Wachs Goliath Guillotine User manual

Goliath Guillotine Pipe Saw
User’s Manual
Copyright © 2007 E.H. Wachs Company. All rights reserved.
This manual may not be reproduced in whole or in part
without the written consent of E.H. Wachs Company.
E.H. Wachs Company
600 Knightsbridge Parkway
Lincolnshire, IL 60069
www.wachsco.com
E.H. Wachs Company Part No. 06-150-520-MAN
Rev. 0-0607, June 2007
Revision History:
Version 1 June 2007

Goliath Guillotine Pipe Saw
Part No. 06-150-520-MAN, Rev. 0-0607 E.H. Wachs Company

Table of Contents
Chapter 1: About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Purpose of This Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
How to Use The Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Symbols and Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Manual Updates and Revision Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Chapter 2: Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operator Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Safety Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Safety Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Machine Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Chapter 3: Introduction to the Goliath Guillotine . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Usage and Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Machine Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Operating Envelope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Chapter 4: Assembly, Disassembly, and Storage. . . . . . . . . . . . . . . . . . . . . . . . . 17
Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Long-Term Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Chapter 5: Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Lifting the Saw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Installing the Blade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Using the Autofeed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Mechanical Autofeed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Hydraulic Autofeed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Operating the Standard Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Connecting the Hoses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Clamping the Saw to the Workpiece . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Operating the Saw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Removing the Saw. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Operating the Machine with the Topside Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Connecting the Hoses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Connecting Hoses to the TCU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Connecting Hoses to the Goliath. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Clamping the Saw to the Workpiece . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Operating the Saw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Mechanical Autofeed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Hydraulic Autofeed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Removing the Saw. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Goliath Guillotine Pipe Saw
Part No. 06-150-520-MAN, Rev. 0-0607 E.H. Wachs Company
Chapter 6: Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Grease Points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Autoclamp Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Chapter 7: Service and Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Chapter 8: Parts List and Ordering Information. . . . . . . . . . . . . . . . . . . . . . . . . . 63
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Autofeed Drawing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Ordering Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Repair Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Return Goods Address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71

Chapter 1, About This Manual
E.H. Wachs Company Part No. 06-150-520-MAN, Rev. 0-0607 1
Chapter 1
About This Manual
PURPOSE OF THIS MANUAL
This manual explains how to operate and maintain the Goli-
ath Guillotine pipe saw. It includes instructions for set-up,
operation, and maintenance. It also contains parts lists and
diagrams, and troubleshooting instructions to help you
order replacement parts and perform user-serviceable
repairs.
Before operating the Goliath, you should read through this
manual and become familiar with all instructions. At a min-
imum, make sure you read and understand the following
chapters:
• Chapter 1, About This Manual
• Chapter 2, Safety
• Chapter 3, Introduction to the Goliath Guillotine
• Chapter 5, Operating Instructions
• Chapter 9, Accessories
If you will be performing service or repairs, make sure you
read and understand these chapters:
• Chapter 1, About This Manual
• Chapter 4, Assembly and Disassembly
• Chapter 6, Routine Maintenance
• Chapter 7, Troubleshooting and Repair.
In This Chapter
PURPOSE OF THIS MANUAL
HOW TO USE THE MANUAL
SYMBOLS AND WARNINGS
MANUAL UPDATES AND
REVISION TRACKING

Goliath Guillotine Pipe Saw
2 Part No. 06-150-520-MAN, Rev. 0-0607 E.H. Wachs Company
You will also want to refer to Chapter 8, Parts Lists and
Drawings.
HOW TO USE THE MANUAL
Throughoutthis manual,refer
to this column for warnings,
cautions, and notices with
supplementary information.
This manual is organized to help you quickly find the infor-
mation you need. Each chapter describes a specific topic on
using or maintaining the equipment.
Each page is designed with two columns. This large column
on the inside of the page contains instructions and illustra-
tions. Use these instructions to operate and maintain the
equipment.
The narrower column on the outside contains additional
information such as warnings, special notes, and definitions.
Refer to it for safety notes and other information.
SYMBOLS AND WARNINGS
The following symbols are used throughout this manual to
indicate special alerts and notes. They appear in the outside
column of the page, next to the section they refer to. Make
sure you understand what each symbol means, and follow
all instructions for cautions and warnings.
This is the safety alert symbol. It is used
to alert you to potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible
injury or death.
NOTE
This symbol indicates a user notice.
Notices provide additional information to
supplement the instructions, or tips for
easier operation.

Chapter 1, About This Manual: Manual Updates and Revision Tracking
E.H. Wachs Company Part No. 06-150-520-MAN, Rev. 0-0607 3
MANUAL UPDATES AND REVISION TRACKING
Current versions of E.H.
Wachs Company manuals
are also available in PDF for-
mat. You can request an
electroniccopy ofthismanual
by emailing customer service
at [email protected]m.
Occasionally, we will update manuals with improved opera-
tion or maintenance procedures, or with corrections if nec-
essary. Revised chapters will be available for customers. If
you receive revised chapters for your manual, remove the
old chapters from your binder and replace them with the
new chapters.
When a manual is revised, we will update the revision his-
tory on the title page and at the bottom of the pages in the
revised chapters. It is important to put the current title page
with the revision history in your manual. This will help you
make sure you have all current information.
You may have factory service or upgrades performed on the
equipment. If this service changes any technical data or
operation and maintenance procedures, we will include
revised sections of the manual when we return the equip-
ment to you. Remove the old chapters from your manual
and replace them with the revised chapters.

Goliath Guillotine Pipe Saw
4 Part No. 06-150-520-MAN, Rev. 0-0607 E.H. Wachs Company

Chapter 2, Safety
E.H. Wachs Company Part No. 06-150-520-MAN, Rev. 0-0607 5
Chapter 2
Safety
The E.H. Wachs Company takes great pride in designing
and manufacturing safe, high-quality products. We make
user safety a top priority in the design of all our products.
WARNING
Read this chapter carefully before operating your Goliath
Guillotine pipe saw. Serious injury or death could result
from improper operation or repair of this equipment.
Repair and/or service to this equipment must only be done
by an authorized and certified dealer.
OPERATOR SAFETY
Follow these guidelines for safe operation of the equipment.
Look for this sym-
bol throughout the
manual.Itindicates
a personal injury
hazard.
•READ THE OPERATING MANUAL. Make sure you
understand all setup and operating instructions before
you begin.
•INSPECT MACHINE AND ACCESSORIES. Before
starting the machine, look for loose bolts or nuts, leak-
ing lubricant, rusted components, and any other physical
conditions that may affect operation. Properly maintain-
ing the machine can greatly decrease the chances for
injury.
•ALWAYS READ PLACARDS AND LABELS. Make
sure all placards, labels, and stickers are clearly legible
In This Chapter
OPERATOR SAFETY
SAFETY LABELS
MACHINE SAFETY

Goliath Guillotine Pipe Saw
6 Part No. 06-150-520-MAN, Rev. 0-0607 E.H. Wachs Company
and in good condition. You can purchase replacement
labels from E.H. Wachs Company.
•KEEP CLEAR OF MOVING PARTS. Keep hands,
arms, and fingers clear of all rotating or moving parts.
Always turn machine off before doing any adjustments
or service.
•SECURE LOOSE CLOTHING AND JEWELRY.
Secure or remove loose-fitting clothing and jewelry, and
securely bind long hair, to prevent them from getting
caught in moving parts of the machine.
•KEEP WORK AREA CLEAR. Keep all clutter and
nonessential materials out of the work area. Only people
directly involved with the work being performed should
have access to the area.
Safety Symbols
This icon is displayed with any safety alert that indicates a
personal injury hazard.
WARNING
This safety alert indicates a potentially hazardous situation
that, if not avoided, could result in death or serious injury.
CAUTION
This safety alert, with the personal injury hazard symbol,
indicates a potentially hazardous situation that, if not
avoided, could result in minor or moderate injury.
NOTICE
This alert indicates a situation that, if not avoided, will
result in damage to the equipment.
IMPORTANT
This alert indicates a situation that, if not avoided, may
result in damage to the equipment.

Chapter 2, Safety: Safety Labels
E.H. Wachs Company Part No. 06-150-520-MAN, Rev. 0-0607 7
SAFETY LABELS
There are two safety labels on the Goliath Guillotine saw.
These are illustrated in Figure 2-1 and Figure 2-2.
Figure 2-1. Observe the warning label for moving
parts hazards.
Figure 2-2. Observe the warning label for blade haz-
ard.
MACHINE SAFETY
NOTICE
Failure to follow the instruc-
tions for machine safety
could result in damage to the
equipment.
Observe the following guidelines for reliable machine oper-
ation and care.
• Make sure all hydraulic couplers are wiped clean before
connection.
• Make sure all pressure and return hoses are connected to
the correct couplings.

Goliath Guillotine Pipe Saw
8 Part No. 06-150-520-MAN, Rev. 0-0607 E.H. Wachs Company
• Always replace blades, hydraulic components, and other
parts with replacement parts recommended by the E.H.
Wachs Company.
• Keep the machine lubricated according to the instruc-
tions in Chapter 6.
• Make sure the blade is tight before cutting.
• Do not exceed the rated hydraulic flow (see Specifica-
tions in Chapter 3).
• Always keep critical tool markings, such as warning
stickers and tags, legible.
• Do not use the saw for applications for which it is not
intended.
• Service and repair should be performed by experienced
personnel only.

Chapter 3, Introduction to the Goliath
E.H. Wachs Company Part No. 06-150-520-MAN, Rev. 0-0607 9
Chapter 3
Introduction to the
Goliath Guillotine
Read this chapter carefully to become familiar with the
components and features of your Goliath Guillotine pipe
saw.
USAGE AND APPLICATIONS
The Goliath Guillotine is designed to cold-cut pipes, solids,
and multi-stranded casing strings from 16” to 32” (41 to 81
cm) in diameter. The Goliath is easy to set up, even sub-sea,
and is available with an autoclamp option and topside con-
trols for remote operation.
The Goliath Guillotine operates on hydraulic power, with
two heavy-duty hydraulic motors requiring a power source
with 15 gpm flow at 1500 psi (standard) or 15 gpm @ 2000
psi (autoclamp).
Figure 3-1 illustrates the components of the standard Goli-
ath Guillotine. Figure 3-2 shows the saw with the optional
autoclamp. The autoclamp arm closes under hydraulic
power and holds the pipe in the pipe saddle during cutting.
In This Chapter
USAGE AND APPLICATIONS
MACHINE CONTROL
SPECIFICATIONS
OPERATING ENVELOPE
ACCESSORIES

Goliath Guillotine Pipe Saw
10 Part No. 06-150-520-MAN, Rev. 0-0607 E.H. Wachs Company
Figure 3-1. Components of the standard Goliath Guil-
lotine are illustrated.
Figure 3-2. Goliath with autoclamp accessory.
Feed handle Pipe saddle Clamping chain
Blade tensionerSaw bow
Chain tension nut
Lift hooks
Lift
hooks Coolant nozzle
Autoclamp arm

Chapter 3, Introduction to the Goliath: Machine Control
E.H. Wachs Company Part No. 06-150-520-MAN, Rev. 0-0607 11
MACHINE CONTROL
The topside control unit (TCU) provides remote controls for
up to three hydraulic drives. On the Goliath Guillotine, one
drive controls the saw motion, and two are used for options:
the autoclamp mechanism and the hydraulic autofeed.
Instructions for operating the saw using the TCU are in
Chapter 5.
Figure 3-3. The topside control unit (TCU) has con-
trols for the cutting and optional clamping and feed
drives on the Goliath Guillotine. It has inputs for
hydraulic power and separate outputs and controls for
up to three drives.
For use with the TCU, the Goliath is fitted with a hydraulic
connector bulkhead, as shown in Figure 3-4 and Figure 3-5.

Goliath Guillotine Pipe Saw
12 Part No. 06-150-520-MAN, Rev. 0-0607 E.H. Wachs Company
Figure 3-4. A hydraulic fitting bulkhead on the Goli-
ath Guillotine has connectors for operating the auto-
clamp and cutting drives remotely from the TCU.
Figure 3-5. For Goliath Guillotines with hydraulic
autofeed, the hydraulic fitting bulkhead has connec-
tors for three drives.

Chapter 3, Introduction to the Goliath: Specifications
E.H. Wachs Company Part No. 06-150-520-MAN, Rev. 0-0607 13
SPECIFICATIONS
Capacity 16-32” (41-82 cm) diameter pipe
Hydraulic Standard: 15 gpm @ 1500 psi
requirements (57 l/m @ 103 bar)
Autoclamp: 15 gpm @ 2000 psi
(57 l/m @ 138 bar)
Feed system Manual or mechanical autofeed
(selectable by operator)
Autofeed rate Low speed: 0.008” (0.020 cm)
(per cycle) High speed: 0.016” (0.041 cm)
Dimensions Length: 76.5” (194 cm)
(standard) Width: 66” (168 cm)
Height: 25” (63.5 cm)
Dimensions Length: 82.5” (210 cm)
(with autoclamp) Width: 78” (198 cm)
Height: 25.9” (65.8 cm)
Weight Standard: 1800 lbs (818 kg)
Autoclamp: 2100 lbs (955 kg)
Finish Painted cast surfaces; chrome-plated rods;
other components zinc-nickel iridescent
chromated.
OPERATING ENVELOPE
The drawing in Figure 3-6 shows the operating envelope for
the Goliath Guillotine saw.

Goliath Guillotine Pipe Saw
14 Part No. 06-150-520-MAN, Rev. 0-0607 E.H. Wachs Company
Figure 3-6. The drawing shows the operating enve-
lope for the Goliath.

Chapter 3, Introduction to the Goliath: Accessories
E.H. Wachs Company Part No. 06-150-520-MAN, Rev. 0-0607 15
ACCESSORIES
• Auto-clamp mechanism for easy, remote set-up and
operation.
• Remote control system with topside control unit (TCU)
and hose reel.
• Machine-mounted control panel with hose connector
bulkhead and control levers.
• Hydraulic autofeed drive (controlled using the TCU).

Goliath Guillotine Pipe Saw
16 Part No. 06-150-520-MAN, Rev. 0-0607 E.H. Wachs Company
