W Box Technologies 0E-4CHNVR2TB User manual

Network Video Recorder (NVR)
User Manual
Issue
V4.2
Date
2018-08-15
0E-4CHNVR2TB
0E-4CHNVR2TB
0E-8CHNVR2TB
0E-16CHNVR2T
0E-16CHNVR4T

About This Document
Network Video Recorder
User Manual
Issue: V4.2 (2018-08-15)
i
About This Document
Purpose
This document describes the network video recorder (NVR) in terms of product
features, hardware installation, network access, network configuration, routine
maintenance, and common fault analysis.
Intended Audience
This document is intended for:
Technical support engineers.
Maintenance engineers.
Network video manger system operators.
Symbol Conventions
The symbols that can be found in this document are defined as follows:
Symbol
Description
Alerts you to a high risk hazard that could, if not avoided，
result in death or serious injury。
Alerts you to a medium or low risk hazard that could, if not
avoided, result in moderate or minor injury.
Alerts you to a potentially hazardous situation which, if not
avoided, result in equipment damage, data loss, performance
deterioration, or unanticipated results.
Provides a tip that may help in solving a problem or saving
time.
Provides additional information to emphasize or supplement
important points in the main text.
Important Statement
Users are required to enable and maintain the lawful interception (LI) interfaces of
video surveillance products in strict compliance with relevant laws and regulations.
Installation of surveillance devices in an office area by an enterprise or individual to
monitor employee behavior and working efficiency outside the permitted scope of the

ii
Issue: V4.2 (2018-08-15)
local law and use of video surveillance devices for eavesdropping of illegal purposes
constitute behaviors of unlawful interception.

Contents
Network Video Recorder
User Manual
Issue: V4.2 (2018-08-15)
iii
Contents
About This Document.................................................................................................... i
Contents........................................................................................................................iii
1Preface ........................................................................................................................ 1
1.1 Important Notes.............................................................................................................. 1
1.2 About This User Manual ................................................................................................ 1
1.3 Installation Environment and Precautions...................................................................... 1
2Basic Operations........................................................................................................ 3
2.1 Power on the Device....................................................................................................... 3
2.2 Power off the Device...................................................................................................... 4
2.3 Log into the System........................................................................................................ 4
2.4 Add Cameras.................................................................................................................. 5
3Wizard ........................................................................................................................ 7
4Quick Navigation..................................................................................................... 15
4.1 Playback....................................................................................................................... 16
4.1.1 Time Search ..................................................................................................... 17
4.1.2 Picture Grid...................................................................................................... 18
4.1.3 Event................................................................................................................ 19
4.1.4 Backup ............................................................................................................. 20
4.2 Main Menu................................................................................................................... 21
5Channel Management ............................................................................................. 23
5.1Camera Management..................................................................................................... 23
5.1.1 Add a Camera Automatically ........................................................................... 23
5.1.2 Add a Camera Manually................................................................................... 24
5.1.3 Delete a Camera............................................................................................... 25
5.2 Encode Parameter......................................................................................................... 25
5.3 Image Parameter........................................................................................................... 26
5.4 OSD Settings................................................................................................................ 27
5.5 Privacy Zone ................................................................................................................ 28
6Record Management ............................................................................................... 30
6.1 Record Schedule........................................................................................................... 30

Network Video Recorder
User Manual
Contents
iv
Issue: V4.2 (2018-08-15)
6.2 Disk.............................................................................................................................. 31
7Alarm Management................................................................................................. 33
7.1 General......................................................................................................................... 33
7.2 Motion Detection.......................................................................................................... 34
7.3 Camera Tamper ............................................................................................................ 35
7.4 Video Loss.................................................................................................................... 36
7.5 Intelligent Analysis....................................................................................................... 38
7.6 Alarm in........................................................................................................................ 39
7.7 Device Malfunction...................................................................................................... 40
8Network Management............................................................................................. 41
8.1 Network........................................................................................................................ 41
8.1.1 IP...................................................................................................................... 42
8.1.2 Port................................................................................................................... 42
8.1.3 PoE................................................................................................................... 43
8.2 DDNS........................................................................................................................... 43
8.3 E-mail........................................................................................................................... 44
8.4 UPnP ............................................................................................................................ 45
8.5 P2P............................................................................................................................... 46
8.6 IP Filter......................................................................................................................... 47
9System Setting.......................................................................................................... 50
9.1 Information................................................................................................................... 50
9.2 General......................................................................................................................... 51
9.2.1 System.............................................................................................................. 51
9.2.2 Date and Time.................................................................................................. 51
9.2.3 Time Zone........................................................................................................ 52
9.2.4 DST.................................................................................................................. 53
9.3 User.............................................................................................................................. 54
9.3.1 User.................................................................................................................. 54
9.3.2 Advance Setting ............................................................................................... 57
9.4 Password ...................................................................................................................... 57
9.5 Display......................................................................................................................... 58
9.6 Logs.............................................................................................................................. 59
9.7 Maintenance................................................................................................................. 60

, please refer
Preface
Network Video Recorder
User Manual
Issue: V4.2 (2018-08-15)
1
1 Preface
1.1 Important Notes
Thank you for choosing the NVR. Please read the user manual carefully before
using this product.
The NVR is a complex system-based device. To avoid disoperation and malfunctions
caused by environmental factors and human factors during installation, commissioning,
and application, note the following points when installing and using this product:
Read the user manual carefully before installing and using this product.
Use Seagate or Western Digital hard disks as the storage devices of the NVR with
high stability and competitive price/performance ratios (the quality of hard disks
sold on markets varies greatly with different brands and models).
Do not open the outer case of this product unless performed by a professional
person to avoid damage and electric shock.
We are not liable for any video data loss caused by improper installation,
configuration, operation, and hard disk errors.
1.2 About This User Manual
Please note the following points before using this user manual:
This user manual is intended for persons who operate and use the NVR.
The information in this user manual applies to the full series NVR
Read this user manual carefully before using the NVR and follow the methods
described in this manual when using the NVR.
If you have any doubts when using the NVR, contact your product seller.
In the case of product upgrade, the information in this document is subject to
change without notice.
1.3 Installation Environment and Precautions
Installation environment
Table 1-1 defines the installation environment of the NVR.
to the real produts.

Network Video Recorder
User Manual
Preface
2
Issue: V4.2 (2018-08-15)
Table 1-1 Installation environment
Item
Description
Electromagnetism
The NVR meets the national standards of electromagnetic
radiation and does not cause harm to the human body.
Temperature
–10oC to +45oC
Humidity
20% to 80%
Atmospheric pressure
86 Kpa to 106 Kpa
Power supply
48V 2A(1 HDD) or 220V 4A(2 HDDs or more)
Power consumption
<15W (excluding the hard disk)
Installation precautions
Note the following points when installing and operating the NVR:
The power adapter of the NVR uses 48V±20% input. Do not use the NVR when
voltage is too high or too low.
Install the NVR horizontally.
Avoid direct sunlight on the NVR and keep away from any heat sources and hot
environments.
Connect the NVR to other devices correctly during installation.
The NVR is not configured with any hard disk upon delivery. Install one or more
hard disks when using the NVR for the first time.
The NVR identifies hard disk capacity automatically and supports mainstream hard
disk models. You are advised to use good brands of hard disk so that the NVR can
operate stably and reliably.
Other precautions
Clean the NVR with a piece of soft and dry cloth. Do not use chemical solvents.
Do not place objects on the NVR.
The NVR meets the national standards of electromagnetic radiation and does not cause
electromagnetic radiation to the human body.

Basic Operations
Network Video Recorder
User Manual
Issue: V4.2 (2018-08-15)
3
2 Basic Operations
2.1 Power on the Device
Ensure that the NVR is correctly connected to a power supply, and a display is
correctly connected to the high definition multimedia interface (HD-OUT) or video
graphics array (VGA) port of the NVR before power-on.
In some environments, abnormal power supply may cause the failure of the NVR to
work properly and even damage the NVR in severe cases. It is recommended to use
a regulated power supply to power the NVR in such environments.
After the NVR is connected to a power supply, the power indicator is steadily on. Start
the NVR. The real-time video screen is displayed, as shown in Figure 2-1.
Figure 2-1 Real-time video screen

Network Video Recorder
User Manual
Basic Operations
4
Issue: V4.2 (2018-08-15)
Users need to provide a hard disk for the NVR. The hard disk is strictly detected during
device startup. If the detection result failed, the possible causes are as follows:
The hard disk is new and is not formatted. Log in to the system and format the hard disk.
The hard disk is formatted, but the file system is inconsistent with the file system
supported by the NVR. Format the hard disk.
The hard disk is damaged.
2.2 Power off the Device
Click the main menu and choose System > Maintenance, the maintenance page is
displayed. Click Shutdown to power off the NVR. You can choose quick main menu’s
shutdown. If there is a power switch on the real panel of the NVR, you can turn off the
power switch to disconnect the NVR from the power supply.
2.3 Log into the System
Log into the device
Step 1 On the NVR login screen, select the language, as shown in Figure 2-2.
Figure 2-2 Login screen
Step 2 Input the username and password.
The username and password are both admin.
If you forget password, click Forgot password. You can choose a way to find previous
password:

Basic Operations
Network Video Recorder
User Manual
Issue: V4.2 (2018-08-15)
5
1. Scan the QR code and send the QR code to your seller.
2. Click Send Password to your E-mail. Apassword retrieval email will be sent to your
email (for details, see 8.3 E-mail). Then you can retrieve password by following
operations described in the email.
Step 3 Modify the default password.
When you login the system for the first time, the screen is displayed, as shown in
Figure 2-3.
Figure 2-3 Modify the default password screen
Step 4 Input new password and confirm password.
Step 5 Click Modify password to access the main User Interface (UI).
----End
2.4 Add Cameras
After the PoE network interfaces are connected to IP cameras, the NVR automatically
adds the IP cameras.
Figure 2-4 shows the topology of NVR

Network Video Recorder
User Manual
Basic Operations
6
Issue: V4.2 (2018-08-15)
Figure 2-4 Network topology of the NVR
----End

Wizard
Network Video Recorder
User Manual
Issue: V4.2 (2018-08-15)
7
3 Wizard
Start wizard button is on the real-time video screen when you login the NVR, click Start
wizard button, the wizard screen is displayed, as shown in Figure 3-1.
Figure 3-1 Network setting wizard
Operation Steps
Step 1 Set the parameters according to Table 1-2.

Network Video Recorder
User Manual
Wizard
8
Issue: V4.2 (2018-08-15)
Table 1-2 NVR network parameters
Parameter
Description
Setting
Obtain IP address
automatically
The device automatically obtains
the IP address from the DHCP
server.
[Setting method]
Click the button on to
disableDHCP.
NOTE
To query the current IP
address of the device, you
must query it on the
platform based on the
device name.
DHCP IP
IP address that the DHCP server
assigned to the device.
N/A
IPAddress
Device IP address that can be set as
required.
[Setting method]
Enter a value manually.
[Default value]
192.0.0.64
Subnet Mask
Subnet mask of the network
adapter.
[Setting method]
Enter a value manually.
[Default value]
255.255.255.0
Gateway
This parameter must be set if the
client accesses the device through a
gateway.
[Setting method]
Enter a value manually.
[Default value]
192.0.0.1
Obtain DNS
automatically
The device automatically obtains
the DNS address from the DHCP
server.
[Setting method]
Click the button on to
enable Obtain DNS
automatically.
NOTE
To query the current DNS
address of the device, you
must query it on the
platform based on the
device name.
DNS1
IP address of a DNS server.
[Setting method]
Enter a value manually.
[Default value]
192.168.0.1

Wizard
Network Video Recorder
User Manual
Issue: V4.2 (2018-08-15)
9
DNS2
IP address of a domain server.
If the preferred DNS server is
faulty, the device uses the alternate
DNS server to resolve domain
names.
[Setting method]
Enter a value manually.
[Default value]
8.8.8.8
UPnP
The method of port mapping.
[Setting method]
Select a value from the
drop-down list.
[Default value]
Auto
Web Port
HTTP port
[Setting method]
When UPnP is auto, the
ports needn’t set.
When UPnP is manually,
Set the ports IP manually.
Data Port
-
Client Port
-
Step 2 Click Next, the basic parameters of NVR is displayed, as shown in Figure 3-2.
Figure 3-2 Date and time setting wizard

Network Video Recorder
User Manual
Wizard
10
Issue: V4.2 (2018-08-15)
1. Select a required date format from the Date Format drop-down list.
2. Click drop-down list next to 24 Hour to disable the 24-hour system. Then the 12-
hour system is enabled. If 24 Hour is set on, the 24-hour system is used and is
enabled by default.
3. Click next to NTP Sync to disable time synchronization. Time
synchronization is enabled by default. Time is synchronized with the PC time.
4. When NTP Sync is disabled, you can set the system time manually.
5. Click Date and scroll the mouse scroll wheel to select the year, month, and date.
6. Click Time and scroll the mouse scroll wheel to select the hour, minute, and
second.
7. Click Modify Time to save the time settings.
Step 3 Go time zone page, select a required time zone from the Time zone drop-down
list, as shown in Figure 3-3.
Figure 3-3 Time zone wizard
Step 4 Click next to DST to enable DST. And select start time, end time,
offset time from the drop-down list respectively, as shown in Figure 3-4.

Wizard
Network Video Recorder
User Manual
Issue: V4.2 (2018-08-15)
11
Figure 3-4 DST wizard
Step 5 Click Next, the camera setting screen is displayed, as shown in Figure 3-5.

Network Video Recorder
User Manual
Wizard
12
Issue: V4.2 (2018-08-15)
Figure 3-5 Camera setting wizard
The details about camera setting, please view chapter 5 Channel Management.
Step 6 Click Next, the disk management screen is displayed, as shown in Figure 3-6.

Wizard
Network Video Recorder
User Manual
Issue: V4.2 (2018-08-15)
13
Figure 3-6 Disk management screen
You can view the disk capacity, used capacity, SN, disk model and status of disks, and
format disk in disk management. Click Next, the resolution management screen is
displayed, as shown in Figure 3-7.

Network Video Recorder
User Manual
Wizard
14
Issue: V4.2 (2018-08-15)
Figure 3-7 Resolution management screen
Step 7 select an output resolution from the drop-down list.
Step 8 Click Finish to end the settings.
----End
