WAGO Edge Computer User manual

Manual
WAGO Edge Computer
752-9800
Version 1.0.0

2 WAGO Edge Computer
752-9800
Manual
Version 1.0.0
© 2021 WAGO Kontakttechnik GmbH & Co. KG
All rights reserved.
WAGO Kontakttechnik GmbH & Co. KG
Hansastraße 27
D-32423 Minden
Phone: [phone] – 0
Fax: [phone] – 1 69
E-Mail: [email protected]
Web: www.wago.com
Technical Support
Phone: [phone] – 4 45 55
Fax: [phone] – 84 45 55
E-Mail: [email protected]
Every conceivable measure has been taken to ensure the accuracy and
completeness of this documentation. However, as errors can never be fully
excluded, we always appreciate any information or suggestions for improving the
documentation.
E-Mail: [email protected]
We wish to point out that the software and hardware terms as well as the
trademarks of companies used and/or mentioned in the present manual are
generally protected by trademark or patent.
WAGO is a registered trademark of WAGO Verwaltungsgesellschaft mbH.

WAGO Edge Computer Table of Contents 3
752-9800
Manual
Version 1.0.0
Table of Contents
1Regulations .................................................................................................5
1.1 Validity of this Documentation..................................................................5
1.2 Document portfolio...................................................................................5
1.3 Copyright..................................................................................................5
1.4 Property rights..........................................................................................6
1.5 Symbols ...................................................................................................8
1.6 Number Notation....................................................................................10
1.7 Font Conventions...................................................................................10
1.8 Legal Bases ...........................................................................................11
1.8.1 Subject to Changes...........................................................................11
1.8.2 Personnel Qualification .....................................................................11
1.8.3 Intended Use.....................................................................................11
1.8.3.1 Improper Use................................................................................11
1.8.3.2 Warranty and Liability ...................................................................11
1.8.3.3 Obligations of Installers/Operators ...............................................12
2Safety Information ....................................................................................13
2.1 Safety Advice (Precautions)...................................................................13
2.2 Special Use Conditions..........................................................................15
3Overview....................................................................................................16
4Properties..................................................................................................17
4.1 View .......................................................................................................17
4.2 Labeling .................................................................................................18
4.3 Connectors.............................................................................................19
4.3.1 Connectors on the front.....................................................................19
4.3.2 “X1”, “X2”, “X11” and “X12” ETHERNET Interfaces .......................... 19
4.3.3 “X3”, “X4”, “X5” and “X6” USB 3.0 Interfaces....................................19
4.3.4 “X7” – HDMI 1.4 Interface Type A.....................................................20
4.3.5 “X8” DP 1.2 Interface.........................................................................21
4.3.6 “X9” Supply Voltage ..........................................................................21
4.4 RTC Battery ...........................................................................................22
4.5 Display Elements ...................................................................................23
4.5.1 PWR LED..........................................................................................23
4.5.2 HDD LED ..........................................................................................23
4.5.3 BTR LED ...........................................................................................23
4.6 Operating Elements ...............................................................................24
4.6.1 ON/OFF Button .................................................................................24
4.6.2 Reset Button .....................................................................................24
4.7 Schematic Diagram................................................................................25
4.8 Technical Data.......................................................................................27
4.8.1 Device ...............................................................................................27
4.8.2 Climatic Environmental Conditions....................................................27
4.8.3 Power Supply ....................................................................................27
4.8.4 Hardware...........................................................................................28
4.8.5 Software ............................................................................................28
4.8.6 Communication .................................................................................28

4 Table of Contents WAGO Edge Computer
752-9800
Manual
Version 1.0.0
4.8.7 Interfaces ..........................................................................................28
4.8.8 Connectors........................................................................................29
4.9 Approvals ...............................................................................................30
4.10 Standards and Guidelines......................................................................30
5Functions ..................................................................................................31
5.1 Network Security....................................................................................31
5.1.1 Users and Passwords .......................................................................31
5.1.2 Services and Users ...........................................................................31
5.1.3 Linux®User Group ............................................................................31
5.1.4 Web Protocols for WBM Access .......................................................32
5.1.5 Opened IP ports ................................................................................32
6Mounting ...................................................................................................33
6.1 Assembly Guidelines/Standards ............................................................33
6.2 Mounting position...................................................................................33
6.3 Mount to the Rail....................................................................................33
7Connecting................................................................................................35
7.1 Grounding ..............................................................................................35
7.2 Connecting the Supply Voltage..............................................................35
8Commissioning.........................................................................................36
8.1 Login ......................................................................................................36
8.2 Configuration..........................................................................................37
8.2.1 Configure Locally in the Terminal......................................................37
8.2.2 Web-Based Configuration with Cockpit.............................................37
8.2.3 Configure Locally with GUI................................................................38
9Removal.....................................................................................................40
9.1 Removal from the Rail ...........................................................................40
10 System Expansion....................................................................................41
10.1 mPCIe Card ...........................................................................................41
10.2 2.5” SSD / HDD......................................................................................41
11 License Agreement ..................................................................................42
11.1 WAGO SOFTWARE LICENSE AGREEMENT ......................................43
12 Disposal.....................................................................................................46
12.1 Electrical and electronic equipment .......................................................46
12.2 Packaging ..............................................................................................46
13 Appendix ...................................................................................................48
13.1 mPCIe Port ............................................................................................48
List of Figures ....................................................................................................50
List of Tables......................................................................................................51

WAGO Edge Computer Regulations 5
752-9800
Manual
Version 1.0.0
1 Regulations
The WAGO product shall only be installed and operated according to the
instructions in this documentation.
Always retain this documentation!
This documentation is part of the product. Therefore, retain the documentation
during the entire service life of the product. Pass on the documentation to any
subsequent user. In addition, ensure that any supplement to this documentation
is included, if necessary.
1.1 Validity of this Documentation
This documentation applies to the product 752-9800.
1.2 Document portfolio
Besides this manual, you should consult the following WAGO documents:
• “Industrial ETHERNET” technology manual
These documents are available for download from the WAGO Website
www.wago.com.
1.3 Copyright
This Manual, including all figures and illustrations, is copyright-protected. Any
further use of this Manual by third parties that violate pertinent copyright
provisions is prohibited. Reproduction, translation, electronic and phototechnical
filing/archiving (e.g., photocopying) as well as any amendments require the
written consent of WAGO Kontakttechnik GmbH & Co. KG, Minden, Germany.
Non-observance will involve the right to assert damage claims.

6 Regulations WAGO Edge Computer
752-9800
Manual
Version 1.0.0
1.4 Property rights
Third-party trademarks are used in this documentation. This section contains the
trademarks used. The “®” and “TM” symbols are omitted hereinafter.
• Adobe®and Acrobat®are registered trademarks of Adobe Systems Inc.
• AndroidTM is a trademark of Google LLC.
• Apple, the Apple logo, iPhone, iPad and iPod touch are registered
trademarks of Apple Inc. registered in the USA and other countries. “App
Store” is a service mark of Apple Inc.
• AS-Interface®is a registered trademark of the AS-International Association
e.V.
• BACnet®is a registered trademark of the American Society of Heating,
Refrigerating and Air Conditioning Engineers, Inc. (ASHRAE).
• Bluetooth®is a registered trademark of Bluetooth SIG, Inc.
• CiA®and CANopen®are registered trademarks of CAN in AUTOMATION –
International Users and Manufacturers Group e.V.
• CODESYS is a registered trademark of CODESYS Development GmbH.
• DALI is a registered trademark of the Digital Illumination Interface Alliance
(DiiA).
• EtherCAT®is a registered trademark and patented technology licensed by
Beckhoff Automation GmbH, Germany.
• ETHERNET/IP™ is a registered trademark of the Open DeviceNet Vendor
Association, Inc (ODVA).
• EnOcean®is a registered trademark of EnOcean GmbH.
• Google PlayTM is a registered trademark of Google Inc.
• IO-Link is a registered trademark of PROFIBUS Nutzerorganisation e.V.
• KNX®is a registered trademark of the KNX Association cvba.
• Linux®is a registered trademark of Linus Torvalds.
• LON®is a registered trademark of the Echelon Corporation.
• Modbus®is a registered trademark of Schneider Electric, licensed for
Modbus Organization, Inc.
• OPC UA is a registered trademark of the OPC Foundation.

WAGO Edge Computer Regulations 7
752-9800
Manual
Version 1.0.0
• PROFIBUS®is a registered trademark of the PROFIBUS
Nutzerorganisation e.V. (PNO).
• PROFINET®is a registered trademark of the PROFIBUS
Nutzerorganisation e.V. (PNO).
• QR Code is a registered trademark of DENSO WAVE INCORPORATED.
• Subversion®is a trademark of the Apache Software Foundation.
• Windows®is a registered trademark of Microsoft Corporation.

8 Regulations WAGO Edge Computer
752-9800
Manual
Version 1.0.0
1.5 Symbols
Personal Injury!
Indicates a high-risk, imminently hazardous situation which, if not avoided, will
result in death or serious injury.
Personal Injury Caused by Electric Current!
Indicates a high-risk, imminently hazardous situation which, if not avoided, will
result in death or serious injury.
Personal Injury!
Indicates a moderate-risk, potentially hazardous situation which, if not avoided,
could result in death or serious injury.
Personal Injury!
Indicates a low-risk, potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
Damage to Property!
Indicates a potentially hazardous situation which, if not avoided, may result in
damage to property.
Damage to Property Caused by Electrostatic Discharge (ESD)!
Indicates a potentially hazardous situation which, if not avoided, may result in
damage to property.
Important Note!
Indicates a potential malfunction which, if not avoided, however, will not result in
damage to property.

WAGO Edge Computer Regulations 9
752-9800
Manual
Version 1.0.0
Additional Information:
Refers to additional information which is not an integral part of this
documentation (e.g., the Internet).

10 Regulations WAGO Edge Computer
752-9800
Manual
Version 1.0.0
1.6 Number Notation
Table 1: Number Notation
Number Code
Example
Note
Decimal
100
Normal notation
Hexadecimal
0x64
C notation
Binary
'100'
'0110.0100'
In quotation marks, nibble separated
with dots (.)
1.7 Font Conventions
Table 2: Font Conventions
Font Type
Indicates
italic
Names of paths and data files are marked in italic-type.
e.g.: C:\Program Files\WAGO Software
Menu
Menu items are marked in bold letters.
e.g.: Save
>
A greater-than sign between two names means the selection of a
menu item from a menu.
e.g.: File > New
Input
Designation of input or optional fields are marked in bold letters,
e.g.: Start of measurement range
“Value”
Input or selective values are marked in inverted commas.
e.g.: Enter the value “4 mA” under
Start of measurement range
.
[Button]
Pushbuttons in dialog boxes are marked with bold letters in square
brackets.
e.g.: [Input]
[Key]
Keys are marked with bold letters in square brackets.
e.g.: [F5]

WAGO Edge Computer Regulations 11
752-9800
Manual
Version 1.0.0
1.8 Legal Bases
1.8.1 Subject to Changes
WAGO Kontakttechnik GmbH & Co. KG reserves the right to provide for any
alterations or modifications. WAGO Kontakttechnik GmbH & Co. KG owns all
rights arising from the granting of patents or from the legal protection of utility
patents. Third-party products are always mentioned without any reference to
patent rights. Thus, the existence of such rights cannot be excluded.
1.8.2 Personnel Qualification
All sequences implemented on Series 752 devices may only be carried out by
electrical specialists with sufficient knowledge in automation technology. These
specialists must be familiar with the current standards and guidelines for the
devices and the automated environments.
1.8.3 Intended Use
The Edge computer is suitable for use in the area of control and automation. Its
use extends industrial areas. Technical data must be observed for all types of
applications.
The product is an open system and is designed for installation in an additional
enclosure.
This product fulfills the requirements of protection type IP40 and is designed for
use in dry indoor spaces.
1.8.3.1 Improper Use
Improper use of the product is not permitted. Specifically, improper use occurs in
the following cases:
• Non-observance of the intended use.
• Use without protective measures in an environment in which moisture, salt
water, salt spray mist, dust, corrosive fumes, gases, direct sunlight or
ionizing radiation can occur.
• Use of the product in areas with special risk that require flawless
continuous operation and in which failure or operation of the product can
result in an imminent risk to life, limb or health or cause serious damage to
property or the environment (such as the operation of nuclear power plants,
weapon systems , aircraft and motor vehicles).
1.8.3.2 Warranty and Liability
The terms set forth in the General Business & Contractual Conditions apply to
deliveries and services of WAGO Kontakttechnik GmbH & Co. KG, and the

12 Regulations WAGO Edge Computer
752-9800
Manual
Version 1.0.0
WAGO Software License Contract applies to software products and products with
integrated software. Both are available at www.wago.com. In particular, the
warranty is void if:
• The product is improperly used.
• The deficiency (hardware and software configurations) is due to special
instructions.
• The hardware or software has been modified by the user or a third party.
Individual agreements always have priority.
1.8.3.3 Obligations of Installers/Operators
The installers and operators bear responsibility for the safety of an installation or
a system assembled with the products. The installer/operator is responsible for
proper installation and safety of the system. All laws, standards, guidelines, local
regulations and accepted technology standards and practices applicable at the
time of installation, and the instructions in the the products’ Instructions for Use,
must be complied with. In addition, the Installation regulations specified by
Approvals must be observed. In the event of non-compliance, the products may
not be operated within the scope of the approval.

WAGO Edge Computer Safety Information 13
752-9800
Manual
Version 1.0.0
2 Safety Information
2.1 Safety Advice (Precautions)
This section includes an overall summary of the most important safety
requirements and notes that are mentioned in each individual section. To protect
your health and prevent damage to devices as well, it is imperative to read and
carefully follow the safety guidelines.
For installing and operating purposes of the relevant device to your system the
following safety precautions shall be observed:
Do not work when devices are energized!
High voltage can cause electric shock or burns.
Always disconnect the power supply from those parts of the system on which you
wish to mount or remove the device!
Ensure a standard connection!
To minimize any hazardous situations resulting in personal injury or to avoid
failures in your system, the data and power supply lines shall be installed
according to standards, with careful attention given to ensuring the correct
terminal assignment. Always adhere to the EMC directives applicable to your
application.
Consider the IP protection type!
The device is an open unit is IP40 protected. If the operating environment does
not fulfill these requirements you have to install the device into cabinet resp.
housing.
Replace defective or damaged devices!
Replace defective or damaged device/module (e.g., in the event of deformed
contacts).

14 Safety Information WAGO Edge Computer
752-9800
Manual
Version 1.0.0
Protect the components against materials having seeping and insulating
properties!
The components are not resistant to materials having seeping and insulating
properties such as: aerosols, silicones and triglycerides (found in some hand
creams). If you cannot exclude that such materials will appear in the component
environment, then install the components in an enclosure being resistant to the
above-mentioned materials. Clean tools and materials are imperative for
handling devices/modules.
Clean only with permitted materials!
Clean housing and soiled contacts with propanol.
Do not use any contact spray!
Do not use any contact spray. The spray may impair contact area functionality in
connection with contamination.
Do not use in telecommunication circuits!
Only use devices equipped with ETHERNET or RJ-45 connectors in LANs.
Never connect these devices with telecommunication networks.
Remove USB mass storage devices when not in use!
Removing a USB mass storage device during operation can lead to data loss.
Only remove USB mass storage devices from the product when it is not in use.
Avoid electrostatic discharge!
The devices are equipped with electronic components that may be destroyed by
electrostatic discharge when touched. Please observe the safety precautions
against electrostatic discharge per DIN EN 61340-5-1/-3. When handling the
devices, please ensure that environmental factors (personnel, work space and
packaging) are properly grounded.

WAGO Edge Computer Safety Information 15
752-9800
Manual
Version 1.0.0
2.2 Special Use Conditions
If not otherwise specified, ETHERNET devices are intended for use on local
networks. Please note the following when using ETHERNET devices in your
system:
• Do not connect control components and control networks to an open
network such as the Internet or an office network. WAGO recommends
putting control components and control networks behind a firewall.
• In the control components (e.g., for CODESYS) close all ports and services
not required by your application to minimize the risk of cyber attacks and to
enhance cyber security.
Only open ports and services during commissioning and/or configuration.
• Limit physical and electronic access to all automation components to
authorized personnel only.
• Change the default passwords before first use! This will reduce the risk of
unauthorized access to your system.
• Regularly change the passwords used! This will reduce the risk of
unauthorized access to your system.
• Regularly perform threat analyses. You can check whether the measures
taken meet your security requirements.
• Use “defense-in-depth” mechanisms in your system's security configuration
to restrict the access to and control of individual products and networks.
Please note the risks of using cloud services!
If you use third-party cloud services, sensitive data is transferred to the cloud
service provider at one's own responsibility. External access may result in
manipulated data and/or unwanted control commands affecting the performance
of your control system.
Use encryption methods to protect your data and observe the information
provided by the Federal Office for Information Security – “Cloud: Risks and
Security Tips”.
Observe comparable publications of the competent, public institutions of your
country.

16 Overview WAGO Edge Computer
752-9800
Manual
Version 1.0.0
3 Overview
The Edge Computer is a wireless and fanless automation computer that can
handle control, monitoring and communication tasks. The product is suitable for
DIN-rail mounting and is characterized by its various interfaces. The product can
be used for applications in mechanical and systems engineering, in the
processing industry and in building technology.
The product is equipped with an Intel® i7-7600U processor with 16 GB RAM
DDR4 memory and 256 GB 2.5" SATA SSD hard disk. The interfaces include 4 ×
Gbit/s ETHERNET, 4 × USB 3.0, 1 × HDMI and 1 × DP.

WAGO Edge Computer Properties 17
752-9800
Manual
Version 1.0.0
4 Properties
4.1 View
Figure 1: Front view
The connectors are located on the front. For details, see section “Properties” >
“Connectors.”

18 Properties WAGO Edge Computer
752-9800
Manual
Version 1.0.0
4.2 Labeling
The type plate is attached on the bottom side.
Table 3: Type Plate
Field
Example
Article number
752-9800
Supply voltage
10 … 36 VDC, 4 A
MAC address
X1: 00:30:DE:46:F6:A1
X2: 00:30:DE:46:F6:A2
X3: 00:30:DE:46:F6:A3
X4: 00:30:DE:46:F6:A4
Serial number
TPAC211489
Release indexes (2 digits each, “00” = not
available):
1. Calendar week,
2. Year,
3. Firmware version,
4. Hardware version,
5. Firmware loader version
2520010100
Figure 1: Type plate (Example)

WAGO Edge Computer Properties 19
752-9800
Manual
Version 1.0.0
4.3 Connectors
4.3.1 Connectors on the front
Table 4: Connectors on the front
Connector
Function
X1, X2, X11, X12
ETHERNET Interface with LED
X3, X4, X5, X6
USB 3.0 Interface
X7
HDMI 1.4 Interface
X8
DisplayPort 1.2 Interface
X9
POWER. Power supply
4.3.2 “X1”, “X2”, “X11” and “X12” ETHERNET Interfaces
The ETHERNET interfaces are RJ-45 ports. The orange LED illuminates when
there is a LINK and the green one blinks during data transfer.
The connectors and cables meet category 5e requirements and guidelines for
ETHERNET interfaces.
The integrated 10/100/1000 Mbit ETHERNET switch supports Auto-MDI(X).
A crossover or patch cable can be used.
4.3.3 “X3”, “X4”, “X5” and “X6” USB 3.0 Interfaces
The USB 3.0 host interfaces are designed with 4-pin type A sockets.
Each interface can supply max. 500 mA.
The connectors comply with the USB 3.0 specification.
Keyboards or mice can be connected as alternative input devices or USB
memory devices. The interfaces are designed for plug-and-play and the USB
devices can be connected / disconnected during operation.

20 Properties WAGO Edge Computer
752-9800
Manual
Version 1.0.0
Table 5: Pin Assignment“ USB 3.0 Interface
Pin
Description
Assignment
1
VBUS
Power
2
D–
USB 2.0 differential pair
3
D+
USB 2.0 differential pair
4
GND
Ground for power return
5
StdA_SSRX–
Super Speed receiver differential
pair
6
StdA_SSRX+
Super Speed receiver differential
pair
7
GND_DRIAN
Ground for signal return
8
StdA_SSTX–
SuperSpeed transmitter
differential pair
9
StdA_SSTX+
SuperSpeed transmitter
differential pair
4.3.4 “X7” – HDMI 1.4 Interface Type A
HDMI stands for “High Definition Multimedia Interface” and is a standard for the
simultaneous transmission of picture and sound using just one cable. The Edge
Computer can be connected to a monitor via HDMI. The maximum resolution is
1920 × 1080 pixels at 60 Hz.
Table 6: Pin Assignment HDMI 1.4 Interface
Pin
Description
1
TMDS data2+
2
TMDS data2 shield
3
TMDS data2–
4
TMDS data1+
5
TMDS data1 shield
6
TMDS data1–
7
TMDS data0+
8
TMDS data0 shield
9
TMDS data0–
10
TMDS clock+
11
TMDS clock shield
12
TMDS clock–
13
CEC
14
Reserved
15
SCL
16
SDA
17
DDC/CEC/HEC ground
18
+5 V Power
19
Hot plug detect
