VOV VWC-1850D User manual

THERMOELECTIRC
WINE COOLER
Model No: VWC-1850D
Operation Manual

Index
. General Safet Precautions…………......…...........………………..2
. Technical
Data………………………....….............………………………….3
. Illustrated
Structure……………………..........…...………………………3
. Electric Principle
Diagram…………………………..……………………4
.
Operation …………………………………………………………………………
…..4
. Particular
Precautions……………………………………………………….5
.
Maintenance………………………………………………………………………
…5
.
Troubleshooting……………………………………………………………………
5

.GENERAL SAFETY PRECAUTIONS
● After removing the wine cooler from the package, make sure it is in
good condition. In case of doubt, do not use it and contact an
authorized service center.
● Plastic bags, nails, etc. should be kept out of the reach of children.
Read the operation manual carefull and check that the rating data
on the rating nameplate corresponds to our power suppl .
● This wine cooler should onl be used as specified. The manufacturer
will not be held responsible for an damage due to improper use or
repairs made b unqualified personnel.
● Before cleaning the wine cooler, make sure it is unplugged. Never
clean the unit with an acid preparation, medical solution, dilution,
gasoline, oil or an other kind of chemical substance that could
damage the refrigerator.
● Repair should onl be made b authorized service centers.

● Caution
1.To reduce the risk of fire, replace onl with same t pe fuse.
2.Free standing installation onl
3.Do not use extension cords.
4.Danger: Risk of child entrapment. Before throwing awa our old
wine cooler, ou must note: a. Take off the door; b. Leave the
shelves in place, so that children ma not easil to climb inside.
.TECHNICAL DATA

III. ILLUSTRATED STRUCTURE
T pe VWC-1850D
Volume (liter) 52L
Case Iron
Material Door Glass
Unit Dimension
(W×H×D)(mm) 345X660X490
Packaging Dimension
(W×H×D)(mm) 385x685x525
Net Weight (Kg) 16
Gross Weight (Kg) 17.8
Power Consumption
(KW·h/24h) 1.5
Fitting ambient temperature range of
working
＜32
Temperature Range 7—18
Rated Voltage AC110V/220V
Rated Frequenc 60HZ/50HZ
Input power 130W

1 Light switch 2 Ream Cover 3 Light
4 Glass Door 5 Handle 6 Fan Mask
7 TEMP Control Board 8 Light
9 Shelf
10 Fan Mask 11 Foot
12 temp — for upper room 13 temp + for
upper room
14 LCD displa
15 temp — for lower room 16 temp + for lower
room
IV. ELECTRIC PRINCIPLE DIAGRAM
V. OPERATION OF WINE COOLER
This is a dual zone wine cooler; the upper zone is for storage of
white wine with temperature from 7 to 12, the lower zone is for
storage of red wine with temperature range from 12 to 18.
Control panel is in the middle of the door with LCD temperature
displa window in the middle. There are four buttons on the panel:
push “Temp △” and “Temp▽“ on the left to increase and decrease
the temperature in upper zone; and push “Temp △” and “Temp
“ on the right to increase and decrease the temperature in lower
zone. You can turn the interior light ON or OFF b pressing the light
switch inside upper compartment.
When the power switch is connected, cooling s stem starts to
work. The temperature is set on certain position, which means that
if the inner temperature reaches the set point, Self-control
Temperature S stem would stop cooling s stem so that the

temperature in the cabinet rises graduall .
When the inside temperature rises above the set point, cooling
Self-control Temperature starts to work again, the cellar enters
into cooling c cles.
The TEMP-ADJ button is set on one certain point when the cellar is
off the assembling line. When ou want to change the temperature
in the cabinet, please select the right zone and change accordingl .
VI. PARTICULAR PRECAUTIONS
● In order to function at its highest potential, this wine cooler needs
to be placed on flat floor, with 2cm spaces at each side and 10cm
space at the backside.
● Use the adjustable iron case to place the cellar full horizontal.
● Avoid direct sunshine and high temperature.
● Do not place heav articles on the top of the cellar.
VII.MAINTENANCE
● Shut off power suppl before cleaning cabinet.
● Take out wine and shelves, and then clean the cabinet with soda
water first and with clean water last.
● Do not use soap or detergent for the cabinet.
● Clean the cellar regularl .
VIII. TROUBLESHOOTING
S mptoms Possible cause Solutions
No cooling
Plug not put in
Low voltage
Fuse broken
Put in the plug
Ensure normal voltage
Change fuse
Temperature
inside not cold
enough
The refrigerator is
placed too close to a
heat source;
Bad ventilation;
Fans don’t work;
The door is not
closed tightl or
opened too
frequentl or for too
long time;
Keep the refrigerator awa from sunshine or
other heat source;
Place the refrigerator in the area with good
ventilation and keep things awa from the
fans;
Check whether the plug is connected or
change the fan;
Close the door tightl and don’t open the door
too frequentl or for too long time.
Peculiar smell
inside
refrigerator
Check whether there is
an thing sour inside Wrap the source or take it out
Inside light
flashes
Set temperature
higher than inner
Adjust the adjustor

temperature;
The automatic
defrost function
start to work
Normal function. No repair needed
Frost on the
cold sink
Too much humidit or
too low temperature
inside the case
Output the plug, stop the power, and defrost b hand,
connect power again when the ice thaws
