Ceramic Hob
Instruction Manual / Installation Manual
MODEL: EBC200DBR1
GBR

01
02
1 0
07
08
1 2
1 6
2 1
SAFETY INSTRUCTIONS
SPECIFICATIONS
PRODUCT OVERVIEW
QUICK START GUIDE
PRODUCT INSTALLATION
OPERATION INSTRUCTIONS
CLEANING AND MAINTENANCE
TROUBLESHOOTING
DISPOSAL AND RECYCLING
22
23
CONTENTS

Danger
This symbol indicates that there are dangers to the life and health of
persons due to extremely flammable gas.
Warning of electrical voltage
This symbol indicates that there is a danger to life and health of
persons due to voltage.
Warning
The signal word indicates a hazard with a medium level of risk which, if
not avoided, may result in death or serious injury.
Caution
The signal word indicates a hazard with a low degree of risk which, if
not avoided, may result in minor or moderate injury.
Attention
The signal word indicates important information (e.g. damage to
property), but not danger.
Observe instructions
This symbol indicates that a service technician should only operate and
maintain this appliance in accordance with the operating instructions.
The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or
incorrect operation of the appliance. Please check the packaging and appliance on arrival to make sure
everything is intact to ensure safe operation. If you find any damage, please contact the retailer or
dealer. Please note modifications or alterations to the appliance are not allowed for your safety concern.
Unintended use may cause hazards and loss of warranty claims.
Read these operating instructions carefully and attentively before using/commissioning the unit and
keep them in the immediate vicinity of the installation site or unit for later use!
Intended Use
Explanation of Symbols
SAFETY INSTRUCTIONS
02

Safety Warnings
Electrical Shock Hazard
Your safety is important to us. Please read this information before using your
cooktop.
Installation
• Disconnect the appliance from the mains electricity supply before carrying
out any work or maintenance on it.
• Connection to a good earth wiring system is essential and mandatory.
• Alterations to the domestic wiring system must only be made by a qualified
electrician.
• Failure to follow this advice may result in electrical shock or death.
Cut Hazard
• Take care - panel edges are sharp.
• Failure to use caution could result in injury or cuts.
Important Safety Instructions
• Read these instructions carefully before installing or using this appliance.
• No combustible material or products should be placed on this appliance at
any time.
• Please make this information available to the person responsible for installing
the appliance as it could reduce your installation costs.
• In order to avoid a hazard, this appliance must be installed according to these
instructions for installation.
• This appliance is to be properly installed and earthed only by a suitably
qualified person.
• This appliance should be connected to a circuit which incorporates an
isolating switch providing full disconnection from the power supply.
• Failure to install the appliance correctly could invalidate any warranty or
liability claims.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
03

Operation And Maintenance
Electrical Shock Hazard
• Do not cook on a broken or cracked cooktop. If the cooktop surface should
break or crack, switch the appliance off immediately at the mains power
supply (wall switch) and contact a qualified technician.
• Switch the cooktop off at the wall before cleaning or maintenance.
• Failure to follow this advice may result in electrical shock or death.
Health Hazard
• This appliance complies with electromagnetic safety standards.
• However, persons with cardiac pacemakers or other electrical implants (such
as insulin pumps) must consult with their doctor or implant manufacturer
before using this appliance to make sure that their implants will not be affect-
ed by the electromagnetic field.
• Failure to follow this advice may result in death.
• Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
• Warning: If the surface is cracked, switch off the appliance to avoid the
possibility of electric shock, for hob surfaces of glass-ceramic or similar
material which protect live parts
• Metallic objects such as knives, forks, spoons and lids should not be placed on
the hob surface since they can get hot
• A steam cleaner is not to be used.
• Do not use a steam cleaner to clean your cooktop.
• The appliance is not intended to be operated by means of an external timer
or separate remote-control system.
• WARNING: Danger of fire: do not store items on the cooking surfaces.
• The cooking process has to be supervised. A short term cooking process has
to besupervised continuously.
• WARNING: Unattended cooking on a hob with fat or oil can be dangerous
and may result in fire. NEVER try to extinguish a fire with water, but switch
off the appliance and then cover flame e.g. with a lid or a fire blanket.
04

Hot Surface Hazard
• During use, accessible parts of this appliance will become hot enough to
cause burns.
• Do not let your body, clothing or any item other than suitable cookware
contact the Induction glass until the surface is cool.
• Keep children away.
• Handles of saucepans may be hot to touch. Check saucepan handles do not
overhang other cooking zones that are on. Keep handles out of reach of
children.
• Failure to follow this advice could result in burns and scalds.
Cut Hazard
• The razor-sharp blade of a cooktop scraper is exposed when the safety cover
is retracted. Use with extreme care and always store safely and out of reach
of children.
• Failure to use caution could result in injury or cuts.
Important Safety Instructions
• Never leave the appliance unattended when in use. Boilover causes smoking
and greasy spillovers that may ignite.
• Never use your appliance as a work or storage surface.
• Never leave any objects or utensils on the appliance.
• Do not place or leave any magnetisable objects (e.g. credit cards, memory
cards) or electronic devices (e.g. computers, MP3 players) near the appliance,
as they may be affected by its electromagnetic field.
• Never use your appliance for warming or heating the room.
• After use, always turn off the cooking zones and the cooktop as described in
this manual (i.e. by using the touch controls). Do not rely on the pan
detection feature to turn off the cooking zones when you remove the pans.
• Do not allow children to play with the appliance or sit, stand, or climb on it.
• Do not store items of interest to children in cabinets above the appliance.
Children climbing on the cooktop could be seriously injured.
• Do not leave children alone or unattended in the area where the appliance is
in use.
• Children or persons with a disability which limits their ability to use the
appliance should have a responsible and competent person to instruct them
in its use. The instructor should be satisfied that they can use the appliance
without danger to themselves or their surroundings.
05

Congratulations on the purchase of your new Ceramic Hob.
We recommend that you spend some time to read this Instruction / Installation
Manual in order to fully understand how to install correctly and operate it. For
installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruction /
Installation Manual for future reference.
• Do not repair or replace any part of the appliance unless specifically
recommended in the manual. All other servicing should be done by a
qualified technician.
• Do not place or drop heavy objects on your cooktop.
• Do not stand on your cooktop.
• Do not use pans with jagged edges or drag pans across the Induction glass
surface as this can scratch the glass.
• Do not use scourers or any other harsh abrasive cleaning agents to clean your
cooktop, as these can scratch the Induction glass.
• This appliance is intended to be used in household and similar applications
such as:
-staff kitchen areas in shops, offices and other working environments;
-farm houses;
-by clients in hotels, motels and other residential type environments;
-bed and breakfast type environments.
• WARNING: The appliance and its accessible parts become hot during use.
• Care should be taken to avoid touching heating elements.
• Children less than 8 years of age shall be kept away unless continuously
supervised.
06

SPECIFICATIONS
Cooking Hob
Cooking Zones
Supply Voltage
Installed Electric Power
Product Size D×W×H(mm)
Building-in Dimensions A×B (mm)
2 Zones
220-240V~ 50Hz or 60Hz
2700-3300W
288X520X55
Weight and Dimensions are approximate. Because we continually strive to improve our products we
may change specifications and designs without prior notice.
268X490
07
EBC200DBR1

NOTE
All the pictures in this manual are for explanation purpose only. Any discrepancy between the real
object and the illustration in the drawing shall be subject to the real subject.
PRODUCT OVERVIEW
08
Top View
Control Panel
Glass plate
Control panel
Max. 1800 W zone
Max. 1200 W zone
ON/OFF control
ON/OFF control
Key lock
control
Timer control Power / Timer
regulating controls
Heating zone selection controls

09
Product Information
The microcomputer ceramic cooker hob can meet different kinds of cuisine demands because of
resistance wire heating, micro-computerized control and multi-power selection, really the optimal
choice for modern families.
The ceramic cooker hob centers on customers and adopts personalized design. The hob has safe and
reliable performances, making your life comfortable and enabling to fully enjoy the pleasure from life.
Working Principle
This ceramic cooker hob directly employs resistance wire heating, and adjust the output power by the
power regulation with the touch controls.
Before Using Your New Ceramic Hob
• Read this guide, taking special note of the ‘Safety Warnings’ section.
• Remove any protective film that may still be on your ceramic hob.

10
• When food comes to the boil, reduce the temperature setting.
• Using a lid will reduce cooking times and save energy by retaining the heat.
• Minimize the amount of liquid or fat to reduce cooking times.
• Start cooking on a high setting and reduce the setting when the food has heated through.
• Simmering occurs below boiling point, at around 85˚C, when bubbles are just rising occasionally to
the surface of the cooking liquid. It is the key to delicious soups and tender stews because the
flavours develop without overcooking the food. You should also cook egg-based and flour thickened
sauces below boiling point.
• Some tasks, including cooking rice by the absorption method, may require a setting higher than the
lowest setting to ensure the food is cooked properly in the time recommended.
Take care when frying as the oil and fat heat up very quickly, particularly if you’re using
PowerBoost. At extremely high temperatures oil and fat will ignite spontaneously and this presents
a serious fire risk.
Cooking Tips
QUICK START GUIDE
Simmering, Cooking Rice
To cook juicy flavorsome steaks:
1. Stand the meat at room temperature for about 20 minutes before cooking.
2. Heat up a heavy-based frying pan.
3. Brush both sides of the steak with oil. Drizzle a small amount of oil into the hot pan and then lower
the meat onto the hot pan.
4. Turn the steak only once during cooking. The exact cooking time will depend on the thickness of the
steak and how cooked you want it. Times may vary from about 2 – 8 minutes per side. Press the
steak to gauge how cooked it is – the firmer it feels the more ‘well done’ it will be.
5. Leave the steak to rest on a warm plate for a few minutes to allow it to relax and become tender
before serving.
Searing Steak
1. Choose an ceramic compatible flat-based wok or a large frying pan.
2. Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking large quantities,
cook the food in several smaller batches.
3. Preheat the pan briefly and add two tablespoons of oil.
4. Cook any meat first, put it aside and keep warm.
5. Stir-fry the vegetables. When they are hot but still crisp, turn the cooking zone to a lower setting,
return the meat to the pan and add your sauce.
6. Stir the ingredients gently to make sure they are heated through.
7. Serve immediately.
For Stir-frying

11
Heat Settings
The settings below are guidelines only. The exact setting will depend on several factors, including your
cookware and the amount you are cooking. Experiment with the Ceramic hob to find the settings that
best suit you.
1 - 2
• delicate warming for small amounts of food
• melting chocolate, butter, and foods that burn quickly
• gentle simmering
• slow warming
3 - 4
• reheating
• rapid simmering
• cooking rice
5 - 6 • pancakes
7 - 8 • sautéing
• cooking pasta
9
• stir-frying
• searing
• bringing soup to the boil
• boiling water
Heat setting Suitability

12
A
B
F
ED
C
SEAL
Min.3mm
G
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 50mm space shall be preserved around the hole.
Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant and insulated
work surface material (Wood and similar fibrous or hygroscopic material shall not be used as work
surface material unless impregnated) to avoid the electrical shock and larger deformation caused by
the heat radiation from the hotplate. As shown below:
The ceramic cooker hob can be used on the table top of cabinet. The ceramic hob should be placed
horizontally. As shown below:
Under any circumstances, make sure the ceramic cooker hob is well ventilated and the air inlet and
outlet are not blocked. Ensure the ceramic cooker hob is in good work state. As shown below
Selection Of Installation Equipment
PRODUCT INSTALLATION
Note: The safety distance between the sides of the hob and the inner surfaces of the worktop
should be at least 3mm.
268＋4
-0 mm
A(mm)
490＋4
-0 mm
B(mm)
50mm min.
C(mm)
50mm min.
D(mm)
50mm min.
E(mm)
50mm min.
F(mm)
3mm min.
G(mm)
50mm min.
A(mm)
50mm min.
B(mm)
A
B

13
Make sure the ceramic hob is well ventilated and that air inlet and outlet are not blocked. In order to
avoid accidental touch with the overheating bottom of the hob, or getting unexpectable electric shock
during working, it is necessary to put a wooden insert, fixed by screws, at a minimum distance of
50mm from the bottom of the hob. Follow the requirements below.
Note: The safety distance between the hotplate and the cupboard above the hotplate should be at
least 760mm.
There are ventilation holes around outside of the hob. YOU MUST ensure these holes are not
blocked by the worktop when you put the hob into position.
• Be aware that the glue that join the plastic or wooden material to the furniture, has to resist to
temperature not below 150°C, to avoid the unstuck of the paneling.
• The rear wall, adjacent and surrounding surfaces must therefore be able to withstand an
temperature of 90°C.
A
B
C
E
D
760mm
Min.30mm
760
A(mm)
50 min.
B(mm)
20 min.
C(mm)
Air intake
D
Air exit 5 mm
E
WARNING: Ensuring Adequate Ventilation
Min. 5 cm
Max. 5 mm Max. 5 mm

14
1. The ceramic cooker hob must be installed by qualified personnel or technicians. We have
professionals at your service. Please never conduct the operation by yourself.
2. The ceramic cooker hob shall not be mounted to cooling equipment, dishwashers and rotary dryers.
3. The ceramic cooker hob shall be installed such that better heat radiation can be ensured to enhance
its reliability.
4. The wall and induced heating zone above the work surface shall withstand heat.
5. To avoid any damage, the sandwich layer and adhesive must be resistant to heat.
6. A steam cleaner is not to be used.
7. This ceramic can be connected only to a supply with system impedance no more than 0.427 ohm. In
case necessary, please consult your supply authority for system impedance information.
The unit should be placed on a stable, smooth surface (use the packaging). Do not apply force onto the
controls protruding from the hob.
Fix the hob on the work surface by screw four brackets on the bottom of hob (see picture) after
installation. Adjust the bracket position to suit for different work surface’s thickness.
Before Locating The Fixing Brackets
Cautions
Under any circumstances, the brackets cannot touch with the inner surfaces of the worktop after
installation (see picture).
HOB
AB
TABLE
BRACKET
HOB
BRACKET
TABLE

15
The power supply should be connected in compliance with the relevant standard, or a single-pole
circuit breaker. The method of connection is shown below.
1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the
proper tools, so as to avoid any accidents.
2. If the appliance is being connected directly to the mains supply, an omnipolar circuit breaker must be
installed with a minimum gap of 3mm between the contacts.
3. The installer must ensure that the correct electrical connection has been made and that it complies
with safety regulations.
4. The cable must not be bent or compressed.
5. The cable must be checked regularly and only replaced by a properly qualified person.
Connecting The Hob To The Mains Power Supply
The bottom surface and the power cord of the hob are not accessible after installation.
220-240V~
L
Brown
Yellow/Green
Blue
PE N

• Do not use cookware with jagged edges or a curved base.
• Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the
cooking zone. Always centre your pan on the cooking zone.
Touch Controls
OPERATION INSTRUCTIONS
• The controls respond to touch, so you don’t need to apply any pressure.
• Use the ball of your finger, not its tip.
• You will hear a beep each time a touch is registered.
• Make sure the controls are always clean, dry, and that there is no object (e.g. a utensil or a cloth)
covering them. Even a thin film of water may make the controls difficult to operate.
Choosing The Right Cookware
• Always lift pans off the ceramic hob – do not slide, or they may scratch the glass.
16

Beware of hot surfaces
“H” will show which cooking zone is hot to touch.
It will disappear when the surface has cooled
down to a safe temperature. It can also be used
as an energy saving function if you want to heat
further pans, use the hotplate that is still hot.
After power on, the buzzer beeps once, all the indicators light up for 1 second then go out, indicating
that the ceramic hob has entered the stat of standby mode.
Touch the ON/OFF control. all the indicators
show “-“
Place a suitable pan on the cooking zone that
you wish to use.
• Make sure the bottom of the pan and the
surface of the cooking zone are clean and dry.
How to Use
Start Cooking
Finish Cooking
Touching the heating zone selection control .
Touching the heating zone selection control
that you wish to switch off.
Select a heat setting by touching the “-” or “+”
control.
• If you don’t choose a heat setting within 1
minute, the ceramic hob will automatically
switch off. You will need to start again at step 1.
• You can modify the heat setting at any time
during cooking.
• By holding down either of these buttons, the
value will adjust up or down.
Turn the cooking zone off by scrolling down to
“0” or touching “-” and “+” control together.
OR
Turn the whole cooktop off by touching the
ON/OFF control.
17

When the hob is in the lock mode, all the controls are disable except the ON/OFF , you can
always turn the ceramic hob off with the ON/OFF control in an emergency, but you shall
unlock the hob first in the next operation.
• You can lock the controls to prevent unintended use (for example children accidentally turning the
cooking zones on).
• When the controls are locked, all the controls except the ON/OFF control are disabled.
Locking the Controls
You can use the timer in two different ways:
• You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when the
set time is up.
• You can set it to turn one or more cooking zones off after the set time is up.
• The timer of maximum is 99 minutes.
Timer Control
If you are not selecting any cooking zone.
• Using the Timer as a Minute Minder
Make sure the cooktop is turned on.
Note: you can use the minute minder even if
you’re not selecting any cooking zone.
Touch the timer control, the timer indicator will
flash ;
Adjust the timer setting by touch the “-” or “+”
controls. The minute minder indicator will start
flashing and will show in the timer display.
Touch the lock control
Make sure the ceramic hob is turned on
Touch and hold the lock control for a while.
The timer indicator will show “ Lo ”
To lock the controls
To unlock the controls
Touching the “-” and “+” together, the timer is
cancelled, and the “--” will show in the minute
display.
When the time is set, it will begin to count down
immediately. The display will show the remaining
time and the timer indicator will flash for 5
seconds.
OR
Buzzer will beep for 30 seconds and the timer
indicator shows “- -” when the setting time
finished.
18
