W Box Technologies HD2s User manual

2
Safety Instructions
S afety Instructions
This product has been manufactured to satisfy the international safety standards. Please read
all of safety and operating instructions before operating the product and keep this manual for
future reference. The information in this user manual is subject to change without notice.
MAINS POWER SUPPLY
AC 90~250V~, 50/60Hz.
Operate your product only from the type of power supply indicated on the marking label. If you
are not sure of the type of power supplied to your home, consult your local power company.
Disconnect the product from the mains before you start any maintenance or installation
procedures.
The mains plug is used as the disconnect device. The disconnect device shall remain readily
operable.
OVERLOADING
Do not overload a wall outlet, extension cord or adapter as this may result in electric shock or
re.
LIQUIDS
The product should not be exposed to any dripping or splashing liquids. No objects lled with
liquids, such as vases, should be placed on the device.
CLEANING
Before cleaning, disconnect the product from the wall outlet. Use a cloth lightly dampened with
water (no solvents) to clean the exterior.
VENTILATION
The slots on top of the product must be left uncovered to allow proper airow to the unit. Do not
place the product on soft furnishings or carpets. Do not expose the product to direct sunlight or
place it near a heater. Do not stack electronic equipment on top of the product.
ATTACHMENTS
Do not use any attachment that is not recommended by the manufacturer; it may cause a
hazard or damage the product.
CONNECTION TO THE TV
Disconnect the product from the mains before connecting or disconnecting the antenna cable.
Failure to do so can damage the TV.
LOCATION
Place the product indoors in order not to expose it to lightning, rain or sunlight.
Do not install the product near any heat sources such as radiators, heating devices, stoves, or
other apparatus (including ampliers) that produce heat.
DURING A LIGHTNING STORM, or WHEN NOT IN USE
Unplug the product from the wall outlet and disconnect the cable during a lightning storm or
when unused for a long time.
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 2 2012-03-22 �� 2:41:15

3
Safety Instructions
SERVICING
Do not attempt to service this product yourself, as opening or removing covers may expose you
to dangerous voltage or other hazard. Refer all servicing to qualied service personnel.
This item incorporates copy protection technology that is protected by U.S. patents
and other intellectual property rights of Rovi Corporation. Reverse engineering and
disassembly are prohibited.
※Do not pull out the mains plug during operation.
Please press “Power” button on your Remote control or unit to turn it off.
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 3 2012-03-22 �� 2:41:15

Contents
4
C ontents
Safety Instructions ................................ 2
Chapter 1
Before You Begin................................... 5
General Features................................. 5
Accessories.......................................... 5
Chapter 2
Controls and Functions ........................ 6
Front / Rear Panel................................ 6
Remote Control Unit ............................ 7
Chapter 3
Connections........................................... 9
Location of your receiver........................ 9
Connecting your receiver to TV.............. 9
Connecting digital audio system ............ 10
Connecting your analog receiver ........... 10
Chapter 4
First Time Installation and Basic
Operations.............................................. 11
First Time Installation ........................... 11
Basic Operation ................................... 12
Switching Channel ................................. 12
Volume Control....................................... 12
Event Information................................... 12
Viewing the Teletext ............................... 13
Selecting the Audio Track....................... 13
Selecting the Subtitle ............................. 13
Electronic Program Guide (EPG)........... 14
PVR Function....................................... 14
Instant Record........................................ 15
EPG Record........................................... 15
Playback................................................. 15
Chapter 5
Menu Map............................................... 16
Main Menu.............................................. 18
Favorites .............................................. 18
TV ........................................................ 19
TV Guide................................................ 19
Search.................................................... 19
Reminders.............................................. 19
TV List.................................................... 19
PVR...................................................... 20
Scheduled recordings ............................ 20
Ongoing recordings................................ 20
Completed recordings............................ 21
Failed recordings.................................... 21
Schedule manual recording ................... 21
Schedule keyword recording ................. 22
Edit a keyword recording........................ 22
Create new directory.............................. 22
Edit a directory ....................................... 23
Radio.................................................... 23
Radio List ............................................... 23
USB...................................................... 23
Parental control.................................... 24
Congure................................................ 24
Change PIN............................................ 24
Block channels....................................... 24
Conax................................................... 24
Conguration........................................ 25
Channel Installation................................ 25
Channel Status....................................... 26
A/V Output Settings................................ 26
Languages ............................................. 26
User Interface......................................... 27
System Settings ..................................... 27
System information ................................ 27
Troubleshooting ................................. 28
Specications ..................................... 30
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 4 2012-03-22 �� 2:41:15

Chapter 1 >> Before You Begin
5
B efore You Begin
General Features
• Supports DVB-C, DVB-T/T2
• MPEG-2 (MP@ML), MPEG-2 (MP@HL), MPEG4 AVC/H.264, HP@L4
• OSD Teletext supported
• EPG (Electronic Program Guide) for On-screen Channel Information
• Parental control function
• HDMI
• S/PDIF OUT OPTICAL
• 1 Smart card Reader
• Ethernet
• USB
Accessories
• User’s Manual
• Remote Control Unit
• Batteries (AAA)
• HDMI Cable
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 5 2012-03-22 �� 2:41:15

Chapter 2 >> Controls and Functions
6
DVB-C, DVB-T/T2
Connect to the cable antenna.
LOOP
Signal output. Connect to the antenna input
of another device, such as a TV.
Ethernet
Connect to the Ethernet with Ethernet cable.
USB
Connection for External HDD or USB
memorystick.
HDMI
Connects to the TV with HDMI cable.
AV
Connect to video/audio input jack on TV or
any external video/audio system.
S/PDIF OPTICAL
Connect to a digital audio component with
OPTICAL cable.
AC Adaptor
AC Adaptor INPUT.
Power LED
Display the power ON/OFF.
IR-receiver
IR Remote Control Receiver.
Smart Card Slot
Smart card shall be paired by informing
the CHIP-ID to your operator. You can nd
the CHIP-ID from CONAX and System
information menu. Insert the card with the
chip inwards and downwards.
C ontrols and Functions
Front / Rear Panel
※The image shown may differ from the actual product.
1 2
3
1 2
3
7
6
5
8
4
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 6 2012-03-22 �� 2:41:22

Chapter 2 >> Controls and Functions
7
Remote Control Unit
4
7
8
10
14
16
17
19
20
22
29
30
31
23
26
12
2
3
5
6
9
11
13
15
18
21
27
24
25
28
1
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 7 2012-03-22 �� 2:41:22

Chapter 2 >> Controls and Functions
8
Remote Control Unit
Power ( )
Turns your receiver On/Off.
Numeric (0~9)
Access channels directly via channel
number.
TV/Radio ( )
Switch between TV and Radio channels.
Last
Switch back to the previous channel.
Red
EPG: Move the EPG timeline one day
backwards.
Green
EPG: Move the EPG timeline to current time.
Yellow
EPG: Move the EPG timeline one day
forwards.
Blue
For future usage
EPG
Display the TV program guide.
VoD
For future usage.
OK
Select a menu or conrm selection.
Display the channel list menu when watching
TV.
Arrow (Up/Down/Left/Right)
Move the cursor up, down, left or right.
Turn volume up/down (Right/Left). Switch
channel up/down (Up/Down).
Back
Close a menu or go to the previous menu.
Option
Display more options when applicable.
Mute ( )
Mute audio output.
Menu
Display the main menu.
Info
Show channel and program information on
the screen.
REC ( )
Start recording a program.
EPG: Sets the selected program to be
recorded.
STOP ( )
Stop a recording or playback.
PVR
Display the PVR (Personal Video Recorder) menu.
REW ( )
Rewind the recorded program.
Play/Pause ( )
Play/Pause the live program or recording.
FF ( )
Fast forward the recorded program.
VOL +/-
Adjust the volume level.
Page ( / )
Move up or down pages on the menu and TV/
Radio List.
PR +/-
Change channel up or down.
Teletext ( )
Start teletext service.
Subtitle( )
Select subtitle languages.
Audio ( )
Select audio track languages.
Fav
Displays the favorites list selection menu.
F1~F4
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 8 2012-03-22 �� 2:41:23

Chapter 3 >> Connections
9
C onnections
Connecting your TV to the set-top box with an HDMI cable will ensure a more vivid picture
and enhance your viewing enjoyment.
Location of your receiver
• Install your receiver in a horizontal position.
• Do not put any heavy items such as a TV on your receiver.
• Do not install your receiver in the following places: vibrating places, places with direct sunlight,
humid places, places with too high or low temperature, and places with no ventilation.
Connecting your receiver to TV
To connect your receiver with your television, you can use 2 different methods: via AV or HDMI
cable.
1. HDMI
Connect the HDMI cable to the terminal marked “HDMI” on the rear panel of your receiver and
its other end to the HDMI input of your TV.
2. AV
Connect the DIN to SCART cable to the terminal marked “AV” on the rear panel of your receiver
and its other end to the SCART input of your TV.
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 9 2012-03-22 �� 2:41:24

Chapter 3 >> Connections
10
Connecting digital audio system
Connect an optical cable to the connector marked “S/PDIF” at the rear panel of your
receiver and its other end to the respective S/PDIF INPUT OPTICAL connector on the digital
audio system.
Connecting your analog receiver
Connect a coaxial cable from output terminal marked “LOOP” to the RF input terminal of your
analog receiver. Now by keeping your receiver in standby, you will be able to tune and view
analog channels from your analog receiver.
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 10 2012-03-22 �� 2:41:24

Chapter 4 >> First Time Installation and Basic Operations
11
F irst Time Installation and Basic Operations
First Time Installation
When starting up your receiver for the rst time, an initial setup of the receiver needs to be
performed before it is ready to be used.
1 Select your language (Finnish/Swedish/English).
2 Select tuner type (Cable/Terrestrial).
3 Select channel scanning type (Auto/Manual).
4 Select Go! and press the OK button to enter the selected
scanning menu.
5 Manual scanning: Adjust variable settings using the
Arrow (▲/▼/ ◄/►) and Numeric (0~9) buttons. Select
Start and press the OK button to start channels search. (If you selected Auto channel
scanning type, you don’t need to perform this step).
6 The results of the search are shown when the scanning has nished. Select Save and
press the OK button to save all found channels.
7 Press the Menu button to exit the scanning menu.
※To change the tuner type, please do Restore Factory Defaults.
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 11 2012-03-22 �� 2:41:24

Chapter 4 >> First Time Installation and Basic Operations
12
Basic Operation
This section explains various functions while watching TV or listening to the Radio.
Switching Channel
You can switch the current channel by three different methods.
Method 1) Press the Arrow (▲/▼) or PR+/- buttons.
Method 2) Press the Numeric (0~9) buttons to select a channel directly.
Method 3) Press the OK button to display the channel list. Select a channel you want to watch
using the Arrow (▲/▼) buttons. The list can be scrolled faster with the Arrow
(◄/►)buttons. Press the OK button to tune to a channel.
[Note] Press the Last button to return to the previous channel.
[Note] Press TV/Radio ( ) button to switch between TV and radio channels.
Volume Control
To control the volume:
• Press the VOL +/- or Arrow (◄/►) buttons.
• Press the Mute ( ) button to turn the sound off.
• Press the Mute ( ) button again or the VOL +/- buttons to cancel muting.
Event Information
Press the Info button to display a banner where you can nd
the following information.
name of the selected channel list
channel number / name
additional information about the program
current program title
next program title
current time / date
icons (widescreen, multichannel audio, lock, subtitles, high denition, audio tracks, teletext,
age rating)
If you press the Info button again, detailed program information will be displayed on the right
side. The banner and detailed information will disappear when you press the Info button for the
third time.
1
4
5
6
7
2
3
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 12 2012-03-22 �� 2:41:24

Chapter 4 >> First Time Installation and Basic Operations
13
Viewing the Teletext
To view the teletext service:
1 Press the Teletext ( ) button to display the teletext
service, if present.
2 Use Arrow (▲ / ▼) or Numeric (0~9) buttons to change
pages. Use Arrow (◄/►) buttons to navigate between
sub pages, if present.
3 To exit the teletext service, press Teletext ( ) button
again. The rst press will switch the Teletext transparent
mode. The second press will close the Teletext service.
Selecting the Audio Track
To select the audio track language:
1 Press the Audio ( ) button and then OK button to display
Audio Track pop-up menu.
2 Select audio track using the Arrow (▲/▼) buttons and
press the OK button to conrm your selection.
Selecting the Subtitle
To select the subtitle language:
1 Press the Subtitle ( ) button and then OK button to
display Subtitle Language pop-up menu.
2 Select subtitle language using the Arrow (▲/▼) buttons
and press the OK button to conrm your selection.
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 13 2012-03-22 �� 2:41:25

Chapter 4 >> First Time Installation and Basic Operations
14
Electronic Program Guide (EPG)
Electronic Program Guide displays program information such as channel number / name,
program titles, broadcasting schedule, and program synopsis.
※ EPG service may differ depending on the service provider.
1 Press EPG button to enter the Electronic Program Guide.
2 Select a program to view more information about it.
• Arrow (▲/▼) buttons: Move program focus up/down
on the program grid. In the one channel mode, move
program focus up/down on the program list.
• Arrow (◄/►) buttons: Move program focus left/right on
the timeline within the same channel. In the one channel
mode, changes the channel that is being viewed.
• Page ( / ) buttons: Move up/down the channel list (or program list in one channel mode)
one page at a time.
• Yellow button: Move the timeline one day forward.
• Green button: Move the timeline to current time.
• Red button: Move the timeline one day backward.
[Note] The timeline displays programs at one hour intervals. A light blue vertical line marks the
current time.
3 To change the EPG mode between program grid and list, press the EPG button again.
4 To use additional functions, press the Option or OK button. For recording related options,
refer to EPG Record on page 15.
(1) Switch to channel / Play: Change to the selected channel.
(2) Remind me: Set up a notication to remind you when the program is beginning.
(3) Show similar: Find similar programs in the EPG.
(4) More info: Display more information about the selected program on the right side of the
screen.
5 To exit from the EPG, press the Back button.
PVR Function
※Do not pull out the mains plug during recording/timeshift. It will cause damage to the external
hard drive and USB. Please press the “Power” button on your remote control to turn it off rst.
Connect an External HDD or USB storage to enable recording. An External HDD is
recommended over a USB ash drive. The recommended minimum storage capacity is 2 GB.
This device has one tuner. It can record two programs at the same time only if they are from the
same channel multiplex.
[Note] Encrypted recordings do not work if the smartcard is changed or not inserted.
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 14 2012-03-22 �� 2:41:25

Chapter 4 >> First Time Installation and Basic Operations
15
Instant Record
1 Press the Record ( ) button to start recording the current program instantly.
2 To stop a recording, press the the Stop ( ) button or the
Record ( ) button again. The list of ongoing recordings will
appear.
3 Select the recording channel and press the OK button.
Available functions:
(1) Stop: ongoing recording will stop.
(2) Play: play the ongoing recording.
(3) Cancel: close the menu.
EPG Record
1 Open EPG and select a program to be recorded using the Arrow (▲/▼/◄/►) buttons.
2 Press Option or OK button to view all recording options.
(1) Record: Set the selected program to be recorded.
(2) Record always: Opens a menu for creating a keyword recording for the selected
program. Recording can be set for all channels or a specic channel. Select Save to
save the keyword recording.
(3) Record repeatedly: Creates a new manual repeating recording for the selected program.
You can adjust the settings of the recording from the menu that is displayed. Available
settings are: Channel, Date, Start time, End time, Repeat (Disabled, Daily, Weekly,
Weekends, or Weekdays). Select save to save the recording.
Playback
The following buttons are usable in playback mode.
(1) Stop ( ): Stops playback.
(2) PVR: Return to the completed recordings list.
(3) REW ( ): Rewind the recorded program.
(4) Play/Pause ( ): Puts the recorded program on pause
or resumes playback.
(5) FF (): Fast forward the recorded program.
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 15 2012-03-22 �� 2:41:25

Chapter 5 >> Main Menu
16
M enu Map
Favorites HDTV
TV
Radio
TV TV Guide
Search
Reminders
PVR
Scheduled recordings
Ongoing recordings
Completed recordings
Failed recordings
Radio
USB
Parental control
Change PIN
Block channels
Conax
About Conax CA
Subscription Status
Event Status
Tokens Status
Messages
Maturity Rating
Change CA Pin
Channel Installation Automatic Channel Scanning
Manual Channel Scanning
Channel Status
A/V Output Settings TV Aspect Ratio
Display Format (SCART)
Display Format (HDMI)
Digital Audio
S/PDIF A/V Sync
Preferred Audio Track
SCART Signal Type
HDMI Video Format
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 16 2012-03-22 �� 2:41:25

Chapter 5 >> Main Menu
17
Languages Menu language
Primary Audio Language
Secondary Audio Language
Primary Subtitle Language
Secondary Subtitle Language
Hard of Hearing Subtitles
User Interface Instant Timeshift
Frontpanel Clock In Standby
PVR Start Margin
PVR End Margin
Autodelete Oldest Recordings
Default PVR Quota
Screensaver Timeout
OSD/Banner Display Time
System Settings Restart Device
Restore Factory Defaults
System Information IP Network
Software
Chip ID
Format Hard Disk(optional)
Use Cable Modem(optional)
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 17 2012-03-22 �� 2:41:26

Chapter 5 >> Main Menu
18
M ain Menu
This menu consists of 8 different menus:
• Favorites • TV
• PVR • Radio
• USB • Parental control
• Conax • Conguration
1Press the Menu button to enter the Menu mode. Menu will open at the last remembered state.
2Use the Arrow (▲/▼/◄/►) buttons to move up, down, left, and right on the menus.
3Navigate to the submenu you are looking for and press the OK button to conrm your choice.
4Use the Arrow (◄) button to return to the previous menu.
5To exit the current menu, press the Back button.
Favorites
Select Favorites using the Arrow (◄/►) buttons and press the Option button to open more
options.
(1) Add new list: Create a new favorites list.
(2) Remove list: Remove an existing list. Default lists
cannot be removed (HDTV, TV, Radio).
(3) Rename list: Rename an existing list.(max. 10 letters)
(4) Rearrange list: Rearrange channels on a list. When
done with rearranging, press the Arrow (►) button, and
then select Save and press the OK button to save your
changes.
(5) Add/remove channels: Add/remove channels on the selected list. When done with
adding/removing channels, press Arrow (►) button, and then select Save and press
the OK button to save your changes.
TV
TV Guide
1 Select TV Guide using the Arrow (▲/▼) buttons on the TV menu and press OK button.
2 TV guide will be displayed.
[Note] Please refer to pages 14 and 15 for instructions on how to use EPG and record
programs.
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 18 2012-03-22 �� 2:41:26

Chapter 5 >> Main Menu
19
Search
1 Select Search using the Arrow (▲/▼) buttons on the TV menu and press OK button to open
the Keypad.
2 Input a keyword using the Arrow (▲/▼/◄/►) and OK buttons. Then select enter and press
the OK button to start the search.
3 A list of matching programs will be displayed on the screen.
4 You can record programs directly from search results. Select a program using the Arrow
(▲/▼) buttons and then press the Option or OK button. Recording options are listed in
more detail in section EPG record on page 15.
Reminders
This menu lists all reminders.
1 Select Reminders using the Arrow (▲/▼) buttons on the
TV menu and press the OK button.
2 Reminders list is displayed.
3 Press the Option button on the reminders list to open more
options.
(1) Delete: Delete the selected reminder.
(2) Delete all: Delete all reminders.
TV List
This part of the menu lists all TV channels with current program information.
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 19 2012-03-22 �� 2:41:26

Chapter 5 >> Main Menu
20
PVR
Scheduled recordings
This menu lists recordings that have been scheduled and are waiting for the determined time or
program to come up.
1 Select Scheduled recordings using the Arrow (▲/▼) buttons on the PVR menu and press
the OK button the display the list of recordings.
2 Press the Option button on the scheduled recordings list to open more options.
(1) Edit: Displays an additional menu for changing details
of the scheduling (Channel, Date, Start time, End time,
Repeat). When done editing, select Save and press the
OK button to save the changes.
(2) Lock/Unlock: Locks or unlocks the selected recording.
Locked recordings cannot be deleted.
(3) Move: Move the selected recording to another folder.
(4) Delete le: Remove the scheduled recording.
(5) Delete all scheduled: Removes all scheduled recordings.
(6) More info: Display more information about the selected program.
Ongoing recordings
This menu lists recordings that are currently active and being recorded.
1 Select Ongoing recordings using the Arrow (▲/▼) buttons on the PVR menu and press
the OK button to display the list of recordings.
2 Press the Option button on the ongoing recordings list to
open more options.
(1) Continue: Resume watching an active recording.
(2) Play from the beginning: Play an active recording
from the beginning.
(3) Stop: Stop an active recording. This le can then be
found in Completed recordings.
(4) Edit: Displays an additional menu for changing details
of the scheduling (Channel, Date,Start time, End time, Repeat). When done editing,
select Save and press the OK button to save the changes.
(5) Lock/Unlock: Locks or unlocks the selected recording. Locked recordings cannot be
deleted.
(6) Move: Move the selected recording to another folder.
(7) Delete: Stop the selected recording and delete it.
(8) Delete all active: Stop and delete all ongoing recordings.
(9) More info: Display more information about the selected program.
M_180_DNA_HD-T63CX_ENG_120322_jte.indd 20 2012-03-22 �� 2:41:26
