Please read this manual carefully before installing and starting up, and store it in a safe place. If
you pass on the product to another person, hand over this instruction manual along with it.
WINE CABINET - INSTRUCTION MANUAL
Models: WSD49, WSD70, WCS15, WCD30-700, WCD30, WCS30PS-700,
WCD30-780, WCD40-700, WCD50-700, WCD60-700, WCD60,
WCD60P-700, WCD60P, WCDD60, WE2D60, WCS60PS-700,
WCD60-780, WCD187H, WKED25P, WKD25, WKD49, WKD70,
WKED112P, WSTO8177, WSTO82, WSTO78T, VCB100SS, VCB125SS,
VCB170SS & VCB220SS.
Lindström & Sondén AB, Havsbadsvägen 1, 262 63 Ängelholm, Sweden

TABLE OF CONTENTS
1. IMPORTANT SAFEGUARDS 3
1.1 For your safety 3
2. DISPOSAL 6
3. CONNECTION TO THE MAINS SUPPLY 7
4. PRODUCT FEATURES 8
5. INSTALLATION 9
5.1 Before using your appliance 9
5.2 Installation of your appliance 9
5.3 Electrical connection 14
5.4 Installing the handle 15
5.5 Reversing the door hinge 15
5.6 Anti-tip bracket installation 21
5.7 Securing the appliance 22
6. OPERATING YOUR APPLIANCE 23
6.1 Use and control - single zone with led display 23
6.2 Use and control – single zone with lcd display 25
6.3 Use and control – dual zone with led display 27
6.4 Use and control – dual zone with lcd display 29
6.5 Use and control – three zone with led display 31
6.6 Use and control - three zone with lcd display 33
6.7 Dierent modes 39
6.8 Bottle loading, noises and hygometry 40
7. CARE AND MAINTENANCE 44
8. PROBLEMS WITH YOUR APPLIANCE 47
8.1 Troubleshooting guide 47
9. WARRANTY 50

3
1. IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions should always be followed to reduce
the risk of re, electric shock, and injury to persons, including the following:
1.1 For your safety
Read all instructions carefully, even if you are quite familiar with the appliance.
• The appliance is intended to be used for the storage of wine. Use this appliance only as
described in this manual. Other uses not recommended may cause re, electric shock or
personal injury.
• In compliance with EN standards: This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
• In compliance with IEC standards: This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety. Children should
be supervised to ensure that they do not play with the appliance.
• Electrical devices are not toys. Always keep the device out of the reach of children. Keep
the mains cord out of the reach of children. Do not let the mains cord hang over the
edge of the table or worktop on which the appliance stands.
• Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.
• To protect against the risk of electric shock, DO NOT IMMERSE the unit, cord, or plug in
water or spray any other liquid.
• Unplug the appliance from the plug socket when not in use, when moving from one
location to another and before cleaning.
• To disconnect the appliance, grip the plug and pull it from the wall outlet. Never pull by
the cord.
• WARNING! Please keep the appliance away from substance, which can cause ignition.
Do not operate the appliance in the presence of explosive and/or ammable fumes.
• Do not place the appliance or any of its part near an open ame, cooking or other
heating appliance.
• Do not operate the appliance with a damage cord or plug, if the product malfunctions,
or if it is dropped or damaged in any manner. If the SUPPLY CORD is damaged, it must
be replaced by the manufacturer, or an authorized service centre or similarly qualied
persons in order to avoid a hazard.

4
• The use of attachments not recommended by the manufacturer may be hazardous.
• Place the unit on a dry level surface.
• Do not operate if the housing is removed or damaged.
• A loose t between the AC outlet (receptacle) and plug may cause overheating and a
distortion of the plug. Contact a qualied electrician to replace loose or worn outlet.
• Locate the unit away from direct sunlight and sources of heat (stove, heater, radiator,
etc.).
• WARNING! This appliance is CFC- and HFC- free and contains small quantities of
Isobutane (R600a) which is environmentally friendly, but ammable. It does not damage
the ozone layer, nor does it increase the greenhouse eect. Care must be taken during
transportation and setting up of the appliance that no parts of the cooling system are
damaged. Leaking coolant can ignite and may damage the eyes.
• In the event of any damage:
» Avoid open ames and anything which creates a spark,
» Disconnect from the mains,
» Air the room in which the appliance is located for several minutes and,
» Contact the Service Department for advice.
• The more coolant there is in an appliance, the larger the room it should be installed
in. In the event of a leakage, if the appliance is in a small room, there is the danger
of combustible gases building up. For every 8 g of coolant at least 1 cubic meter of
room space is required. The amount of coolant in the appliance is stated on the data
plate inside the appliance. It is hazardous for anyone other than an Authorised Service
Person to carry out servicing or repairs to this appliance. In Queensland of Australia the
authorized person must hold a Gas Work Authorisation for hydrocarbon refrigerants,
before carrying out servicing or repairs which involve the removal of covers.
• WARNING! Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction. No liability will be accepted for any damage incurred
owing to misuse of the appliance or as a result of repairs carried out by unqualied
personnel. In this case neither the guarantee nor any other liability claims will apply.
• WARNING! Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
• WARNING! Do not damage the refrigerant circuit. Never use an appliance with a
damaged circuit.
• WARNING! Do not use any electrical appliance inside the food storage compartment of
the appliance, unless they are of the type recommended by the manufacturer.
• WARNING! To avoid a hazard due to instability of the appliance, it must be xed in
accordance with the instructions.

5
• CAUTION! Please keep the products away from the re or similar glowing substance
before you dispose the appliance.
• WARNING! Do not store explosive substances such as aerosol cans with a ammable
propellant in this appliance.
• WARNING! When position the appliance, ensure the supply cord is not trapped or
damaged.
• WARNING! Do not locate multiple portable socket-outlets or portable power supplies at
the rear of the appliance.
• WARNING! To avoid contamination of food, please respect the following instructions:
» Opening the door for long periods can cause a signicant increase of the
temperature in the compartments of the appliance.
» Clean regularly surfaces that can come in contact with food and accessible drainage
system.
» Clean water tanks if they have not been used for 48 hours; ush the water system
connected to a water supply if water has not been drawn for 5 days.
» Store raw meat and sh in suitable containers in the refrigerator, so that it is not in
contact with or drip onto other food.
» Two-star frozen-food compartments are suitable for storing pre-frozen food, storing
or making ice cream and making ice cubes.
» One, two and three-star compartments are not suitable for the freezing of fresh
food.
» If the refrigerating appliance is left empty for long periods, switch o, defrost, clean,
dry, and leave the door open to prevent mould developing with the appliance.
• Regarding the information pertaining to the use of the appliance, thanks to refer to the
below paragraph of the manual.
• Regarding the method for replacing illuminating lamps (if the lamps can be replaced by
the user), thanks to refer to the below paragraph of the manual.
• This appliance is intended to be used in household and similar applications such as:
» sta kitchen areas in shops, oces and other working environments;
» farm houses and by clients in hotels, motels and other residential type
environments;
» bed and breakfast type environments;
» catering and similar non-retail applications.
• Do not attempt to repair or replace any part of your appliance unless it is specically
recommended in this manual. All other servicing should be referred to a qualied
technician.

6
• Replace all panels after service before operating.
• WARNING! Glass breakage. Danger of injury from broken glass. If installed at altitudes
above 1500m there is a risk of the glass in the door breaking because of changes in air
pressure. Shards of glass can cause severe injury if not handled with care.
• Use two or more people to move and install the appliance. Failure to do so can result in
back or other injury.
• Never clean appliance parts with ammable uids. These fumes can create a re hazard
or explosion. And do not store or use gasoline or other ammable vapors and liquids
in the vicinity of this or any other appliance. The fumes can create a re hazard or
explosion.
• Do not connect or disconnect the electric plug when your hands are wet.
• It is recommended that a separate circuit, serving only your appliance be provided. Use
receptacles that cannot be turned o by a switch or pull chain.
• If you have a lockable appliance, do not keep the key near the appliance or within reach
of children.
• If you have lost the instruction manual, please contact the local agent or send us an
email for the electronic version.
WARNING! To reduce the risk of re, electric shock or personal injury, unplug or disconnect
the appliance from the power supply before servicing.
SAVE THESE INSTRUCTIONS
If you are experiencing problems, check the Troubleshooting Guide at the back of this
manual. It lists causes of minor operating problems that you can correct by yourself.
2. DISPOSAL
Dispose of your appliance packaging properly. Ensure that any plastic wrappings, bags etc.
are disposed of safely and kept out of the reach of babies and young children. Danger of
suocation!
Refrigeration equipment must be properly disposed of in a professional and appropriate
way, in accordance with the current local regulations and laws which protects the
environment this applies to your old appliance and to your new unit once it has reached the
end of its service life.
WARNING! Please ensure that old, worn appliances are rendered unusable before disposal
by removing the doors, removing the plug, cutting the network cable, and removing
or destroying any snap fastenings or bolts. You will thus prevent children from locking

7
themselves in the appliance during play (risk of suocation) or endangering their lives in
any other way. DO NOT dispose of the appliance in landll as the insulation (Cyclopentane)
and refrigerant gas (R600a) contained in these appliances are ammable.
Disposal instructions:
• The appliance must not be disposed of in the dustbin or with normal household
rubbish.
• The coolant circuit, particularly the heat exchanger at the back/bottom of the unit, must
not be damaged.
• The symbol on the product or its packaging indicates that this product is not to
be handled as normal household waste but is to be taken to a recycling collection
point for electrical and electronic goods. By correctly disposing of this product you
are contributing to the protection of the environment and to the health of your fellow
human beings. Improper disposal endangers health and the environment. Further
information about the recycling of the product may be obtained from your town hall,
refuse collection department or the store where you purchased the product.
3. CONNECTION TO THE MAINS SUPPLY
UK, IRL, HK, SINGAPORE
Check that the voltage marked on the product corresponds with your supply voltage.
This product is tted with a 13A plug complying with BS1363.
If this plug is unsuitable or needs to be replaced, please note
the following:
WARNING! THIS APPLIANCE MUST BE EARTHED.
Important: The wires in the mains lead are coloured in
accordance with the following code:
GREEN/YELLOW  EARTH
BLUE  NEUTRAL
BROWN  LIVE
This appliance is equipped with a plug tted with a 13 amp fuse. Should the fuse fail, then it
must be replaced with an ASTA approved fuse (conforming to BS1362) of the same rating. If
you need to replace the plug or if the plug is of the incorrect type for your socket, remove it
and replace it with an appropriate type. Dispose of the old plug safely.
As the colours of the wires in the mains lead of this appliance may not correspond with the
coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/

8
YELLOW wire is the EARTH and must be connected to the terminal which is marked with
the letter‘E’or by the earth symbol or coloured GREEN or GREEN/YELLOW.
The BLUE wire is the NEUTRAL and must be connected to the terminal which is marked
with the letter‘N’or coloured BLACK.
The BROWN wire is the LIVE wire and must be connected to the terminal which is marked
with the Letter‘L’or coloured RED.
Always ensure that the plug cord grip is fastened correctly.
If in doubt consult a qualied electrician who will be pleased to do this for you. This product
conforms to all stutatory safety standards.
DANGER
Electric
Shock Risk
EN
4. PRODUCT FEATURES
• Built-in or Free-standing installation with single, dual or three temperature zone,
depending on your model.
• Continuously variable electronic temperature control with digital display and
SMARTLIGHT touchpad input.
• Temperature can be set from 5° to 20°C (41° to 68°F ) for either compartment and can be
displayed in either Fahrenheit or Celsius degree.
• Can be set to the long time storage maturing temperature or a specic serving
temperature for red/white/sparkling wines.
• Cooling and Heating to maintain the perfect storage and/or service condition.
• Dynamic compressor type cooling to ensure interior air circulation with even
distribution of temperature and humidity.
• Soft LED Interior Light with ON/OFF switch – Function mode and Showcase mode.
• Open-door and malfunction warning system.
• Sabbath mode will allow the lights to remain o during certain religious observances.
• Temperature memory function - If power is interrupted (power surge, breaker switch,
etc.) and then powered up again, the unit will operate with the last temperature
set-point.
DANGER
Electric
Shock Risk

9
• Automatic defrosting with defrost water evaporation.
• Reversible tempered double/triple pane smoked glass door protects your wine from UV
light and creates an attractive display with minimal condensation and low noise.
• Black coated matte steel outer frame and black plastic interior liner oer lifetime
performance and stability. The black liner prevents excessive light from damaging the
maturing process.
• Optional stainless steel-framed glass door with stainless steel handle.
• Optional roll-out and adjustable solid varnished beech shelves allow for maximum
convenience and exibility to accommodate various size bottles.
• Environmentally friendly refrigerant and foaming insulation gas.
• Optional security lock system with keys.
• Optional humidity control system (Humidity Box).
• Optional active charcoal air lter.
5. INSTALLATION
5.1 Before using your appliance
• Remove all exterior and interior packing. Clean the interior surface with lukewarm water
using a soft cloth. The unit may have residual odors at rst, they will disappear as the
unit cools.
• Before connecting the appliance to the power source, let it stand upright for at least 24
hours. This will reduce the possibility of a malfunction in the cooling system caused by
handling during transportation to ensure that oil ows back into the compressor. During
this time we recommend that you leave the door open to clear any residual odors.
• The door on this appliance can be opened from either the left or the right side. The unit
is delivered with the door opening on the left side. Should you wish to open the door
from the right, follow the instructions‘Reversing the door hinge’.
• Install the handle on the door if necessary.
NOTE! Features and specications are subject to change without notice.
5.2 Installation of your appliance
• The appliances are designed to be built-in or recessed or freestanding installation
depending on your model. For the freestanding installation only models, it is not
intended to be used as a built-in appliance.

10
• WARNING! Do not store or install the appliance outdoors. The unit is for indoor use only.
• WARNING! Do no install the appliance in the laundry. Avoid locating the unit in damp
areas.
• Place your appliance on a oor/surface that is strong enough to support it when it is
fully loaded. To level your unit, adjust the front leveling leg at the bottom of the unit.
• For freestanding installation, 100mm of space between the back and sides of the unit
are suggested, which allows the proper air circulation to cool the compressor and
condenser for energy saving. Even with built-in installation, it is a must to keep 5mm
space on each side and at the top to ensure proper service access and ventilation. Take
care that the air vent at the front of the appliance must never be covered or blocked in
any way.
• Locate the unit away from direct sunlight and sources of heat (stove, heater, radiator,
etc.). Direct sunlight may aect the acrylic coating and heat sources may increase
electrical consumption. Extreme cold ambient temperatures may also cause the unit not
to perform properly.
• Plug the unit into an exclusive, easily accessible plug socket. Any questions concerning
power and/or grounding should be directed towards a qualied electrician or an
authorized products service centre.
• The appliance must be installed to all electrical, plumbing, water and drain connections
in accordance with state and local codes.
• IMPORTANT! HIGH HUMIDITY CLIMATE. During periods of high humidity, some
condensation may appear on outside surface of glass door. This condensation will
disappear when humidity levels drop. For prevention, it is advisable to install the
appliance with sucient ventilation in a dry and/or an air-conditioned place or switch
on the ANTI-CONDENSATION MODE if available.
NOTE! The appliance must be positioned so that the plug is accessible.
5.2.1 BUILT-UNDER INSTRUCTIONS
Make sure your installation does not block the front ventilation grille. The unit is designed
to t under worktops between 820 and 890mm in height, using the height-adjustable
ventilation grille to ensure that the feet are concealed from front view. Remove the
adjustable ventilation grille screws and slide it to the required height. Tighten the screws to
lock the grille in position.
If the unit is fully integrated to be installed for tting kitchen plinth, make sure that the
ventilation gaps in the plinth are at least 300 square centimeters and remove the ventilation
grilles, so that warm air can disperse unhindered. Otherwise the appliance has to work
harder, resulting in an increase in electricity consumption.

11
NOTE! When pushing the appliance into the niche, make sure that the mains cable does not
get trapped.
NOTE!
H – Can be 700, 720, 780 or 800mm and it depends on the actual product specication.
h – Can be 80, 100, 120 or 150mm and it depends on the actual product specication. The
standard maximum adjustable height for plinth is 70mm. If you need the more adjustable
height legs, they can be purchased from your dealer or from the Spare Parts Department.
For ush inset built-in installation, an extra 3mm door clearance is required for dimension B.
A (mm) B (mm) C (mm) D (mm)
15 cm wide 148 150 455 75
30 cm wide 295 300 440/460 115
40 cm wide 395 400 460 115
50 cm wide 495 500 460 115
60 cm wide 595 600 440/460 115
A (mm) B (mm) C (mm)
37.5 cm wide 375 380 495
44.5 cm wide 445 450 520
60 cm wide 595 610 520
75 cm wide 750 760 520

12
5.2.2 FULLY INTEGRATED BUILT-IN-COLUMN INSTRUCTIONS
RISK OF DAMAGE! The wine cabinet has an elongated glass door and must not be set down
vertically at any time!
DESIGN 1 – The unit door seals the installed unit
almost completely, so an air vent must be provided
in the base of the housing. Warmed air must be
conducted via the ventilation shaft to the rear wall
of the housing and then expelled upwards. The
ventilation channels should measure at least 200
square centimeters in cross-section.
Aperture A (mm) B (mm) C (mm)
45 cm H 448 455 450
60 cm H 588 595 590
88 cm H 878 885 880
122 cm H 1221 1234 1225-1230
178 cm H 1771 1784 1775-1780
WARNING! To ensure the proper functioning of the appliance, air vents should never be
blocked or covered.
Remark: The dimension A does not include the adjustable legs and the units are permitted
to be installed without the adjustable legs.
DESIGN 2 - Air at the back of the unit gets warm. The unit is equipped with an integrated
ventilation system to disperse the warm air automatically. Air intake is provided underneath
the appliance door and the air escapes at the top of the door. The air inlet and outlet must
not be covered or blocked in any way. They must also be regularly cleaned of dust.
After installation make sure that the appliance door opens and closes properly.

13
Aperture A (mm) B (mm) C (mm)
45 cm H 450 449 450
60 cm H 590 588 589-593
68 cm H 715 674 675-685
88 cm H 885 872 874-880
122 cm H 1234 1221 1223-1230
178 cm H 1784 1771 1773-1780
WARNING! If the ventilation gaps given are not observed, the compressor will run more
frequently and for longer periods. This will result in increased energy consumption and a
higher operating temperature for the compressor. This may, in turn, cause damage to the
compressor. It is essential to observe the ventilation gaps given.

14
5.2.3 BUILT-IN CABINETRY INSTRUCTIONS
Make sure your installation does not block the front
ventilation grille. And be sure the door will open and
close properly in the chosen location.
a (mm) b (mm) c (mm)
100 1476 575 595
125 1768 575 595
170 1768 680 595
125S 1820 575 595
170S 1820 680 595
220 1820 680 680
NOTE! To ensure proper service access and ventilation, A must be at least 5mm more than
a, B must be at least 5mm more than b and C must be at least 5mm more than c. For ush
inset built-in installation, an extra 3mm door clearance is required for dimension C.
5.3 Electrical connection
WARNING! Improper use of the grounded plug can result in the risk of electrical shock.
If the power cord is damaged, have it replaced by a qualied electrician or an authorized
service center.
All electrical work should be carried out by a suitably qualied and competent person in
accordance with local and national safety regulations.
Check that the voltage marked on the product corresponds with your supply voltage.
Connect this appliance to a separate at least 13A circuit.
Connection should be made via a suitable switched socket which is easily accessible. For
extra safety it is advisable to install a residual current device (RCD) with a trip current of
30mA.
Have the receptacle and the circuit checked by a qualied electrician to ensure that the
socket is grounded correctly.
NOTE! In locations where there is frequent lightning, it is advisable to use surge protectors.
Do not connect the appliance to the mains electricity supply by an extension lead.

15
Extension leads do not guarantee the required safety of the appliance (e.g. danger of
overheating).
The appliance must not be connected to an inverter and must not be used with a plug
adapter as these can cause damage to the appliance’s electronic unit.
The cord must rest securely behind the appliance and not be allowed to lie or hang
unprotected.
WARNING! This appliance must be earthed.
5.4 Installing the handle
IMPORTANT! Do not overtighten the screws & do not use power tools to install the handle.
DESIGN 1 - Locate the handle (1) over the mounting stubs (3) of the
door and tighten the grub screws (2) with an Allen key to secure the
handle.
DESIGN 2 –
1. Remove the door gasket (2) on the side you wish to install the
handle - you can see two designated holes for handle installation.
2. Install the handle (4) tightly as shown above with two screws (1)
and at washers (3)provided.
3. Replace the door gasket.
5.5 Reversing the door hinge
It is possible to reverse the door on this appliance, if required. To do so, follow the steps
below:
NOTE! All parts removed must be saved to do the reinstallation of door.

16
DESIGN 1 – For built-under models
1. Remove the bottom hinge (1) by unscrewing the four lock screws (2). Be careful to hold
the glass door rmly after removing the screws. (Fig. 1)
2. Gently pull down to remove the glass door from the right top hinge and place it on a
padded surface to avoid the risk of damage. Then remove the right top hinge (5). (Fig. 3)
3. Unscrew and transfer hinge pin (3) and/or door stopper (4) of the bottom hinge to the
opposite side. (Fig. 2)
4. Pop out the cover caps on the left side of cabinet and use them to cover the screw holes
on the right hand side.
5. Screw the alternative left top hinge (7), included in the ttings, on the left hand side of
cabinet. (Fig. 3)
6. Unscrew and transfer the holes cover (8) and lock catch (9) to the opposite side of glass
door. (Only for models with lock on the ventilation grille) (Fig. 4)
7. Rotate the door 180° (No need for models with lock on the door) and relocate the
door to the designated position. Then screw the bottom hinge assembly on the left
designated position and tighten it after the door is leveled.
8. Transfer the handle & plugs to the opposite positions if need.

17
DESIGN 2 – For fully integrated models
1. Remove the glass door by unscrewing the eight lock screws (3) and (4). Be careful to
hold the glass door rmly after removing the screws and place it on a padded surface to
avoid the risk of damage.
2. Unscrew and transfer the door supporter (2) to the opposite side.
3. Rotate the glass door 180°and ret the glass door to the opposite side. Then screw and
tighten it after the door is leveled.
1. Remove the glass door by unscrewing the eight lock screws (5) and (6). Be careful to
hold the glass door rmly after removing the screws and place it on a padded surface to
avoid the risk of damage.
2. Unscrew the screws (1) and (3) then transfer the door supporter (2) and decoration cover
(4) to the opposite side.
3. Rotate the glass door 180° and ret the glass door to the opposite side. Then screw and
tighten it after the door is leveled.

18
DESIGN 3 – For tall models
1. Remove the right bottom hinge (2) and/or left bottom hinge (1) by unscrewing the eight
lock screws (3). Be careful to hold the door (4) rmly after removing the screws. (Fig. 1)
2. Gently pull down to remove the door from the right top hinge and place it on a padded
surface to avoid the risk of damage. Then remove the right top hinge (12). (Fig. 4)
3. Pop out the cover caps on the left side of cabinet and use them to cover the screw holes
on the right hand side.
4. Screw the alternative left top hinge (11), included in the ttings, on the left hand side of
cabinet. (Fig. 4)
5. Unscrew and transfer hinge pin (6) and/or door supporter (5) to the opposite bottom
hinge. (Fig. 2)
6. Unscrew and transfer the door adapter (9) and/or lock catch (8) to the top designated
positions of the door. (Fig. 3)
7. Rotate the door 180° and relocate it to the designated position. Then screw the bottom
hinges on the designated positions and tighten them. (Fig. 5)
8. Recheck and adjust the door alignment by loosening the screws (10) and moving the
door adapter (9). Tighten the screws (10) after the door is levelled. (Fig. 5)

19
DESIGN 4 – For vertical double door models
1. Remove the right bottom hinge (1) by unscrewing the four screws (2). Be careful to hold
the lower glass door (3) rmly after removing the screws. And then gently pull down to
remove the lower glass door from the middle hinge and place it on a padded surface to
avoid the risk of damage. (Fig. 1)
2. Unscrew and transfer the door adapter (7) and (10) to the designated opposite position
of lower glass door. At the same time unscrew and transfer hinge pin (5) of the left
bottom hinge (4) included in the ttings. (Fig. 2 & 3)
3. Remove the door adapter (16) by unscrewing the two lock screws (15). Be careful to hold
the upper glass door rmly after removing the screws. And then gently pull down to
remove the upper glass door (17) from the top hinge and place it on a padded surface to
avoid the risk of damage. Then remove the right top hinge (12). (Fig. 5 & 4)
4. Unscrew and transfer the middle hinge (14) and the middle xing plate (13) to the
opposite position. (Fig. 5)
5. Pop out the cover caps on the left side of cabinet and use them to cover the screw holes
on the right hand side.
6. Screw the alternative left top hinge (11), included in the ttings, on the left hand side of
cabinet. (Fig. 4)
7. Relocate the door adapter (16) on the middle hinge.
8. Set the upper glass door to the designated position and install the two lock screws to
connect the door adapter (16) with the upper glass door and tighten them before the
door is leveled.
9. Set the lower glass door to the designated position. Then screw the left bottom hinge on
the left designated position and tighten them.

20
10. Recheck and adjust the lower door alignment by loosening the screws (8) & (9) and
moving the door adapter (7) & (10). Tighten the screws (8) & (9) after the door is levelled.
11. Transfer the handles and plugs to the opposite positions.
DESIGN 5 – For models with articulated hinge
WARNING! Use extreme caution with the articulated hinges. The hinge is self-closing and
many pinch points exist prior to built-in installation.
1. Remove the cover caps (3) and then remove the glass door by unscrewing the four
screws (1) and (2). Be careful to hold the glass door rmly after removing the screws and
place it on a padded surface to avoid the risk of damage.
2. Pop out the cover caps on the left side of cabinet and use them to cover the screw holes
on the right hand side.
3. Rotate the glass door 180° and ret the glass door to the opposite side. Then screw and
tighten it after the door is leveled.
