Waeco CF-1 User manual

M_81003
CF-18,CF-25,CF-35, CF-40,
CF-50, CF-50DZ, CF-60
AUS Compressor Cooler Instruction Manual
CF-40 AC
CF-50 AC
CF-50 ACDZ
CF-60 AC
CF-25
CF-18
CF-35 AC
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 1

3
CoolFreeze
Please read this operating manual carefully before starting the device.
Keep it in a safe place for future reference. If the device is handed over to
another person, this operating manual must be handed over along with the
device.
Contents
1 Notes on using the manual ...................................................... 7
2 Safety instructions ........................................................................ 7
2.1 General safety ................................................................................ 8
2.2 Operating the device safely .......................................................... 9
3 Scope of delivery ........................................................................... 10
4 Intended use .................................................................................... 10
5 Function description ..................................................................... 11
5.1 Operating and display elements ................................................... 12
5.2 Accessories ...................................................................................... 14
6 Operation ........................................................................................... 14
6.1 Before initial use ............................................................................ 14
6.2 Energy saving tips .......................................................................... 15
6.3 Connecting the cooler .................................................................... 16
6.4 Using the battery monitor ............................................................. 17
6.5 Using the cooler ............................................................................. 18
6.6 Setting the temperature ................................................................ 19
6.7 Using the Emergency Switch ......................................................... 20
6.8 Switching off the cooler ................................................................. 20
6.9 Defrosting the cooler ...................................................................... 20
6.10 Replacing the device fuse (240V) ................................................. 21
6.11 Replacing the plug fuse (12/24 V) ............................................... 21
6.12 Replacing the light bulb ................................................................. 22
7 Cleaning and maintenance ........................................................22
8 Warranty ........................................................................................... 22
9 Troubleshooting ...............................................................................23
10 Disposal ............................................................................................... 24
11 Technical data .................................................................................. 24
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 3

4
CoolFreeze
1
4
2
3
1
12/24V DC
COLD FREEZE
ERROR
POWER
HIGH
0
LOW
TEMPERATURE BATTERY MONITOR
1 2 3 4
5
1
2
3
CF-25, CF-35, CF-40,
CF-18
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 4

5
CoolFreeze
ON
OFF
SET
POWER
UP
+
DOWN
–
ERROR
°
1 3 4 5 6 72
1
21
4
7
12/24V DC
14
5
CF-25, CF-35, CF-40, CF-50, CF-60
CF-35, CF-40, CF-50, CF-60
CF-25
CF-35, CF-40, CF-50, CF-60
100-240V~AC
FUSE
EMERGENCY OVERRIDE
NORMAL USE
12
12/24V DC
34
6
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 5

6
CoolFreeze
8
1 2 3
4
5
6
9
1 2
10
CF-50, CF-60
AB
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 6

7
CoolFreezeNotes on using the manual
1 Notes on using the manual
The following symbols are used in this operating manual:
Caution!
Safety instruction: Failure to observe this instruction can cause personal
injury or damage the device.
Caution!
Safety instruction: relating to a danger from an electrical current or
voltage. Failure to observe this instruction can cause injury or damage
the device and impair its function.
Note:
Supplementary information for operating the device.
➤Action: This symbol indicates that action is required on your part.
The required action is described step-by-step.
✔This symbol indicates the result of an action.
Fig. 21, page 3: This refers to an element in an illustration. In this
case, item 1 in figure 2on page 3.
Please observe the following safety instructions.
2 Safety instructions
• Caution!
WAECO International will not be held liable for claims for damage
resulting from the following:
– Damage to the device resulting from mechanical influences and
overvoltage
– Alterations to the device made without the explicit permission of
WAECO International
– Use for purposes other than those described in the operating manual.
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 7

8
CoolFreeze Safety Instructions
2.1 General safety
•Caution – Danger of electrocution!
– When using the device on boats: If the device is powered by the
mains, ensure that the power supply is protected with a ground
fault interrupter circuit.
•Check that the voltage specification on the type plate corresponds to
that of the energy supply.
•Only connect the device as follows:
– With the cable supplied (Fig. 1 2, page 4) to the cigarette lighter
in the vehicle or to a 12/24 V plug socket in the vehicle
– or with the enclosed connection cable (Fig. 13, page 4) to the
100-240 V AC mains (only CF-35, CF-40, CF-50, CF-60).
•If the connection cable is damaged, it must be replaced to prevent
possible electrical hazards.
•Do not pull the plug out of the cigarette lighter or the socket by the
cable.
•Pull out the connection cable:
– Before cleaning and maintenance
– After use
– Before changing a fuse
•Disconnect the cooling device and other power consuming devices
from the battery before you connect the battery to a quick charging
device. Overvoltage can damage the electronics of the device.
•Electronic devices are not toys!
Always keep and use the device out of the reach of children.
•Do not operate the device if it is visibly damaged.
•This device may only be repaired by qualified personnel. Inadequate
repairs can lead to considerable hazards.
•Should your device need to be repaired, please contact WAECO
customer service.
•Do not open the refrigerant circuit under any circumstances!
•The cooler is not suitable for transporting caustic materials or
materials containing solvents.
•Food may only be stored in its original packaging or in suitable
containers.
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 8

9
CoolFreeze
Intended use
2.2 Operating the device safely
•Caution – Danger of electrocution!
Do not touch exposed cables with your bare hands. This especially
applies when operating the device from an AC mains.
•Before starting the device, ensure that the power supply line and the
plug are dry.
•Do not place any electrical devices inside the cooler.
•Set up the device in a dry location where it is protected against
splashing water.
•Protect the device and the cable against rain and moisture.
•Do not place the device near naked flames or other heat sources
(heaters, direct sunlight, gas ovens etc.)
•Caution! Danger of overheating!
Ensure at all times that there is sufficient ventilation so that the heat
generated during normal operation is able to dissipate. Ensure that
the ventilation slots are not covered. Make sure that the device is
sufficiently far away from walls and other objects so that the air can
circulate.
•Never immerse the device in water.
•Do not fill the inner container with ice or fluid.
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 9

10
CoolFreeze Function description
3 Scope of delivery
Fig. 1page 4, shows the scope of delivery.
Item Quantity Description
1 1 Cooler
2 1 Connection cable for 12/24 VDC connection
31
(except CF-18, CF-25) Connection cable for 100 – 240 VAC connection
42(except CF-18, CF-25) Carrying handle, consisting of:
– 2 holders
– 1 handle
– 4 fastening screws
–1
(CF-18 only) Plastic grille divider
–1
(CF-35 only) Powdercoated steel evap. protector
–1(except CF-18, Powdercoated steel basket
CF-25, CF-50DZ)
–2(CF-50DZ only) Powdercoated steel basket
–2
(CF-50DZ only) Internal compartment divider (plastic)
– 1 Operating manual
4 Intended use
The cooler is suitable for cooling and freezing foods. The device is also
suitable for use on boats.
The device is designed to be operated from a 12 VDC or 24 VDC on-
board supply socket of a vehicle (e. g. cigarette lighter), boat or caravan
as well as from a 100 – 240 V AC mains (for CF-18 and CF-25 an
optional accessory adaptor is required for connection to AC mains
power).
Caution – When cooling perishable medicines!
If you wish to cool medicines, please check if the cooling capacity of the
device is adequate for this purpose.
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 10

11
CoolFreeze
Operation
5 Function description
The cooler can chill products, keep them cool as well as freeze them. A
low maintenance, CFC-free refrigerant circuit with compressor provides
the cooling. The extra strong CFC-free insulation and powerful
compressor ensure especially fast cooling.
The cooler is designed for mobile use and can be carried by using a
folding carrying bracket (CF-18), two recessed grips (CF-25) or two
removable carrying handles (CF-35, CF-40, CF-50, CF-60).
When used on boats, the cooler can withstand a constant heel
(inclination) of 30˚.
Scope of functions:
CF-18 CF-25 CF-35, CF-40,
CF-50*, CF-60
Power supply with
priority circuit for –– •
connecting to the
AC mains
Battery monitor for
protecting the vehicle 2-level 3-level
battery
Turbo mode for rapid
cooling
Display with temperature
gauge
Temperature setting With
rotary With two buttons in steps of 1 ˚C (2 ˚F)
control
Removable carrying handles
*Note: unless otherwise stated, throughout this manual CF-50 refers to
both CF-50 AC and CF-50 ACDZ.
•
–••
–••
–– •
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 11

12
CoolFreeze Operation
5.1 Operating and display elements
CF-25, CF-35, CF-40
Lock for lid: Fig. 21, page 4.
CF-18
Operating panel and connection socket (Fig. 3page 4):
Item Description Explanation
1 TEMPERATURE Temperature controller,
cooling temperature at the end positions:
COLD: +10 ˚C (+50 ˚F)
FREEZE: –18 ˚C (0 ˚F)
2 POWER Operating display
LED is lit green: Device is switched on
and ready for operation
LED is lit amber: Set temperature has
been reached
3 ERROR LED flashes red: Switched on device
is not ready for operation
4 BATTERY Switch-on device/battery monitor:
MONITOR 0: Device is switched off
HIGH: Device is switched on, battery
monitor is in HIGH mode
LOW: Device is switched on, battery
monitor is in LOW mode
5 12/24V DC Connection socket DC voltage supply
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 12

13
CoolFreeze
Operation
CF-25, CF-35, CF-40, CF-50, CF-60
Operating panel (Fig. 4page 5)
Item Description Explanation
1 ON Switches the cooler on or off when the
OFF button is pressed for between one and two seconds
2 POWER Status indication
LED lights up green: Compressor is on
LED lights up amber: Compressor is off
LED flashes amber: Voltage insufficient
3 ERROR LED flashes red: Device is switched on
but not ready for
operation
4 SET Selects the input mode
- Temperature setting
- Celsius or Fahrenheit display
- Set battery monitor
5 – Display, shows the information
6 UP + Press once to increase the value
7 DOWN – Press once to decrease the value
CF-25
Connection socket (Fig. 5page 5):
Item Description
1 Connection socket DC voltage supply
CF-35, CF-40, CF-50, CF-60
Connection sockets (Fig. 6page 5):
Item Description
1 Connection socket AC voltage supply
2 Fuse holder
3 Connection socket DC voltage supply
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 13

14
CoolFreeze Operation
5.2 Accessories
If you want to operate the coolers CF-18 and CF-25 from the
240 V AC mains, be sure to use the rectifier WAECO CoolPower EPS-816
(CF-18 only) or EPS-817 (CF-18 and CF-25).
6 Operation
6.1 Before initial use
Note
Before starting your new cooler for the first time, you should clean it
inside and outside with a damp cloth for hygienic reasons (please also
refer to the chapter “Cleaning and maintenance” on page 22).
Mounting the handles
CF-35, CF-40, CF-50, CF-60
The handles are enclosed unassembled. If you wish to attach the
handles, proceed as follows:
➤Make a handle by putting two holders (Fig. 71, page 5) and a
handle (Fig. 72, page 5) together.
➤Fasten the grip with the enclosed screws in the holes provided.
Turning the lid around
CF-50, CF-60
You can turn the lid around if you want to open the lid from the other
side.
To do this, proceed as follows:
➤Open the lid and pull it out (Fig. 8A, page 6).
➤Turn the lid.
➤Insert the lid in the lid holders on the opposite side of the cooler
(Fig. 8B, page 6).
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 14

15
CoolFreeze
Operation
Selecting the temperature units – ºC or ºF
CF-25, CF-35, CF-40, CF-50, CF-60
You can switch the temperature display between Celsius and Fahrenheit.
This is how to do it:
➤Switch on the cooler.
➤Press the “SET” button (Fig. 4 4, page 5) twice.
➤Use the “UP +” (Fig. 4 6, page 5) and “DOWN -” (Fig. 4 7,
page 5) buttons to select Celsius or Fahrenheit.
✔The selected temperature units then appear in the display for a few
seconds. The display flashes several times before it returns to the
current temperature.
6.2 Energy saving tips
●Choose a well ventilated installation location which is protected
from direct sunlight.
●Allow hot food to cool down first before you place it into the
device.
●Do not open the cooler more often than necessary.
●Do not leave the lid open for longer than necessary.
●Defrost the cooler once a layer of ice forms.
●Avoid unnecessarily low temperatures.
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 15

16
CoolFreeze Operation
6.3 Connecting the cooler
Connecting to a battery (Vehicle or boat)
The cooler can be operated with 12 V or 24 V DC.
Caution – Danger of damaging the device!
Disconnect the cooler and other consumer units from the battery before
you connect the battery to a quick charging device.
Overvoltage can damage the electronics of the device.
For safety reasons the cooler is equipped with an electronic system to
prevent polarity reversal. This protects the cooler against short-circuiting
when connecting to a battery.
➤Plug the 12/24-V connection cable (Fig. 12, page 4) into the DC
voltage socket, the cigarette lighter or a 12 V or 24 V socket.
Connecting to a 100–240 V AC mains (E.g. in the home or office)
Caution – Danger of electrocution!
Never handle plugs and switches with wet hands or if you are standing
on a wet surface.
Caution – Danger of electrocution!
If you are operating your cooler on board a boat from a mains
connection of 100–240 V AC, you must install a residual current circuit
breaker between the 100–240 V AC mains and the cooler.
Seek advice from a trained technician.
CF-35, CF-40, CF-50, CF-60
The coolers CF-35, CF-40, CF-50, CF-60 have an integrated multi-voltage
power supply with priority circuit for connecting to an AC voltage source
of 100–240 V. The priority circuit automatically switches the cooler to
mains operation, if the device is connected to a 100–240 V AC mains,
even if the 12/24 V connection cable is still attached.
When switching between the AC mains and the battery supply, the red
LED may light up briefly.
➤Plug the 100 – 240 V connection cable (Fig. 13, page 4) into the
AC voltage socket and connect it to the 100 – 240 V AC voltage
mains (only CF-35, CF-40, CF-50, CF-60).
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 16

17
CoolFreeze
Operation
CF-18
CF-18, CF-25
To operate the coolers CF-18 and CF-25 from the 220–240 V AC mains,
use the optional accessory rectifier WAECO CoolPower EPS-816 (CF-18
only) or EPS-817 (CF-18 and CF-25).
6.4 Using the battery monitor
The device is equipped with a multi-level battery monitor that protects
your vehicle battery against excessive discharging when the device is
connected to the on-board 12/24 V supply.
If the cooler is operated when the vehicle ignition is switched off, the
cooler switches off automatically as soon as the supply voltage falls
below a set level. The cooler will switch back on once the battery has
been recharged to the restart voltage level.
Note – during low voltage
When switched off by the battery monitor, the digital display (Fig. 4
5, page 5) goes blank and the power LED (Fig. 42, page 5) flashes
amber.
Caution – Danger of damage!
When switched off by the battery monitor, the battery will no longer be
fully charged. Avoid starting repeatedly or operating current consumers
without longer charging phases. Ensure that the battery is recharged.
In “HIGH” mode, the battery monitor responds faster than at the levels
“LOW” and “MED” (see the following table).
CF-25, CF-35, CF-40,
CF-50, CF-60
Battery monitor mode LOW HIGH LOW MED HIGH
Switch-off voltage at 12 V 10.4 V 11.5 V 10.1 V 11.4 V 11.8 V
Restart voltage at 12 V 11.5 V 12.5 V 11.1 V 12.2 V 12.6 V
Switch-off voltage at 24 V 22.1 V 24.0 V 21.5 V 24.1 V 24.6 V
Restart voltage at 24 V 23.6 V 25.4 V 22.9 V 25.3 V 26.2 V
The method of battery mode selection follows:
CF-18
➤Slide the selection switch (Fig. 34, page 4) to “LOW” if operating
from a supply battery, or “HIGH” if operating from a standard vehicle
starter battery.
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 17

18
CoolFreeze Troubleshooting
(LOW) (MED) (HIGH)
CF-25, CF-35, CF-40, CF-50, CF-60
➤Switch on the cooler.
➤Press the “SET” button (Fig. 4 4, page 5) three times.
➤Use the “UP +” (Fig. 46, page 5) and “DOWN -” (Fig. 47,
page 5) buttons to select the battery monitor mode.
➤Digital display will be as follows.
✔The selected mode then appears in the display for a few seconds.
The display flashes several times before it returns to the current
temperature.
Note
When the cooler is supplied by the starter battery, select the battery
monitor mode “HIGH”. If the cooler is connected to a supply battery, the
battery monitor mode “LOW” will suffice.
If you wish to operate the cooler from the AC mains, set the battery
monitor to the “LOW” position.
6.5 Using the cooler
Caution – Danger of overheating!
Ensure at all times that there is sufficient ventilation so that the heat
generated during operation can dissipate. Ensure that the ventilation
slots are not covered. Make sure that the device is sufficiently far away
from walls and other objects so that the air can circulate.
➤Place the cooler on a firm foundation.
Make sure that the ventilation slots are not covered and that the
heated air can dissipate.
➤Close the cooler, see “Connecting the cooler” on page 16.
Note
If you wish to operate the cooler from the AC mains, set the battery
monitor to the “LOW” position.
Caution – Danger from excessively low temperature!
Ensure that the only objects placed in the cooler are those intended to
be cooled at the selected temperature.
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 18

19
CoolFreezeTechnical Data
CF-18
➤Slide the sliding switch (Fig. 3 4, page 4) to “LOW” or “HIGH”
battery protection (See 6.4 “using the battery monitor” for suitable
level).
✔The “POWER” LED is lit green.
✔The cooler starts cooling the interior.
✔When the cooling temperature has been reached, the “POWER” LED
is lit amber.
CF-25, CF-35, CF-40, CF-50, CF-60
➤Press the “ON/OFF” button (Fig. 4 1, page 5) and hold down for
between one and two seconds.
✔The “POWER” LED lights up.
✔The display (Fig. 45, page 5) switches on and shows the current
temperature.
Note – Displayed temperatures (Digital display models only).
CF-25, CF-35, CF-40, CF-50, CF-60 (Not CF-50DZ)
The temperature displayed is that of the middle of the large interior
compartment.
CF-50DZ
i With plastic dividers in: the display temperature is that of the
middle of the freezer compartment (furthest away from control
panel).
ii With plastic dividers removed: the actual compartment
temperature will be considerably warmer than the displayed
temperature.
ALL MODELS
Temperatures elsewhere in the compartment (away from centre) will
deviate from the displayed temperature.
✔The cooler starts cooling the interior.
Locking the cooler
➤Close the lid.
➤Press the lock (Fig. 21, page 4) down, until it latches in place
audibly.
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 19

20
CoolFreeze
6.6 Setting the temperature
CF-18
➤Set the cooling temperature with the temperature controller
(Fig. 31, page 4).
CF-25, CF-35, CF-40, CF-50, CF-60
➤Press the “SET” button (Fig. 44, page 5) once.
➤Use the “UP +” (Fig. 46, page 5) and “DOWN -” (Fig. 47,
page 5) buttons to select the cooling temperature.
✔The cooling temperature appears in the display for a few seconds.
The display flashes several times and then the current temperature
is displayed again.
6.7 Using The Emergency Switch
➤The emergency override switch (Fig. 5& 64, page 5) is
located in the connection panel.
➤For normal operation the switch should be in the ‘NORMAL USE’
position.
➤In the unlikely event of an electronic control failure slide the Switch
to ‘EMERGENCY OVERRIDE’.
NOTE: in this position the appliance will run all the time and will
therefore perform as a freezer only.
6.8 Switching off the cooler
➤Empty the cooler.
➤Switch the cooler off.
➤Pull out the connection cable.
If you do not want to use the cooler for a longer period of time:
➤Leave the lid slightly open. This prevents odour build-up.
6.9 Defrosting the cooler
Humidity can form frost in the interior of the cooling device or on the
evaporator. This reduces the cooling capacity. Defrost the device in good
time to avoid this.
Caution – Danger of damaging the device!
Never use hard or pointed tools to remove ice or to loosen objects
which have frozen in place.
To defrost the cooler, proceed as follows:
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 20

21
CoolFreeze
➤Take out the contents of the cooling device.
➤If necessary, place them in another cooling device to keep them
cool.
➤Switch off the device.
➤Leave the cover open.
➤Wipe off the defrosted water.
6.10 Replacing the device fuse (240V)
Only CF-35, CF-40, CF-50, CF-60
Caution – Danger of electrocution!
Disconnect the connection cable before you replace the device fuse.
➤Pull off the connection cable.
➤Pry out the fuse insert (Fig. 62, page 5) with a screwdriver.
➤Replace the defective fuse with a new one that has the same
rating (T4,0AL 250V).
➤Press the fuse insert back into the housing.
6.11 Replacing the plug fuse (12/24 V)
➤Pull the adapter sleeve (Fig. 94, page 6) off of the plug.
➤Unscrew the screw (Fig. 95, page 6) out of the upper half of the
housing (Fig. 91, page 6).
➤Carefully raise the upper half of the housing from the lower
(Fig. 96, page 6) half.
➤Take out the contact pin (Fig. 93, page 6).
➤Replace the defective fuse (Fig. 92, page 6) with a new one that
has the same rating (8A 32V).
➤Re-assemble the plug in the reverse order.
CF18-60_M_81003:PowerVac_PV-100 3/9/08 3:53 PM Page 21
