Wacker Neuson BFS 1318AS User manual

CONCRETE SAW
BFS Series
Rev. 02/07
www.wackergroup.com
www.wackergroup.com
Floor Saw
BFS 1318AS
BFS 2002AS
OPERATOR’S MANUAL
0162594en 001
0207
0162594EN
www.wackergroup.com
Floor Saw
BFS 1318AS
BFS 2002AS
OPERATOR’S MANUAL
0162594en 001
0207
0162594EN

2Revision 03/05/07BFS SERIES
PAGE INTENTIONALLY LEFT BLANK

3
Revision 03/05/07 BFS SERIES
Table of Contents
1. Foreword.....................................................................................................................3
2. Safety Information......................................................................................................4
2.1 Operating Safety........................................................................................5
2.2 Operator Safety while using Internal Combustion Engines....................... 6
2.3 Service Safety...........................................................................................7
2.4 Hazard Symbols........................................................................................8
2.5 Damage Prevention Messages..................................................................9
2.6 Safety Labels.............................................................................................9
3. Saw Features............................................................................................................10
3.1 Blade Drive System.................................................................................10
3.2 Depth Indicator.........................................................................................10
3.3 Tach / Hourmeter.....................................................................................11
3.4 Water System..........................................................................................11
3.5 Saw Dimensions......................................................................................11
4. Unpacking, Assembly and Preparation.................................................................12
4.1 Initial Servicing.........................................................................................12
4.2 Engine Preparation..................................................................................12
4.3 Battery Preparation..................................................................................13
4.4 Hydrostatic Transmission.........................................................................13
4.5 Mounting the Blade.................................................................................14
4.6 Front Pointer Alignment...........................................................................14
5. Saw Operations........................................................................................................15
5.1 Description of Controls......................................................... ...................15
5.2 Description of Controls......................................................... ...................16
5.3 Operation in Enclosed Areas...................................................................16
5.4 Engine Starting Procedures.....................................................................16
5.5 Maneuvering the Saw..............................................................................17

4Revision 03/05/07BFS SERIES
Table of Contents
5.6 Wet Cutting..............................................................................................18
5.7 Dry Cutting...............................................................................................18
5.8 Aligning the Saw with a Marked Line.......................................................19
5.9 Starting a Cut...........................................................................................19
5.10 Sawing a Straight Line.............................................................................20
5.11 Finishing a Cut.........................................................................................20
5.12 Cutting with the Blade on the Left Side....................................................21
5.13 Blade Speed and Throttle Setting............................................................21
6. Maintenance.............................................................................................................22
6.1 Cleaning.................................................................................................. 23
6.2 Engine Maintenance................................................................................23
6.3 Grease Points..........................................................................................23
6.4 Controls...................................................................................................24
6.5 Hydrostatic Transmission........................................................................24
6.6 Drive Chain..............................................................................................24
6.7 Friction Drive Wheels Adjustment............................................................24
6.8 Neutral Adjustment..................................................................................24
6.9 V-Belts.....................................................................................................25
6.10 Electrical System.....................................................................................26
6.11 Battery.....................................................................................................26
6.12 Depth Control...........................................................................................26
6.13 Water System..........................................................................................26
7. Troubleshooting.......................................................................................................27
8. Service Record.........................................................................................................28

5
Revision 03/05/07 BFS SERIES
CALIFORNIA
Proposition 65 Warning:
Engine exhaust, some of its constituents, and certain vehicle
components contain or emit chemicals known to the State of
California to cause cancer and birth defects or other reproductive
harm.
1. Foreword
This manual provides information and procedures to safely operate
and maintain this Wacker model. For your own safety and protection
from injury, carefully read, understand and observe the safety
instructions described in this manual.
Keep this manual or a copy of it with the machine. If you lose this
manual or need an additional copy, please contact Wacker
Corporation. This machine is built with user safety in mind; however,
it can present hazards if improperly operated and serviced. Follow
operating instructions carefully! If you have questions about operating
or servicing this equipment, please contact Wacker Corporation.
The information contained in this manual was based on machines in
production at the time of publication. Wacker Corporation reserves
the right to change any portion of this information without notice.
All rights, especially copying and distribution rights, are reserved.
Copyright 2007 by Wacker Corporation.
No part of this publication may be reproduced in any form or by any
means, electronic or mechanical, including photocopying, without
express written permission from Wacker Corporation.
Any type of reproduction or distribution not authorized by Wacker
Corporation represents an infringement of valid copyrights and will be
prosecuted. We expressly reserve the right to make technical
modifications, even without due notice, which aim at improving our
machines or their safety standards.
WARNING

6Revision 03/05/07BFS SERIES
Safety Information
2. Safety Information
This manual contains DANGER, WARNING, CAUTION, NOTICE and
NOTE callouts which must be followed to reduce the possibility of personal
injury, damage to the equipment, or improper service.
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
NOTICE: Used without the safety alert symbol, NOTICE indicates a
hazardous situation which, if not avoided, could result in property
damage.
Note: Contains additional information important to a procedure.
WARNING
DANGER
CAUTION

7
Revision 03/05/07 BFS SERIES
Safety Information
2.1 Operating Safety
Familiarity and proper training are required for the safe operation of
equipment! Equipment operated improperly or by untrained personnel
can be dangerous! Read the operating instructions contained in both
this manual and the engine manual and familiarize yourself with the
location and proper use of all controls. Inexperienced operators
should receive instruction from someone familiar with the equipment
before being allowed to operate the machine.
NEVER operate this machine in applications for which it is not
intended.
NEVER allow anyone to operate this equipment without proper
training. People operating this equipment must be familiar with the
risks and hazards associated with it.
NEVER touch the engine or muffler while the engine is on or
immediately after it has been turned off. These areas get hot and
may cause burns.
NEVER use accessories or attachments that are not recommended
by Wacker. Damage to equipment and injury to the user may result.
NEVER leave machine running unattended.
NEVER tamper with or disable the function of operating controls.
NEVER use choke to stop engine.
NEVER operate the machine in areas where explosions may occur.
ALWAYS read, understand, and follow procedures in Operator’s
Manual before attempting to operate equipment.
ALWAYS be sure that all other persons are at a safe distance from
the machine. Stop the machine if people step into the working area
of the machine.
ALWAYS be sure operator is familiar with proper safety precautions
and operation techniques before using machine.
ALWAYS wear protective clothing appropriate to the job site when
operating equipment.
ALWAYS wear hearing protection when operating equipment.
ALWAYS keep hands, feet, and loose clothing away from moving
parts of the machine.
ALWAYS use common sense and caution when operating the
machine.
ALWAYS be sure the saw will not tip over, roll, slide, or fall when
not being operated.
ALWAYS turn the engine OFF when the saw is not being operated.
WARNING
2.1.1
2.1.2
2.1.3
2.1.4
2.1.5
2.1.6
2.1.7
2.1.8
2.1.9
2.1.10
2.1.11
2.1.12
2.1.13
2.1.14
2.1.15
2.1.16
2.1.17

8Revision 03/05/07BFS SERIES
Safety Information
ALWAYS guide the saw in such a way that the operator is not
squeezed between the saw and solid objects. Special care is
required when working on uneven ground or when compacting
coarse material. Make sure to stand firmly when operating the
machine under such conditions.
ALWAYS operate the saw in such a way that there is no danger
of it turning over or falling in, when working near the edges of breaks,
pits, slopes, trenches and platforms.
ALWAYS store equipment properly when it is not being used.
Equipment should be stored in a clean, dry location out of the reach
of children.
ALWAYS close fuel valve on engines equipped with one when
machine is not being operated.
ALWAYS operate machine with all safety devices and guards in place
and in working order. DO NOT modify or defeat safety devices. DO
NOT operate machine if any safety devices or guards are missing or
inoperative.
2.2 Operator Safety while using Internal Combustion Engines
Internal combustion engines present special hazards during
operation and fueling! Read and follow warning instructions in engine
owner’s manual and safety guidelines below. Failure to follow
warnings and safety guidelines could result in severe injury or death.
DO NOT smoke while operating machine.
DO NOT smoke when refueling engine.
DO NOT refuel hot or running engine.
DO NOT refuel engine near open flame.
DO NOT spill fuel when refueling engine.
DO NOT run engine near open flames.
DO NOT run machine indoors or in an enclosed area such as an
enclosed room unless adequate ventilation, through such items as
exhaust fans or hoses, is provided. Exhaust gas from the engine
contains poisonous carbon monoxide gas; exposure to carbon
monoxide can cause loss of consciousness and may lead to death.
ALWAYS refill fuel tank in well-ventilated area.
ALWAYS replace fuel tank cap after refueling.
ALWAYS check fuel lines and fuel tank for leaks and cracks before
starting engine. Do not run machine if fuel leaks are present or fuel
lines are loose.
2.1.18
2.1.19
2.1.20
2.1.21
2.1.22
DANGER
2.2.1
2.2.2
2.2.3
2.2.4
2.2.5
2.2.6
2.2.7
2.2.8
2.2.9
2.2.10

9
Revision 03/05/07 BFS SERIES
Safety Information
2.3 Service Safety
Poorly maintained equipment can become a safety hazard! In order
for the equipment to operate safely and properly over a long period of
time, periodic maintenance and occasional repairs are necessary.
DO NOT attempt to clean or service machine while it is running.
Rotating parts can cause severe injury.
DO NOT operate machine without air cleaner.
DO NOT remove air cleaner cover, paper element, or precleaner
while engine is running.
DO NOT alter engine speeds. Run the engine only at speeds
specified in the Technical Data Section.
DO NOT crank a flooded engine with the spark plug removed on
gasoline-powered engines. Fuel trapped in the cylinder will squirt out
the spark plug opening.
DO NOT test for spark on gasoline-powered engines, if engine is
flooded or the smell of gasoline is present. A stray spark could ignite
fumes.
DO NOT use gasoline or other types of fuels or flammable solvents
to clean parts, especially in enclosed areas. Fumes from fuels and
solvents can become explosive.
ALWAYS replace safety devices and guards after repairs and
maintenance.
ALWAYS keep area around muffler free of debris such as leaves,
paper, cartons, etc. A hot muffler could ignite them, starting a fire.
ALWAYS do Periodic Maintenance as recommended in Operator’s
Manual.
ALWAYS clean debris from engine cooling fins.
ALWAYS replace worn or damaged components with spare parts
designed and recommended by Wacker.
ALWAYS disconnect spark plug on machines equipped with gasoline
engines, before servicing, to avoid accidental start-up.
ALWAYS keep machine clean and labels legible. Replace all missing
and hard-to-read labels. Labels provide important operating
instructions and warn of dangers and hazards.
ALWAYS follow instructions when disconnecting fuel lines. Failure to
do so may result in fuel squirting from fuel system.
2.3.1
2.3.2
2.3.3
2.3.4
2.3.5
2.3.6
2.3.7
2.3.8
2.3.9
2.3.10
2.3.11
2.3.12
2.3.13
2.3.14
2.3.15
WARNING

10 Revision 03/05/07BFS SERIES
Safety Information
2.4 Hazard Symbols
Symbol Meaning
EXPLOSIVE FUEL
Gasoline is extremely flammable and its vapors can explode if ignited.
Store gasoline only in approved containers, in well-ventilated, unoccupied
buildings, away from sparks or flames. Do not fill the fuel tank while the
engine is hot or running, since spilled fuel could ignite if it comes in contact
with hot parts or sparks from ignition. Do not start the engine near spilled
fuel. Never use gasoline as a cleaning agent.
HOT PARTS
Engine components can get extremely hot from operation. To prevent severe
burns, do not touch these areas while the engine is running or immediately
after it is turned off. Never operate the engine with heat shields or guards
removed.
OVER SPEED
Never tamper with the governor components or settings to increase the
maximum speed. Severe personal injury and damage to the engine or
equipment can result if operated at speeds above maximum.
ACCIDENTAL STARTS
Before servicing the engine or equipment, always remove the key and
disconnect the spark plug lead to prevent the engine from starting
accidentally. Ground the lead to prevent sparks that could cause fires. Make
sure the equipment is in neutral.
ROTATING PARTS
Keep hands, feet, hair, and clothing away from all moving parts to prevent
injury. Never operate the engine with covers, shrouds, or guards removed.
LETHAL EXHAUST GASES
Engine exhaust gases contain poisonous carbon monoxide. Carbon
monoxide is odorless, colorless, and can cause death if inhaled. Avoid
inhaling exhaust fumes, and never run the engine in a closed building or
confined area.
ELECTRICAL SHOCK
Never touch electrical wires or components while the engine is running. They
can be sources of electrical shock which could cause severe injury or burns.
((
))
on
((
))
on
