V-TAC VT-80301 User manual

In case of any query/issue with the product, please reach out to us at: [e-mail]
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code to
access the manual in multiple languages.
INSTRUCTION MANUAL
MICROWAVE SENSOR
TECHNICAL DATA
MODEL VT-80301
SKU 23164
INPUT POWER AC: 220-240V, 50/60 Hz
RATED LOAD Max. 1200W
300W +LED
TIME DELAY Min. 10sec ±3sec
Max. 12min ±1min
DETECTION
RANGE 180°
DETECTION
DISTANCE 5-12m Adjustable
DETECTION
MOVING SPEED 0.6-1.5m/s
WORKING
TEMPERATURE -20°C to +40°C
POWER
CONSUMPTION Approx, 0.9W
AMBIENT LIGHT <3-2000 LUX (Adjustable)
INSTALLATION
HEIGHT 1.5-3.5m
POWER
CONSUMPTION Approx 0.9w
DETECTION
MOTION SPEED 0.6-1.5 m/s
HF SYSTEM 5.8Ghz CW Radar, ISM
Band
DIMENSION 119.5x80x51.5 mm
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product.
V-TAC LED
RANGE (UPTO 600W)
COMPATIBLE WITH

This marking indicates that this prod-
uct should not be disposed of with
other household wastes.
Caution, risk of electric shock.
FUNCTION
WARNING
1. Please make sure to turn o the power before starting the installation.
2. Installation must be performed by a qualified electrician.
1. Can identify day and night: It can work in the daytime and at night when it is adjusted on the
“sun” position (max). It can work in the ambient light less than 3LUX when it is adjusted on the
“3” position (min). As for the adjustment pattern, please refer to the testing pattern.
2. SENS adjustable: It can be adjusted according to using location. The detection distance of low
sensitivity could be only 5m and high sensitivity could be 15m which fits for large room.
3. Time-Delay is added continually: When it receives the second induction signals within the first
induction, it will restart to time from the moment.
4. Time–Delay is adjustable. It can be set according to the consumer’s desire. The minimum time
is 10sec±3sec. The maximum is 12min±1min.
NOTE: the high-frequency output of the HF sensor is
<0.2Mw- that is just one 5000th of the transmission
power of a mobile phone or the output of a microwave
oven, the baby can’t touch it
INSTALLATION
CONNECTION-WIRE DIAGRAM
• Loosen the screw on the bottom and unload the bottom (refer to the figure1).
• Pass the power wire through the hole with gasket in the bottom. Connect the power wire into
connection-wire column according to the connection-wire diagram.
• Fix the bottom with inflated screw on the selected position (refer to the figure2).
• Install back the sensor on the bottom, tighten the screw and then test it.
L (BROWN)
N (BLUE)
L (RED)
L
N
Figure 2Figure 1

• Turn the LUX knob clockwise on the maxi-
mum (sun). Turn the SENS knob clockwise
on the maximum (+). Turn the TIME knob
anti-clockwise on the minimum (10s).
• When you switch on the power, the light
will be on at once. And 10sec±3sec later
the light will be o automatically. Then if
the sensor receives induction signal again,
it can work normally.
• When the sensor receives the second
induction signals within the first induction,
• Electrician or experienced human can install it.
• Can not be installed on the uneven and shaky surface
• In front of the sensor there shouldn’t be obstructive object aecting detection.
• Avoid installing it near the metal and glass which may aect the sensor.
• For your safety, please don’t open the case if you find hitch aer installation.
• In order to avoid the unexpected damage of product, please add a safe device of current 6A
when installing microwave sensor, for example, fuse, safe tube etc.
• The load don’t work:
a. Check the power and the load.
b. Whether the indicator light is turned on aer sensing? If yes, please check load.
c. If the indicator light is not on aer sensing, please check if the working light corresponds to the
ambient light.
d. Please check if the working voltage corresponds to the power source.
• The sensitivity is poor:
a. Please check if in front of the sensor there shouldn’t be obstructive object that aect to receive
the signals.
b. Please check if the signal source is in the detection fields.
c. Please check the installation height.
• The sensor can’t shut automatically the load:
a. If there are continual signals in the detection fields.
b. If the time delay is set to the longest.
c. If the power corresponds to the instruction.
TEST
NOTES
SOME PROBLEM AND SOLVED WAY
Note: when testing in daylight, please turn LUX knob to ☼ (SUN) position, otherwise the
sensor lamp could not work!
it will restart to time from the moment.
• Turn LUX knob anti-clockwise on the minimum (3). If the ambient light is less than 3LUX (dark-
ness), the inductor load could work when it receives induction signal.
