Voxx Electronics Prestige APS510Z Installation and operating manual

Installaon and Reference Guide
2020 Voxx Electronics Corporaon. All rights reserved. APS510Z_RevC_08/20
2 Wire Harness Colors and Funcons
2 Power / Nocaon Connector
3 Input / Output Connector
4 Door Lock Connector
5 External Components
5 Shock Sensor
5 RF Antenna Kit
5 Data Bus Interface (DBI)
5 Telemacs
5 Weblink Programming
6 Setup Opons
6 Remote Programming
7 Security Control
11 System Operaon
11 Remote Operaon
APS510Z
Vehicle Security / Keyless Entry System
12 System Programming
12 Programming Mode Entry / Exit
13 Feature Bank Opons
13 Data Port Protocol
14 Dome Light
14 Silent Arm and Disarm
14 User Selectable LED
14 System Diagnoscs
14 Troubleshoong Trigger Zones
14 Adjusng Shock Sensor
15 Alarm Override Procedures
16 Wiring Diagrams
16 Door Lock Connecons
19 Starter Kill Relay
20 Full System Connecons
Thank you for trusng Presge products! If you are a consumer, please note:
Professional installaon is strongly recommended.
This manual assumes the installer has adequate knowledge of the following experse. Therefore, it does not
cover these topics in detail:
• 12-volt electronics
• Tesng and verifying circuits
• Making safe and lasng wiring connecons
• Factory ignion, power, lighng, data bus and sensing systems
• Factory systems and components to avoid
• Safe wire roung, circuit protecon and product placement
• Access to vehicle-specic technical informaon
In addion, this manual assumes the installer has the proper tools, skill and facilies to perform a professional installaon.
Performing an improper installaon could result in damage to the vehicle or its components, improper system funcon,
unsafe vehicle operaon or physical injury. Such instances would not be covered by the vehicle manufacturer's warranty,
nor by Voxx Electronics, Inc.
Detailed Descripons Quick Reference

APS510Z_RevC_08/20
2
Detailed Descripons: Wire Harness Colors and Funcons
6. RED – 12-Volt Input (+)
The RED wire connects to the vehicle’s primary 12-Volt (+) wire to power the system.
Vericaon: The power wire registers 12-Volt (+) at all mes.
Note: Before making this connecon, remove all module fuses unl the system is completely connected.
1 3 5
2 4 6
Power / Nocaon Connector (6-pin connector) See page 20 for the full system diagram.
These wires are listed in order of their placement in the harness connector.
3. WHITE/RED – Parking Light Relay Input (Internal Relay Pin 87)
The WHITE/RED connects to vehicle 12-Volt (+) or Ground (-) to supply the relay output (WHITE wire).
Vericaon for default seng:
• If the vehicle parking light wire registers 12-Volt (+) when the park lights are on, connect the WHITE/RED wire to a
constant 12-Volt (+) vehicle wire.
• If the vehicle parking light wire registers Ground (-) when the park lights are on, connect the WHITE/RED wire to a
reliable vehicle ground source.
1. WHITE – Parking Light Relay Output (Internal Relay Pin 30)
At its default seng, the WHITE wire supplies 12-Volt (+) or Ground (-) to the vehicle's park light wire based on the
connecon of the relay input (WHITE/RED wire).
Vericaon: The vehicle parking light wire registers 12-Volt (+) or Ground (-) when the park lights are turned on.
2. BLACK – Ground Input (-)
The BLACK wire connects to a reliable vehicle ground (-) source to power the system.
Vericaon: The vehicle ground (-) source wire registers ground (-) at all mes.
Note: Before making this connecon, remove all module fuses unl the system is completely connected.
5. WHITE/BLACK – Siren Output (+)
The WHITE/BLACK wire supplies 12-Volt (+) to power the siren. Aer mounng the siren, connect its BLACK wire to a
reliable ground source, and connect the BROWN wire to the siren’s RED wire.
4. ORANGE – Starter Kill Output N.C. (-)
The ORANGE wire supplies Ground (-) when the alarm is armed.

APS510Z_RevC_08/20 3
Detailed Descripons: Wire Harness Colors and Funcons
Input / Output Connector (14-pin connector) See page 20 for the full system diagram.
These wires are listed in order of their placement in the harness connector.
1
2
3 5 7 911 13
46810 12 14
4. PURPLE – Door Trigger Input (+)
The PURPLE wire connects to the vehicle's door trigger wire. This wire will detect a 12-Volt (+) input.
Vericaon: The vehicle door trigger wire registers 12-Volt (+) when a door is opened and opposite when closed.
Note: If the door trigger registers as Ground (-) when a door is opened, use the BROWN, Pin 8, input.
5. DARK BLUE – Trunk Release Output (-)
At its default seng, the DARK BLUE wire connects to the vehicle trunk release wire or relay and supplies Ground (-)
when acvated from the remote control.
Vericaon: The vehicle trunk release wire registers 12-Volt (+) or Ground (-) when the trunk release buon is acvated.
1. DARK BLUE/BLACK -- External Start Output (-)
The DARK BLUE wire connects to an external remote start. If the vehicle ignion is o, this input will acvate the remote
start funcon.
3. GREEN/LIGHT BLUE – Ch. 4 Aux. Output (-)
The GREEN/LIGHT BLUE wire supplies Ground (-) when acvated from the remote control.
Note: This feature is controlled by Feature Bank 2, Feature 13; Ch. 4 AUX.
6. LIGHT GREEN – Trunk / Hatch Input (-)
The LIGHT GREEN wire connects a device or switch that, when triggered, supplies a Ground (-) output. If the system is
armed, this input will trigger the alarm.
7. LIGHT BLUE/GREEN – Ch. 5 Aux. Output (-)
The LIGHT BLUE/GREEN wire supplies Ground (-) when acvated from the remote control.
Note: This feature is controlled by Feature Bank 2, Feature 14; Ch. 4 AUX.
8. BROWN – Door Trigger Input (-)
The BROWN wire connects to the vehicle's door trigger wire. This wire will detect Ground (-) input.
Vericaon: The vehicle door trigger wire registers Ground (-) when a door is opened and opposite when closed.
Note: If the door registers as 12-Volt (+) when the door is opened, use the PURPLE (Pin 3) input.
2. ORANGE/WHITE – Starter Kill Output N.O. (-)
The ORANGE wire supplies Ground (-) when the alarm is disarmed .
9. GREEN/WHITE – Dome Light Output (-)
The GREEN/WHITE wire supplies Ground (-) when Unlock is acvated from the Remote Control. This output will
automacally turn o aer 30 seconds.

APS510Z_RevC_08/20
4
Detailed Descripons: Wire Harness Colors and Funcons
Input / Output Connector (14-pin connector) (Cont.) See page 20 for the full system diagram.
These wires are listed in order of their placement in the harness connector.
14. BLACK/WHITE – Horn Output (-)
The BLACK/WHITE wire connects to the vehicle's horn wire and supplies Ground (-) when acvated from the system.
Vericaon: The vehicle horn wire registers Ground (-) when the horn is acvated.
Note: This feature is controlled by Feature Bank 2, Feature 8; Horn Timing
Door Lock Connector (3-pin connector) See page 20 for the full system diagram.
These wires are listed in order of their placement in the harness connector.
12. DARK GREEN – Instant Trigger Input (-)
The DARK GREEN wire connects a device or switch that, when triggered, supplies a Ground (-) output. If the system is
armed, this input will trigger the alarm.
13. YELLOW – Ignion Input (+)
The YELLOW wire connects to the vehicle's primary ignion wire. This wire will be used for system programming and
override.
Vericaon: This ignion wire registers 12-Volt (+) when the key is in the accessory, ignion, and start posions.
Note: Before making this connecon, remove all module fuses unl the system is completely connected.
11. WHITE/BLUE – Headlight Output (-)
The WHITE/BLUE wire supplies a Ground (-) when the lock or unlock buon is pressed on the remote. This output will
automacally turn o aer 30 seconds.
Note: This feature is controlled by Feature Bank 2, Feature 4; Exterior Illuminaon.
1. RED – Door Lock (-) (NOC 1)
The RED wire supplies Ground (-) when the Lock funcon is acvated from the remote control or system.
Vericaon: The vehicle lock wire registers 12-Volts (+) or Ground (-) when the Lock buon is acvated.
Note: Addional parts may be required. See Page 16 for common door lock wire diagrams.
2. GREEN – Door Unlock (-) (NOC 2)
The GREEN wire supplies Ground (-) when the Unlock funcon is acvated from the remote control or system.
Vericaon: The vehicle lock wire registers 12-Volt (+) or Ground (-) when the Unlock buon is acvated.
Note: Addional parts may be required. See Page 16 for common door lock wire diagrams.
3. RED/BLACK – 2nd Unlock Output (-)
At its default seng, the RED/BLACK wire supplies a Ground (-) pulse when the Unlock buon is pressed 2x within 10
seconds.
Note: This requires Feature Bank 2, Feature 10, to be programed ON. Addional Parts may be required.
123
10. Empty
This posion is empty on this harness.

APS510Z_RevC_08/20 5
Detailed Descripons: External Components
Shock Sensor
The shock sensor plugs into a 4-pin connector on the Presge module. It should be securely aached to a vehicle surface
or sturdy wire harness. Tesng takes place aer all connecons are made and the system is powered up. Refer to Quick
Reference: System Diagnoscs on page 14 for instrucons on tesng and adjusng the shock sensor.
LED / Valet Programming Port
The LED / Valet Programming port is used to for feature programming and Valet Override.
1. Find a suitable locaon to mount the supplied LED / Valet Programming buon. Locate a clear spot on the vehicle’s
dashboard that will be seen from the outside of the vehicle.
2. Drill a 5/16 inch hole and mount the LED / Valet buon. Route the wires to module and plug into proper locaon.
Data Bus Interface (DBI) Port
The 4-pin Data Bus Interface enables a FlashLogic door lock or transponder interface to connect to and communicate
with the vehicle data bus. The combined system saves installaon me as many features that normally require individual
connecon can be accessed and controlled through the data bus. Please refer to the D2D (Data to Data) funcon list
available per vehicle at www.FlashLogic.com.
Telemacs Interface / Weblink Programming Port
The 4-pin Telemacs port enables a connected interface such as CarLink to expand system control to a smartphone or
tablet. The following features may be able to be acvated from a connected device:
• Door Lock Control
• Remote Start
• Trunk Release
• Auxiliary Output
• Sliding Doors
Weblink Programming
This port can also be used to connect your FlashLogic Weblink for feature programming and soware updang. Once
connected please visit www.ashlogic.com.

APS510Z_RevC_08/20
6
Detailed Descripons: Setup Opons
Bank 1: Add / Remove Remote Controls
To Auto Program a remote control:
1. Turn the ignion key to ON.
2. Press and release the valet/override buon three (3) mes.
3. The system will beep one (1) me, indicang you have accessed Bank 1, Remote Programming.
4. Press the Lock buon of each remote control you wish to program. (Channels 1-3 of the remote control will be
programmed.) The system will beep one (1) me when each remote control is added.
5. Turn the ignion key to OFF to exit programming mode, or cycle the ignion key OFF/ON to advance to the next
Feature Bank.
To delete a remote control:
This system will store a maximum of four (4) remote controls in the memory. Addional programmed remote controls
will delete the oldest-programmed remote control.
Deleng All Remotes:
1. Perform steps 1-3 above.
2. Press and Hold the Valet/Override Buon for ve (5) seconds.
3. The system will sound one (1) long beep. This indicates all remotes have been deleted from memory.
Notes:
• The system will store in the memory a maximum of four (4) remote controls. Addional programmed
remote controls will delete the oldest-programmed remote control.
• The system will accept a maximum of two (2) 2-Way remote controls.
• During normal operaon, the Programmed Transmier Nocaon (PTN) funcon indicates how many
remote controls are programmed by ashing the LED a certain number of mes when the vehicle ignion is
turned on.
AUX Output Controls.
AUX Output Controls are not congured during the Auto Programming sequence. This allows for customizaon by the
installer or user. To program AUX Output Control:
1. Repeat steps 1-3 above.
2. Press the valet buon to advance to the AUX Channel to be programmed. The system will beep to indicate the
channel number.
3. Press the desired buon or buon combinaon selected to control the AUX output. The system will beep 1x to
indicated the channel is programmed.
4. Repeat steps 2-3 unl all desired AUX outputs are programmed or turn the ignion key to OFF to exit programming.
Remote programming is located in Feature Bank 1. This system will Auto Program basic funcons of the remote with one
(1) buon press. Basic funcons are channels 1-3, Lock, Unlock, and Trunk / Start.
1 Auto Program/Lock
2 Unlock
3 Trunk/Start
4 Ch. 4 AUX
5 Ch. 5 AUX
6 Ch. 6 AUX
7 Ch. 7 AUX
Channel
Feature Bank 1
Press Lock buon on remote
Press Unlock buon on remote
Press Trunk/Start buon on remote
Press buon/buonsto control AUX Ch. 4
Press buon/buonsto control AUX Ch. 5
Press buon/buonsto control AUX Ch. 6
Press buon/buonsto control AUX Ch. 7
Descripon

APS510Z_RevC_08/20 7
Detailed Descripons: Setup Opons
Security Control (Bank 2) See page 12 for Programming Instrucon.
1 Chirp 2 Chirp
3 Chirp 4 Chirp 5 Chirp 6 Chirp
1 Lock / Unlock Funcon 500ms 3.5sec 500ms L, DBL UL DBL L, 500ms UL DBL L, DBL UL 500ms L, 350ms UL
2 Ignion Lock OFF ON
3 Ignion Unlock OFF Unlock All Unlock Driver
4 Exterior Illuminaon OFF With Arm With Disarm With Arm & Disarm
5 Auto Relock OFF Auto Lock Auto Lock & Arm
6 Auto Arming OFF Auto Arm Auto Lock & Arm
7 Nocaon Sound Both Siren Horn
8 Horn Timing 16ms 30ms 40ms 50ms 10ms
9 Valet Override Method Valet Custom Code
10 Driver Priority Unlock OFF ON
11 Silent Choice OFF From Transmier OEM Style
12 Park Light / Trunk Swap NA
13 AUX Ch. 4 Pulse Push & Hold 10sec 20sec Latch On/OHold 3/s for O/P
14 AUX Ch. 5 Pulse Push & Hold 10sec 20sec Latch On/OHold 3/s for O/P
15 Alarm Trigger Length 30sec 45sec 60sec 90sec 120sec
16 Dome Light Delay Timer Off/ Program 15sec
30sec 45sec 60sec 120sec
17 Security Prole All On Doors O
Hood/trunk OAll OAll On w/ OEM RS
18 Data Port Protocol ADS DBI
Feature Bank 2
Opons
Features
Feature 1: Lock / Unlock Funcon
Funcon: Set the lock / unlock output ming and funconality for specic vehicle lock types.
Seng Choices:
• Opon 1 - Lock and Unlock outputs will pulse for 500 milliseconds.
• Opon 2 - Lock and Unlock outputs will pulse for 3.5 seconds.
• Opon 3 - Lock output will pulse for 500ms ; Unlock output will pulse twice, 500ms each.
• Opon 4 - Lock output will pulse twice, 500ms each ; Unlock output will pulse for 500ms.
• Opon 5 - Lock and Unlock outputs will pulse twice for 500ms.
• Opon 6 - Lock output will pulse for 500ms ; Unlock output will pulse for 350ms.
Feature 2: Accessory-Acvated Lock
Funcon: Set the door locks to lock when brake is pressed aer the ignion is turned ON.
Seng Choices:
• Opon 1 - Doors do not lock with ignion.
• Opon 2 - Doors Lock when brake is pressed aer ignion on.
Feature 3: Accessory-Acvated Unlock
Funcon: Set the door locks to unlock when the ignion is turned o with the key.
Seng Choices:
• Opon 1 - Doors do not unlock with ignion o.
• Opon 2 - All Doors Unlock with ignion o.
• Opon 3 - Driver Door Unlocks with ignion o.

APS510Z_RevC_08/20
8
Feature 4: Exterior Illuminaon
Funcon: Set the parking lights and head lights to remain on for 30 seconds when the doors are locked or unlocked
with the remote control.
Seng Choices:
• Opon 1 - The lights will funcon normally.
• Opon 2 - The lights will remain on for 30 seconds when the doors are locked with the remote control.
• Opon 3 - The lights will remain on for 30 seconds when the doors are unlocked with the remote control.
• Opon 4 - The lights will remain on for 30 seconds when the doors are locked or unlocked with the remote
control.
Detailed Descripons: Setup Opons
Security Control (Bank 2) (cont.) See page 12 for Programming Instrucon.
Feature 7: Nocaon Sounds
Funcon: Set the siren and/or horn to nofy when the system is armed or disarmed.
Seng Choices:
• Opon 1 - Siren and horn will emit audible beeps when the system is armed and disarmed.
• Opon 2 - Siren will emit audible beeps when the system is armed and disarmed.
• Opon 3 - Horn will emit audible beeps when the system is armed and disarmed.
Note: Siren and horn will both sound if the system is triggered, regardless of this seng.
Feature 6: Automac Arming
Funcon: Set the system to arm automacally aer exing the vehicle.
Seng Choices:
• Opon 1 - System will arm and doors will lock only when the alarm is armed from the remote control.
• Opon 2 - System will arm automacally 1 minute aer the last door is closed, and when the alarm is
armed from the remote control.
• Opon 3 - System will Arm and Lock doors automacally 1 minute aer the last door is closed, and when
the alarm is armed from the remote control.
Feature 5: Auto ReLock Seng
Funcon: Set the doors to re-lock if the system has been accidentally disarmed.
Seng Choices:
• Opon 1 - Auto ReLock is disabled.
• Opon 2 - If the system has been disarmed but no doors have been opened in 3 minutes, the system will
relock the doors but not re-arm the alarm.
• Opon 3 - If the system has been disarmed but no doors have been opened in 3 minutes, the system will
relock the doors and re-arm the alarm.
Note: This feature is not associated with the passive locking or passive arming features.
Feature 8: Horn Output Duraon
Funcon: Set the horn output to acvate for a set me.
Seng Choices:
• Opon 1 - Output pulses for 16 milliseconds.
• Opon 2 - Output pulses for 30 milliseconds.
• Opon 3 - Output pulses for 40 milliseconds.
• Opon 4 - Output pulses for 50 milliseconds.
• Opon 5 - Output pulses for 10 milliseconds.

APS510Z_RevC_08/20 9
Security Control (Bank 2) (Cont.) See page 12 for Programming Instrucon.
Detailed Descripons: Setup Opons
Feature 12: Park Light / Trunk Relay Funcon
This feature is not available on this model.
Feature 11: Silent ChoiceTM
Funcon: Set audible beeps on or o when arming and disarming the system.
Seng Choices:
• Opon 1 - Pressing Lock or Unlock at any me will perform the funcon with audible beeps.
• Opon 2 - Pressing Lock or Unlock for 1.5sec on remote will control system without an audible beep.
• Opon 3 - First press of Lock or Unlock on the remote control will perform the funcon without an audible
beep. Second press within 10sec will result in audible beeps.
Feature 10: Driver Priority
Funcon: Set the behavior of unlock outputs when arming and disarming the system.
Seng Choices:
• Opon 1 - Unlock pulse will be on the Green wire unlock output only.
• Opon 2 - First press of unlock on remote will pulse Green wire ; Second press within 10sec will pulse
RED/BLACK wire.
Feature 9: Override Method
Funcon: Set the Alarm Override Method. This will be used if the Remote is lost or inoperable.
Seng Choices:
• Opon 1 - Alarm Override method is normal. Ignion Key ON, press Valet buon 1x
• Opon 2 - Alarm Override method is set for a Custom Code.
Note: See Alarm Override and Custom Code Programming procedures on page 18.
Feature 13: AUX Ch. 4 Output Control
Funcon: Set the AUX Ch. 4 Output Timing
Seng Choices:
• Opon 1 - System will output a 1 second pulse when acvated from the remote control.
• Opon 2 - System will output for the length of me the remote control is pressed.
• Opon 3 - System will output a 10 second pulse when acvated from the remote control.
• Opon 4 - System will output a 20 second pulse when acvated from the remote control.
• Opon 5 - System will latch the output ON when acvated from the remote control and remain on unl
acvated again from the remote control.
• Opon 6 - System will output a 1 second pulse when the remote buon is pressed for 3 seconds.
Feature 14: AUX Ch. 5 Output Control
Funcon: Set the AUX Ch. 5 Output Timing
Seng Choices:
• Opon 1 - System will output a 1 second pulse when acvated from the remote control.
• Opon 2 - System will output for the length of me the remote control is pressed.
• Opon 3 - System will output a 10 second pulse when acvated from the remote control.
• Opon 4 - System will output a 20 second pulse when acvated from the remote control.
• Opon 5 - System will latch the output ON when acvated from the remote control and remain on unl
acvated again from the remote control.
• Opon 6 - System will output a 1 second pulse when the remote buon is pressed for 3 seconds.

APS510Z_RevC_08/20
10
Feature 18: Data Bus (DBI) Port Protocol
Funcon: Set funconality of the data bus connector to accept integraon modules of diering protocols.
Seng Choices:
• Opon 1 - The data bus connector will be congured to work with modules that use the ADS Protocol.
• Opon 2 - The data bus connector will be congured to work with modules that use the DBI Protocol.
Detailed Descripons: Setup Opons
Security Control (Bank 2) (Cont.) See page 12 for Programming Instrucon.
Feature 17: Security Prole
Funcon: Set the system to funcon as a keyless entry / convenience system or full-featured alarm / convenience
system.
Seng Choices:
• Opon 1 - All security, keyless entry and convenience features are enabled.
• Opon 2 - Door Trigger zone is disabled.
• Opon 3 - Hood and Trunk Trigger zones are disabled.
• Opon 4 - All security trigger zones are disabled.
• Opon 5 - All security zones are enabled: Doors, Hood, and Trunk will be bypassed for ve (5) seconds
with Ignion ON ; Shock will be bypassed anyme Ignion is ON.
Feature 16: Dome Light Delay Timer
Funcon: Set the delay mer when using the vehicle's Dome Light as a door trigger.
Seng Choices:
• Opon 1 - OFF / Delay Timer will be OFF or use the programmed me. See page ## for dome light delay
programming procedure
• Opon 2 - 15 seconds, System will wait 15 seconds before monitoring the door trigger input.
• Opon 3 - 30 seconds, System will wait 30 seconds before monitoring the door trigger input.
• Opon 4 - 45 seconds, System will wait 45 seconds before monitoring the door trigger input.
• Opon 5 - 60 seconds, System will wait 60 seconds before monitoring the door trigger input.
• Opon 6 - 120 seconds, System will wait 120 seconds before monitoring the door trigger input.
Feature 15: Alarm Trigger Length
Funcon: Set the length of me the Alarm Nocaon will sound for each cycle.
Seng Choices:
• Opon 1 - 30 seconds, System will Alarm Cycle will sound for 30 second.
• Opon 2 - 45 seconds, System will Alarm Cycle will sound for 45 second.
• Opon 3 - 60 seconds, System will Alarm Cycle will sound for 60 second.
• Opon 4 - 90 seconds, System will Alarm Cycle will sound for 90 second.
• Opon 5 - 120 seconds, System will Alarm Cycle will sound for 120 second.
Note: The system will check the trigger inputs between each Alarm Cycle. If the trigger input is sll acve the system will
nofy the user with another cycle.

APS510Z_RevC_08/20 11
Five Buon Remotes (1-Way & 2-Way LED)
Buon Acon Funcon
Press 1x Lock
Hold 3 Seconds Panic ON/OFF
Press 1x Unlock
Hold 3 Seconds Panic ON/OFF
Press 2x Ch. 3 ALT Output
Hold 3 Seconds Trunk Release
Press 1x
Press & Hold
Press 1x
Press & Hold
Programable AUX
Programable AUX
Detailed Descripons: System Operaon
Remote Control Operaon
This system includes two (2) 1-Way ve (5) buon remotes. The matrix below describes the basic funcons of each
remote. See Owners Guide for complete remote operaon matrix.

APS510Z_RevC_08/20
12
2= Bank 2
3= Bank 3
Ignition On
Ignition O
Press and Release
Override Button
1 Chirp = Bank 1
(Program Remotes)
Cycle Key to Advance
Banks (2,3)
Chirps Indicate
Bank Number
Chirps Indicate
Option Number
Press Override Button to
Advance Within Bank
Repeat Steps to Program
Another Feature Bank...
... or Exit
Programming
Press to Change
Feature Option
LED Indicates
Feature Selection
3X
Note: Programming will time out after 60sec with no activity or Ignition Off for 5sec.
1X
Repeat Steps to Program
Another Feature ...
L
O
C
K
A
C
C
O
N
S
T
A
R
T
L
O
C
K
A
C
C
O
N
S
T
A
R
T
L
O
C
K
A
C
C
O
N
S
T
A
R
T
Once the system is installed and powered up, you will use the vehicle ignion, override buon and a programmed
remote control to set all system opons. Feature opons are divided into categories, or Banks, as described throughout
this secon. Ensure that at least one remote control is programmed to the system. If not, or if you need to program
more remote controls, use the diagram steps to access Bank 1.
The siren and LED will indicate your status and selecons. Follow the diagram below to enter and maneuver through the
programming procedure.
Quick Reference: System Programming
Programming Mode Entry and Exit Procedure
1. Turn the ignion ON.
2. Press and release the valet/override buon three (3) mes.
3. The system will beep (1) one me, indicang you have accessed Bank 1.
4. Each cycle of the Ignion, OFF/ON, will advance to the next bank (up to Bank 3) then restart at Bank 2. (Note: To re-
access Bank 1 for transmier programming, you will need to exit and re-enter programming mode.)
5. The system will beep a number of mes to indicate the Bank number:
• 1 beeps: Bank 1 - Programming Remote Controls
• 2 beeps: Bank 2 - Security Control Opons
6. Once you have accessed the desired bank, press the valet/override buon to advance though the features. The LED
will ash a number of mes to indicate the feature, based on the charts that follow this secon. The system will chip
a number of mes to indicate the Opon programmed.
7. Once you have accessed the desired feature, press the LOCK buon on the remote control to advance though the
feature's seng opons. The system will beep a number of mes to indicate the Opon seng, based on the charts
that follow this secon.
8. Once you have made the desired seng, you can press the valet/override buon to advance through the
features within the bank, or cycle the Ignion key OFF/ON to advance to the next bank.
9. Once you have completed programming, you MUST turn the ignion key to OFF to exit the programming
mode. Programming will automacally exit aer 60 seconds of inacvity.
Data Port Protocol Selecon
The default data port protocol of this model is ADS (iDatalink 2-Way). This model is capable of detecng the correct
data port protocol (ADS or DBI) and automacally conguring Feature Bank 2; Feature 18. To inialize the detecon
procedure:
1. Press and hold the valet buon.
2. Cycle the vehicle’s Ignion ON/OFF two (2) mes.
3. Release the valet buon.
Note: This feature is only available on module rmware v2.0 or higher.

APS510Z_RevC_08/20 13
Quick Reference: System Programming
Bank 1: Transmier Programming Opons See pages 6 for a detailed descripon.
Bank 2: Security Opons See pages 7-10 for detailed descripons.
1 Chirp 2 Chirp
3 Chirp 4 Chirp 5 Chirp 6 Chirp
1 Lock / Unlock Funcon 500ms 3.5sec 500ms L, DBL UL DBL L, 500ms UL DBL L, DBL UL 500ms L, 350ms UL
2 Ignion Lock OFF ON
3 Ignion Unlock OFF Unlock All Unlock Driver
4 Exterior Illuminaon OFF With Arm With Disarm With Arm & Disarm
5 Auto Relock OFF Auto Lock Auto Lock & Arm
6 Auto Arming OFF Auto Arm Auto Lock & Arm
7 Nocaon Sound Both Siren Horn
8 Horn Timing 16ms 30ms 40ms 50ms 10ms
9 Valet Override Method Valet Custom Code
10 Driver Priority Unlock OFF ON
11 Silent Choice OFF From Transmier OEM Style
12 Park Light / Trunk Swap NA
13 AUX Ch. 4 Pulse Push & Hold 10sec 20sec Latch On/OHold 3/s for O/P
14 AUX Ch. 5 Pulse Push & Hold 10sec 20sec Latch On/OHold 3/s for O/P
15 Alarm Trigger Length 30sec 45sec 60sec 90sec 120sec
16 Dome Light Delay Timer Off/ Program 15sec
30sec 45sec 60sec 120sec
17 Security Prole All On Doors O
Hood/trunk OAll OAll On w/ OEM RS
18 Data Port Protocol ADS DBI
Feature Bank 2
Opons
Features
1 Auto Program/Lock
2 Unlock
3 Trunk/Start
4 Ch. 4 AUX
5 Ch. 5 AUX
6 Ch. 6 AUX
7 Ch. 7 AUX
Channel
Feature Bank 1
Press Lock buon on remote
Press Unlock buon on remote
Press Trunk/Start buon on remote
Press buon/buonsto control AUX Ch. 4
Press buon/buonsto control AUX Ch. 5
Press buon/buonsto control AUX Ch. 6
Press buon/buonsto control AUX Ch. 7
Descripon

APS510Z_RevC_08/20
14
Quick Reference: System Programming & Diagnoscs
Silent Arm and Disarm
Program the Presge system to arm and disarm without nocaon beeps. (The siren will sound if the system is
triggered while armed.)
1. Turn the ignion ON then OFF.
2. Press and release the valet/programming buon three (3) mes. The system will respond with one (1) beep for ON or
two (2) beeps for OFF.
Dome Light Delay
To program the Presge system to wait unl the dome light turns o before arming:
1. Close all doors.
2. With the vehicle ignion o, press LOCK, UNLOCK, LOCK ,UNLOCK, LOCK, UNLOCK, LOCK on the remote control. The
dash-mounted LED will turn on.
2. Immediately OPEN then CLOSE the door WITHOUT disarming the system. Aer the dome light turns o, the LED will
ash to indicate programming compleon.
3. Disarm and exit the vehicle.
To return the system to default dome light sensing:
1. Turn the vehicle ignion ON then OFF three (3) mes, then press and hold the valet buon for ve (5) seconds.
2. The system will beep one (1) me indicang the learned delay has been cleared.
User Selectable LED
This feature will control whether the LED is ON or OFF when the system is Armed/Locked. This will be selectable in
feature programming OR on-the-y without entering the programming feature banks.
1. Turn the ignion ON, OFF, ON, OFF.
2. Press and hold valet buon for ve (5) seconds.
The system will respond with one (1) beep for ON or two (2) beeps for OFF.
Adjusng the Shock Sensor
1. Arm the system, wait 5-10 seconds, then with an open palm carefully apply impact to areas of the vehicle to test the
shock sensor’s sensivity.
2. To adjust, turn the adjustment knob on the shock sensor counter-clockwise for less sensivity; clockwise for more
sensivity.
3. If the proper sensivity sll cannot be achieved, re-locate the shock sensor.
Troubleshoong Trigger Zones
Test the doors, hood, trunk, and shock sensor to ensure they trigger the security system. Once triggered, the LED ashes
to indicate the trigger source:
1 Shock
2 Trunk/Hood
3 Door

APS510Z_RevC_08/20 15
The Valet Override procedure will disable the alarm when the remote is not available or has become inoperave. If the
vehicle door is opened without disarming, the alarm will sound and the vehicle will not start when aempng to start
with the key. To disable the alarm:
1. Turn the vehicle ignion to ON.
2. Within ve (5) seconds, press and release valet buon on Antenna one (1) me.
The alarm will silence and the vehicle will now start normally with the key.
Quick Reference: Alarm Override Procedures
Valet Alarm Override
Custom Code Override
Unlike the default Valet Override, Custom Code Override is a user personalized code that oers a higher lever of security.
If the user chooses to use Custom Code Override, Feature Bank 2 ; Feature 9 must be programmed for "Custom Code".
Once the opon has been selected the code must be programmed. Once the Custom Code is programmed it cannot be
changed without rst disarming the alarm.
Custom Code Override Procedure
The Custom Code is made up of 2 numbers. Each chosen number must be between digits 1-9. The default Custom Code
is "11". To disarm the alarm using the Custom Code opon:
1. Turn the vehicle ignion to ON.
2. Within ve (5) seconds, Press the valet buon one (1) me.
3. Within ve (5) seconds, Turn the ignion OFF/ON.
4. Within ve (5) seconds, Press the valet buon one (1) me.
5. Turn the vehicle ignion to OFF then ON to start the vehicle.
Custom Code Programming Procedure
In this example, the user has selected Custom Code "23". To program a user selected custom code start with the alarm
disarmed:
1. Turn the ignion to the ON posion
2. Within ten (10) seconds, press the valet buon three (3) mes to enter programming.
3. Within ten (10) seconds, Cycle the ignion OFF/ON, OFF/ON, OFF/ON. The system will beep one (1) me.
4. Within ten (10) seconds, Press the valet buon two (2) mes. This number will indicate the rst digit of the chosen
Custom Code.
5. Within ten (10) seconds, Cycle the ignion OFF/ON.
6. Within ten (10) seconds, Press the valet buon three (3) mes. This number will indicate the second digit of the
chosen Custom Code.
7. Cycle the ignion OFF.
If the Custom Code was accepted the LED will ash the rst number (2), pause, then the second number (3). This will
repeat two (2) more mes to conrm the Custom Code entry. If aer 15sec the LED does not ash please repeat steps
1-7.

APS510Z_RevC_08/20
16
Quick Reference: Wiring Diagrams
Door Lock Connecons
Posive-Trigger Door Locks
Vericaon: The vehicle wires register 12V+ when the Lock and Unlock switches are acvated.
Negave-Trigger Door Locks
Vericaon: The vehicle wires register Ground when the Lock and Unlock switches are acvated.
Lock
Unlock
Vehicle Door Lock
Control Relays
RED ( - ) Lock Output
GREEN ( - ) Unlock Output
Lock
Unlock
87
87a
86 85
30
87
87a
86 85
30
Vehicle Door Lock
Control Relays
Fused +12 Volt
Baery Souce
Fused +12 Volt
Baery Souce
RED ( - ) Lock Output
GREEN ( - ) Unlock Output

APS510Z_RevC_08/20 17
Quick Reference: Wiring Diagrams
Door Lock Connecons
Single-Wire Negave Mulplex Door Locks (Relays required)
Vericaon: The vehicle wire registers variable Ground values when the Lock and Unlock switches are acvated. Please
consult the vehicle-specic wire and locaon chart for resistor values.
Single-Wire Posive Mulplex Door Locks (Relays required)
Vericaon: The vehicle wire registers variable 12V+ values when the Lock and Unlock switches are acvated. Please
consult the vehicle-specic wire and locaon chart for resistor values.
Lock
Unlock
Vehicle Door Lock
Control Relays
RED ( - ) Lock Output Green ( - ) Unlock Output
87
87a
86
30
87
87a
86
30
85 85
Fused +12 Volt
Baery Source
Ground
Resistor
Lock
Unlock
Vehicle Door Lock
Control Relays
RED ( - ) Lock Output Green ( - ) Unlock Output
87
87a
86
30
87
87a
86
30
85 85
Fused +12 Volt
Baery Source
Resistor

APS510Z_RevC_08/20
18
Quick Reference: Wiring Diagrams
Door Lock Connecons
Reverse-Polarity Door Locks (Relays required)
Vericaon: The vehicle wires rest at Ground and register 12V+ when the Lock and Unlock switches are acvated.
Aermarket Actuators (Relays and door lock actuators required)
Lock
Unlock
87
87a
86 85
30
87
87a
86 85
30
Fused +12 Volt
Baery Souce
Fused +12 Volt
Baery Souce
RED ( - ) Lock Output
Green ( - ) Unlock Output
X
Cut
X
Cut
To Door Lock Motor
To Door Lock Motor
30
87
87a
86 85
Fused +12 Volt
Baer y Source
Door Lock
Actuator
30
87
87a
86 85
Chassis
Ground
Chassis
Ground
RED ( - ) Lock Output
GREEN ( - ) Unlock Output
Fused +12 Volt
Baer y Source
M

APS510Z_RevC_08/20 19
Quick Reference: Wiring Diagrams
Starter Kill / An-Grind Relay Connecons
Included Starter Kill / An-Grind Relay
L
O
C
K
A
C
C
O
N
S
T
A
R
T
CUT
87
87a
86 85
30
To Vehicle Ignion
To ORANGE - Starter Kill /
An-Grind Output (-) From Alarm

APS510Z_RevC_08/20
20
Quick Reference: Wiring Diagrams
1 2 3 4
1 2 3 4
VOXX
1 Dk. Blue/Black ALT. Ch.3 Output (Start) (-)
2 Orange/White Starter Kill Output N.O. (-)
3 Green/Lt. Blue Ch. 4 AUX Output (-)
4 Purple DoorTriggerInput (+) 5
Dk. Blue TrunkOutput (-)
6 Lt. Green Instant TriggerInput (Hood/Trunk) (-)
7 Lt. Blue/GreenCh. 5 Aux Output (-)
8 Brown DoorTriggerInput (-) 9 Green/White Dome light Output (-)
10 Empty Empty
11 White/Blue Headlight Output (-)
12 Dark Green Sensor Input (-)
13 Yellow IgniƟon Input (+)
14 Black/White Horn Output (-)
14 Pin Input/Output
1 White Parking Light (30)Output
2 Black Ground Input (-) 3 White/Red Parking Light (87)Input
4 Orange Starter Kill Output N.C. (-) 5 White/Black Siren Output (+)
6 Red BaƩery 12VInput (+)
6 Pin Power
1 Blue Data TX
2 White Data RX
3 Black Ground (-) 4 Red BaƩery 12V (+)
CarLink
4 Red BaƩery 12V (+)
3 Blue Data TX
2 Black Ground (-) 1 White Data RX
DBI
4 Red BaƩery 12V (+)
3 Black Data TX
2 Green Warn AwayInput (-) 1 Blue Full TriggerInput (-)
Shock
2 Red BaƩery 12V (+)
1 Blue LED Output (-)
LED
2 Gray Valet Input (-)
1 Black Ground (-)
Valet
3Red/Black 2nd Unlock Output (-) 2 GreenUnlock Output (-) 1 Red Lock Output (-)
Door
Lock
Not Included Replacement Part #4120473
Replacement Part #4120472
Not Included
Replacement Part #4700033
Replacement Part #4120474 Replacement Part #4120475
85 Red
IgniƟon Input (+)
86 OrangeStarter Kill Input (-)
87ABlack Starter Interrupt - Key Side
30 White/Black Starter Interrupt - Motor Side
Starter Kill
Replacement Part #4360828
86 85
87
87A
30
Replacement Part #4360846
1 2
3 5 7 9 11 13 4 6 8 10 12 14
1 2 3
1 2 3 4
1 3 5
2 4 6
Shock Sensor
Part #4700033
185BP185BP
