Voyager AOC130XP Assembly Instructions

AOC130XP / AOC130XPB
OBSERVATION SYSTEM
AOC130XP Features:
- High Resolution, 1/3” CCD(Sony EX-view) Color Camera
- Compact/LightweightAluminum Die Cast Body
- Waterproof Housing
- Waterproof Microphone
- Waterproof Normal/MirrorImage Switch
- Adjustable Viewing Angle
- Optional Wind Deflector
Audiovox Specialized Applications, LLC
53200 Marina Drive
Elkhart, IN 46514
Camera
Wind Deflector
Bracket
Hardware Kit
*Specifications
are subject to
change without
notice.
P/N A002850
REV. A

Mounting Bracket Footprint:
Installation and Pin Out:
Installation without Wind Deflector:
Hardware Kit:
4mm x .7mm x 25.4mm Phillips
Hex Head Screw w/Washers
4
4mm x .7mm Hex Nuts
Screw w/Attached Lockwashers
#8-32 x 5/16" Phillips Hex
Screw for use without Wind Deflector
Screw for use with Wind Deflector
Screw w/Attached Lockwashers
#8-32 x 3/8" Phillips Hex
4
4
4
4mm x .7mm Hex Nuts
