Vulkan HRD 92 S.C User manual

HRD 92 S.C
PAGE | 1
FR
USER MANUAL
HRD 92 S.C
EN
EN

HRD 92 S.C
PAGE | 2
TABLE OF CONTENTS
1 PRESENTATION ..................................................................................................................15
2 TECHNICAL CHARACTERISTICS ...........................................................................................15
3 SPECIFICATION ACCORDING TO NF EN 14624 STANDARD.............................................16
4 GENERAL SAFETY INSTRUCTIONS.......................................................................................16
5 PRECAUTIONS OF USE ..........................................................................................................17
6 DESCRIPTION OF THE DEVICE..............................................................................................18
6.1 DETECTOR’S MODULES.....................................................................................................................18
6.2 FRONT PANEL OF THE BOX .............................................................................................................18
7 START UP & USE....................................................................................................................19
7.1 CALIBRATION .......................................................................................................................................19
7.2 START UP ...............................................................................................................................................20
7.3 DETECTION............................................................................................................................................20
7.4 ADJUSTING THE SENSITIVITY AND THE TYPE OF GAS ...........................................................21
7.5 LIGHT « S » SATURATION / CONTAMINATION ........................................................................21
7.6 ZERO & AMBIENT CONTAMINATION..........................................................................................21
7.7 POWER & BATTERY RECHARGING.....................................Error! Bookmark not defined.2
8 PERIODICAL CHECKS & OPERATING ANOMALIES ............................................................22
7.1 PERIODICAL CHECKS..........................................................................................................................22
7.1 OPERATING ANOMALIES..................................................................................................................22
9 MAINTENANCE & GUARANTEE...........................................................................................23
9.1 FILTER REPLACEMENT .......................................................................................................................23
9.2 BATTERY REPLACEMENT...................................................................................................................23
9.3 CURRENT MAINTENANCE PARTS..................................................................................................23
9.4 ACCESSORIES .......................................................................................................................................24
9.5 MAINTENANCE....................................................................................................................................24
9.6 GUARANTEE..........................................................................................................................................24
EN

HRD 92 S.C
PAGE | 3
We advise you to read this manual carefully , so that you can
make the best use of the detector's features , and avoid false
manipulations that may damage it. VULKAN is at your disposal
for any further information .
1 PRESENTATION
The HRD 92 SC Leak Detector is designed for the detection of refrigerant gas leaks by
sniffing at atmospheric pressure.
It allows locating and estimating the value of the leak.
2 TECHNICAL CHARACTERISTICS
Housing
Shockproof plastic case, Height 22 cm, Width 6.5 cm, Depth 3 cm,
Weight 0.350 kg
Power Supply
Built in rechargeable batteries, Recharge time 12 h around
Autonomy 4 h [option : 8 h autonomy batteries]
Uses
For worksite and intermittent applications. Optimum performance between 10 et
40°c
Detection Bloc
Detection Bloc with suction for the best localisation of the leak and a fast
response and degassing time.
Fast connecting plug for easy replacement, Interchangeable flexible sniffer
pipe.
• General use BlocHFC, HFO, R600, R290, H2/N2 mixture
• Specific Bloc for Tracer MixtureH2/N2
Cable
Twin plug cable, length 1 m
Warm-up
Around 1 min. Automatic zeroting
Response Time
Less 1 second
Lower Sensitivity
•1 g/yr for HFC, HFO
•1 g/yr for R600 & R290
•1.10-5 cc/s for H2/N2 mixture [equivalent 1 g/yr R134a]
3 Sensitivity Position
•x1 > graduation 1 to 10 g/yr
•LO > x3 graduation 3 to 30 g/yr
•HI > x0.3 gradation 0.3 to 3 g/yr
•3 Position Gas Selector: HFO, HFC, HC, H2/N2
Light Rail
•Graduated light rail : x1, x2, x3, x5, x10
•Lamp for degassing time. Audible signal by buzzer over light 3
Warning Light
« Contamination-Saturation » Light. A progressive lightning indicate the
ambient contamination or the Sensor saturation when detecting a big leak
FR

HRD 92 S.C
PAGE | 4
Carrying Case
Detector delivered in carrying case with a 110/220v charger
& Instruction for use
3 SPECIFICATION ACCORDING TO NF EN 14624 STANDARD
The HRD 92 gas detector complies with standard NF EN 14624 which determines the following
elements:
Minimum sensitivity threshold
Fixed : 1 g/year
Moving : 1 g/year
Maximum sensitivity threshold
Fixed : > 50 g/year
Moving : > 50 g/year
Minimum detection time
< 1 seconde
Threshold of sensitivity in a polluted
atmosphere
2 g/year
Recovery time after exposure
1 to 10 seconds (depending on detection
level and sensitivity threshold)
Calibration frequency
Once a year
4 GENERAL SAFETY INSTRUCTIONS
• Intended use: The HRD 92 should only be used for the leak detection process described
in this manual. The device is a gas leak detector and should not be used for measurement
or control of ambient air. In the event of improper use and / or order, the user or third
parties may be exposed to hazards. Any deviation from the intended use described in this
manual will result in warranty restrictions and the manufacturer's liability for damage.
• Personnel and user : HRD 92 should only be operated by qualified personnel trained for
these activities. The contents of this manual must be explicitly communicated to the user
and the user agrees to follow the instructions to ensure the proper functioning of the
detector.
• Surrounding environment : HRD 92 should not be used in environments exposed to
explosion hazard and / or other hazardous environments. It is forbidden to smoke in the
surrounding area. The environment of use and the storage environment must be free of all
soils and contaminations and must in particular be protected against the influence of
chemical substances such as silicones for example. Silicon and sulfur containing media or
inorganic impurities, oils, fats and evaporating liquids can cause poisoning phenomena on
EN

HRD 92 S.C
PAGE | 5
the gas sensor that can change the sensitivity and / or selectivity of the sensor. Reduced
sensitivity, unstable calibration or false detections can be possible consequences.
• Sensitive Electronics : Handle the HRD 92 with care and avoid shock or fall. Check that
the device is not damaged before each use. Do not hold the trace gas leak detector cell on
a gas cylinder valve and open the gas cylinder. The hole in the leak detector's detection cell
must always be kept clean and free of oil or grease.
• Repairs, cleaning and maintenance : Interventions on the device as well as maintenance
and repair work are only allowed to be carried out by the manufacturer's after-sales service
or by competent specialists . In case of non-observation, the device may be damaged. Any
unauthorized intervention exposes the user to a risk, threatens the safe operation of the
device and restricts warranty rights. The activities described in the chapter "MAINTENANCE
AND MAINTENANCE" are an exception.
• Batteries Pack : This device has Ni-MH batteries. Do not try to disassemble, open or
maintain the pack ba tterie. Do not crush, pierce, throw into fire or water the battery pack.
Do not store above 60 ° C.
• Accessories / Spare Parts : Only use accessories and spare parts from the manufacturer.
Do not dispose of your electronic device with household waste. Return it to
VULKAN Company at the end of its useful life. In accordance with Directive
2002/96 / EC on WEEE, we provide separate collection for environmentally friendly
treatment.
5 PRECAUTIONS OF USE
• The detector must be charged before first use.
• To prevent clogging of the suction pipe, do not allow the pipe to come into contact with
water, grease or other dirt.
• Replace regularly and as often as necessary the fiber filter that is accessible after
unscrewing the sniffer pipe.
• Beware of foaming products for testing "to the bubble test", Whose residues can be
sucked by the device and which are often corrosive. Clean the points to be checked (wipe
with a cloth to remove various dirt, condensation, grease).
• Beware of silicone oils which may desensitize irredeemably the detection cell.
• Attention the detector is studied for the optimal detection of leaks lower than 10 g / year
(about 1 mg / hour ).
ENEN

HRD 92 S.C
PAGE | 6
In case of large leaks, do not leave the detector on the point of leakage, which saturates the
cell and can reduce its sensitivity.
• The detector is a measuring device and must be handled as such. He fears violent shocks,
corrosive or salty atmospheres.
• After use, store the detector in its case, which should remain clean and dry.
WARNING DETECTOR NOT EXPLOSION PROOF
NEVER USE IN EXPLOSIVE ATMOSPHERE
EN

HRD 92 S.C
PAGE | 7
6 DESCRIPTION OF THE DEVICE
6.1 DETECTOR’S MODULES
The device is delivered in plastic suitcase, with wedging foam including :
• The detector housing includes the battery packs and the processing electronics.
• A Detection Block with quick release, connected by cable to the housing and
including :
-the suction turbine,
-the detection cell
-a sniffing pipe screwing.
• A Screw on sniffer tube with a Fibre filter is fitted at the entry of the Bloc (bag of 10)
• A battery charger suitable for the type of battery equipping the unit.
6.2 FRONT PANEL OF THE BOX
EN

HRD 92 S.C
PAGE | 8
1
One Lighted display with from left to right :
• ORANGE light « D » : WAIT function during warm-up period
: WAIT function during degassing period
• GREEN light « 0 »
• RED lights « 1, 2 ,3 ,5, 10 » : Indicating the leak level after calibration of the
Detector. A BUZZER alarm signal sound past level « 3 »
2
ORANGE light « S » Saturation Contamination
3
A switch : Stop « OFF », On « BAT »
4
GREEN light « BAT » showing correct charge of the batteries
5
ORANGE light « CHARGE » Indicating battery charging
6
Sensitivity selector with three positions :
• UP position « x1 » Normal sensitivity.
Estimated reading of the value of the leak on the graduated ramp
• CENTRAL position « HI » Sensitivity 3 times stronger
Reading on the graduated ramp 0.3, 0.6, 1, 1.5, 3 g/year
•BOTTOM position « LO » Sensitivity 3 times lower for locating large leaks
Reading on the graduated ramp 3, 6, 9, 15, 30 g/year
7
3-Position Central Inverter : HFO –HFC & H/N2 - HC
Adapts Detector Sensitivity curve to Detected Gas Family
8
Battery Charger Connection Port, On the right side of the device
7 START UP & USE

HRD 92 S.C
PAGE | 9
7.1 CALIBRATION
The detector is calibrated on delivery.
Initial Calibration can be changed by opening the Detector cabinet and should
only be performed by a qualified person with the necessary equipment.
7.2 START UP
The Detector is designed for the detection of refrigerant gas leaks by sniffing at atmospheric
pressure. It allows locating and estimating the value of the leak.
1
• After connecting the Detection Block to the cable through the quick-release
socket, toggle the STOP switch up, and check that the GREEN light " BATT " is
lit indicating the good charge of the batteries.
• If the LED is off, or is dimly lit , there is insufficient battery charge and these need
to be recharged.
2
At start-up, the Detector controls the luminous ramp and the Buzer , then goes
into heating position with lighting of the Orange light " D ".
3
After about a minute, the light " D " Indicates that the unit is ready to detect.
4
The light " S " SATURATION / CONTAMINATION comes on during the Detector
heating period and is normally off or very dimly lit. It is best to wait for the LED to
go out before you begin detection.
7.3 DETECTION
EN

HRD 92 S.C
PAGE | 10
The detection response time is less than the second. The operator must wait, for each point
to control, the time necessary for a possible detection.
• For quick response and good detection, the sniffer probe should be as close as possible
to the leakage point to be controlled.
• When a leak is detected, the light ramp lights in proportion to the value of the detected
leak.
oImmediately remove the probe from the leakage point to avoid saturation
of the cell.
oIn case of big leaks, the degassing of the cell causes the lighting of the
ORANGE light " D ".
Wait until the LED goes off " D " and possibly the light " S " before continuing
the detection.
Example : With Sensitivity switch in position "x1" Estimation of the value of the leak
detected on the light beam : - 1g/year light 1 on
-5 g/year light 5 on

HRD 92 S.C
PAGE | 11
7.4 ADJUSTING THE SENSITIVITY AND TYPE OF GAS
• ADJUSTING THE SENSITIVITY : using the Sensitivity Inverter
>UP position « x1 » Normal sensitivity.
Estimated reading of the value of the leak on the graduated ramp
>CENTRAL position « HI » Sensitivity 3 times stronger
Reading on the graduated ramp 0.3, 0.6, 1, 1.5, 3 g/year
>BOTTOM position « LO » Sensitivity 3 times lower for locating large leaks
Reading on the graduated ramp 3, 6, 9, 15, 30 g/year
• ADJUSTING THE GAS TYPE : using the Gas Inverter
>« HFC » for R22, R134a, R404a, R407c, and mixtures.
(For the R410a use the HF0 position)
>« HFO » for R 1.2.3.4ze & 1.2.3.4ye and mixtures.
>« HC » for R600 & R290.
>For the tracer mixture H2 / N2 - Put the inverter Gas on « H2 / N2 » and sensitivity
inverter on « HI ». If sensitivity is too large, pass on the position « 1 » or « LO ».
7.5 LIGHT « S » SATURATION / CONTAMINATION
• This light will be ON during the warm-up time of the detector and will then light OFF or
stay very tiny ON.
• If the light is on, the atmosphere of the room is contaminated and it is desirable to limit
the maximum duration of use of the detector to avoid accelerated weakness of the sensor
sensitivity.
• If the light flash when detecting a leak. Pull off the sniffing pipe from the leak point and
wait for the necessary degassing time of the detector until the “S” light is OFF.
7
6
EN

HRD 92 S.C
PAGE | 12
7.6 ZERO & AMBIENT CONTAMINATION
• The detector automatically adjusts its ZERO according to the ambient conditions. The
detector's automatic zeroing allows leak detection in contaminated conditions
• However, contamination always produces a 'masking' effect on leaks and it should be
limited as much as possible. The lower the ambient contamination the better one can
detect minor leaks.
• High contamination can result in ZERO instability with the lighted display being on. In such
a case it is essential to ventilate the premises, as the excessive level of contamination will
make valid leak hunting impossible.

HRD 92 S.C
PAGE | 13
7.7 POWER & BATTERY RECHARGING
The unit is equipped with a set of batteries giving a full-charge continuous-working of
approx. 4 hours.
During charging the orange « CHARGE » light must be ON.
Full charging takes approx. 12 hours and must never exceed 24 hours.
3 hours of charge for 1 hour of use.
NEVER USE A DIFFERENT CHARGER TO THE ONE SUPPLIED WITH
THE DETECTOR (E.G. CALCULATOR CHARGER OR OTHER).
The unit can be charged from a 12V car-battery, when using the special charger delivered
for this purpose.
The batteries equipping the unit have little memory effect and can be recharged when the
user need it suitable.
8 PERIODICAL CHECKS & OPERATING ANOMALIES
7.1 PERIODICAL CHECKS
• To check the sensitivity of the detector, it is essential to have a Refrigerant gas « Test
Leak » of known value.
Present the pipe to port sniffing « Test leak ».
Check the correct lighting of the lightbar and the response time.
If the Sensitivity of the Detector has been checked with an R134a Test Leak on the position
« HFC » or 1234ze on the position « HF0 » sensitivity can be considered as valid for other
gases or mixtures.
• As part of the Quality Assurance standards, we recommend that you carry out an annual
audit at the Vulkan manufacturer, which will draw up a verification report in accordance
with the EN 14624 standard valid for one year.
NEVER EXPOSE THE DETECTOR TO A JET (EVEN VERY FINE) OF PURE GAS TO
TEST THE SENSITIVITY. THIS WOULD DESENSITIZE OR DESTROY THE
DETECTION CELL.
EN

HRD 92 S.C
PAGE | 14
7.1 OPERATING ANOMALIES
The main defect of the detector is a long response time following the detection of a leak.
It can be due to several factors:
• Check for clogging of the pipe or filter (main factor).
• Check the tightness of the pipe sniffing
• Check the correct charge of the batteries
• Check the normal noise of the suction motor.
The central cabinet has no routine maintenance.

HRD 92 S.C
PAGE | 15
9 MAINTENANCE & GUARANTEE
9.1 FILTER REPLACEMENT
1
Unscrew the sniffing pipe
2
Remove the filter from the inside of the probe and discard it
3
Insert a new filter into the probe
4
Finally screw the sniffing pipe on the probe
9.2 BATTERY REPLACEMENT
The replacement of the battery pack is done by opening the case of the detector. Only
one VULKAN battery pack must be used.
1
Remove the 4 screws from the box
2
Unscrew the wires from the old battery block of the battery terminal block
3
Screw the wires of the new battery pack in the correct polarity :
Red wire> terminal +
Black wire > terminal -
4
Close and rescrew the 4 screws of the houssing
FR

HRD 92 S.C
PAGE | 16
9.3 CURRENT MAINTENANCE PARTS
Références
Spare parts available on order
S92-BSD-R
Detection Block Refrigerants Gas, directly interchangeable.
(Detection block delivered with flexible sniffing pipe + 10 Filter).
S92-BSD-H2N2
Specific detection block H2 / N2, directly interchangeable.
(Detection block delivered with flexible sniffing pipe + 10 Filter).
S92-CS2P
Spiralled Cable with 2 plugs
S92-CBS9V
Mains 220V charger
S92-PBV12V
Car 12v charger
S92-PF170
Flexible sniffing pipe (+ 10 Filters)
S92-VMB
Case, with foam
9.4 ACCESSORIES
•Test Leak - 5g/year R134a (FTB92 R134a)
•Test Leak - 5g/year R1.2.3.4ze (FTB92 R1234ze)
ENEN

HRD 92 S.C
PAGE | 17
9.5 MAINTENANCE
VULKAN ensures, with the competence of the builder the maintenance and the calibration
of your detector, which will be carried out, with the best conditions in the best delay.
We perform calibration, adjustment and maintenance of your devices to ensure a consistent
level of quality of your measurements. As part of the Quality Assurance standards, we
recommend that you perform an annual audit.
9.6 GUARANTEE
The guarantee is ONE year parts and labour against vice of manufacture, material returned
free of port, packing and insurance in our buildings in Aix en Provence.
This guarantee does not apply to the fair wear and tear of the material, nor with the
consequences of an incorrect, unskilful or negligent use.
The guarantee cannot be asserted by the user to ensure the normal maintenance of the
material during one year or to make carry out new calibrations or to make repairs due to a
misuse.
The guarantee does not apply to the desensitizing of the Detection bloc, whose qualities
and performances are checked before forwarding and for which the possible duration of
use depends directly on the conditions of exploitation.
Non exclusive list of not dealt with of repairs to the guarantee voucher :
- Desensitizing of the Detection bloc by saturation or pollution.
- Running damage of the pumping fan by choc or fall.
- Crash of the of the Detection bloc by choc or fall.
- Crash of the cabinet, or of the case.
- Crushing, cut, deformation of the cable.
- Crushing, pull off, obstruction of the sniffing pipe.
The guarantee is strictly limited to the repair of the detectors, the supplier who cannot be,
in no case, held responsible for the direct or indirect consequences of the use of VULKAN
material.
WARNING DETECTOR NOT EXPLOSION PROOF
NEVER USE IN EXPLOSIVE ATMOSPHERE
