Wagan 2326 User manual

Item no. 2326
User’s Manual
Cordless Wet/Dry
Vacuum Cleaner

www.wagan.com
2
Cordless Wet/Dry Vacuum Cleaner by Wagan Tech
©2009 Wagan Corporation
All Rights Reserved
Wagan and wagan.com are trademarks used by Wagan Corporation
Thank you for purchasing the Cordless Wet/Dry Vacuum Cleaner by Wagan Tech.
With normal care and proper treatment it will provide years of reliable use. Please
read all operating instructions carefully before use and keep it for reference.
Semicircular Brush
Liquid Nozzle
Crevice Tool
Front Cover (Dust Bin)
Filter Cover
Filter
Vacuum Cleaner
1.
2.
3.
4.
5.
6.
7.
LED Indicator Light
Power Switch
Front Cover Release
Plastic Mounting Screws
Metal Mounting Screws
Charging Cradle
AC/DC Adaptor
8.
9.
10.
11.
12.
13.
14.
Product Parts
1.
2.
3.
4. 5. 6.
10.
8.
9.
7.
11.
12.
13.
14.

www.wagan.com
©2009 Wagan Corporation
All Rights Reserved
Wagan and wagan.com are trademarks used by Wagan Corporation 3
User’s Manual—Please read before using this equipment
IMPORTANT: In order to maximize power, the unit should be fully charged
for at least 24 hours before initial use.
Charging
Set “ON/OFF” switch into the “OFF” position.
Set unit into charging base.
Ensure that the indicator light is on. If it is not, please retry steps 1 & 2.
After the initial charge, the vacuum will require 8–12 hours for a full charge.
The vacuum will run for roughly 15 minutes on a full charge.
Before Use
While charging, make sure the indicator light is on. In order to maximize
the suction power, the vacuum should be fully charged for at least 24 hours
before first use.
Empty the Dust Bin compartment regularly if you have vacuumed dust.
Store the vacuum cleaner in a clean, dry area when not in use.
Vacuuming Liquids
Before vacuuming liquids, empty the Dust Bin compartment.
Place the vacuum vertically, keep the nozzles downward and check the
liquid level.
Never Point the nozzles upward with liquids to prevent leaking.
It is recommended to empty the Dust Bin compartment immediately when the
liquid level reaches the “Max” line. If the compartment contents exceed this
1.
2.
3.
4.
5.
•
•
•
1.
2.
3.
4.

www.wagan.com
4
Cordless Wet/Dry Vacuum Cleaner by Wagan Tech
©2009 Wagan Corporation
All Rights Reserved
Wagan and wagan.com are trademarks used by Wagan Corporation
designated level, permanent damage to the vacuum can result.
After the Dust Bin compartment and filter are fully dried, reassemble the
vacuum.
Hints and Precautions
Check the condition of the filter regularly, and make sure that it is firmly in
place. If the vacuum cleaner loses suction power or makes abnormal noises,
open it and check if the vacuum cleaner inlet is blocked. Check if the filter is
full. The filter is reusable and washable.
In case of abnormal operation, such as motor overheating, turn off the
vacuum cleaner and solve the problem first (e.g. blockages in the vacuum
inlet or accessories). If the vacuumed dust or debris fall out from the vacuum
cleaner, check to see if the filter is full.
Safety Instructions
This vacuum is only designed for use with the included AC/DC adapter.
For better performance of the rechargeable battery, do not operate or store
the battery in temperatures of −4°F (−20°C) or over 104°F (40°C).
Check whether the filter has been properly fitted. Never turn on the vacuum
without a filter.
The vacuum is not a toy. The vacuum should be used and stored out of the
reach of the children. Keep nozzles away from eyes and ears at all times.
Do not vacuum hot or smoldering substances, large pieces of sharp-edged
debris such as glass, solvents, corrosive liquids, acidic liquids, flammable or
explosive substances.
Never immerse the vacuum or AC/DC adapter in water.
5.
•
•
•
•
•
•
•
•

www.wagan.com
©2009 Wagan Corporation
All Rights Reserved
Wagan and wagan.com are trademarks used by Wagan Corporation 5
User’s Manual—Please read before using this equipment
Do not store outdoors.
Do not continue to use this vacuum if it appears to be malfunctioning.
If the vacuum is not working as it should, has been damaged, dropped, left
outdoors or dropped into water, bring it to a licensed electrician or shop for
repair.
Do not use the AC/DC adapter if the wire or plug is damaged.
The vacuum contains a Sealed Lead Acid battery. Do not expose this
vacuum to fire: batteries inside this vacuum may explode or leak.
Under normal use and when properly maintained, the battery will provide
power for many years. When the useful life of the battery has been
exceeded however, the battery should be disposed of properly. Contact
your local recycling authority for further information.
Wagan will not be responsible for any damages or injuries for operating this
unit improperly or not operating as described in this manual.
•
•
•
•
•
•
•
www.wagan.com
[e-mail]
USA & CAN Toll Free: 1.800.231.5806
1.510.471.9221
31088 San Clemente Street
Hayward, CA. 94544
U.S.A.
20091112

Detach and return bottom portion to the address below.
All WAGAN Corporation products are warranted to the original purchaser of
this product.
Warranty Duration: This product is warranted to the original purchaser for a
period of one (1) Year from the original purchase date, to be free of defects in
material and workmanship. WAGAN Corporation disclaims any liability for
consequential damages. In no event will WAGAN Corporation be responsible
for any amount of damages beyond the amount paid for the product at retail.
In the event of a defective item, please contact WAGAN Corporation at
[phone] to obtain a Returned Merchandise Authorization number
(RMA#), and return instructions. Each item returned will require a separate
RMA#. After you have received the RMA# and the return instructions from
WAGAN Corporation, please follow the instructions and send the item with
PREPAID SHIPPING, along with all of the required documentation, a complete
explanation of the problem, your name, address and daytime phone number.
WAGAN Corporation will, at its option, replace or repair the defective part.
A Returned Merchandise Authorization number (RMA#) is REQUIRED when
sending in any defective item. WAGAN Corporation is not responsible for
any item(s) returned without an official Returned Merchandise Authorization
number. The item(s) must be returned with prepaid shipping. WAGAN
Corporation is not responsible for any shipping charges incurred in returning
the item(s) back to the company for repair or replacement. This warranty is
void if the product has been damaged by accident, in shipment, unreasonable
use, misuse, neglect, improper service, commercial use, repairs by
unauthorized personnel or other causes not arising out of defects in materials
or workmanship. This warranty is effective only if the product is purchased and
operated in the USA and does not extend to any units which have been used in
violation of written instructions furnished.
Warranty Disclaimers: This warranty is in lieu of all warranties expressed or
implied and no representative or person is authorized to assume any other
liability in connection with the sale of our products. There shall be no claims
for defects or failure of performance or product failure under any theory of
tort, contract or commercial law including, but not limited to negligence, gross
negligence, strict liability, breach of warranty and breach of contract.
Warranty Performance: During the above one (1) Year warranty period, a
product with a defect will be replaced with a comparable model when the
product is returned to WAGAN Corporation with an original store receipt. The
replacement product will be in warranty for the balance of the one (1) Year
warranty period. ©2008 WAGAN Corp. Updated August 2008
