Technical data sheet for
GAS GRIDDLE STATIC ELECTRIC
OVEN RANGE 1200mm
GP8121GE
Heavy-duty thermostatic gas griddle
20mm thick griddle plate
Ribbed plate options
Chromed mirror plate options
Top weld sealed plates
108MJ thermostatic griddle burner system
Separate left, centre, and right heat zones
GN 2/1 6.5kW electric static oven
Drop down door
Storage cabinet on right hand side
Stainless steel exterior
Easy clean
Easy service
Fully modular
Controls
• Large easy use control knobs - heat resistant reinforced
• Easy view control settings on knobs
Griddle
• Separate left, centre and right side heat zones
• Three 90-300˚C thermostats
• Flame failure pilot burners
• Piezo ignition to each pilot burner
Oven
• Separate temperature and top heat power regulation controls
• 50-320˚C thermostatic control
• Lo-Hi top heat control
• Indicator lights for power and heating
Cleaning and Servicing
• All models with easy clean stainless steel external finish
• Plate is finished front and rear with overlap construction to remove
cleaning traps
• Control service and gas conversion through front of unit
• Burner service requires plate removal
• Removable oven racking and sole plate
• Easy clean vitreous enamel oven and door inner
• Door hinge spring adjustable on unit (door outer removed)
• Door disengages for lift off removal and increased service access
• Access to all parts from front of unit
Overall Construction
• Galvanized steel chassis
• Welded hob surround with 1.5mm 304 stainless steel bull nose
• Splashback and hob sides 1.2mm 304 stainless steel
• Front panels and oven sides 0.9mm 304 stainless steel
• Full 0.9mm stainless steel storage cabinet on right hand side
• 150mm legs in 63mm dia. heavy-duty 1.2mm 304 stainless steel with
adjustable feet
Griddle
• 20mm thick machined top plates standard
• Optional ribbed plate sections
• Optional mirror finish hard chrome plates
• 2.5mm thick 304 stainless steel splash guards sides and rear
• 2.0mm thick grease channel
• Three 36MJ 3 bar even heat burners with three thermostatic controls
• Full pilot and flame failure protection with piezo ignition
• Stainless steel grease drawer
• Overlapping finish at front and rear of plate for easy clean
Oven
• Fully welded and vitreous enamelled oven liner
• GN 2/1 capacity with 4 position racking
• Heavy-duty easy remove heavy wire chrome rack supports
• Cast iron even heat oven sole plate
• 6.5kW heating elements
• Welded frame drop down door with heavy-duty spring hinge system
• 0.9mm 304 stainless steel door outer
• 1.0mm press formed vitreous enamelled door inner
• High density fibreglass insulated
• Stay cool stainless steel door handle with cast metal handle mounts
• Supplied with two chrome wire oven racks

Australia
Moffat Pty Limited
Victoria/Tasmania
740 Springvale Road
Mulgrave, Victoria 3170
Telephone [phone]
acsimile 03-9518 3833
[email protected]
New South Wales
Telephone [phone]
[email protected]
South Australia
Telephone [phone]
[email protected]
Queensland
Telephone [phone]
[email protected]
Western Australia
Telephone [phone]
[email protected]
New Zealand
Moffat Limited
Christchurch
Telephone [phone]
[email protected]
Auckland
Telephone [phone]
[email protected]
Australia
www.moffat.com.au
New Zealand
www.moffat.co.nz
ISO9001
All Waldorf products are designed and
manufactured by Moffat using the
internationally recognised ISO9001 quality
management system, co ering design,
manufacture and final inspection, ensuring
consistent high quality at all times.
ISO9001
Quality
Management
Standard
Designed and manufactured by
In line with policy to continually de elop and
impro e its products, Moffat Limited reser es
the right to change specifications and design
without notice.
Specifications
Burners
Three 36MJ 3 bar chromed steel burners - Griddle
Individual pilot, flame failure and piezo ignition
Elements
4.5kW bottom heat element
2.0kW top heat element
Gas power
108MJ/hr, 30kW
Electrical requirements
6.5kW
1 phase connection:
230-240Vac, 50/60hz, 1P+N+E, 27A
3 phase connection:
400-415Vac, 50/60hz, 3P+N+E
L19.4A
L29.4A
L38.3A
Plate
Cooking surface 1192mm x 530mm, 6318cm2
Oven Dimensions
Width 665mm
Depth590mm
Height 385mm
Rack size 660mm x 540mm
Rack positions 4
Gas connection
R 3/4(BSP) male
130mm from RH side, 32mm from rear,
and 655mm from floor
Optional underside connection
(refer specification drawing)
All units supplied with Natural and LP gas regulator
Electrical connection
369mm from RH side, 484mm from rear,
and 150mm from floor
Dimensions
Width 1200mm
Depth805mm
Height 915mm
Incl. splashback 1130mm
Packing data
1.37m3
Width 1240mm
Depth865mm
Height 1255mm
Gas types
Available in Natural gas and LP gas
Please specify when ordering
Units supplied complete with gas type
conversion kits
Other gas types on request
Options at extra cost
Joining caps
Castors
Plinth mounting
Ribbed plate options
Chrome plate options
