Wagner Electronics L610 User manual

Copyright Notice
DOCUMENT NO:500-61001-001
REV:D
WAGNER MODEL L610
"DIGITAL RECORDING"
MOISTURE METER
O
WNER
'
S
M
ANUAL

500-61001-001 Rev. C Page 2of 30
Wagner Model L610“Digital Recording” Moisture Meter Owner’s Manual
© Copyright 1996-2004 Wagner Electronic Products, Inc. All Rights Reserved Worldwide. No part of this publication may
be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any other language in any form by
any means without the express written permission of Wagner Electronic Products, Inc.
Technical Support
Should you require support, please consult your printed documentation to resolve your problem. If you are still
experiencing difficulty, you may contact a Wagner Technical Service representative during normal business hours—
7:30 a.m. to 4:00 p.m. Pacific Standard Time, Monday through Friday.
Voice: [phone]
Fax: [phone]
E-Mail: [email protected]
Mail: Technical Services Department
Wagner Electronic Products, Inc.
326 Pine Grove Road
Rogue River, OR 97537

500-61001-001 Rev. C Page 3of 30
Table of Contents
Table of Contents.................................................................3
FCC Compliance Statement..............................................4
L610 Moisture Meter............................................................4
Getting Started......................................................................6
Taking Measurements.........................................................7
Meter Storage........................................................................7
Turning ON the Meter..........................................................8
%MC Readings......................................................................8
Storing Readings.................................................................8
Changing Groups.................................................................9
Menu Selection.....................................................................9
Menu Selection List.............................................................9
AVG/STD Stats....................................................................10
HI/LOW Stats .......................................................................10
Change Species..................................................................11
Edit SG Mode.......................................................................11
Edit Name Mode .................................................................11
Battery Check......................................................................12
Backlight...............................................................................12
Clear Menu...........................................................................13
Clear Menu List...................................................................13
Clear Group .........................................................................13
Clear Reading......................................................................14
Restore Factory..................................................................14
Clear All Groups.................................................................14
Calibration............................................................................15
Technical Notes..................................................................16
Factory Species List..........................................................17
Technical Bulletin 13.........................................................18
Species Setting Tables.....................................................19
Specific Gravity Correction Value Sources................21
Species Corrections..........................................................22
Checking the Moisture Content in Veneer..................22
Commentary on Species Adjustment...........................23
Determining Specific Gravity..........................................24
Questions and Answers...................................................25
Warranty...............................................................................29
Repair Service.....................................................................30

500-61001-001 Rev. D Page 4of 30
FCC Compliance Statement
This equipment has been tested and found to comply within the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in residential installations.
This equipment generates, uses and can radiate radio frequency
energy, and if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause interference to radio or television
equipment reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Move the equipment away from the receiver
• Plug the equipment into an outlet on a circuit different from that
to which the receiver powered
• If necessary, the user should consult the dealer or an
experienced radio/television technician for additional
suggestions.
CAUTION: Only equipment certified to comply with Class B
(computer input/output devices, terminals, printers, etc.) should be
attached to this equipment.
Finally, any changes or modifications to the equipment by the user
not expressly approved by the grantee or manufacture could void the
user’s authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Canadian Department of Communications
Compliance Statement
This Class B digital apparatus meets all requirements of the
Canadian Interference Causing Equipment Regulations.
Avis de conformité aux normes du ministère des
Communications du Canada
Cet appareil numerique de la classe B respecte toutes
les exigences du Reglement sur le material broilleur du
Canada.
L610 Moisture Meter
In response to today’s growing need for timely, accurate
moisture monitoring information and record keeping,
Wagner introduces the L610 Digital Recording Moisture
Meter. This remarkable instrument combines Wagner’s
unique “Wood-Friendly” electromagnetic scanning with
Wagner’s latest microcomputer technology.
•Stores and displays up to 50 user-selected species
adjustments by name.
•Stores up to 500 separate moisture readings.
•Stores readings in up to 5 groups.
Using non-volatile memory, stored readings are retained

500-61001-001 Rev. D Page 5of 30
even when the batteries are removed. A backlit LCD
display features a 2-line, 32 character display. Function
buttons and scroll arrows operate a menu system that
guides the user step-by-step through the selecting,
storing and reporting process. The meter has auto-shut-
off to extend battery life. It can operate accurately in
virtually every wood drying and processing environment.
Like all Wagner handmeters, it is virtually unaffected by
wood temperature.**
** Contact Wagner technical support for guidelines when
wood is below freezing.
To learn more about Wagner Electronics, visit us on the
Web at: http://www.wwwagner.com
L610 Specifications
Physical Size (in): L 8.5 x W 4 x H 3.75
(mm) L 216 x W 102 x H 95
Scanning Area (in): 2.5 x 2.5
(mm) 63.5 x 63.5
Scanning Depth (in): 1.0 in. (25.4 mm)
Weight: 18 oz. (510 g)
Power: 4 AA Alkaline Batteries
Battery Life: ~8 hours of continual use.
Auto Power Shut Down: After 1 minute of non-use.
Moisture Measurement Range: 5 to 30% (dependent on
species setting)
Specify Gravity Range: 0.30 to 0.75
Meter Operating Temperature: 30° to 120°F
Patent Number:5,486,815

500-61001-001 Rev. D Page 6of 30
Getting Started
This sections informs you about
•Turning on the meter
•Moisture readings
•Storing a reading
•What is a group
•Viewing statistics
•The menu system
•Changing species
Before you begin, make sure your hand-meter has a
freshset of batteries.
Turning on the meter
Turn on the meter by pressing theSTORE button for one
second. The display will momentarily show the model,
software version, and revision numbers. Your meter is
now ready to take moisture readings.
Moisture readings
Take moisture readings by pressing the bottom of the
meter to the wood surface. The first line of the display
shows the species for which the meter is calibrated. The
second line shows the reading in percent moisture
content.
Storing a reading
While pressing the bottom of the meter to the wood
surface at the location of interest, press theSTORE button
to save that reading in a group.
What is a group?
A group is a set of readings that belong together. You
determine which readings belong together. Switch to
another group by first pressing the GROUP button. Press
the ARROW buttons to select a different number. Press
the STORE button to activate the selection. The active
group number is shown in the bottom right corner of the
display.
Viewing statistics
Statistical values such as mean, standard deviation,
highest reading, and lowest reading are calculated on
individual groups. They may be accessed for viewing by
using the menu system.
The menu system
For example, to view the mean and standard deviation
values for the active group, press theMENU button to
activate the main menu. Press the ARROW button to
scroll through the menu until the menu item Mean/Std is
displayed. Press the STORE button to activate the menu
item.
Changing species
If the meter is not set to the species you are measuring
change it using the menu system. See the section
“Factory Species List” for a complete list of available
species. If your species is not listed, you may customize
a species as outlined in the section “Changing Species.”

500-61001-001 Rev. D Page 7of 30
Taking Measurements
In order to take correct moisture content measurements,
ensure that the meter’s specific gravity (species) setting
is the correct one for your species of wood as listed in the
Species Setting Table or Species lists.
Be sure to press down firmly on the center of the meter
with approximately 3 pounds of force to ensure good
sensor plate contact with the wood surface. This is
especially important on rough-sawn lumber. Do not take
readings where there is a noticeable defect or knot in the
lumber.
If there is visible surface moisture or water, wipe off any
excess, and let the surface of the wood dry-out for a
couple of minutes, then take the reading. If possible, turn
the board over and measure the other side. If the
thickness of the piece is greater than 3 inches, it is a
good idea to take measurements on both sides.
Ensure that there is nothing (especially your hand or
metal) under the material you are measuring. The actual
moisture sensing area is a 2 ½ inch by 2 ½ inch
rectangle on the meter’s backside (opposite side of the
panel meter). In order to take a valid measurement, this
sensing area must be completely covered with the wood
you are measuring. If the sensing area is not completely
covered, your moisture reading will be inaccurate.
Additional meter corrections may be necessary if you are
measuring Raft Wood (salt water permeated), or lumber
treated with Copper, Chrome, Arsenic (CCA), or
Ammonical, Copper, Quantenary (ACQ). Contact Wagner
Technical Services for further information for these
applications.
Meter Storage
Meter Storage
For a long service life, it is important to store your meter
properly. Avoid excessively hot or cold locations. Do not
store the meter in an area with excessive electro-
magnetic interference, such as near an electric motor, or
where it could be crushed, such as in front of a forklift. Do
not leave the meter in an operating kiln during the drying
cycle.

500-61001-001 Rev. D Page 8of 30
Turning ON the Meter %MC Readings Storing Readings
OPERATION
To turn ON the Meter, press the
STORE button for one second.
The Meter will turn OFF after 1 minute
of inactivity.
Inactivity means no change in
moisture readings or button presses.
The Meter takes continuous %MC
readings and puts them on the display.
When a reading is below 5%, the first
line shows the current species and
group field label. The second line
shows the current %MC reading and
group number. When a reading is
above 5%, the first line becomes a bar
graph representing the current %MC
reading.
When a valid reading is stored, the
second line will display a message
stating that it was stored as sample #
xxx. When attempting to store an
invalid reading, a message will state
the reading was too low and last
sample # xxx.
DISPLAY
WAGNER L610
V 1.00 R1.00
Douglas Fir Grp
.0 %MC 0
Storing MC # 14 or
MC too low # 13
STORE
To turn the Meter ON, press the
STORE button for one second.
Press the STORE button to store the
current MC reading into the current
group.
GROUP
MENU
ARROWS

500-61001-001 Rev. D Page 9of 30
Changing Groups Menu Selection Menu Selection List
OPERATION
Press the GROUP button to activate
the Change Group function.
Use the ARROW buttons to select the
desired group number.
Press the STORE button to accept the
new group change.
The group number range is from 0 to
4.
Press the MENU button to activate the
Menu Selection function.
Press the ARROW buttons to scroll
through the menu list.
Press the STORE button to activate
the selected menu item.
AVG/STD Stats
HI/LOW Stats
Calibration
Backlight
Battery Check
Clear Menu
Change Species
DISPLAY
Change Group
New Group #: 1
Menu Selection
AVG/STD Stats
STORE
Press the STORE button to accept the
new group change.
Press the STORE button to activate
the selected menu item.
GROUP
Press the GROUP button tocancel a
new group change.
Press the GROUP button to leave the
Menu Selection function.
MENU
Press the MENU button to cancel a
new group change.
Press the MENU button to activate the
selected menu item.
ARROWS
Press the ARROW buttons to
increment or decrement the group
number.
Press the ARROW buttons to scroll
through the menu list.

500-61001-001 Rev. D Page 10of 30
AVG/STD Stats HI/LOW Stats
OPERATION
Enter the Menu Selection function and
activate the AVG/STD Stats item.
Use the ARROW buttons to scroll
through the group statistics. Only
groups which contain readings will be
shown.
Press the STORE button to return to
the %MC Readings mode.
Enter the Menu Selection function and
activate the HI/LOW Stats item.
Use the ARROW buttons to scroll
through the group statistics. Only
groups which contain readings will be
shown.
Press the STORE button to return to
the %MC Readings mode.
DISPLAY
Avg Std Grp
8.3 4.7 0
High Low Grp
11.0 6.1 1
STORE
Press the STORE button to return to
the %MC Readings mode.
Press the STORE button to return to
the %MC Readings mode.
GROUP
Press the GROUP button to advance
to the next valid group.
Press the GROUP button to advance
to the next valid group.
MENU
Press the MENU button to return to
the %MC Readings mode.
Press the MENU button to return to
the %MC Readings mode.
ARROWS
Press the ARROW buttons to scroll
through the AVG/STD group stats.
Press the ARROW buttons to scroll
through the HI/LOW group stats.

500-61001-001 Rev. D Page 11of 30
Change Species Edit SG Mode Edit Name Mode
OPERATION
Enter the Menu Selection function and
activate the Change Species item.
Use the ARROW buttons to scroll
through the species list.
Press the STORE button to activate
the selected species.
The factory default species list is
shown in the Appendix.
Enter the Edit SG mode through the
Change Species item.
Use the ARROW buttons to change
the SG number.
Press the STORE button to accept the
change.
Enter the Edit Name mode through the
Change Species item and Edit SG
mode.
Use the ARROW buttons to change
the alpha character.
Press the MENU button to move the
edit cursor to the right.
Press the STORE button to accept the
change.
DISPLAY
Species List SG
Walnut,Black.41
Edit.........SG
Walnut,Black.45
Edit Name......
Walnut,Black.45
STORE
Press the STORE button to activate
the selected species.
Press the STORE button to accept the
change.
Press the STORE button to accept the
change.
GROUP
Press the GROUP button to return to
the %MC Readings mode.
Press the GROUP button to cancel
any change.
Press the GROUP button to cancel
any change.
MENU
Press the MENU button to activate the
Edit SG mode.
Press the MENU button to activate the
Edit Name mode.
Press the MENU button to move the
edit cursor one character to the right.
That character will be replaced with a
BLANK.
ARROWS
Press the ARROW buttons to scroll
through the species list.
Press the ARROW buttons to change
the SG number.
Press the ARROW buttons to cycle
through the alphabet.

500-61001-001 Rev. D Page 12of 30
Battery Check Backlight
OPERATION
Enter the Menu Selection function and
activate the Battery Check item.
When a low battery condition occurs,
GRP will be replaced by BAT in the
%MC Readings mode.
Life time for alkaline batteries are ~8
hours (continuous use, backlight
OFF).
Enter the Menu Selection function and
activate the Backlight item.
Press the STORE button to change
state of the backlight.
DISPLAY
xxxxxx
E..Bat 4.0 V..F
Backlight: ON
STORE
Press the STORE button to return to
the %MC Readings mode.
Press the STORE button to change
state of the backlight.
GROUP
Press the GROUP button to return to
the %MC Readings mode.
Press the GROUP button to return to
the %MC Readings mode.
MENU
Press the MENU button to return to
the %MC Readings mode.
Press the MENU button to return to
the %MC Readings mode.
ARROWS
Press the ARROW buttons to return to
the %MC Readings mode.
Press the ARROW buttons to return to
the %MC Readings mode.

500-61001-001 Rev. D Page 13of 30
Clear Menu Clear Menu List Clear Group
OPERATION
Enter the Menu Selection function and
activate the Clear Menu item.
Press the ARROW buttons to scroll
through the Clear Menu list.
Press the STORE button to activate
the selected menu item.
Clear Group
Clear Reading
Restore Factory
Clear All Groups
Enter the Clear Menu function and
activate the Clear Group item.
Press the ARROW buttons to select
the group to clear. Only groups which
contain readings will be shown.
Press the STORE button to clear the
selected group.
DISPLAY
Clear Menu
Clear Group
Clear Group?Grp
21
STORE
Press the STORE button to activate
the selected menu item.
Press the STORE button to clear the
selected group
GROUP
Press the GROUP button to leave the
Clear Menu function.
Press the Group button to select the
group to clear.
MENU
Press the MENU button to activate the
selected menu item.
Press the Menu button to cancel
operation.
ARROWS
Press the ARROW buttons to scroll
through the menu list.
Press the ARROW buttons to select
the group to clear.

500-61001-001 Rev. D Page 14of 30
Clear Reading Restore Factory Clear All Groups
OPERATION
Enter the Clear Menu function and
activate the Clear Reading item.
Press the ARROW buttons to select
the reading to clear.
Press the STORE button to clear the
selected reading.
Enter the Clear Menu function and
activate the Restore Factory item.
Press the STORE button to restore
factory settings.
Press ANY OTHER button to cancel
operation and return to the %MC
Readings mode.
Enter the Clear Menu function and
activate the Clear All Groups item.
Press the STORE button to clear all
groups.
Press ANY OTHER button to cancel
operation and return to the %MC
Readings mode.
DISPLAY
Clear? Rd # Grp
17.6 % 10 21
Restore Factory
Yes = STORE
Clear all grps?
Yes = STORE
STORE
Press the STORE button to clear the
selected reading.
Press the STORE button to restore
factory settings.
Press the STORE button to clear all
groups.
GROUP
Press the Group button to change
group to clear readings from.
Press the Group button to cancel
operation.
Press the Group button to cancel
operation.
MENU
Press the MENU button to return to
the %MC Readings mode.
Press the MENU button to cancel
operation.
Press the MENU button to cancel
operation.
ARROWS
Press the ARROW buttons to select
the reading to clear.
Press the ARROW buttons to cancel
operation.
Press the ARROW buttons to cancel
operation.

500-61001-001 Rev. D Page 15of 30
Calibration
OPERATION
Enter the Menu Selection function and
activate the Calibration item.
DISPLAY
Check Calibratn
xx.x %MC
STORE
Press the any button to return to the
%MC Readings mode.
GROUP
MENU
ARROWS
Checking Calibration
Calibration is factory set. It may be checked by using a
Wagner Calibration Verification Block (CVB) (P/N: 840-
60130-002). Use only to verify L610 factory calibration is
within tolerance limits. If calibration is out of tolerance,
return L610 to factory or repair depot for re-calibration.
Never adjust L610 to this device. Protect CVB from
direct sunlight. Store in cool dry place. Follow these
steps for checking calibration.
1. Enter the Calibration menu item.
2. Hold the meter in mid air so the bottom is several feet
from any object. The correct reading for air is .0
%MC. If the reading is outside the range, -2 to 2
%MC, the unit is out of calibration.
3. Place the CVB, rubber feet down, on a metal surface:
such as a file cabinet, a piece of sheet metal, etc.
4. Orientate the long axis of the handmeter with the long
axis of the CVB. Press the handmeter sensor in the
center of the CVB and observe the reading. The
correct reading is 17.5 %MC. If the reading is outside
the range, 15.5 to 19.5 %MC, the unit is out of
calibration.
Warning—There are two (2) hole plugs located on either
side of the L610 handle. Do not remove these plugs
because the adjustments below them are factory set and
should not be adjusted by the customer. If adjustment is
attempted, the unit will not be in calibration and will
require factory re-calibration. Also if adjustment is
attempted, warranty will be voided.

500-61001-001 Rev. D Page 16of 30
Technical Notes
Readings and Groups--The L610 can store up to 500
readings in up to 5 groups. Groups are numbered 0 to 4
and can be selected at random. There is no limit to the
number of readings per group as long as the total
readings of all groups do not exceed 500.
Automatic Menu Escape--When in the menu system
and 15-seconds of no key presses, the Meter will
automatically return to the %MC Reading mode ready to
store the next reading in the current group.
Repeat Key--If a key (button) is held down for more than
one (1) second, then the key pressed is repeated at a
rate of one (1) repeat each second. After 5 repeats the
rate doubles and after an additional 5 repeats the rate
doubles again. Use this feature to scroll through long list
of species or readings.

500-61001-001 Rev. D Page 17of 30
Factory Species List
The L610 has a factory default of 50 species. The
specific gravity (SG) and name may be adjusted from the
Species menu item. This allows you to tailor the Meter
calibration to a species not listed.
Note: SA denotes South Africa.
Species SG
Alder,Red .41
Basswood,Amer.37
Cedar,EastRed.47
Cedar,WestRed.32
Cherry,Black .50
Douglas Fir .50
Ebony,E Indn .70
Elliottii,SA .49
Euca Grand SA.70
Fir,Balsam .35
Fir,Cal Red .38
Fir,Subalpine.32
Fir,White .39
Hemlock,East .40
Hemlock,West .45
Hickory,Nutmg.60
Hickory,Pecan.66
Hickory,Mockr.72
Jarrah .67
Keruing .64*
Larch,Western.52
Mahogany,True.59*
Maple,Bigleaf.48
Maple,Sugar .63
Oak,Black,Red.61
Oak,Califrnia.51 *The values
Oak,North Red.63 for these
Oak,South Red.59 species
changed
Oak,Bur,White.64 per Technical
Oak,White .66 Bulletin #13,
Patula SA .50 shown on next
Pine,E White .35 page.
Pine,Jack .43
Pine,Loblolly.51
Pine,Ldgepole.41
Pine,Longleaf.59
Pine,Parana .54*
Pine,Pnderosa.40
Pine,Shrtleaf.51
Pine,Slash .59
Pine,Sugar .36
Poplar,Yellow.42
Primavere .45*
Redwood, Old .40

500-61001-001 Rev. D Page 18of 30
SYP .51*
Taeda,SA .58
Tamarack .53
Teak .59*
Walnut,Black .55
Custm Species.50
Technical Bulletin 13
L610 SPECIES ADJUSTMENT
In our quest to continually upgrade our products and
services, it has come to our attention that some of the
lesser used species adjustment values (SG) stored in the
default list of L610 hand-meter are not the correct values.
If you use any of the following species in your operation,
please store the new values to ensure the greatest
accuracy of your hand-meter. Should the internal lithium
battery in the meter fail, or the meter is sent in for
service, you will have to re-enter the appropriate values.
Please place this bulletin in the back of your L610
manual.
Change SG: From To
Keruing 0.69 0.64
Mahogany, True 0.45 0.59
Pine, Parana 0.46 0.54
Primavere 0.40 0.45
SYP 0.55 0.51
Teak 0.55 0.59
(Revised 10/28/02)

500-61001-001 Rev. D Page 19of 30
This change can be performed by turning on the meter
and editing the species value by pressing:
Menu > up/down arrows to select Change Species >
Store> Select appropriate species with up/down arrows >
Store > press Menu until “Edit” is displayed > up/down to
select new SG value > Store to save.
Wagner Electronics
Technical Services Department
Species Setting Tables
for Hardwoods, Softwoods, and Imported Species
Hardwood Species
Spec. Gravity: Hardwood Species:
0.41 . . . . . . . . . . . . . . . . . Alder, Red
0.61 . . . . . . . . . . . . . . . . . Apple
0.49 . . . . . . . . . . . . . . . . . Ash, Black
0.58 . . . . . . . . . . . . . . . . . Ash, Blue
0.56 . . . . . . . . . . . . . . . . . Ash, Green
0.55 . . . . . . . . . . . . . . . . . Ash, Oregon
0.55 . . . . . . . . . . . . . . . . . Ash, Red
0.60 . . . . . . . . . . . . . . . . . Ash, White
0.39 . . . . . . . . . . . . . . . . . Aspen, Bigtooth
0.38 . . . . . . . . . . . . . . . . . Aspen, Quaking
0.37 . . . . . . . . . . . . . . . . . Basswood, American
0.64 . . . . . . . . . . . . . . . . . Beech, American
0.55 . . . . . . . . . . . . . . . . . Birch, Paper
0.65 . . . . . . . . . . . . . . . . . Birch, Sweet
0.55 . . . . . . . . . . . . . . . . . Birch, White
0.62 . . . . . . . . . . . . . . . . . Birch, Yellow
0.38 . . . . . . . . . . . . . . . . . Butternut
0.50 . . . . . . . . . . . . . . . . . Cherry, Black
0.43 . . . . . . . . . . . . . . . . . Chestnut, American
0.34 . . . . . . . . . . . . . . . . . Cottonwood, Balsam Poplar
0.35 . . . . . . . . . . . . . . . . . Cottonwood, Black
0.40 . . . . . . . . . . . . . . . . . .Cottonwood, Eastern
0.64 . . . . . . . . . . . . . . . . . Dogwood, Flowering
0.50 . . . . . . . . . . . . . . . . . Elm, American
0.63 . . . . . . . . . . . . . . . . . Elm, Rock
0.53 . . . . . . . . . . . . . . . . . Elm, Slippery
0.53 . . . . . . . . . . . . . . . . . Hackberry
0.66 . . . . . . . . . . . . . . . . . Hickory (Pecan), Bitternut
0.60 . . . . . . . . . . . . . . . . . Hickory (Pecan), Nutmeg
0.66 . . . . . . . . . . . . . . . . . Hickory, Pecan
0.62 . . . . . . . . . . . . . . . . . Hickory (Pecan), Water
0.72 . . . . . . . . . . . . . . . . . Hickory (True), Mockernut
0.75 . . . . . . . . . . . . . . . . . Hickory (True), Pignut
Spec. Gravity: Hardwood Species:
0.72 . . . . . . . . . . . . . . . . . Hickory (True), Shagbark
0.69 . . . . . . . . . . . . . . . . . Hickory (True), Shellbark
0.50 . . . . . . . . . . . . . . . . . Holly, American
0.63 . . . . . . . . . . . . . . . . . Hophornbeam, Eastern
0.51 . . . . . . . . . . . . . . . . . Laurel, California
0.69 . . . . . . . . . . . . . . . . . Locust, Black
0.58 . . . . . . . . . . . . . . . . . Madrone, Pacific
0.50 . . . . . . . . . . . . . . . . . Magnolia, Southern
0.48 . . . . . . . . . . . . . . . . . Maple, Bigleaf
0.57 . . . . . . . . . . . . . . . . . Maple, Black
0.66 . . . . . . . . . . . . . . . . . Maple, Hard
0.54 . . . . . . . . . . . . . . . . . Maple, Red
0.47 . . . . . . . . . . . . . . . . . Maple, Silver
0.51 . . . . . . . . . . . . . . . . . Maple, Soft
0.63 . . . . . . . . . . . . . . . . . Maple, Sugar
0.61 . . . . . . . . . . . . . . . . . Oak (Red), Black
0.51 . . . . . . . . . . . . . . . . . Oak, California Black
0.68 . . . . . . . . . . . . . . . . . Oak (Red), Cherrybark
0.63 . . . . . . . . . . . . . . . . . Oak (Red), Laurel
0.63 . . . . . . . . . . . . . . . . . Oak (Red), Northern Red

500-61001-001 Rev. D Page 20of 30
0.63 . . . . . . . . . . . . . . . . . Oak (Red), Pin
0.67 . . . . . . . . . . . . . . . . . Oak (Red), Scarlet
0.59 . . . . . . . . . . . . . . . . . Oak (Red), Southern Red
0.63 . . . . . . . . . . . . . . . . . Oak (Red), Water
0.69 . . . . . . . . . . . . . . . . . Oak (Red), Willow
0.64 . . . . . . . . . . . . . . . . . Oak, Red (1).
0.64 . . . . . . . . . . . . . . . . . Oak (White), Bur
0.66 . . . . . . . . . . . . . . . . . Oak (White), Chestnut
0.63 . . . . . . . . . . . . . . . . . Oak (White), Overcup
0.67 . . . . . . . . . . . . . . . . . Oak (White), Post
0.67 . . . . . . . . . . . . . . . . . Oak (White), Swamp Chestnut
0.72 . . . . . . . . . . . . . . . . . Oak (White), Swamp White
0.66 . . . . . . . . . . . . . . . . . Oak, White
0.64 . . . . . . . . . . . . . . . . . Persimmon, Common
0.46 . . . . . . . . . . . . . . . . . Sassafras
0.52 . . . . . . . . . . . . . . . . . Sweetgum
0.49 . . . . . . . . . . . . . . . . . Sycamore, American
(1). See page 21 for footnote sources.
Spec. Gravity: Hardwood Species:
0.58 . . . . . . . . . . . . . . . . . Tanoak
0.50 . . . . . . . . . . . . . . . . . Tupelo, Black
0.50 . . . . . . . . . . . . . . . . . Tupelo, Water
0.55 . . . . . . . . . . . . . . . . . Walnut, Black
0.39 . . . . . . . . . . . . . . . . . Willow, Black
0.42 . . . . . . . . . . . . . . . . . Yellow-Poplar
Softwood Species
Spec. Gravity: Softwood Species:
0.46 . . . . . . . . . . . . . . . . . Baldcypress
0.44 . . . . . . . . . . . . . . . . . Cedar, Alaska
0.32 . . . . . . . . . . . . . . . . . Cedar, Atlantic White
0.47 . . . . . . . . . . . . . . . . . Cedar, Eastern Red Cedar
0.37 . . . . . . . . . . . . . . . . . Cedar, Incense
0.31 . . . . . . . . . . . . . . . . . Cedar, Northern White
0.43 . . . . . . . . . . . . . . . . . Cedar, Port Orford
0.32 . . . . . . . . . . . . . . . . . Cedar, Western Red Cedar
0.44 . . . . . . . . . . . . . . . . . Cedar, Yellow
0.50 . . . . . . . . . . . . . . . . . Douglas Fir
0.35 . . . . . . . . . . . . . . . . . Fir, Balsam
0.38 . . . . . . . . . . . . . . . . . Fir, California Red
0.37 . . . . . . . . . . . . . . . . . Fir, Grand
0.39 . . . . . . . . . . . . . . . . . Fir, Noble
0.43 . . . . . . . . . . . . . . . . . Fir, Pacific Silver
0.32 . . . . . . . . . . . . . . . . . Fir, Subalpine
0.39 . . . . . . . . . . . . . . . . . Fir, White
0.40 . . . . . . . . . . . . . . . . . Hemlock, Eastern
0.45 . . . . . . . . . . . . . . . . . Hemlock, Mountain
0.45 . . . . . . . . . . . . . . . . . Hemlock, Western
0.52 . . . . . . . . . . . . . . . . . Larch, Western
0.35 . . . . . . . . . . . . . . . . . Pine, Eastern White
0.43 . . . . . . . . . . . . . . . . . Pine, Jack
0.51 . . . . . . . . . . . . . . . . . Pine, Loblolly
0.41 . . . . . . . . . . . . . . . . . Pine, Lodgepole
0.59 . . . . . . . . . . . . . . . . . Pine, Longleaf
0.52 . . . . . . . . . . . . . . . . . Pine, Pitch
0.56 . . . . . . . . . . . . . . . . . Pine, Pond
Spec. Gravity: Softwood Species:
0.40 . . . . . . . . . . . . . . . . . Pine, Ponderosa
0.46 . . . . . . . . . . . . . . . . . Pine, Red
0.48 . . . . . . . . . . . . . . . . . Pine, Sand
0.51 . . . . . . . . . . . . . . . . . Pine, Shortleaf
0.59 . . . . . . . . . . . . . . . . . Pine, Slash
0.44 . . . . . . . . . . . . . . . . . Pine, Spruce
0.36 . . . . . . . . . . . . . . . . . Pine, Sugar
0.48 . . . . . . . . . . . . . . . . . Pine, Virginia
0.38 . . . . . . . . . . . . . . . . . Pine, Western White
0.40 . . . . . . . . . . . . . . . . . Redwood, Old-Growth
0.35 . . . . . . . . . . . . . . . . . Redwood, Young-Growth
0.42 . . . . . . . . . . . . . . . . . Spruce, Black
0.35 . . . . . . . . . . . . . . . . . Spruce, Engelmann
0.40 . . . . . . . . . . . . . . . . . Spruce, Red
0.40 . . . . . . . . . . . . . . . . . Spruce, Sitka
0.36 . . . . . . . . . . . . . . . . . Spruce, White
0.51 . . . . . . . . . . . . . . . . . SYP (Southern Yellow Pine)
0.53 . . . . . . . . . . . . . . . . . Tamarack
