be controlled with the switch
is dangerous and must be repaired.
Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
WARNING! Use only accessories
recommended for this tool. Follow
the instructions that accompany the
accessories. The use of improper
accessories may result in injury to the
operator or damage the tool.
WARNING! If any part is missing or
damaged, do not plug the tool into the
power source or install any accessory until
the missing or damaged part is replaced.
Failure to follow this instruction could
result in serious personal injury.

WARNING
PLEASE READ THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE
Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power tool
while you are tired or under the influence
of drugs, alcohol or medication. A
moment of inattention while operating
power tools may result in serious personal
injury.
Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job
better and safer at the rate for which it
was designed.
Do not overreach. Keep proper footing
and balance at all times. This will enable
better control of the power tool in
unexpected situations.
AVOIDING KICKBACK
Maintain a firm grip on the power tool
and position your body and arm to allow
you to resist kickback forces. Always
use the auxiliary handle, if provided, for
maximum control over kickback or torque
reaction during start up.
The operator can control torque reactions
or kickback forces, if proper precautions
are taken.
Never place your hand near the rotating
accessory the accessory may kickback
over your hand.
Do not position your body in the area
where power tool will move if kickback
occurs. Kickback will propel the tool in
the direction opposite to the wheel’s
movement at the point of snagging.
Use special care when working corners,
sharp edges etc. Avoid bouncing and
snagging the accessory. Corners, sharp
edges or bouncing have a tendency to
snag the rotating accessory and cause
loss of control or kickback.
MAINTENANCE & STORAGE.
Maintain the power tool. Check for
misalignment or binding of moving
parts, breakage of parts and any other
condition that may affect the power tool’s
operation. If damaged, have the power
tool repaired before use. Many accidents
are caused by poorly maintained power
tools.
Store idle power tools out of reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands
of untrained users.
SERVICE.
Have your power tool serviced by a
qualified repair person using identical
replacement parts only to ensure that the
safety of the power tool is maintained.
IMPORTANT PRODUCT CARE
INFORMATION.
This tool uses Lithium-ion battery cells.
Care MUST be taken to ensure both
the safety and life of the battery is
maintained. Ensure you have read all of
the safety information in the previous
pages before using the tool.
Safety devices and circuitry for this tool
are located in the battery of this tool. The
battery is a vital component, not just for
the power source, but also for the full
safety control for both the charging and
tool operation.
Avoid overloading the tool during
operation.
NOTE: The battery is more susceptible to
overloading when at the lower end of the
charge.
ADDITIONAL SAFETY INFORMATION
FOR THE CHARGER.
This tool is powered by Lithium-ion
batteries which may only be charged
with the specifically designed Lithium-ion
battery charger purchased with this tool.
Do not attempt to charge the battery
with any charger other than the one

WARNING
PLEASE READ THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE
3
supplied as this is potentially dangerous.
Do not plug anything other than the
supplied battery into the charger as other
objects may touch dangerous voltage
points or short out parts which may result
in fire or electric shock.
Before using the charger, read all
instructions, labels and cautionary
markings on the charger and battery,
as well as the instructions on using the
battery.
Do not use the charger if it has been
subjected to a heavy knock, dropped or
otherwise damaged in any way. Take the
charger to an authorised service centre
for it to be checked and repaired.
DANGER! If the battery is cracked or
damaged in any way, do not insert it into
the charger.
Do not attempt to disassemble the
charger. Opening or removing covers
may expose you to dangerous voltages
or other risks. Incorrect reassembly may
result in the risk of fire or electric shock.
If there is a problem with the battery or
tool, take it to your nearest authorised
service centre.
Take the tool or charger to your nearest
authorised service centre:
If liquid has been spilled into the tool or
charger, or if rain or water has touched
the tool or charger.
If the tool or charger does not operate
normally after you follow the operating
instructions.
If the tool or charger exhibits a distinct
degradation in performance.
If the tool or charger is damaged in any
way.
If the battery is not charged within the
time frame as specified in this manual,
turn the charger off.
Use the battery charger indoors only.
Do not place the tool or charger on an
uneven surface as a fall may cause serious
damage.
Do not operate the charger in a cabinet
or other enclosure unless proper
ventilation is provided.
Never place the tool or charger near or
over a heat source such as radiator or
heater.
Do not charge batteries or use the
tool and battery in locations where the
temperature may be below 0°C, or
above 40°C such as inside sheds or metal
structures.
The battery can be charged or operated
at temperatures between 0°C and 40°C.
WARNING! Never charge your Lithium-
ion battery below or above temperatures
recommended as this may result in fire or
serious damage to the battery.
The most suitable temperatures to charge
the battery are between 20°C and 25°C.
Do not place any object onto the charger
or allow any object to rest on the charger.
Make sure that the charger cable is
positioned where it will not be stepped
on, tripped over or otherwise subjected
to damage or stress. Keep the lead away
from operating machinery.
Do not use an extension cord unless
absolutely necessary. The use of an
improper extension cord could result in
fire or electric shock.
Never attempt to connect two chargers
together.
WARNING! Do not allow water or any
other liquid to come into contact with
the charger as this may result in electric
shock. Do not position the tool or battery
charger near water. Take care not to spill
liquid of any kind on the tool or charger.
To reduce the risk of electric shock,
unplug the charger from the power
supply before attempting to clean it. To
clean the tool or charger, wipe with a

WARNING
PLEASE READ THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE
damp cloth. Use of any other cleaners is
not recommended.
Do not pull on the lead of the charger
to disconnect it from the mains power
socket.
ADDITIONAL SAFETY INFORMATION
RELATED TO BATTERY SAFETY.
Use only the battery supplied with
this tool or DOMU Brands approved
replacements.
Do not use the battery to power any
device other than the tool it was sold
with.
Charge the battery only with the charger
supplied with the tool or approved
replacements and according to the
instructions in this manual.
Do not charge the battery in a place
where static electricity is generated, or
let the battery touch anything that is
statically charged.
Handle batteries with care to avoid
shorting the battery with conducting
materials such as nails, screws, metal
watches, hands, rings, bracelets and keys.
The battery may overheat and could
cause burns.
Never attempt to open the battery,
puncture the battery, or subject the
battery to strong physical shock.
Stop using the product if it exhibits
abnormal heat, odour, colour,
deformation, or is in an abnormal
condition.
If you detect leakage or a foul odour, it is
especially important to keep the battery
away from fire. If battery liquid leaks onto
your skin or clothes, wash well with clean
water immediately. If liquid leaking from
the battery leaks into your eyes, do not
rub your eyes; rinse eyes well (for at least
10 minutes) with clean water, and consult
a doctor immediately. Never use a leaking
battery.
Always allow the battery to cool down
after charging. Do not leave in a hot
environment.
Take care where the tool is stored. Do not
store in areas of corrosive fumes, or salt
air or similar conditions. Try to store the
tool in the packaging it is supplied in.
WARNING! Never store or leave your
Lithium-ion battery in temperatures over
that recommended as this may result in
fire.
Do not store the Lithium-ion battery
anywhere that the temperature can
easily reach temperatures higher than
recommended (garden sheds, vehicles in
direct sunlight etc.) Think before leaving
your Lithium-ion battery in storage.
Do not dispose of the battery in a fire, or
put the battery into a microwave oven,
conventional oven, dryer or high-pressure
container, as the battery may explode
under these conditions.
After it has reached the end of its useful
life, we recommend recycling the battery
at your local municipal council recycling
centre. DO NOT attempt to replace the
battery cells in the product or repair or
modify any part of the battery assembly.
When recycling, make the battery non-
conductive by applying insulating tape to
the terminals located on the battery.
WHEN TO CHARGE THE BATTERY.
The battery should be fully charged
before use.
The battery can be recharged at any
time during use, provided the pack is not
overheated.
If the battery starts to cut out due to low
voltage, or tasks previously undertaken
can no longer be performed, it is
recommended to stop using the tool and
recharge the battery.

WARNING! Pay
attention to all
safety and
guidance
Read manual
before use
Wear a dust
mask
Wear protective
gloves
Wear eye and
ear protection
The following safety symbols may appear on this product. Please ensure you
understand their meanings before operating this product in order to prevent personal
injury and avoid damage to the tool.
SAFETY SYMBOLS
5
DECLARATION OF CONFORMITY
We:
DOMU Brands Ltd
5th Floor The Tower
Deva City Office Park
Manchester
M3 7BF
Declare under our sole responsibility that the product:
SKU: 3500006
Description: VonHaus 20V Max Angle Grinder
To which this declaration relates is in conformity with the following
directives:
2014/30/EU, 2014/35//EU, 2006/42/EC, 2011/65/EU, 2013/56/EC

V
20 Max
BATTERY BATTERY
TYPE
Li-ion
DISC
DIAMETER
115
Ømm
SPECIFICATION
1. Shoe
2. Spindle Lock
3. Handle Thread
4. ON/OFF Switch/Safety Switch
5. Outer Washer
6. Inner Washer
7. Handle with Spanner Storage
8. Spanner
9. Guard
10. Battery Charger
11. Charge Indication Lights
12. 20V Max Battery
13. Battery Release Button
14. Battery Level Indication
15. Battery Level Indication Button
10
11
13
14
15
12
1
7
8
3
4
5
6
2
9
CHARGER
OUTPUT
21V 2.4A
V

BATTERY CAPACITY INDICATOR
When in use you can check the status of the 20V Max Battery (12) by pressing the Battery Level
Indication Button (15). Pressing this will illuminate the 20V Max Battery’s level of charge.
0-10% Charged 10-25% Charged 25-50% Charged
50-75% Charged 100% Charged
CHARGING LIGHTS
Connect the Battery Charger (10) to the power outlet socket.
• Frequently monitor the Battery Charger and 20V Max Battery while connected.
• Unplug the Battery Charger (10) and disconnect it from the 20V Max Battery (13) when
finished.
• Allow the 20V Max Battery (12) to cool completely before using it.
• Store the Battery Charger (10) and 20V Max Battery (12) indoors, and out of reach of children.
IMPORTANT if the battery does not fit properly, disconnect it and confirm that the battery
pack is the correct model for this charger as shown on the specification chart. Do not charge
any other battery pack or any battery pack that does not securely fit the charger.
7
GREEN LIGHT RED LIGHT BATTERY ON THE
CHARGER CHARGING STATUS
ON OFF NO Charger connected to power
supply.
OFF FLASHING YES Battery being charged.
ON OFF YES Battery fully charged.
ON ON YES Battery defective of faulty
connection.
Contact DOMU customer
services.
ON ON YES Battery too hot or too cold to
be charged. Battery will begin
to charge once the Battery has
cooled sufficiency.

ATTACHING THE SAFETY GUARD &
THE GRINDING DISK
WARNING! Always make sure that the Battery is removed from the Angle Grinder before making adjustments
or performing maintenance to the tool.
Take the Guard (9) and slot over the Shoe (1). Align
the notches and secure into place by closing the clip
and then tightening the screw.
IMPORTANT: Ensure the Guard is in between the
user and the blade.
Place the Inner Washer (6) onto the thread of the
Shoe (1) and align the flat edges with those on the
thread.
Place the Grinding Disc (10) over the Shoe (1) and
rest it upon the Inner Washer (6).
Take the Outer Washer (5) and place the flat side
against the Grinding Disc (10). Use the Spanner to
tighten together.
To tighten, hold down the Spindle Lock (2) and turn
the Grinding Disc until the Spindle Lock locates.
Place the Spanner (8) over the corresponding holes
and tighten whilst holding down the Spindle Lock.
9
6
10
5
8
1
Close to secure

BATTERY INSERTION/REMOVAL
WARNING! Before making any adjustments ensure
the appliance is switched off or remove the 20V Max
Battery (12).
Hold the Angle Grinder with one hand and the 20V
Max Battery (12) with the other.
To install, push and slide 20V Max Battery into the
battery port, make sure the Battery Release Button
(13) of the 20V Max Battery snaps into place and is
secure before beginning operation.
To remove, press the Battery Release Button and pull
the 20V Max Battery out at the same time.
POWERING ON/OFF
HANDLE ASSEMBLY
WARNING! Always make sure that the Battery is removed from the Angle Grinder before making adjustments
or performing maintenance to the tool.
WARNING! Always make sure that the Battery is removed from the Angle Grinder before making adjustments
or performing maintenance to the tool.
Before powering the Angle Grinder on/off, attach the
Handle (7) on either side you work from and ensure it
is tightened into place.
IMPORTANT: Always ensure you have a stable grip
when using the Angle Grinder.
9
To power on the Angle Grinder, press the
Safety Switch down then the squeeze the ON/
OFF Switch (4).
To power off the tool, push the ON/OFF Switch
towards the rear of the tool.
1.Press
2.Squeeze

TROUBLESHOOTING
PROBLEM SOLUTION
Check that the battery is correctly inserted.
Brushes may be worn. Please contact a qualified
engineer to have them replaced.
TOOL DOES NOT POWER ON.
DISK DOES NOT MOVE.
POOR PERFORMANCE.
DISK BECOMES HOT.
DISK JUDDERING OR
VIBRATING ABNORMALLY.
The Disk may be blocked. Power off and remove the
battery, safely remove the blockage.
Check that the Disk is correctly fitted.
Disk may have become worn. Replace as necessary.
You may be using the wrong type of Disk for the
material.
There may be a blockage. Remove the battery and
carefully remove the blockage.
Check that there are no obstructions.
Ensure the Disk has been put on securely
Ensure the Clamp Bolt is securely fastened.
CARE AND MAINTENANCE
To clean the Angle Grinder effectively, it is
recommended to use compressed air. If unavailable,
use a brush to remove dust and chips from the Saw.
IMPORTANT: Make sure to clean the ventilation
outlets regularly so as to prevent the Saw from
overheating.
Clean the exterior body of the tool with a soft damp
cloth using mild detergent to remove dust. Dry
thoroughly.
CAUTION: Never use any caustic agents - such as
gasoline, carbon tetrachloride, chlorinated cleaning
solvents, ammonia and household cleaners containing
ammonia - to clean the body of the tool.
Always check the tool for damage or wear before
each use. In particular, inspect the Saw Disk for wear
and replace if necessary.
Always store in a dry, frost-free place away from
children.
WARNING! Always make sure that the Battery is removed from the Angle Grinder before making adjustments
or performing maintenance to the tool.

11
USER NOTES

COPYRIGHT
WARRANTY
CUSTOMER SERVICE
All material in this instruction manual are copyrighted
by DOMU Brands.
Any unauthorised use may violate worldwide
copyright, trademark, and other laws.
To register your product and find out if you qualify for a free extended warranty please go to
www.Vonhaus.com/warranty.
Please retain a proof of purchase receipt or statement as proof of the purchase date.
The warranty only applies if the product is used solely in the manner indicated in the Warnings page of this
manual, and all other instructions have been followed accurately. Any abuse of the product or the manner in
which it is used will invalidate the warranty.
Returned goods will not be accepted unless re-packaged in its original packaging and accompanied by a
relevant and completed returns form. This does not affect your statutory rights.
No rights are given under this warranty to a person acquiring the appliance second-hand or for commercial or
communal use.
If you are having difficulty using this product and require support, please contact [email protected]
DISPOSAL INFORMATION
PRODUCT DISPOSAL INFORMATION
For electrical products sold within the European Community, at the end of the
electrical product’s useful life, it should not be disposed of with household
waste. Please recycle where facilities exist.
Contact your local authority for details of collection schemes in your area.
In all circumstances:
• Do not dispose of in domestic waste.
• Do not incinerate.
• Do not abandon in the environment.
• Do not dispose of WEEE as unsorted municipal waste.
HEALTH AND SAFETY FOR BATTERIES
Do not put in fire or mutilate – cells may burst and release toxic material.
Do not short-circuit cells as this may cause fire or burns.
The battery must be removed from the appliance before being scrapped.
The battery is to be disposed of safely.
BATTERY DISPOSAL INFORMATION
Do not mutilate batteries as corrosive electrolytes and flammable materials will
be released.
Do not incinerate – Danger of explosion and release of toxic fumes.
Do not dispose of batteries or cells in a charged condition.
Expired lithium-ion batteries must be recycled/disposed of in accordance with
the appropriate regulation or legislation. They should be returned to your local
warranty agent/stockist.
Li-ion

VonHaus®is a registered trademark of DOMU Brands Ltd
Made in China for DOMU Brands Ltd M24 2RW
Thank you for purchasing the 20V Max Angle Grinder
