Vulcan-Hart VHL2G User manual

Item # __________________________
C.S.I. Section 11420
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
A2780
ISO9001
Vulcan-Hart Co.
F-32425 (8-04)
SPECIFICATIONS:
Gas fired boiler Super Steamer, Vulcan-Hart Model No. (VHL2G)
(VHL3G). 6 psi pressure steam cooker. Cooker body is 8 gauge
satin finish type 304 stainless steel exterior. Doors have a
removable aluminum alloy inner liner with full perimeter gasket
and sealed by turning a "T" type handle. The door cannot be
opened while the steamer is on. Automatic timed compartment
controls with 60 minute timer, add the suffix "S" to the model
number. Lift-out stainless steel wire Adapt-A-PanTM supports
eight 21/2", six 4", or four 6" deep food pans (one for 2 compart-
ments)(two for 3 compartments) and one manual pull out shelf.
Water fall compartments interior bottom to lip out at front.
Steamer mounted on 28" high base cabinet with stainless steel
frame, front full height doors, slip-off stainless steel side and
aluminized rear panel with 6" adjustable legs with flanged feet for
anchoring. 270,000 BTU/hr. high efficiency steam boiler with
electronic ignition builds 5.5 BHP. Includes CSD-1 compliant high
pressure limit switch (15 psi), low water cut-off, automatic water
fill, automatic boiler blowdown, 15 psi pressure relief valve and
15 psi kettle connection. Service connections include: 1" gas
connection, 1/2" water connection for boiler feed and 1/2" cold water
condenser, 120 volt control circuit and 11/4" drain connection.
Exterior dimensions:
VHL2G: 36"w x 357/16"d x 65"h.
VHL3G: 36"w x 357/16"d x 80"h.
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
CSA design certified. Classified by U L to NSF Std. #4. Meets
ASME code.
VHLG SERIES
SUPER STEAMER, HIGH EFFICIENCY GAS BOILER
TWO OR THREE COMPARTMENT MODELS
MODEL: VHLG SERIES Super Steamer, High Efficiency Gas Boiler
■■VHL2G (S) (P) 2 compartments
■■VHL3G (S) (P) 3 compartments
STANDARD FEATURES
■6 psi pressure steam cooker.
■Cooker body is 8 gauge satin finish type 304 stainless steel
exterior. Doors have a removable aluminum alloy inner liner
with full perimeter gasket and sealed by turning a "T" type
handle. The door cannot be opened when the steamer is on.
■Automatic timed compartment controls with 60 minute timer
add the suffix "S" to the model number.
■Lift-out stainless steel wire Adapt-A-PanTM supports eight 21/2",
six 4" or four 6" deep food pans (one for 2 compartments)(two
for 3 compartment) and one manual pull out shelf.
■Water fall front edge compartment interior bottom to lip out at
front.
■Steamer mounted on 28" high base cabinet with stainless steel
frame, front full height doors, slip-off stainless steel side and
aluminized rear panel with 6" adjustable legs with flanged feet
for anchoring.
■270,000 BTU/hr. high efficiency steam boiler with electronic
ignition builds 5.5 BHP. Includes CSD-1 compliant high
pressure limit switch (15 psi), low water cut-off, automatic
water fill, automatic boiler blowdown, 15 psi pressure relief
valve and 15 psi kettle connection.
■Service connections include 1" gas connection, 1/2" cold
water connection for boiler feed and 1/2" cold water condenser,
120 volt control circuit and 11/4" drain connection.
■One year limited parts and labor warranty.
OPTIONS
■■PreVentTM, automatic load compensated timed, combination
pressure and free venting cooking with automatic exhaust,
add the suffix "P" to the model number.
■■Correction facility package:
a. Cabinet door with hasp (lock by others).
b. Security type tamper resistant fasteners.
c. Control cover (lock by others).
■■Control circuit step down transformer to 120V, if higher than
120 volts.
■■Mount and interconnect boiler base with kettle at factory.
Includes steam supply piping. Shipped on one skid.
■■Second year extended limited parts and labor warranty.
ACCESSORIES
■■Stainless steel back panel.
■■Interconnecting steam supply plumbing kit.
■■Manual sliding shelf (Qty. ____).
■■Removable 12 x 20 sliding shelf (Qty. ____).
■■Adapt-A-Pan™ support (Qty. ____).
■■Water treatment system.

Printed On Recycled Paper
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-32425 (8-04)
VHLG SERIES
SUPER STEAMER, HIGH EFFICIENCY GAS BOILER
TWO OR THREE COMPARTMENT MODELS
SERVICE CONNECTIONS:
GAS CONNECTION: 1" NPT.
ELECTRICAL CONNECTION FOR CONTROLS: 120/60/1,
300 watt maximum, power supply with grounding wire required.
(For other than 120 volt supply consult factory for location of
this connection.)
DRAIN: Condenser box, compartment and boiler, 11/4" NPT.
(Provide an open air type drain within 12" of condenser box and
for best results at a distance so that steam vapors will not enter
the steamer from underneath the control area. Do not connect
solidly to any drain connections.)
COLD WATER CONNECTION: 1/2" NPT for boiler feed. Inlet
water pressure between 20 and 60 psi.
COLD WATER CONNECTION: 1/8" NPT for condensate box.
Inlet water pressure between 20 and 60 psi.
STEAM TAKE-OFF CONNECTION: 3/4" NPT.
WATER QUALITY STATEMENT:
The fact that a water supply is potable is no guarantee that it is suitable
for steam generation. Your water supply must be within these general
guidelines:
SUPPLY PRESSURE 20 - 60 psig
HARDNESS* less than 3 grains
SILICA less than 13 ppm
TOTAL CHLORIDE less than 4.0 ppm
pH RANGE 7-8
UN-DISSOLVED SOLIDS less than 5 microns
*17.1 ppm = 1 grain of hardness
Other factors affecting steam generation are iron content, amount of
chloridation and dissolved gases. Water supplies vary from state to state
and from locations within a state. Therefore it is necessary that the local
water treatment specialist be consulted before the installation of any
steam generating equipment.
IMPORTANT:
1. A pressure regulator sized for this unit is included. Minimum supply
pressure: Natural gas 7" W.C., Propane gas 11" W.C.
2. Gas line connecting to unit must be 3/4" or larger. If flexible connectors
are used, the inside diameter must be at least the same as the 3/4" iron
pipe.
3. An adequate ventilation system is required for commercial cooking
equipment. Information may be obtained by writing to the National
Fire Protection Association, Batterymarch Park, Quincy, MA 02289.
When writing, refer to NFPA No. 96.
4. These units are manufactured for installation in accordance with
ANSZ223.1A (latest edition), National Fuel Gas Code. Copies may be
obtained from the American Gas Association, 1515 Wilson Blvd.,
Arlington, VA 22209.
5. Clearance: Combustible Non-Combustible
Rear 6" 6"
Left & Right Side 6" 6"
NOTE:
•Dimensions which locate the above connections have a tolerance of
+ or -3" (+ or -75 mm).
•Installation of backflow preventers, vacuum breakers and other specific
code requirements is the responsibility of the owner and installer. It is
the responsibility of the owner and installer to comply with local codes.
•Plastic drains are not recommended due to inherent limited tempera-
tures of the plastic. Boiler purge temperatures may exceed 180°F. The
installer may be required to provide means to reduce boiler purge water
temperature to be that of the condensate temperature of 140°F or less.
•This appliance is manufactured for commercial installation only and is
not intended for home use.
