Vortex PURE PRO Installation instructions

PURE PRO
Specifications & User manual
Description:
Vortex is a professional manufacturer of advanced computer input device on the global market. Our
product range comprises unique and standard keyboards which are primarily characterized by their
high degree of flexibility and their extreme reliability, making the ideal option for professional
applications.
The 0% tiny size keyboard is the perfect solution for limited spaces in situations.
The combine key is an epoch-making designed. Plus arbitrary change the key code that you want.
Enjoy now for this fantastic tool and your typing feeling.

Main Features:
1. Removable
2. 0% keyboard with QWERTY layout ( 7 Key)
3. Cherry MX key switch (Black, Blue, Brown, Red)
4. Dual layer PCB
5. Key cap material: ABS(UV coating- Backlit version only)、PBT
. LED backlight (Backlit version only)
7. USB Interface
Package Material
1. Keyboard x 1
2. User Manual x 1
3. USB Cable x 1
Technical Specification
Number of ke s: Interface:
US ASCII ( 7 keys) = US Layout USB (DC5V ----100mA)
Dimension: Available la out:
29.5 x 10.2 x 3.8cm (Keyboard) US USA
Cable: JP JAPAN
1.5 meters (mini USB B type)
Ke switch life time: Package:
Cherry: >5000 actuations 20 keyboards / 1 outer box
Programming Instruction
1. Press PMode(FN + Right CTRL) to enter the programming mode (PN LED flashing)
2. Press the key you want to program (PN LED on)
3. Key in the programming content and then press PN (PN LED flashing again)
4. Repeat step 2 and step 3 to program other keys
5. Press PMode(FN + Right CTRL) to exit programming mode (PN LED off)
Note:
•Support FN layer programming, you can select the FN combination key (e.g., FN + A) to program it
•Under SELECT state (step 1), you can press PN + any key to view its content in a word processing
software (e.g., Notepad)
•Support time delay, press 15ms key(FN + F) each time to delay 15ms, press 0.1s key(FN + G) each time
to delay 0.1s, press 0.5s key(FN + H) each time to delay 0.5s. Consecutive delay will add up but will only
be counted as 1 key stroke
•Every key can program up to 14 key strokes
•If there is no key pressed for 15 sec in programming, it will exit to normal mode

Programming Usage
Press PN + Programmed key, OR
Press Toggle(FN+Right SHIFT) to light up right FN key first. Then press the programmed key directly. If you
press PN + Programmed key at this moment, it will output the original key code.
Programming Examples
1. Program A as 123: FN + Right CTRL, A, 1, 2, 3, PN
2. Continue to program FN + A as 45 : FN + A, 4, 5, , PN
3. Continue to program B as CTRL + C: B, CTRL(Not release), C, Release CTRL and C, PN
4. Continue to program C invoking CMD under WIN7: WIN, C, FN + G, M, FN + G, D, FN + H, ENTER, PN
5. Finish programming: FN + Right CTRL
. Invoking programmed A: PN + A => Output 123
7. Invoking programmed FN + A: PN + FN+ A => Output 45
8. Invoking programmed C: PN + C => Running CMD.EXE
9. Switch to PN layer: Toggle(FN + Right SHIFT) => Right FN LED on
(1) Invoking programmed B: B => Outpu CTRL + C (Same as copy)
(2) Invoking programmed FN + A: FN+ A => Output 45 (No need to press PN)
(3) Invoking programmed C: C=> Running CMD.EXE
(4) If you need to get the A back (Now pressing A is 123): PN + A => A
Restore to factor default
Press and hold FN + R, Toggle LED is flashing after 3 sec. Continue to hold FN + R until the Toggle LED flashes
for 9 times will restore to factory default
FN General ke s Remark
1 F1
2 F2
3 F3
4 F4
5 F5
F
7 F7
8 F8
9 F9
0 F10
- _ F11
= + F12
I INS
P Print Screen
[ { Scroll Lock
] } Pause
X APP
↑ Page Up
↓ Page Down
← HOME
FN +
→
=
END
Key code change

FN Multimedia ke s Remark
Y Calculator
N Volume Down
M Volume Up
FN +
, <
=
Mute
Key code change
FN LED Control ke s Remark
Backlit LED on (Except Left FN, Right FN
and PN)
Press the 1
st
time
V
Backlit LED off Press the 2
nd
time
C Reduce LED brightness
FN + B =
Increase LED brightness
Totally 7 level of
brightness, backlight
status and brightness will
be saved after power
down
FN Programming Control ke s Remark
R Restore to factory default Need to hold for 12 sec
Switch to program layer Press the 1
st
time (Right FN on)
Right SHIFT Switch to visible layer Press the 2
nd
time (Right FN LED
off)
Enter Programming Mode Press the 1
st
time (PN LED
flashing)
Right CTRL
Exit Programming Mode Press the 2
nd
time (PN LED off)
F Delay 15ms
G Delay 0.1s
FN +
H
=
Delay 0.5s
Only valid in Programming Mode
FN Special ke s Remark
SHIFT key is down even when the SHIFT
key is released. Press the SHIFT key again
will make the SHIFT key up
Press the 1
st
time (Left FN
LED on)
FN + Z =
SHIFT key returns to normal Press the 2
nd
time (Left FN
LED off)

DIP Switch
ON OFF Remark
CAP = Left FN
CAP LED = Left FN LED
CAP = CAP
CAP LED = CAP LED
SW 1 Left FN = CAP
Left FN LED = CAP LED
Left FN = Left FN
Left FN LED = Left FN LED
Default = OFF
SW 2 Right CTRL = ` ~ Right CTRL = Right CTRL Default = OFF
SW 3 N/A N/A Default = OFF
SW 4
Write protect, try to press
FN+R to program a key will
cause PN LED flashing
quickly for one sec and then
returns to normal
Default = OFF
Keyboard Layout (Top view):
