Logik LWC32B10 User manual

Wine Cooler
Instruction Manual
LWC32B10
LWC32B10_IB_final110309.indd 1 09/03/2011 11:43 AM

LWC32B10_IB_final110309.indd 2 09/03/2011 11:43 AM

Contents
Unpacking.................................................................................................................................... 4
Installation ................................................................................................................................... 5
Location ..................................................................................................................................................................... 5
Reversing the Door Swing................................................................................................................................... 5
Levelling the Unit ................................................................................................................................................... 7
Cleaning Before Use .............................................................................................................................................. 7
Before Using Your Unit.......................................................................................................................................... 7
Product Overview........................................................................................................................ 8
Operation ..................................................................................................................................... 9
Switching On Your Wine Cooler ........................................................................................................................ 9
Using the humidier............................................................................................................................................10
Filling water in humidier .................................................................................................................................10
Stacking the Wine Bottles..................................................................................................................................10
The Internal Light .................................................................................................................................................10
Noises Inside the Wine Cooler .........................................................................................................................11
Storing Wine in Your Wine Cooler...................................................................................................................11
Filling Your Wine Cooler .....................................................................................................................................12
Space Around the Wine Cooler .......................................................................................................................12
Keep the Door Closed.........................................................................................................................................12
Cleaning ..................................................................................................................................... 13
Cleaning the Inside of the Wine Cooler........................................................................................................13
Cleaning the Outside of the Wine Cooler....................................................................................................13
Cleaning Tips..........................................................................................................................................................13
Maintenance .............................................................................................................................. 14
Changing the Internal Light .............................................................................................................................14
Care When Handling ...........................................................................................................................................14
Installation ..............................................................................................................................................................14
Servicing..................................................................................................................................................................14
Switching O for Long Periods of Time........................................................................................................14
Disposal...................................................................................................................................... 14
Specication .............................................................................................................................. 15
Safety Warnings......................................................................................................................... 16
LWC32B10_IB_final110309.indd 3 09/03/2011 11:43 AM

4
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
The Main Unit
Shelf
P.N.: Cjj02-01
Adjustable Shelves x 4
P.N.: Cjj04
Top Adjustable Shelf
P.N.: Cjj04A
Instruction Manual
P.N.: LWC32B10-002
Bottle Rack
P.N.: Cjj-14
Thank you for purchasing your new Logik Wine Cooler.
We recommend that you spend some time reading this instruction manual in
order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
LWC32B10_IB_final110309.indd 4 09/03/2011 11:43 AM

Location
When selecting a position for your unit make sure the floor is flat and firm, and that the
room is well ventilated with an average room temperature of between 16°C and 32°C. Avoid
locating your unit near a heat source, e.g. a cooker, boiler or radiator. Avoid direct sunlight.
If you are placing your unit in an outbuilding such as a garage or annex ensure that the unit
is placed above the damp course, otherwise condensation will occur on the cabinet. Never
place the unit in a wall recess or into fitted cabinets or furniture.
When installing the unit, ensure that 2 cm of free space is left at both sides and 3 cm at the
rear of the unit. The door can open to the right or the left, depending on what better suits
the location. Please ensure there is adequate space for the door to fully open.
• If you want to have the door swing reversed, we recommend that you contact a
qualified technician. You should only try to reverse the door yourself if you believe
that you are qualified to do so.
• All parts removed must be saved to do the reinstallation of the door. You should
rest the unit on something solid so that it will not slip during the door change
process. Do not lay the unit flat as this may damage the coolant system. Ensure
the unit is unplugged and empty.
Reversing the Door Swing
Tools required: Phillips style screwdriver / Flat bladed screwdriver / Hexagonal spanner.
• Ensure the unit is unplugged and empty.
• Adjust the two levelling feet to their highest position.
• To take the door off it is necessary to tilt the unit backwards. You should rest the
unit on something solid, e.g. a chair just below the top panel.
• All parts removed must be saved to do the reinstallation of the door. You should
rest the unit on something solid so that it will not slip during the door reversing
process.
• Do not lay the unit flat as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
1. Tilt the unit carefully. 2 people are required to tilt the
unit during the door reversing process.
2. Remove the two screws that hold the lower hinge
(Right side) to the frame. Also, remove the levelling
foot. Remove the left levelling foot and transfer it to the
right side.
INSTALLATION
5
LWC32B10_IB_final110309.indd 5 09/03/2011 11:43 AM

5. Remove the top hinge pin and spring inside. Refit on to
the opposite side.
3. Place the two screws, the bottom bracket and the
levelling feet to one side.
4. Lift the door and place it on a padded surface to
prevent scratching it.
6. Set the door back on to the top hinge. Screw the
bottom hinge into place on the new side. Also screw in
the levelling foot.
7. Check that the door is aligned horizontally and
vertically and that the seals are closed on all sides
before finally tightening the bottom hinge. Re-adjust
the levelling feet.
INSTALLATION
6
LWC32B10_IB_final110309.indd 6 09/03/2011 11:43 AM

Levelling the Unit
To do this use the two levelling feet at the front of the unit.
If the unit is not level, the door and magnetic seal
alignments will not be covered properly.
Cleaning Before Use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm
water using a ‘wrung-out’ sponge or cloth. Wipe completely dry before replacing the shelves
and bottle rack. Clean the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the
unit.
• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant fluid needs time
to settle.
Before Using Your Unit
Before placing any wine in the unit, turn it on and wait for 24 hours, to make sure it is
working properly and to allow it time to fall to the correct temperature. Your unit should not
be overfilled.
INSTALLATION
7
LWC32B10_IB_final110309.indd 7 09/03/2011 11:43 AM

8
Product Overview
Thermostat
(at the rear of the Cooler)
Humidier
Glass Door
Adjustable
Shelves
Shelf
Bottle Rack
Levelling Feet
LWC32B10_IB_final110309.indd 8 09/03/2011 11:43 AM

9
Operation
Switching On Your Wine Cooler
1. The internal temperature of the wine cooler is
controlled by a thermostat. There are four settings
MIN, NORMAL, MAX and SUPER.
2. Before connecting the wine cooler to the mains
socket, make sure that the thermostat control dial,
located at the rear of the wine cooler on the right
hand side is set to MAX. Connect the mains cable
to the mains socket.
3. After the wine cooler has been on for 20 minutes
adjust the thermostat control dial to NORMAL.
This is the recommended setting when operating
at normal room temperature (between 16°C and
32°C).
4. The wine cooler may not operate at the correct
temperature if it is in a particularly hot or a
particularly cold room, or if you open the door
often.
5. If you are concerned that the wine cooler is not
being kept cold enough and wish to check the
temperature you will need a special fridge/freezer
thermometer. You may also need a hygrometer to
check the humidity of your wine cooler. These are
available from most supermarkets and hardware
shops.
Place the thermometer and hygrometer on the
middle shelf of the wine cooler, where it can be
read easily. Leave overnight, the temperature in the
wine cooler should be between 5°C and 20°C and
the humidity in the wine cooler should be between
50%-80% RH depending on the type of wine.
THERMOSTAT CONTROL DIAL
NORMAL
SUPER
MIN
MAX
In the MIN position the wine cooler will
not operate, but the power supply remains
connected.
LWC32B10_IB_final110309.indd 9 09/03/2011 11:43 AM

10
Using the humidier
Using the humidifier can protect wine from too much or too less humidity. If your wine
cooler is too dry (below 50% RH), the cork dries up. The air can get into the wine and alter its
composition.
But the humidity of the wine cooler can’t be too high (above 80% RH), as the humidity damages
the cork and the smell of the cork will go into the wine.
Filling water in humidier
1. Take out the wine bottle from the bottle rack.
2. No need to remove the humidifier.
3. Use a bottle to fill water into the water tank to the level of 350 ml.
4. Remember to fill water every 6 days (depending on the actual humidity in your wine cooler).
Stacking the Wine Bottles
The shelf system has been designed so that a
range of shelf heights can be selected. All the
shelves can be adjusted. There is also a bottle
rack at the bottom of the wine cooler.
The Internal Light
The wine cooler has an internal light which can
be left on while the glass door is shut. Switch the
ON/OFF button as desired.
ON OFF
Max Capacity : 32 bottles
The temperature inside the wine cooler
will be higher if the internal light is left on.
