Installation
Gas Connection
NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY A QUALIFIED SERVICE PERSON.
1. Waldorf Pasta Cookers do not require an electrical connection, they function totally on the gas
supply only.
2. It is essential that the gas supply is correct for the appliance to be installed and that adequate
supply pressure and volume are available. The following checks should therefore be made before
installation:-
a. The Gas Type the appliance has been supplied for is shown on
coloured stickers located above the gas entry point and next to
the rating plate. Check that this is correct for the gas supply
the appliance is being installed for. The gas conversion
procedure is detailed in this manual.
b. Supply Pressure required for this appliance is shown in the
‘Specifications’ section of this manual. Check the gas supply to
ensure that adequate supply pressure exists.
c. Input Rate of this appliance is also stated on the Rating Plate
fitted to the inside of the access door and in the ‘Specifications’
section of this manual. The input rate should be checked
against the available gas supply line capacity. Particular note
should be taken if the appliance is being added to an
existing installation.
NOTE: It is important that adequately sized piping runs directly to the connection joint on the
appliance, with as few tees and elbows as possible to give maximum supply volume.
3. Fit the gas regulator supplied, into the gas supply line as close to the appliance as possible.
NOTE: The gas pressure regulator provided with this appliance is convertible between Natural Gas
and LPG as per the ‘Gas Conversion Section’ in this manual.
Ensure the regulator is converted to the correct gas type that the appliance will operate on.
The regulator outlet pressure is fixed ex-factory for the gas type that the regulator is
converted to and it is NOT to be adjusted.
The regulator connections are 3/4" BSP female.
The connection to the appliance is 3/4" BSP male.
(Refer to the 'Specifications' section for the gas supply location dimensions).
NOTE: A Manual Isolation Valve must be fitted to the individual appliance supply line.
4. Correctly locate the appliance into its final operating position and using a spirit level, adjust the legs
so that the unit is level and at the correct height.
5. Connect the gas supply to the appliance.
6. Check gas operating pressure to as shown in the ‘Specifications’ section. If the pressure is incorrect,
adjust the pressure by adjusting the regulator screw of the gas control valve as shown in the ‘Gas
Conversion and Specifications’ section.
7. Check all gas connections for leakages using soapy water or other gas detecting equipment.
NOTE: The operating pressure is to be measured at the Burner Operating Pressure test point on
the gas control valve, this is to be carried out with the burner operating at the 'High Flame'
setting. The operating pressure is ex-factory set, through the appliance regulator and not to
be adjusted, apart from when carrying out gas conversion, if required. Refer to the ‘Gas
Conversion and Specification’ Section for further details.
Rating Plate
Location
Fig 1
WARNING:
DONOT USE ANAKED FLAME TO CHECK FOR GAS LEAKAGES.
